QUICK START GUIDE
HPX-AV102-DP-R DisplayPort 4K60 Module with
Retractable MyTurnTM Ready Cable
Overview
HydraPort Retractable Cable Modules are designed to be used in conjunction with the
HPX-600/900/1200/1800 or the HydraPort Touch (7”/10”) Connection Port base
assembly, to provide the convenience of various types of cables in a HydraPort System.
The HPX-AV102-DP-R DisplayPort 4K60 Module with Retractable MyTurn Ready Cable
(FG552-33) provides a Display cable for resolutions up to 4K60 in a retractable spool
that mounts into the HydraPort base assembly (FIG. 1).
With the addition of a MyTurn™ Source Selection Button (FG554-21) participants can
send their content to the display at the press of a button without moving from their
seat. Any MyTurn-Ready cable may be equipped with the MyTurn solution. See
“MyTurn™ Source Selector Button” on page 2.
The HPX-AV102-DP-R also features Dual Mode DisplayPort (DP++) compatibility and
includes a DP to HDMI adapter for connection to HDMI inputs. The retractable module is
detachable from the module faceplate for easier installation and replacement
Installation
Warning! - Do not attempt to open the retractable cable module enclosure. There are
no serviceable parts inside the module.
- Opening the module enclosure may result in an uncontrolled release of spring
forces which could cause serious injury and/or equipment damage.
- Opening the module enclosure will void the product warranty.
Warning! - installation of the Hydraport in the table should ensure the pull-out length
of the cable can reach all potential users of connectivity, as excessively pulling on a
fully extended cable can irreparably damage the retractor module.
Caution: Only use a hand-held #2 Phillips-head screwdriver for mounting this unit. Over-
tightening the screws can hinder performance or damage the unit.
For existing HPX installations, the HPX base must be removed from the mounting
surface. See “Existing Installations” on page 2. for HPX Base removal instructions.
1. Remove the (silver) pivot screw in the center of the End Cap (FIG. 2). There is an
internal tooth washer underneath it. Keep them together for re-installation.
2. Remove the four (black) sheet metal screws that secure the two-piece End Cap to
the HPX assembly (additional top two screws only on one-piece end cap models).
3. Gently slide the End Cap out of the HPX base assembly.
The HPX-AV102-DP-R RCM cable cartridge has a new mounting scheme from
underneath the table to simplify installation and upgrade of retractable cable modules.
This version RCM has a detachable mounting collar that is installed into the Hydraport
base first and then the cable cartridge is reattached to the mounting collar.
Securely holding the HPX-AV102-ETH-R RCM, extract enough cable to lay the cable
cartridge on the floor while installing the mounting collar into the HPX Base Assembly
(~3ft). When extracting 5 foot (1.5m) cable from the RCM, follow these simple steps:
4. Pull up to 1.5 meters of cable straight up out of the RCM and then lay it down.
5. Watch for red tape on the cable when extracting. It is a warning to slow pull for
the final 1 foot to avoid damage to the RCM (FIG. 3) .
6. Pull the cable cartridge trigger (FIG. 4) to release the mounting collar tongue.
7. Lift the mounting collar away from the cable cartridge until the tongue is clear and
then slide to the side to clear the hook.
8. Feed the mounting collar up through the table cutout to reach the HPX base
assembly. Align the mounting notches on the mounting collar with the mounting
rails on the HPX (FIG. 5).
Note: Module mounting collars are notched in a “tongue and groove" type fashion
to ensure that all modules are oriented correctly in the HPX. Note the orientation of
the notched mounting collar on each module before sliding the module(s) into the
HPX assembly. On RCMs, ensure the retract buttons are all on the same side.
9. Slide the mounting collar into position.
10. Install any remaining module mounting collars into the HPX base.
Re-Install the End-Cap
Caution: Do not use a high-powered torque screw driver. Over-tightening these screws
can damage the product.
1. Align the Mounting Notches on the End Cap with the Mounting Rails on the HPX base.
2. Slide the End Cap into the HPX base until it is fully inserted against the end of the
base assembly. Watch out for the tension spring under the pivot pawl popping the
pivot pawl off the end cap while pressing against the lid pivot point.
3. Secure the End Cap with the 4 to 6 (black) sheet metal screws (FIG. 2).
4. Replace the (silver) pivot screw in the center of the End Cap.
FIG. 1 HPX-AV102-HDMI-R HDMI-R MODULE WITH RETRACTABLE CABLE
FIG. 2 HPX BASE ASSEMBLY - MOUNTING/PIVOT SCREW LOCATIONS
Retractable 5 foot (1.5 meter) DisplayPort MyTurn Ready
cable connects to Source device
Cable Retract Push Button
Mounting notches (both sides)
5 foot cable pigtail (1.5 meter) connects
to Display device DP input
Pull trigger to initiate
separation of the mounting
collar from cartridge
Slide-hook and catch secures
mounting collar to cartridge
Remove Pivot Pawl
and Pivot Screw
Remove four remaining
sheet metal screws
(highlighted)
Remove top two screws
(only on one-piece end
cap models)
FIG. 3 EXTRACTING CABLE - WARNING BAND
FIG. 4 HPX-AV102-DP-R MOUNTING COLLAR REMOVAL
FIG. 5 RETRACTABLE CABLE MODULE - MOUNTING INTO AN HPX BASE ASSEMBLY
Warning Tape
4 Feet
1 Foot
Slow Pull Pull
Trigger
Detachable
Mounting
cable cartridge
Collar
Slide the mounting
notches on both sides
of the mounting collar onto
the mounting rails on both
sides of the HPX Base
HPX Base Top Surface
Table cutout
Mounting
Collar
Retract Button

© 2016 Harman. All rights reserved. Hydraport, AMX, AV FOR AN IT WORLD, HARMAN, and their respective logos are registered trademarks of
HARMAN. Oracle, Java and any other company or brand name referenced may be trademarks/registered trademarks of their respective
companies.
AMX does not assume responsibility for errors or omissions. AMX also reserves the right to alter specifications without prior notice at any time.
The AMX Warranty and Return Policy and related documents can be viewed/downloaded at www.amx.com.
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 AMX.com | 800.222.0193 | 469.624.8000 | +1.469.624.7400 | fax [phone]
AMX (UK) LTD, AMX by HARMAN - Auster Road, Clifton Moor, York, YO30 4GD United Kingdom • [phone] • www.amx.com/eu/
93-0552-33 REV: A
Last Revised: 5/12/2016
Mount the HPX into the Mounting Surface
Caution: Do not use a high-powered torque screw driver. Over-tightening these screws
can damage the product.
Note: For detailed instructions on installing the HPX base assembly, refer to the HPX-
600/900/1200/1800 and HydraPort Touch (7”/10”) Installation Guides (available
online at www.amx.com).
1. Carefully insert the HPX base into the cutout in the mounting surface.
2. Tighten the four mounting screws (FIG. 6) located inside and at each end of the
HPX base assembly, to rotate the retaining tabs (FIG. 7) into locking position
under the mounting surface.
3. Feed the excess cable up through the mounting collar and insert the cable
cartridge hook into the mounting collar cutout.
4. Push the cable cartridge trigger up onto the mounting collar tongue until it
latches (opposite of FIG. 4).
5. Use the Push button to retract the cable into the cartridge.
6. Attach the display ends of the cables as necessary.
7. Use cable ties to secure cable bundles as necessary.
Note: Use of an extension cable on the display end of this cable can be achieved
using the AMX DP-HDMI Adapter and HDMI Extender (FG558-21) to ensure optimal
performance. See “DP-HDMI Adapter” on page 2.
Existing Installations
For existing HPX installations, the HPX Base Assembly must be removed from the table
surface before the Retractable Cable Modules can be installed:
1. Cut/remove any cable ties that would restrict the removal of the HPX Base Assembly.
2. Loosen the four mounting screws located inside and at each end of the HPX base
assembly (FIG. 6), in order to rotate the retaining tabs from under the mounting
surface.
Note: When the cover of the HPX base is open, only two of these screws are visible.
To access the other two screws, tip the cover over to the opposite open position.
3. Once the retaining tabs have been rotated out from under the mounting surface,
the HPX assembly can be lifted away from the mounting surface.
FIG. 7 provides a cutaway view of the End Cap, showing the retaining tabs
highlighted in both the loose position and the tightened (secure) position.
4. Return to the installation section at the bottom left column of page 1 to continue
with installing the RCM into the HPX Base assembly.
Mounting Dimensions
FIG. 8 provides dimensions for the retractable cable module, when installed in an HPX
base assembly:
MyTurn™ Source Selector Button
The HPA-MYT-TX MyTurn™ Source Selector Button
(FG554-21) clips into the specially designed groove
built into the end of a MyTurn ready cable. Users
press to send the content on their device to the
display. When pressed, the button transmits a signal
to a receiver (FG554-23) that plugs directly into an
AMX switching device such as a Solecis SDX, Enova
DVX, or NX Series Controller.
MyTurn Source Selector Buttons are illuminated briefly when that specific device is
selected, making it easy to determine whose content is being shown on the display at
any given time. Refer to the HPA-MYT-TX documentation for further details
Replacing HPX-AV102-DP-R
Removal of the HPX Base assembly
is not required to replace this RCM:
1. Detach the cable cartridge
from the mounting collar
using the trigger and slide
method described in FIG. 4.
2. From the top of the mounting
collar, press a small flat blade
screwdriver into the notch on
the split side of the pop out
panel and pop it out of place.
3. Slip the cable out through the slot in the mounting collar panel.
4. Replace with new RCM in reverse order ensuring the cable is not twisted and the
pop out panel split is oriented towards the notch in the collar.
DP-HDMI Adapter
The DP-HDMI adapter (FIG. 11) is
included with the HPX-AV102-DP-R
DisplayPort 4K60 Module with
Retractable MyTurn Ready Cable.
Plug it into the end of the DisplayPort
cable to connect to
HDMI ports on
some displays or the AMX HDMI
Extender (
FG558-21 ).
Additional Documentation
Refer to the Products > Architectural Connectivity catalog page on www.amx.com
(Dealer Site) for additional product documentation.
FIG. 6 HPX BASE ASSEMBLY (SHOWN MOUNTED) - MOUNTING SCREWS LOCATIONS
FIG. 7 HPX BASE ASSEMBLY (SHOWN MOUNTED) - MOUNTING SCREWS LOCATIONS
Retaining tab
(to secure the unit)
shown tightened
Retaining tab
(to remove the unit)
shown loosened
FIG. 8 RCM MODULE (INSTALLED IN AN HPX BASE) - DETAILED DIMENSIONS
5 ft Cable Pigtail
HPX Base Assembly Top
Mounting Surface Top
Removable RCM
cable cartridge
mounted to
(285.3 mm)
11.2 inches
(200.6 mm)
7.9 inches
Removable RCM
mounting collar
mounted to HPX
Base
mounting collar
Mounting Collar
Pop-out panel
Slip cable through
slot in panel
Notch in Collar used to
pop out panel
FIG. 9 MYTURN SOURCE SELECTOR
FIG. 10 RCM MOUNTING COLLAR POP-OUT PANEL
FIG. 11 DP-HDMI ADAPTER
