Hanover KAMADO User manual

BARBECUE GRILLS
BARBECUE GRILLS
MANUAL
OWNER’S
KAMADO

WELCOME Page 1
Accessories
Ash Cleaning Tool Secondary Cooking Grid
(Half Grid)
Chimney Top Control
Ceramic Top (dome lid)
Ceramic Base
Cart
Bottom Air Control &
Ash Clean Out
Thermometer
Inside of Grill
Fire Grate
Fire Box
Fire Ring
Oak Shelf
Grill Cover
Congratulations on the purchase of your Hanover Kamado Grill and Smoker!
You now have one of the most versatile cookers available for your BBQ adventures.

PARTS IDENTIFIER Page 2
Left Shelf Bracket
Left Oak Side Shelf Right Oak Side Shelf
Hinge Assembly
Right Shelf Bracket
Handle
Shelf Stop Tab
Shelf Stop Tab
Shelf Support
10 mm Acorn Nut w/
Flat Head Screw (8) Top & Bottom Bands
H5 Band Tension Bolt w/10mm Nut & Washer
Springs (2) 10mm Acorn Nut w/ Flat
Head Screw
Oak Filler
Oak Handle Retainer
Screws w/ Nuts
Handle Bracket
Shelf Support

Large Phillips head screwdriver, 10 mm wrench (included), 5 mm (3/16”) Allen wrench (included).
Locate the serial number of your grill on the lower base portion of the grill box or on the inside wall of the
grill hinge. Record your serial number for future reference.
Built-in Enclosure Dimensions Please use the following dimensions and guidelines for built-in applications.
It is always best to build a non-combustible enclosure with masonry and/or steel studs and cement board
(Hardiebacker, Wonderboard, Durock, etc.).
It is best to keep your countertops and the area underneath the grill of non-combustible materials. Always
keep the surface of the grill at least 1”away from combustible materials inside the enclosure and 1” at the
counter top.
In a sealed, combustible enclosure make sure there is at least 20 square inches of ventilation at the bottom
and 20 square inches of ventilation at the top of the enclosure. This will provide enough air to cool the
enclosure and feed the re. Note that an open enclosure ensures the best air ow and easy access to the
Bottom Air Control.
22½” Combustible Top
22 “ Non Combustible Top
ASSEMBLY - for Built-in Applications Page 3
Assembly Tools Required

1. If your grill will be on a combustible surface, the Ceramic Feet and Stainless Steel Heat Shield (SSHS)
must be used.
2. Place the Feet and Shield in the position you would like the grill.
3. The Feet should be arranged underneath the Shield with equal spacing between them. One should be
placed directly in the center on the back side of the Shield and the other two on the left and right of the
front side. Fig. 1
4. The ceramic Feet and Heat Shield may be replaced with a non-combustible slab. The slab should be a
solid stone or masonry unit (at least 1¼” thick). The recommended dimensions of the slab are at least 16”
square or round. Fig. 2
Unbox the Grill
Ceramic Feet and Heat Shield
1. Cut and remove the plastic bands from the box.
2. Lift o the top of the box.
3. The sides of the box are individually removable.
4. Open the grill and remove the cooking grid and discard the cardboard.
5. Remove other items from their packaging and set aside: Stainless Steel Heat Shield, Ceramic Feet (3pcs.),
Chimney Top, Handle, Grate and Stainless Steel Eciency Plate.
6. The stainless steel heat shield and ceramic feet are packaged separately and are only provided for
built-in applications (These items are not included if grill is purchased with cart)
ASSEMBLY - for Built-in Applications Page 4
Warning:
If the grill is placed on or near a combustible surface, such as a wood deck, it is the owner’s responsibility to
ensure embers do not escape the grill and ignite the wood. A non-combustible protective pad is recommended
underneath and in front of the lower air control/ash clean out door. 10:00am
Fig.1
Fig.2
Proceed to nal grill assembly on page 6
(Skip assembly for cart application).

Assembly Tools Required
Large Phillips head screwdriver, 10 mm wrench (included), 5 mm (3/16”) Allen wrench (included).
Unbox the Grill
1. Cut and remove the plastic bands from the box.
2. Lift o the top of the box.
3. The sides of the box are individually removable.
4. Open the grill and remove the cooking grid and discard the cardboard.
5. Remove the items in the bottom of the grill and set aside: Stainless Steel Heat Shield, Chimney Top,
Handle, Grate and Stainless Steel Eciency Plate.
6. Unbox cart kit.
7. Unbox shelf kit (optional).
Cart Assembly
8. Remove the bubble wrap from Leg Joiners and the four stainless
steel Cart Legs.
9. Slide the two Leg Joiners into one of the legs that has a locking
castor wheel. Fig.1 The at side of the Joiners should be facing up.
Screw them into place with a Phillips head screw driver.
ASSEMBLY - for Cart Applications Page 5
10. Select one of the stainless steel legs without the locking caster and
slide it onto the Leg Joiner opposite the rst leg. Screw into place
loosely.
11. The remaining two legs may now be attached without regard to their
position. After the legs are all in, place the cart in an upright position
and securely tighten down the screws. Fig. 2
Fig. 2
Fig.1
Warning:
Do not fully tighten any of the screws until completion. Take care that the screws
are going in straight so the threads are not ruined. Be gentle and do not force the
screws. They should turn with very little pressure.
Fig. 1

4. Unpack the Top Dome Handle.
8. For Built-in Application-Place the Stainless Steel Eciency Plate in the
bottom of the rebox with the small leg spacers facing down.
9. Place the ceramic Firebox into the grill so that the Bottom Air Control Port
aligns with the bottom Air Control Door on the grill. Place the Fire Ring on
top of the Firebox with the three notches facing upward and with one of the
notches all the way to the back. Fig. 7
Placing Grill in Cart
6. With assistance, grip the stainless steel hinge and grip inside the bottom air control and lift the grill into
the Cart. The front of the grill should be located between the two legs with locking caster wheels.
Placing Grill in Built-in Enclosure
7. If you are placing the grill into the hole of an enclosure one person should grip the stainless steel hinge
at the rear of the grill. The second person should open the lid and grip the Bottom Air Control from the
inside of the grill. Keep the other hand on the Main Handle. Put the grill into position on the feet or slab.
5. Check the rest of the pre-installed acorn nuts to ensure that they are all tight
(use the 10mm wrench). Fig. 6 If the acorn nuts spin without tightening,
just use a rapid jerking action as you tighten and this usually cause them
to tighten suciently. The pre-installed Band Tension Bolts should also be
checked for tightness.
3. Remove the cardboard pad from the bottom inside of the grill and discard.
2. Remove the packing materials from around the perimeter of the Firebox
and lift it out of the grill. Set it aside. It is easiest to lift it by the holes or the
clean-out port at the bottom. Fig. 4
FINAL GRILL ASSEMBLY Page 6
Fig. 4
Fig. 3
Fig. 7
Fig. 5
Fig. 6
Acorn Nuts
Note:
There are 2 acorn nuts packaged with the handle. Use the acorn nuts to fasten the
handle to the two screws protruding from the stainless steel band on the front of
the grill. Fig. 5
Note:
The Band Tension Bolt may be tightened very securely without fear of damaging the ceramics (usually 2 or 3
revolutions). This ensures that the hinge will be stable and secure and that you may use the hinge or shelf brackets to
lift the grill without incident. Use the 5mm or 3/16 hex key (Allen wrench) to hold the bolt in position. Use the 10mm
wrench to turn the nuts. Do not turn the bolt as it may ruin the threads.
Unpack the Grill
1. Remove the packing materials from around the perimeter of the ceramic
Fire Ring and lift out of the grill. Set it aside. It will be necessary to hold
the Fire Ring from the inside to avoid pinching your ngers. Fig. 3
Proceed to step 9.

10. Replace the grate and then place the cooking grid on top of the ceramic Fire Ring. Fig. 9
11. Place the Chimney Top Control on the top of the grill. No fasteners are
necessary. Fig.10
12. To properly install your side shelves hold the shelf close to the inside
edge in a downward position and drop the pin into the shelf bracket.
Slowly lift up the shelf until the locking hook is aligned with the pin stop
tab.
Great job! You are now ready to barbecue!
ASSEMBLING YOUR GRILL Page 7
Fig.9a Fig.9b
Fig.10
Fig.11
Fig.12
Note:
If you position the Chimney Top hinge on the right side it will close when the grill is
opened (recommended).
Note:
Side shelf brackets are part of the shelf kit and must be attached. Fig.11
Please ensure that the left and right shelves are properly installed. The right
shelf has a protective metal plate to prevent the grill bands from touching the
wood shelves.
Note:
When you lift the shelf up, slide the hook on the shelf support back so they align
underneath the Stop Tab. Fig.12
Stop Tab

USING YOUR GRILL Page 8
1. Remove the cooking grid.
2. If you have charcoal left in the grill from the previous re, stir it around enough to knock the ash down
through the grate. This will allow better air ow for a quicker start. The remaining charcoal is good to use
again.
3. Pour lump charcoal into the rebox until it covers the series of round holes in the rebox. (see Fig.13)
You may ll it to the top of the rebox if you need to cook or smoke for more than three hours.
Starting the Fire
4. If you are using a combustible re-starter, nestle it down into the charcoal. You may place re starters
in more than one spot in the charcoal if you want to get the whole area burning more quickly for high
temperature grilling and searing. You may stack some charcoal around the starter to speed up the
process. Be sure to leave enough air space around the stacked charcoal for the air and ame or it will not
burn properly. Now light the starter. Fig.13
5. If you are using an electric re-starter, nestle it down into the charcoal so it is resting on the charcoal just
above the grate. The charcoal should envelop the lower half of the starter element. Plug in the starter
and let it operate for no more than 8 minutes.
6. Unplug and remove the starter within 8 minutes to avoid damaging the starter. You do not have to leave
the starter in longer as the re will continue to increase after removing it. Fig.14
7. Replace the cooking grid and close the grill. Swing the chimney top damper fully open until the grill is
up to your desired temperature.
8. When the grill has reached your desired cooking temperature, adjust the top and bottom damper for the
desired temperatures as seen on next page.
9. When you are nished cooking, close the Top and Bottom Air Controls to snu the re out. This will
preserve any remaining coals for the next use.
Fig.14Fig.13
CAUTION: DO NOT USE LIGHTER FLUID INSIDE THIS GRILL! IT WILL VOID YOUR WARRANTY.
Not only does lighter uid create a bad smell in the neighborhood and on your food, but it is not good for the ceramics
in your grill.
Note:
You may close the air controls before the food is done as it will hold the heat for a long time and allow the food to
nish cooking.

CLEANING YOUR GRILL Page 9
Cooking Grids
Safe Practices
It is not necessary to use soap to clean the Cooking Grids after every use. The easiest way to keep your
grids clean is by using a brass or stainless steel bristled brush just before cooking. After starting the re,
put the Cooking Grid into position and allow it to heat up at a high temperature setting for 5 to 10 minutes.
Brush the grids, close the lid and slow the grill down with the air control. A good way to nish cleaning and
prepare the grid for food is to wipe it with a cloth soaked with vegetable or olive oil. You can use your grill
brush to aid in the application. A small piece of cloth will normally stick to the wire brush quite well. Do this
just before putting food on.
Ash is removed through the Bottom Air Control. Prevent ash from lling up to the re grate. The Ash
Cleaning Tool (ACT) or similar shaped implement is used to scrape the ashes out the door and into a metal
container. DO NOT STORE ASHES IN A COMBUSTIBLE CONTAINER.
We recommend that the top and bottom air controls be adjusted in sync with one another so that the
bottom control is not open much more than the top control. As air reaches the re and is superheated it
expands greatly. With this in mind, it is better to slow the re down by closing the bottom damper and then
reducing the top damper opening to ne tune the temperature.
Starter & High Temperature Grilling and Searing 500º to 600º
Medium Temperature for Roasting and Grilling 300º to 450º
Low Temperature for Smoking 200º to 300º
Top Control - Swing chimney top fully open.
Top Control - Chimney top closed with
spin damper holes 100% open.
(Swing chimney top open a little if needed for more heat)
Top Control - Chimney top closed with
spin damper holes open halfway.
Bottom Control - 1 to 2 inches open.
Bottom Control - approx. 1/2 to 1 inches open.
Bottom Control - approx. 1/8 to 1/4 inches
WARNING::
If it has only been a couple of minutes since you have closed down the air setting on a very hot fire, do not
abruptly open the lid. As with most grills, this can cause the additional smoke in the top of the grill to ignite
into flame when it is open. When opening the grill it is always good practice to open the Chimney Top rst and then
lift the lid open one or two inches and hold there for a count of 5. Then open the lid fully. This allows the excess smoke
to exit the grill safely.

HIGH TEMPERATURE GRILLING AND SEARING Page 10
For Roasting and Smoking you will want to cook with indirect heat to avoid burning the surface of your
meat. This can be accomplished by putting your food on a rack which is placed inside a pan. Water, juice,
etc. may be added to the pan for a more eective buer from the heat.
The best method for indirect heat and smoking is to use the optional Heat Deector.
1. After starting the re, place the ceramic Heat Deector on the Cooking Grid Holder.
2. You may also use the Cooking Grid Holder as a lifting tool for the Heat Deector in order to keep your
hands out of the re and direct heat.
3. Lift it into the grill as shown placing the Legs of the Cooking Grid Holder into the notches on the Fire
Ring. Fig.24
Using the Heat Deflector
By placing the cooking grid directly on the ceramic Fire Ring you are closest to the coals for the highest
temperatures. Fig. 21A You may also use the optional Cooking Grid Holder to raise the grid up level with the
top of the grill opening. The 3 legs of the Holder should rest in the 3 notches in the top of the ceramic Fire
Ring. Fig. 21B The Cooking Grid is then placed on top of the Holder. Fig. 22 The Cooking Grid may be left in
this elevated position all the time, if desired, as it is still hot enough for searing at that level.
Fig.21A Fig.21B Fig.22
Cooking Grid Holder
Roasting and Smoking
Fig. 24
Notch
Note:
The Cooking Grid Holder is for use with both the grate and the Heat Deector .

ROASTING AND PIZZA COOKING Page 11
Secondary Cooking Grid (Sold Separately)
Pizza Cooking
For more cooking area you may use the Secondary Cooking Grid (SCG). The SCG increases the cooking
area by 45%. Two SCG may also be used side by side. There is a tab welded to the bottom of the Cooking
Grid at the back. The rear leg of the SCG rests on the tab and the front legs interlock with the bars on the
grid. This provides a second, sturdy cooking surface above the main grid. And provides enough room to
accommodate even large cuts of meat under the SCG.
The best way to cook pizza on your grill is with the use of a Pizza Stone and the Cooking Grid Holder.
1. After starting the re, leave the cooking grid o the grill.
2. Place the Cooking Grid Holder into position so the 3 legs rest in the 3 notches of the Fire Ring.
3. Bring the grill up to 500 -600 degrees and maintain at that temperature with dampers at the medium to
high settings (bottom control 1” open and top damper slid 1/2 to 3/4 open).
Place the Pizza Stone/ Ceramic Heat Deector on top of the Cooking Grid Holder. The Pizza Stone will be
level with the top of the grill so the pizza may be easily accessed. Fig.28
4. Once the grill has reached 500-600 degrees, do not wait much more than a couple of minutes to put the
pizza on. Spread a layer of corn meal on top of the pizza stone just before placing the pizza. Vigilance is
required to ensure the pizza crust does not burn.
If you have thick pizza, you should put it on the pizza stone before placing the pizza stone on the grill. This
way the crust will not burn before the inside is done. Try using the Stainless Steel Heat Shield and pizza stone
together to help avoid burning the crust.
Fig. 28
To add additional smoked avor to your food, you may use wood chips or chunks. These may be added
through the access doors at the front of your Cooking Grid. Fig.22
Roasting
1. Place the Cooking Grid on top of the Cooking Grid with the Cooking Grid Access Door to the front of the
grill as shown previously. Fig.22.
2. You may then place the food directly on the Cooking Grid if desired. A pan to catch drippings may be
used on the Deector or on top of the Cooking Grid.
Smoke Flavor

NOTES/RECIPES Page 12

NOTES/RECIPES Page 13

“LIMITED” WARRANTY PROGRAM
For the periods listed below, Hanover Products/XLS Products, Inc. (“Manufacturer”) will either repair or replace defective components in
accordance with this Limited Warranty. This warranty is between Manufacturer and the original purchaser and is valid only when accompanied
by the original purchaser’s sales receipt showing original date of purchase and location of purchase. Replacements under this warranty revert
back to the date of original purchase for future warranty.
Manufacturer or its authorized retailer can accept or reject warranty claims based on its ndings. This warranty applies in normal residential
use only, where an issue with the product is due to a defect in material or workmanship. Manufacturer can make substitutions as required
of materials, components, and sub-components of comparable value and utility. This warranty is limited to product repair or replacement
(to be determined solely by Manufacturer). Warranty return is limited to only the single aected component.
This warranty covers only manufacturing defects and does not cover normal wear and tear, damage, abuse or misuse, including: water
damage, chemical damage, damage during shipment or installation, exposure to extreme heat or cold or abrasion. This item is intended for
internal use only. This warranty is invalid if the product is not used for intended purpose. Manufacturer disclaims liability for any aspect of
installation and any inconvenience caused by a defective part of a component.
All items may be charged actual freight costs plus $15 for handling. Repairs or replacement will be made at the Manufacturer’s option.
Shipping and handling charges are the responsibility of the consumer.
1. Components subjected to abuse, including abuse intended to simulate failure.
2. Damages caused by retailer, shipper or user (such as scratches, tears, chips, broken pieces, etc.).
3. Any part which merely exhibits normal wear yet functions essentially as new, including chips, discoloration or scratches.
4. Items sold “as is” or oor models
Certain items are not covered by this warranty. These include, but are not limited to the following:
• The Model Number and Serial Number of the unit
• A copy of the original sales receipt
• A brief description of the problem.
• Your email address and daytime telephone or cell phone #.
To make a claim, please call the toll-free number below. Please have available:
• 10 Years – Ceramic Parts: Ceramic Bottom, Ceramic Top, Ceramic Fire Ring, Ceramic Fire Box
• 5 Years – Stainless Steel Parts: Chimney Top Control, Cooking Grid, Hinge, Bands, Ash Door and Cart
• 1 Year – All other components
Charcoal/Kamado Grills (PARTS ONLY):
Gas (LP/NG) Grills (PARTS ONLY):
• 5 Years – Control Valve, Grill Body, Flame Tamers, Heat Zone Separators and Cart
• 1 Year – All other components
THIS IS THE ENTIRE EXCLUSIVE EXPRESS LIMITED LIABILITY. THE MANUFACTURER NEITHER MAKES NOR IS RESPONSIBLE FOR ANY
OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING THOSE OF RETAILING DEALERS. THIS EXCLUSIVE REMEDY IS LIMITED
TO RECEIPT OF A CREDIT IN CONNECTION WITH THE REPAIR OR REPLACEMENT OF ANY PRODUCT OR COMPONENT DEEMED TO
BE DEFECTIVE UNDER THE TERMS AND CONDITIONS AS STATED IN THIS WARRANTY. NEITHER XLS PRODUCTS, INC., THE PRODUCT
MANUFACTURER NOR ITS AGENTS SHALL BE LIABLE IN ANY CASE FOR INCIDENTAL, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY OR NEGLIGENCE EVEN IF IT
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. EXCEPT AS OTHERWISE MAY BE REQUIRED BY LAW, THERE ARE NO
OTHER EXPRESS OR IMPLIED WARRANTIES OTHER THAN THE WARRANTY DESCRIBED HEREIN, AND ALL OTHER WARRANTIES,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED.
Contact Warranty Services at: [e-mail]
www.Hanover-Products.com
877-397-5144
