Harman Kardon SUB-TS1 User manual

Rev A 11/99
SUB-TS1
TECHNICAL MANUAL
Amplifier/Subwoofer
Harman Consumer Group
250 Crossways Park Drive
Woodbury, N.Y. 11797
1-800 422-8026 in the USA
A Harman International Company

2
Amplifier/Subwoofer Harman Kardon
SUB-TS1
GENERAL SPECIFICATIONS
HKTS-1 System
Frequency Response
35Hz – 20kHz (–6dB)
SUB-TS1
Amplifier . . 75 watts RMS
Bass .....8"woofer, bass-reflex enclosure
Dimensions (HxWxD)
10!x18!x10!inches
267 x 470 x 267mm
Weight . . . 29.9 lbs/13.6 kg
Refinements may be made on occasion to existing products without notice,
but will always meet or exceed original specifications unless otherwise stated.
TABLE OF CONTENTS
COVER...........................................................................1
GENERAL SPECIFICATIONS .......................................2
TABLE OF CONTENTS.................................................2
HKTS1 SPECIFICATIONS.............................................3
CONTROLS AND THEIR FUNCTION...........................5
HKTS1 SPEAKER LEVEL CONNECTIONS .................6
HKTS1 LINE LEVEL CONNECTIONS ..........................7
SUB-TS1 TEST SET UP AND PROCEDURE ..............8
SIMPLE TROUBLESHOOTING.....................................9
HKTS1 PACKING.........................................................10
SUB-TS1 EXPLODED VIEW .......................................11
SUB-TS1 PCB COMPONENT SIDE ...........................12
SUB-TS1 PCB SOLDER SIDE....................................13
SUB-TS1 ELECTRICAL PARTS LIST.........................14
SUB-TS1 INTEGRATED CIRCUIT DIAGRAMS .........16
SUB-TS1 POWER AMP SCHEMATIC DIAGRAM......17
SUB-TS1 PRE-AMP SCHEMATIC DIAGRAM ............18
The SUB-TS1 is part of the HKTS1 system

HKTS1 SPECIFICATIONS
LINE VOLTAGE Yes/No Hi/Lo Line Unit Notes
US 120vac/60Hz Yes 108-132 Vrms Normal Operation
EU 230vac/50-60Hz Yes 207-264 Vrms Normal operation, MOMS
required
Asia 100vac/50Hz Yes 90-110 Vrms Normal Operation
Spec. Unit Limits Conditions Notes
Amp Section
Type (Class AB, D, other) AB AB n/a Sink required for Class AB
Load Impedance (speaker) 4 Ohms n/a Nominal Z-curve required
Rated Output Power 80 Watts 80 1 input driven
THD@ Rated Power 0.08 % 0.3 22k filter
THD @ 1 Watt 0.1 % 0.5 22k filter
DC Offset 10 mV-DC 20 @ Speaker Outputs
Damping factor <200 DF n/a
Input Sensitivity
Input Frequency 50 Hz 50 Nominal Freq. 1 input driven
Line Input 220 mVrms ±2dB To Rated Power 1 input driven
Speaker/Hi Level Input 4.26 Vrms ±2dB To Rated Power (-26dB below Line In)...1
input driven
Signal to Noise
SNR-A-Weighted 100 dBA 90 rel. to rated power A-Weighting filter
SNR-unweighted 80 dBr 60 rel. to rated power 22k filter
SNR @ 1W-unweighted 60 dBr 55 rel. to 1W Output 22k filter
Residual Noise Floor 1.5 mVrms 2.5 Volume @max, using RMS reading DMM/VOM (or A/P)
Residual Noise Floor 1 mVrms(max) 2 Volume @max, w/ A/P Swept Bandpass Measurement
(Line freq.+ harmonics)
Input Impedance
Line Input 15K ohms n/a Nominal
Speaker/Hi Level Input 4.7K ohms n/a Nominal
Filters
Low Pass (fixed or
variable)
fixed — —
Low Pass filter (point or
range)
135 Hz ±2dB -3dB Point
Slope 24 dB/Octave n/a
Q 1.8 Damping n/a 2 cascaded 2nd order
filters of 1.8 &0.7 Q
Subsonic filter (HPF) 31 Hz ±2dB -3dB Point
Slope 12 dB/Octave n/a
Q 1.4 Damping n/a
3
Amplifier/Subwoofer Harman Kardon
SUB-TS1

Signal Sensing (ATO)
Auto-Turn-On (yes/no) yes — functional
ATO Input Frequency 50 Hz functional
ATO Level 2 mV functional 2mV@50Hz into Line Input
w/ 1 ch. driven
ATO Bandwidth 5k Hz functional ATO-LPF for noise
immunity
DV1 measured 7mV @
5kHz…. 2mV @ 1kHz
ATO Turn-on time 5 ms functional Amp connected and AC on, then input signal applied
Auto Mute/ Turn-OFF Time 20 minutes functional T before muting, after
signal is removed
Power on Delay time 3 sec. functional AC Power Applied
Transients/Pops
ATO Transient 5 mV-peak 10 @ Speaker Outputs
Turn-on Transient 50 mV-peak 100 @ Speaker Outputs AC Line cycled from OFF to
ON
Turn-off Transient 50 mV-peak 100 @ Speaker Outputs AC Line cycled from ON to
OFF
Efficiency
Stand-by Input Power 10 Watts n/a @ nom. line voltage
Power Cons.@rated power 160 Watts n/a @ nom. line voltage
Protection
Short Circuit Protection Yes — functional Direct short at output
Thermal Protection 65 deg.
C
— functional @1/8 max unclipped
Power
DV1:Plate=50deg.C
max.Tab=90deg.C max.T-on
=65deg.C
DC Offset Protection yes — functional DC present at Speaker
Out leads
Relay or crowbar (for
driver/fire protection)
Line Fuse Rating 2 Amps 2 Type-T or Slo Blo External fuse with UL/SEMKO
rated holder
4
Amplifier/Subwoofer Harman Kardon
SUB-TS1

1. Speaker Level Outputs - Connect the Left, Center
and Right speakers to these connectors.
2. Speaker Level Inputs - These High Level Inputs are
for receivers that do not have line-level “pre-amp out”
or “subwoofer out” jacks. When a pair of main or
satellite speakers are attached to the OUTPUT
terminals, they are driven the full range of frequencies
as generated by the music source (receiver, amplifier,
etc.)
3. Line Level Input - These left and right Line Level
Inputs are normally used when the receiver/ processor
has line-level “pre-amp out ” or “subwoofer out” jacks.
4. Auto/On Switch - This switch allows you to set the
Mode of the Amplifier. Turn the switch to Auto to
cause it to Auto-matically turn on when it receives a
signal and Auto-matically turn off after twenty minutes
without a signal. If this switch is left “On”, the
subwoofer will always be ON when the power switch
is turned On, regardless of input signal.
5. Subwoofer Level - This knob controls the volume
level of the SUB125.
6. LED - Red & Green. The LEDs indicate the Mode
status that the subwoofer is in. When the SUB125 is
turned OFF neither LED will be lit. The Green LED
will light when the SUB125 is ON and receiving a
signal. The Red LED will light when the amplifier has
not received a signal for twenty minutes. The
subwoofer will turn on when your receiver/amplifier
begins playing again.
7. Power Switch - This the master power switch. Use it
(in Off mode) to disconnect power to the amplifier.
8. Fuse - Use only same type of fuses. For the U.S.
120V version use only a 2A 250V fuse. For the
European 230V version use only a 1A fuse.
9. AC Cord
5
Amplifier/Subwoofer Harman Kardon
SUB-TS1
AC 120V ,60Hz
160W
~
POWER
RL
MIN MAX
FUSE
STAND BY
ON
FUSE
2A/250V
TYPE T
LINE LEVEL
INPUT
SUBWOOFER
LEVEL
SPEAKER
LEVEL
OUTPUT
SPEAKER
LEVEL
INPUT
L
L
C
C
R
R
ON
AUTO
SUB-TS1
1
2
3
4
5
6
7
8
9
CONTROLS AND THEIR FUNCTION

6
Amplifier/Subwoofer Harman Kardon
SUB-TS1
HKTS1 SPEAKER LEVEL CONNECTIONS
SPEAKER LEVEL OUTPUTSPEAKER LEVEL INPUT
LL
CC
RR
SUB-TS1
Receiver
Left Front
Left Surround
Right Front
Right Surround
Center
Left Front
Left Surround Right Surround
Right Front
Center

7
Amplifier/Subwoofer Harman Kardon
SUB-TS1
HKTS1 LINE LEVEL CONNECTIONS
SUB-TS1
Receiver
Left Front Subwoofer
Out
Left Surround
Right Front
Right Surround
Center
Left Front
Left Surround Right Surround
Right Front
Center
RL
R
L
LINE LEVEL
INPUT

8
Amplifier/Subwoofer Harman Kardon
SUB-TS1
SUB-TS1 TEST SET UP AND PROCEDURE
OUTPUT FROM
AMPLIFIER
FROM
PRE AMP
SPEAKER
AMPLIFIER
CD PLAYER
PRE AMP
AC VOLT METER ( 6V )
SPEAKER
UNDER TEST
LINE
LEVEL
SPEAKER LEVEL
RL
MIN MAX
LINE LEVEL
INPUT
SUBWOOFER
LEVEL
SPEAKER
LEVEL
OUTPUT
SPEAKER
LEVEL
INPUT
L
L
C
C
R
R
ON
AUTO
General Function
UUT = Unit Under Test
1. Connect both right and left line level inputs (RCA) to
signal generator and UUT. Use Y-cable if necessary
from mono source. VOLUME control should be full
counterclockwise.
2. Turn on generator, adjust to 200mV, 50 Hz.
3. Plug in UUT; red LED should be ON. Turn VOLUME
control full clockwise.
4. LED should turn Green; immediate bass response should
be heard and felt from port tube opening.
5. Turn off generator, turn VOLUME control fully
counterclockwise, disconnect RCA cables.
6. Connect one pair of speaker cables to both high level
input terminals on UUT. Cables should be connected to
an integrated amplifier fed by the signal generator.
7. Turn on generator and adjust so that speaker level output is 3.0V, 50 Hz. Turn VOLUME control full clockwise.
8. Green LED should light, immediate bass response should be heard and felt from the port tube opening.
Sweep Function
1. Follow steps 1-4 above, using a sweep generator as a signal source.
2. Sweep generator from 20Hz to 300Hz. Listen to the cabinet and drivers for any rattles, clicks, buzzes or any
other noises. If any unusual noises are heard, remove driver and test.
Driver Function
1. Remove driver from cabinet; detach + and - wire clips.
2. Check DC resistance of driver; it should be 3.3 ohms.
3. Connect a pair of speaker cables to driver terminals. Cables should be connected to an integrated amplifier fed by
a signal generator. Turn on generator and adjust so that speaker level output is 5.0V.
4. Sweep generator from 20Hz to 1kHz. Listen to driver for any rubbing, buzzing, or other unusual noises.

9
Amplifier/Subwoofer Harman Kardon
SUB-TS1
SIMPLE TROUBLESHOOTING
If there is no sound from any of the
speakers, check the following:
•Receiver/amplifier is on and a source is playing.
•Powered subwoofer is plugged in and is either in the “On”
or “Auto”position.
•Check all wires and connections between receiver/
amplifier and speakers. Make sure all wires are connected.
Make sure none of the speaker wires are frayed, cut or
punctured.
•Review proper operation of your receiver/amplifier. If there
is no sound coming from one speaker, check the following:
•Check the “Balance”control on your receiver/amplifier.
If the system plays at low volumes but
shuts off as volume is increased, check the
following:
•Check all wires and con-nections between receiver/
amplifier and speakers. Make sure all wires are connected.
Make sure none of the speaker wires are frayed, cut or
punctured.
•If more than one pair of main speakers is being used,
check the minimum impedance requirements of your
receiver/amplifier.
If there is low bass output, check the
following:
•Make sure the connections to the left and right “Speaker
Inputs”have the correct polarity (+ and –).
•Powered subwoofer is plugged in and is either in the “On”
or “Auto”position.
If there is no sound from the surround
speakers, check the following:
•Check all wires and connections between receiver/
amplifier and speakers. Make sure all wires are connected.
Make sure none of the speaker wires are frayed, cut or
punctured.
•Review proper operation of your receiver/amplifier and its
surround sound features.
•Receiver mode must be in Dolby Pro logic, Dolby Digital,
or any other mode that creates a surround-sound effect.
Even under normal operation, when viewing movies and
television, surround sound is not present at all times at a
high volume - only when the program has chosen to send
information there.

10
Amplifier/Subwoofer Harman Kardon
SUB-TS1
HKTS1 PACKING
HKTS1
OWNER'S
MANUAL
#AI5058
FEET/PADS
#WI5162 (10)
WARRANTY
CARD
#AT5073
PLASTIC
BAG
OUTER CARTON
#WB5452
SUBWOOFER
FOAM SET
#WB5078
SATELLITE
FOAM SET
#WP5071
SUB-TS1
SUBWOOFER
OPTIONAL SAT-TS1 SPEAKER STANDS: FSTS1
WALL HOOKS
#WI0408 (5)
MURAL STANDS
#WI0409 (5)
HKTS1
HKTS1
SATELLITE
SPEAKERS
SAT-TS1 (5)
#HKTS1/SAT
ACCESSORY WIRES
PART NUMBER
SAL5010
SAL063-1
SAL5009
DESCRIPTION
Right, Left &Center cables (1 pack, 3 pairs)
High level input cables (3 pack, 1pair each)
Surround cables (2 pack, 1 pair each)
