Harley Benton HBW-80 User manual

ATTENTION
To avoid to damage amplifier or other equipments, please turn off the level of all equipments before
connection and power off the equipments as well.
Power on the equipments ordinal.
This amplifier equips with protected circuit, which will startup for few seconds after the amplifier powers on.
PANEL DESCRIPTIONS
IMPORTANT SAFETY INSTRUCTIONS
BASS AMPLIFIER
HBW-80
To reduce the risk of fire or electric shock. Do not expose this apparatus to rain or moisture. To reduce the
risk of electric shock. Do not remove cover. Refer servicing to qualified service personnel for repair this
apparatus.
The exclamation point within an equilateral triangle is intended to alert you to the presence of
important operating and servicing instructions.
The lighting flash & arrowhead symbol, within an equilateral triangle, is intended to alert you to the
presence of danger.
1. INPUT(1/4")
Use this jack to connect electric bass.
2. GAIN
Use this control to adjust gain level.
3. BRIGHT
Use this control to boost the HIGH frequency of amplifier.
4. BOOST
Use this control to boost the LOW frequency of amplifier.
5. LOW LOW MID MID HIGH HIGH
Use these controls to adjust be LOW MID and HIGH frequency level, within 12dB
3510
4289
7
6
11211 13
1. Connect the amplifier ONLYto a properly grounded AC outlet of the proper voltage for your amp.
2. Avoid the thread to be under kick or heavily hustled.
3. Do not block any ventilation openings on this amplifier.
4. Do not operate near any heat source.
5. Do not expose this amplifier to rain or moisture.
6. Disconnect the power cord if the amplifier is not in use for longer period.
7. To reduce the risk of electric shock, DO NOT remove the cover.
Please read before using this product and strictly follow the owner's manual
Please keep this manual for future reference.
WARNINGS CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Youmust use this device only with an AC outlet of
the correct voltage
HBW-80
BASS AMPLIFIER

Input sensitive/Impedance------------------------- -20dBu/1M (@1KHz)
Output(RMS)---------------------------------------------80W/4 Ohm
Speaker---------------------------------------------------12 (30cm)x1
Effect------------------------------------------------------Chorus
Connection----------------------------------------------- Input(1/4 )
--------------------------------------------------------------Headphone(1/4 )
--------------------------------------------------------------Line out(1/4 )
--------------------------------------------------------------Aux In(RCA)
EQ(4 Band EQ)-------------------------------------------Low Low Mid Mid High High
Power Input-----------------------------------------------100V/50Hz-60Hz, 110V/60Hz, 220V/50Hz,
230V/50Hz, 240V/50Hz
Net weight-------------------------------------------------18Kg
Packing Size----------------------------------------------534x409x569mm
SPECIFICATION
14
14. SOCKET
REAR PANEL
6. CHORUS
Use this control to adjust depth and rate of chorus at the same time.
7. LIMIT LED
The limit circuit is to limit harsh, transient peaks and even out bass guitar signal in power-amp.
This LED illuminates when the limit circuit is in work.
8. MASTER
Use this control to adjust the output level of the amplifier.
9. AUXIN(RCA)
Use this jack to connect CD drum machine etc..
10. LINE OUT(1/4 )
Use this jack to connect line output.
11. HEADPHONE OUTPUT(1/4 )
Use this jack to connect headphone.
12. LED
This LED illuminates when the amplifier is power on.
13. POWER SWITCH
Use this switch to turn the amplifier on/off
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Built-in Limit
Bright/Boost Switch
BASS AMPLIFIER
SERIAL NO :
OUTPUT (RMS) : 80 W/4 Ohm
HBW-80
