Harman JBL QUANTUM 610 WIRELESS User manual

QUICK START GUIDE
610
WIRELESS
HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 1HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 1 10/21/2021 2:44:33 PM10/21/2021 2:44:33 PM

Software requirements
PLATFORM: Windows 7 (64 bit) / Windows 10 (64 bit) only
500MB of free hard drive space for installation
*Always use the latest version of Windows 10 for the most optimal experience on JBL QuantumENGINE
*JBL QuantumSURROUND and DTS Headphone:X V2.0
available on Windows only. Software installation required.
Download JBL QuantumENGINE to gain full access to features on your JBL Quantum headsets - from
headset calibration to adjusting 3D audio to suit your hearing, from creating customized RGB lighting
effects to determining how the boom microphone side-tone works. JBLquantum.com/engine
JBL QuantumENGINE
HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 2HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 2 10/21/2021 2:44:33 PM10/21/2021 2:44:33 PM

USB charging
cable
JBL quantum610 WIRELESS headset
3.5MM AUDIO
CABLE
USB
WIRELESS DONGLE
QSG | WARRANTY CARD |
Safety Sheet
Windshield foam for
boom microphone
001 WHAT'S IN THE BOX
HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 3HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 3 10/21/2021 2:44:33 PM10/21/2021 2:44:33 PM

002 Requirements
System compatibility
PC | Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR
PLATFORM: Windows 7 (64 bit) / Windows 10 (64 bit) only
500MB OF FREE HARD DRIVE SPACE FOR INSTALLATION
SOFTWARE REQUIREMENTS
JBL
Connectivity PC PS4/PS5 XBOX™ Nintendo Switch™ Mobile MAC VR
3.5 mm Audio Cable Stereo Stereo Stereo Stereo Stereo Stereo Stereo
2.4GWireless Stereo Not
Compatible Stereo Not Compatible Stereo Stereo
HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 4HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 4 10/21/2021 2:44:33 PM10/21/2021 2:44:33 PM

01 Game audio-chat balance dial
02 Volume Control
03 Detachable Windshield foam
04* Notification LED for mic mute / unmute
05* RGB-lit JBL logo
06 CHARGING LED
07 3.5mm Audio Jack
08 USB-C port
09 Voice Focus Boom Microphone
10 Flat-fold ear cup
11* Microphone Mute / unMute
12 POWER / 2.4G LED
13 POWER ON / OFF slider
14 2.4G PAIRING BUTTON
15 Volume Control
16 MIC MUTE BUTTON
003 OVERVIEW
08
*
HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 5HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 5 10/21/2021 2:44:33 PM10/21/2021 2:44:33 PM

004 POWER ON & CONNECT
power on
01
2.4G Wireless
MANUAL CONTROLS
02
PC | mac | PLAYSTATIONTM
>5S
>5S
01 02
HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 6HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 6 10/21/2021 2:44:34 PM10/21/2021 2:44:34 PM

005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR
HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 7HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 7 10/21/2021 2:44:34 PM10/21/2021 2:44:34 PM

006 BUTTON COMMAND
INCREASE CHAT VOLUME
INCREASE GAME VOLUME
ON OFF
INCREASE MASTER VOLUME
DECREASE MASTER VOLUME
ON / OFF
x1
>5S
Microphone Mute / unMute
HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 8HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 8 10/21/2021 2:44:34 PM10/21/2021 2:44:34 PM

007 First time setup
JBL Quantum610 WIRELESS
Game
JBL Quantum610 WIRELESS
Chat
7a Connect the headset to your PC via 2.4G USB wireless
connection.
7b Go to “Sound Settings” -> “Sound Control Panel”.
7c Under “Playback” highlight “JBL QUANTUM610 WIRELESS GAME”
and select “Set Default” -> “Default Device”.
7d Highlight “JBL QUANTUM610 WIRELESS CHAT” and select “Set
Default” -> “Default Communication Device”.
7e Under “Recording” highlight “JBL QUANTUM610 WIRELESS CHAT”
and select “Set Default” -> “Default Device”.
7f In your chat application select “JBL QUANTUM610 WIRELESS
CHAT” as the default audio device.
7G Follow the onscreen instructions to personalize your sound
settings.
HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 9HP_JBL_Quantum 610_QSG_Global_SOP_V5.indd 9 10/21/2021 2:44:34 PM10/21/2021 2:44:34 PM
