ASSEMBLY AND OPERATION
INSTRUCTIONS
BARREL SPIT
grill roast smoke

Barrel spit
Warranty Details
Hark Enterprises Pty Ltd warrants that this genuine HARK® brand product is free from
defects in workmanship and materials for 12 months from the date of purchase.
If as a result of normal use in compliance with the manufacturer’s instructions the product
fails to operate within the warranty period, we will repair or replace the product. This
warranty does not extend to cover any damage due to burn out or rust.
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law.
You are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
The benets given to you in this warranty are in addition to other rights and remedies in
respect of the product that the consumer has under the Competition and Consumer Act
2010 and similar state and territory laws.
In the event of a product failure, the goods should be returned at your cost to the original
place of purchase, with specic details of the complaint, and a copy of the purchase
receipt.
After Sales Support
Hark Enterprises Pty Ltd
Telephone: [phone]
[phone]
Email: [email protected]
YEAR
WARRANTY
grill roast smoke

4
Model No.: HK0529
Product Name: BARREL SPIT
FOR OUTDOOR USE ONLY. PLEASE READ INSTRUCTIONS CAREFULLY BEFORE
ASSEMBLING. RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Tools needed for assembly
Phillips Head Screwdriver (not included)
Before assembly
Please read all instructions thoroughly before proceeding.
Find a large, clean area in which to assemble your Barrel Spit. Please refer to the parts list and
assembly diagram as necessary.
Ensure any transit protection or packaging is removed.
Do not throw out any packaging until the Barrel Spit is fully assembled in case parts are still
enclosed.
Line drawings are not to scale. Actual products may differ from drawing depending on the model purchased.
Specications are subject to change without notice.

5
READ ALL INSTRUCTIONS, WARNINGS & SAFEGUARDS PRIOR TO ASSEMBLY & OPERATION.
FAILURE TO DO SO MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY.
DANGER DANGER
- The Hark®Barrel Spit ("spit") is for
OUTDOOR USE ONLY.
- Never operate the spit unattended.
- The use of alcohol, prescription or non prescription
drugs may impair your ability to properly assemble or
safely operate the spit.
- Never operate this spit within 7.5 metres (25 feet) of
any flammable liquids.
- Keep the area clear of all flammable liquids,
combustible material including but not limited to
wood, dry plants and including grass, brush, paper
and canvas.
- Use this spit only on a level, stable non-combustible
surface like brick, concrete or dirt. Do not use spit
on or around any surface that will burn or melt, such
as on wooden decks, dry grass, wood rails, vinyl or
plastic.
- Never use inside an enclosed area such as screen
patios, garages, buildings and tents. Keep a minimum
clearance of 3 metres (10 feet) from all sides of the
spit to all overhead construction and 1 metre (3 feet)
from any walls or rails.
- Never operate this spit under any overhead roof
covering, awning or overhang.
- Keep your hands, hair and face away from any naked
flame. Do not lean over or into the firebox or grill when
lighting or operating the spit. This spit has an open
flame. Be careful of loose clothing and hair that could
catch fire during operation of the spit.
- Always wear shoes and protective clothing during
operation of this spit.
- The spit is HOT while in use and after use. Always
wear protective gloves or mitts when operating the
spit. Avoid touching hot surfaces at all times.
- Keep CHILDREN AND PETS away from the spit at
all times. Do not allow anyone to conduct activities
around the spit during or following its use until the unit
has cooled.
- Never move the spit when it is in use. Allow the spit to
cool before moving or storing it.
- Never use this spit as a heater.
- Never use in or on recreational vehicles and/or boats.
- Never use this product for anything other than its
intended purposes. This spit is not intended for
commercial use.
- Accessory attachments and cookware not supplied by
Hark®are not recommended for use.
- Never use glassware, plastic or ceramic cookware in
the spit.
- Do not use in windy conditions or days of a Total Fire
Ban.
- Do not allow charcoal and or wood to rest on the body
of the barrel spit. Doing so will greatly reduce the life
of the metal finish.
- Only build the fire in the charcoal tray.
- The Electric motor is for 240V AC only.
To protect against electrical shock, do not immerse
cord or plug in water or other liquids.
- Do not operate or leave the motor in the rain.
- Do not operate with damaged cord or plug.
- Do not allow cord to touch hot surfaces.
- Unplug the motor from power outlet before cleaning.
- Unplug the motor from power outlet and remove from
barrel spit when not in use.
OUTDOOR USE ONLY
SAVE AND FILE THESE INSTRUCTIONS FOR FUTURE REFERENCE

6
PARTS LIST

No. Description Qty
1 Grill body 1
2 Charcoal tray 1
3 Leg 2
4 Caster wheels 4
5 Cooking grid 2
6 Motor (with bracket) 1
7 Spit rod 1
8 End suport bracket 1
9 Single sided 4 prong skewer 2
10 Leg brace 1
11 Double sided 4 prong skewer 1
12 Neck brace 1
13 Single 2 prong skewer 1
14 Angle lock pin 2
No. Description Qty
A M6 X 30 Screw 6
B M6 Flange Nut 6
Hardware List
Parts List

7
A. ASSEMBLY OF THE BARBECUE
STEP 1 ATTACH CASTER WHEELS
—Attach 1 x plain caster wheel and 1 x locking caster wheel to each leg as per Fig. 1. The
locking caster wheel should be attached to the ‘longer’ leg.
STEP 2 ATTACH LEGS TO BODY
—Stand the grill body up on the end. Place some cardboard or newspaper under the grill body
to prevent scratching or damaging the finish.
—Attach a leg to the grill body with 3 x M6x30 screws and M6 flange nuts. The screws should
be attached from the outside, with the nuts on the inside of the grill body. See Fig 2.
—Turn unit over and repeat for the other end of grill body.
—Stand unit upright on the caster wheels.


Fig 1
Fig 2

8
STEP 3 POSITION CHARCOAL TRAY
—Place the charcoal tray into the bottom of the grill body. Place the 2 cooking grids on the top
ledge if using the BBQ function.
STEP 4 POSITION MOTOR
—Refer to Fig 4. Slide the electric motor with bracket onto one vertical upright and use an angle
locking pin to fix the height position where the rotisserie spit rod will be located.


Fig 3
Fig 4

9
STEP 5 POSITION END SUPPORT BRACKET
—Refer to Fig 5. Slide the end support bracket onto the other vertical upright. And use an angle
locking pin to fix the height position. When you install the rotisserie spit rod, you can adjust
and fix the final height position of the support bracket, in order to have the spit rod level.

Fig 5
STEP 6 POSITION SPIT ROD
Fig 7A. The position and method to support the rotisserie spit rod rid.
Fig 7B. How to position and x the spit rod in the electric motor.
Note: The pin of the motor must t into the slot of the spit rod.

Fig 7A Fig 7B
Motor drive shaft

10
ROTISSERIE FORKS AND ATTACHMENTS
The Barrel Spit has been supplied with a variety of rotisserie forks and attachments for different
types of Rotisserie Cooking.
ROTISSERIE SET UP

Neck brace
Leg brace
Single 4 prong skewer
Double 4 prong skewer
Single 4 prong skewer
Single 2 prong skewer
Spit rod
motor end
Whole Lamb or Suckling Pig set up
To secure a whole animal there are three main components you use.

U Shackle Back brace – Push the U
Shackle through the back of the animal, so
that it sits either side of the backbone and
then secure with the clamp. This will hold
the animal in place.
Two prong skewer. This can be pushed
into the front of the animal into the
shoulder area.

U Shackle Leg brace – This is used to
secure the back legs. Each leg can be
clamped through a U shackle to hold
them in place.

11
Multiple Cuts of Meat or Chickens
The double sided skewer is positioned in the middle of the spit rod and the food is positioned
either side of this. The single sided skewers are then placed on either end and pushed together
to secure the meat in place.
When tightening the attachments to the spit rod, do not over tighten. The screw clamps only
need to be done up nger tight to hold in place. Do not use spanners or pliers to tighten.
Single Sided Skewer Double Sided Skewer
WARNING

12
DIRECT GRILLING
—To set your Barrel Spit for direct grilling, spread the charcoal across the bottom of the charcoal
tray, then place the cooking grid on top so that you are able to place the food directly above
the coals.
—To spread the coals you will need a small shovel or some long handled tongs and should use a
BBQ mitt to avoid any burns. Be careful, the coals will be extremely hot.
—Direct cooking is a high heat method and is best used for searing steaks, hamburgers,
sausages, chicken fillets, fish and vegetables.
—You can get better heat control if you spread your coals into three zones in the charcoal tray.
a. Hot zone – Double layer of coals. Used for initially searing the food to seal in all the juices.
b. Medium zone – Single layer of coals. Used for cooking the food.
c. Cool zone – No Coals. Used for warming or resting the food if it starts to burn.
LIGHTING YOUR FIRE
—Remember, patience is a virtue! Cooking with charcoal and wood is more complicated
than using gas but you will get a much better result. Always allow yourself plenty of time to
prepare the fire prior to cooking.
—Allow 30-45 minutes for the fire to start properly before cooking. To start a charcoal fire using
lump charcoal or beads, place two or three firelighters in the charcoal tray where you plan to
build your fire. Then pile the charcoal on top in a pyramid formation.
—Light the fire lighter’s and let the charcoal burn. Once the coals have a light coating of grey
ash you are ready to cook. Do not disturb the coals in this initial lighting process. They will
not look like they are lighting but you need to wait at least 45 minutes for this to occur.
—If using wood to start your fire, start off with small pieces that are no longer than 30cm in
length. Make sure they are dry and able to burn. Light using firelighter’s or paper and as the
fire burns add larger pieces of wood to increase the fire.
—Always wear protective BBQ mitts when lighting your fire.
