Harman JBL PULSE User manual

Service Manual
PULSE
Wireless sound system with rechargeable battery, Bluetooth® and custom LED light show.
Released EU 2013 Harman International Rev 3, 08/2015
8500 Balboa Boulevard
Northridge, California 91329
OWNER’S MANUAL 2
EXPLODED VIEW AND PARTS 7
PACKING VIEW AND PARTS 8
SPARE PARTS LIST 9
DISASSEMBLY PROCEDURE 10
RESET PROCEDURE 26
SPECIFICATION SHEET 27
CONTENTS

Pulse
JBL
PULSE Service Manual
Page 2 of 38

Pulse
Quick Start Guide
Guide de démarrage rapide
Battery level indicator
2
3
JBL Pulse
JBL Pulse
JBL
PULSE Service Manual
Page 3 of 38

Pulse
Quick Start Guide
Guide de démarrage rapide
JBL MusicFlow App
JBL MusicFlow
JBL MusicFlow
JBL
PULSE Service Manual
Page 4 of 38

Pulse
Quick Start Guide
Guide de démarrage rapide
LED Behavior
NA
Pairing mode
Product is ON
Product is OFF
Not connected
Power
NA Light is ON
Connected
Light is OFFBlack light Mode
Bluetooth
Blinking
6
7
Drag
Press
Faites glisser
arrastrar
arrastar
ziehen
trascinare
1
2
slepen
dra
vetää
тащить
dra
Træk
ドラッグ
드래그
拖动
拖動
Appuyer
Pulsar
Premir
Drücken
Premere
Indrukken
Trykk
Paina
Нажать
Tryck på
Tryk
押す
누르기
按1 次
按一下
JBL
PULSE Service Manual
Page 5 of 38

EN
• Power supply: 5VDC, 2.3A
• Transducers:1.5”(40mm)x2
• Amplifier power: 6W X2
• Frequency response:105~20kHz
• Signal-to-noise ratio: 80dB
• Dimensions (Dia x H): 79mmx182mm
• Battery type: Polymer Li-ion
3.7V/4000mAh
• Input connections:3.5mm
• Listening time on battery power: 5 hours
• Battery charge time: 3 hours
• Bluetooth transmitter frequency range:
2.402 – 2.480 GHz
• Bluetooth transmitter power: 0 ~ 4dBm
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
FR
• Alimentation électrique: 5 VCC, 2,3A
• Transducteurs: 40 mm (1,5") x 2
• Puissance de l'amplificateur: 6 W x 2
• Plage de fréquences: 105~20 kHz
• Rapport signal sur bruit: 80 dB
• Dimensions (Dia x H): 79 mm x 182 mm
• Type de batterie: lithium-ion polymère
3,7 V / 4000 mAh
• Connexions d'entrée : 3,5 mm
• Durée d'écoute sur batterie : 5 heures
• Temps de charge de la batterie :
3 heures
• Bande de fréquences de l'émetteur
Bluetooth : 2,402 – 2,480 GHz
• Puissance de l'émetteur Bluetooth :
0 ~ 4 dBm
• Modulation de l'émetteur Bluetooth :
GFSK, π/4 DQPSK 8DPSK
ES
• Alimentación: 5VDC, 2,3A
• Transductores: 1.5"(40mm)x2
• Potencia de amplificación: 6W X2
• Respuesta de frecuencia: 105~20kHz
• Relación señal-ruido: 80dB
• Dimensiones (Dia x A) 79mmx182mm
• Tipo de batería: Iones de polímero de
litio 3.7V/4000mAh
• Conexiones de entrada: 3.5 mm
• Tiempo de audición con alimentación a
batería: 5 horas
• Tiempo de carga de la batería: 3 horas
• Alcance de frecuencia del transmisor
Bluetooth: 2.402 – 2.480 GHz
• Potencia del transmisor Bluetooth:
0 ~ 4dBm
• Modulación del transmisor Bluetooth:
GFSK, π/4 DQPSK, 8DPSK
PT
• Fonte de alimentação: 5V CC, 2,3A
• Transdutores: 40mm (1,5") x2
• Potência do amplificador: 6W x2
• Resposta em frequência: 105~20kHz
• Relação sinal/ruído: 80dB
• Dimensões (Diâm. x A): 79mm x 182mm
• Tipo de bateria: Polímero de iões de lítio
3,7V/4000mAh
• Ligações de entrada: 3,5mm
• Tempo de audição com bateria: 5 horas
• Tempo de carregamento da bateria:
3 horas
• Gama de frequências do transmissor
Bluetooth: 2,402 – 2,480GHz
• Potência do transmissor Bluetooth:
0 ~ 4dBm
• Modulação do transmissor Bluetooth:
GFSK, π/4 DQPSK, 8DPSK
Pulse
Quick Start Guide
Guide de démarrage rapide
JBL
PULSE Service Manual
Page 6 of 38

UnRegistered
JBL
PULSE Service Manual
Page 11 of 38
JBL PULSE EXPLODED VIEW

JBL PULSE PACKING VIEW AND PARTS

JBL Pulse spare parts
Ref.NO. Part Name_English Part .NO Description QTY per Corresponding PCBA P/N
1 Grille MM-HM08000100-B
SPCC T=0.6mm,BLACK PAINTED 1.0
2Lens MP-HM08A00300-B
ABS (MILK WHITE) 1.0
3Nonwovens MC-HM08000100-B 70g(Fabric KL180MB) 212*137.5）(212*137.5）1.0
4Double side tape AA-PD00400100-B
S-512,W=4mm，25m 0.0
5Back support MR-HM08S00301-B
SILICON RUBBER ,MATTE WITH PRINT（3M9448) 1.0
6Wind-screen MC-HM08000600-B
28mm*11mm*0.1mm 180 1.0
7Port_A MP-HM08A00400-B
ABS757 (BLACK) 1.0
8Port_B MP-HM08A00500-B
ABS757 (BLACK) 1.0
9LED Indicate PCBA FG-HM08GN0700-B PCBA LED Indicate 1.0
10 USB PCBA FG-HM08GN0200-B
PCBA USB 1.0
11 AUX Pcba FG-HM08GN0300-B
PCBA AUX 1.0
12 Screw MS-GEPBAPC099-B
ST2.0X7,D=3.2,Cr3+ 1.0
13 Rear house MP-HM08A00200-B
ABS757(BLACK) 1.0
14 Battery EU-BT00003600-B
3.7V/4000mAh 1.0
15 Rubber Button MR-HM08000200-B φ54.9±0.1mm,3M9448) 1.0
16 Key PCBA
FG-HM08GN0600-B PCBA Key 1.0
17 Double side tape MC-HM08000300-B
3M(9448)Φ52MM 1.0
18 Top cover MP-HM08C00100-B
ABS757 (WHITE),TPE( BLK),logo 1.0
19 Bottom cover MP-HM08C00200-B
ABS757 (WHITE),TPE( BLK) 1.0
20 Rubber Button MR-HM08000100-B
φ54.6±0.1mm,SILICON RUBBER (MATTE BLACK)
（
3M9448) 1.0
21 Rubber Block MR-HM08000400-B
SILICON RUBBER 11.8*8.04mm BLACK 60 1.0
22 Baffle MP-HM08A00100-B
ABS757(BLACK) 1.0
23 Screw MS-GEPBAPC0A5-B
ST2.6x7,Cr3+ 13.0
24 Screw MS-GEWBAPC034-B
ST2.0*7
，
W=Φ5.0MM, Cr3+ 3.0
25 Screw MS-GEPBAPC0A5-B
ST2.6x7,Cr3+ 13.0
26 Driver EB-M04000080300-B
Dimention: 40mm;Rated impedance: 8 Ohm;SPL: 80dB at 200,400,600,800;FO: 170Hz+/-20% 2.0
27 Main PCBA FG-HM08GN0400-B PCBA Main
1.0
28 LED Bar PCBA FG-HM08GN0500-B PCBA LED Bar 8.0
29 Double side tape MC-HM08000200-B
3M(9448)149.6MM*4.8MM 8.0
30 Connect cable driver EW-MC01205100-B
AWG#24,4,L=120MM 1.0
31 EVA MF-HM08000400-B
426*3.5*0.5mm 1.0
32 FFC cable EW-MC01151700-B
14P,L=115mm 4.0
33 FFC cable EW-MC01508000-B
14P,L=150mm 4.0
34 FFC cable EW-MC01550100-B
10P,L=155mm 1.0
35 EVA Bluetooth antenna MF-HM08000900-B
43x6.5x2mm 1.0
36 Antenna bluetooth EU-EL00000100-B
PCB 1.0
37 Mainboard EVA MF-HM08000201-B
12MM*4MM*1MM 2.0
38 Aux Socket EVA MF-HM08000500-B
12.0*8.0*2.0mm 1.0
39 Battery EVA bottom MF-HM08000701-B
2.0mm（20mm*20mm）2.0
40 Battery EVA top MF-HM08000600-B
12*12*4mm 1.0
41 FFC cable EW-MC01701100-B
7P,L=170mm 1.0
42 FFC cable EVA MF-HM08000100-B
30*20*1.0mm 1.0
43 Port EVA MF-HM08000300-B
55*20*0.5mm 2.0
Packing
4USB cable EW-MA10001000-B
L=1000mm,OD=4.5mm, MicroUSB to USB charger 1.0
5Adaptor ET-A240V0A100-B Switching AC/DC adapter, input:AC 100V-240V, output:USB DC 5V/2.3A,-Black 1.0
5a EU plug EG-000000DB00-B
5b GB plug EG-000000DA00-B
15 Master carton PC-HM08000100-B
219x215x183mm 0.5

1、Open top panel
To disassemble the unit
JBL
PULSE Service Manual
Page 13 of 38

2、Unplug FFC cable. Key board separated
JBL
PULSE Service Manual
Page 14 of 38

3、Remove 4 screws on top cover
JBL
PULSE Service Manual
Page 15 of 38

4、Top cover separated
JBL
PULSE Service Manual
Page 16 of 38

5、Separate Lens & Grille from main body
JBL
PULSE Service Manual
Page 17 of 38

6、Open bottom panel
JBL
PULSE Service Manual
Page 18 of 38

7、Remove 4 screws from bottom cover
JBL
PULSE Service Manual
Page 19 of 38

8、Bottom cover separated
JBL
PULSE Service Manual
Page 20 of 38

9、Remove sealing silicon rubber from main body
JBL
PULSE Service Manual
Page 21 of 38

10、Separate FFC cable from connectors
JBL
PULSE Service Manual
Page 22 of 38

11、Separate front and back baffle – (unscrew 5 screws)
JBL
PULSE Service Manual
Page 23 of 38
