Harman Kardon AVR 430 Instruction Manual

430
fi
·
db
hf
j‡
39
31
37 35 33
41
›
fl
°
a
c
eg
ki
34 32
40
36
42
38
™£¢∞
¡§¶•ª⁄
2
‚‹
AVR 430 REAR-PANEL CONNECTIONS
NOTE:To assist in making the correct connections for
multichannel input, output and speaker connections,
all connection jacks and terminals are color-coded in
conformance with the latest CEA standards as follows:
Front Left:White
Front Right: Red
Center: Green
Surround Left: Blue
Surround Right: Gray
Surround Back Left: Brown
Surround Back Right:Tan
Subwoofer: Purple
Digital Audio: Orange
Composite Video:Yellow
Component Video “Y”: Green
Component Video “Pr”: Red
Component Video “Pb”: Blue
¡AM Antenna
™FM Antenna
£Preamp Outputs
¢Subwoofer Output
∞A-BUS Connector
§Surround Speaker Outputs
¶Front Speaker Outputs
•Fan Vents
ªCenter Speaker Outputs
‚Surround Back/Multiroom Speaker Outputs
⁄Switched AC Accessory Outlet
¤Unswitched AC Accessory Outlet
‹AC Power Cord Jack
›Video Monitor Outputs
fiDVD Video Inputs
flVideo 1 Video Inputs
‡Video 1 Video Outputs
°Video 2 Video Inputs
·Video 2 Video Outputs
aVideo 3 Video Inputs
bComponent Video Monitor Outputs
cComponent Video 1 Inputs
dComponent Video 2 Inputs
eRS-232 Port
fMultiroom IR Input
gRemote IR Input
hRemote IR Output
iCoaxial Digital Audio Output
jMultiroom Audio Outputs
kOptical Digital Audio Output
CD Audio Inputs
DVD Audio Inputs
Optical Digital Audio Inputs
Tape Inputs
Tape Outputs
Coaxial Digital Audio Inputs
Video 1 Audio Inputs
Video 1 Audio Outputs
Video 2 Audio Inputs
8-Channel Direct Inputs
Video 2 Audio Outputs
Video 3 Audio Inputs
