Spectrum™MediaStore
Component Replacement Guide
Revision C

Manual Part No. 006-0206-001
02 2016
Copyright © 2015–2016 Harmonic Inc. All rights reserved. Harmonic, the Harmonic logo, Omneon, the Omneon logo, [all other Harmonic products
mentioned] are trademarks, registered trademarks or service marks of Harmonic Inc. in the United States and other countries. Dolby, Dolby Digital,
Dolby Digital Plus and Dolby E are registered trademarks of Dolby Laboratories. Implementations of AAC and HE-AAC by Fraunhofer IIS. Other
company, product and service names mentioned herein may be trademarks or service marks of their respective owners. All product and application
features and specifications are subject to change at Harmonic's sole discretion at any time and without notice.
Disclaimer
Harmonic reserves the right to alter the product specifications and descriptions in this publication without prior notice. No part of this publication
shall be deemed to be part of any contract or warranty unless specifically incorporated by reference into such contract or warranty. The information
contained herein is merely descriptive in nature, and does not constitute a binding offer for sale of the product described herein. Harmonic assumes
no responsibility or liability arising from the use of the products described herein, except as expressly agreed to in writing by Harmonic. The use and
purchase of this product does not convey a license under any patent rights, copyrights, trademark rights, or any intellectual property rights of Harmonic.
Nothing hereunder constitutes a representation or warranty that using any product in the manner described herein will not infringe any patents of third
parties.
Third-party product trademarks
Adobe® After Effects®, Photoshop®, Flash® Professional, Premiere®
Avid® Media Composer®
Jünger Audio™
Apple® QuickTime®
Microsoft® Mediaroom®
Microsoft PlayReady®
DOCSIS® 3.0
Start Over® TV
Dolby is a registered trademark of Dolby Laboratories.
Dolby Digital, Dolby Digital Plus, Dolby Pulse, aacPlus, AC-3, and Dolby® E are trademarks of Dolby Laboratories.
Level Magic and Jünger are trademarks of Jünger Audio Studiotechnik GmbH.
MPEG Audio technology licensed from Fraunhofer IIS http://www.iis.fraunhofer.de/amm/.
PitchBlue® is a registered trademark of Vigor Systems.
QuickTime and the QuickTime logo are trademarks or registered trademarks of Apple Computer, Inc., used under license therefrom.
Third-party copyright notes
Harmonic software uses version 3.15.4 of the FreeImage open source image library under FreeImage Public License (FIPL). See http://
freeimage.sourceforge.net for details. The product may include implementations of AAC and HE-AAC by Fraunhofer IIS; and MPEG Audio technology
licensed from Fraunhofer IIS.
The software described in this publication may use version 2.8 of FFmpeg open source package under Lesser General Public License (LGPL).
The software described in this publication is furnished under a nondisclosure agreement, or the License Agreement and Limited Warranty stated below,
and the end user license agreement (which is furnished with the software), which may have additional terms. The software may be used or copied only
in accordance with the terms of those agreements. By using the software, you acknowledge you have read the end user license agreement and the
License Agreement and Limited Warranty provision.
The product described in this publication maybe covered by one or more of U.S. Patents, their foreign counterparts and pending patent applications.
The product is distributed with certain other software that may require disclosure or distribution of licenses, copyright notices, conditions of use,
disclaimers and/or other matter. Use of this product or otherwise fulfilling their conditions constitutes your acceptance of it, as necessary. Copies of
such licenses, notices, conditions, disclaimers and/or other matter are available in any one of the following locations: the LEGAL NOTICES AND
LICENSES section of the documentation directory of the product, user guide, or by contacting us at [email protected].
Notice
Information contained in this publication is subject to change without notice or obligation. While every effort has been made to ensure that the
information is accurate as of the publication date, Harmonic Inc. assumes no liability for errors or omissions. In addition, Harmonic Inc.assumes no
responsibility for damages resulting from the use of this guide.
License agreement and limited warranty
1. AGREEMENT: This is a legal agreement ("Agreement") between you ("you" or "your") and Harmonic, or its appropriate local affiliate ("Harmonic",
"we", "us" or "our"). Use of our product(s) and any updates thereto purchased or validly obtained by you (the "Products"), and/or the Software (as
defined below) (collectively, the "System"), constitutes your acceptance of this Agreement. "Use" includes opening or breaking the seal on the
2

packet containing this Agreement, installing or downloading the Software as defined below or using the Software preloaded or embedded in your
System. As used herein, the term "Software" means the Harmonic owned software and/or firmware used in or with the Products and embedded
into, provided with or loaded onto the Products in object code format, but does not include, and this Agreement does not address, any third-party
or free or open source software separately licensed to you ("Third Party Software"). If you do not agree to this Agreement, you shall promptly
return the System with a dated receipt to the seller for a full refund.
2. LICENSE: Subject to the terms and conditions of this Agreement (including payment), we hereby grant you a nonexclusive, nontransferable
license to use the object code version of the Software embedded into, provided solely for use with or loaded onto the Product, and the
accompanying documentation ("Documentation") for your internal business purposes. The Software and any authorized copies are owned by us
or our suppliers, and are protected by law, including without limitation the copyright laws and treaties of the U.S.A. and other countries. Evaluation
versions of the Software may be subject to a time-limited license key.
3. RESTRICTIONS: You (and your employees and contractors) shall not attempt to reverse engineer, disassemble, modify, translate, create
derivative works of, rent, lease (including use on a timesharing, applications service provider, service bureau or similar basis), loan, distribute,
sublicense or otherwise transfer the System, in whole or part except to the extent otherwise permitted by law. The Software may be operated
on a network only if and as permitted by its Documentation. You may make one (1) back up copy of the object code of the Software for archival
purposes only. Evaluation Software will be run in a lab, nonproductive environment. Results of any benchmark or other performance tests may
not be disclosed to any third party without our prior written consent. Title to and ownership of the Software and Documentation, and all copyright,
patent, trade secret, trademark, and other intellectual property rights in the System, shall remain our or our licensors' property. You shall not
remove or alter any copyright or other proprietary rights notice on the System. We reserve all rights not expressly granted.
4. LIMITED WARRANTY: (a) Limited Warranty. We warrant to you that, commencing on your receipt of a Product and terminating 1 year thereafter,
the System will perform substantially in accordance with its then-current appropriate Documentation. The Product (including replacements) may
consist of new, used or previously-installed components. (b) Remedies. If the System fails to comply with such warranty during such period,
as your sole remedy, you must return the same in compliance with our product return policy, and we shall, at our option, repair or replace the
System, provide a workaround, or refund the fees you paid. Replacement Systems are warranted for the original System's remaining warranty
period. (c) Exclusions. EVALUATION SOFTWARE IS LICENSED ON AS-IS BASIS AND SUBJECT TO 4(d). We will have no obligation under
this limited warranty due to: (i) negligence, misuse or abuse of the System, such as unusual physical or electrical stress, misuse or accidents; (ii)
use of the System other than in accordance with the Documentation; (iii) modifications, alterations or repairs to the System made by a party other
than us or our representative; (iv) the combination, operation or use of the System with equipment, devices, software or data not supplied by
us; (v) any third party hardware or Third Party Software, whether or not provided by us; (vi) any failure other than by us to comply with handling,
operating, environmental, storage or maintenance requirements for the System in the Documentation, including, without limitation, temperature
or humidity ranges. (d) Disclaimers. We are not responsible for your software, firmware, information, or data contained in, stored on, or integrated
with any Product returned to us for repair or replacement. SUCH LIMITED WARRANTY IS IN LIEU OF, AND WE SPECIFICALLY DISCLAIM,
ANY AND ALL OTHER WARRANTIES, WHETHER EXPRESS, IMPLIED OR STATUTORY, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF SATISFACTORY QUALITY, MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT.
WE DO NOT WARRANT THAT THE SYSTEM WILL MEET YOUR REQUIREMENTS OR BE UNINTERRUPTED OR ERROR-FREE. NO
ADVICE OR INFORMATION, WHETHER ORAL OR WRITTEN, OBTAINED FROM US OR ELSEWHERE, WILL CREATE ANY WARRANTY
NOT EXPRESSLY STATED IN THIS AGREEMENT. Some jurisdictions do not allow the exclusion of implied warranties or limitations on how long
an implied warranty may last, so such exclusions may not apply to you. In that event, such implied warranties or limitations are limited to 60 days
from the date you purchased the System or the shortest period permitted by applicable law, if longer. This warranty gives you specific legal rights
and you may have other rights which vary from state to state or country to country.
5. LIMITATION OF LIABILITY: WE AND OUR AFFILIATES, SUPPLIERS, LICENSORS, OR SALES CHANNELS ("REPRESENTATIVES") SHALL
NOT BE LIABLE TO YOU FOR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE, OR EXEMPLARY DAMAGES OF ANY KIND,
INCLUDING BUT NOT LIMITED TO LOST REVENUES, PROFITS OR SAVINGS, OR THE COST OF SUBSTITUTE GOODS, HOWEVER
CAUSED, UNDER CONTRACT, TORT, BREACH OF WARRANTY, NEGLIGENCE, OR OTHERWISE, EVEN IF WE WERE ADVISED OF
THE POSSIBILITY OF SUCH LOSS OR DAMAGES. NOTWITHSTANDING ANY OTHER PROVISIONS OF THIS AGREEMENT, WE AND
OUR REPRESENTATIVES' TOTAL LIABILITY TO YOU ARISING FROM OR RELATING TO THIS AGREEMENT OR THE SYSTEM SHALL
BE LIMITED TO THE TOTAL PAYMENTS TO US UNDER THIS AGREEMENT FOR THE SYSTEM. THE FOREGOING LIMITATIONS SHALL
NOT APPLY TO DEATH OR PERSONAL INJURY TO PERSONS OR TANGIBLE PROPERTY IN ANY JURISDICTION WHERE APPLICABLE
LAW PROHIBITS SUCH LIMITATION. YOU ARE SOLELY RESPONSIBLE FOR BACKING UP YOUR DATA AND FILES, AND HEREBY
RELEASE US AND OUR REPRESENTATIVES FROM ANY LIABILITY OR DAMAGES DUE TO THE LOSS OF ANY SUCH DATA OR FILES.
SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO SUCH
EXCLUSIONS MAY NOT APPLY TO YOU.
6. CONFIDENTIALITY: Information in the System and the associated media, as well as the structure, organization and code of the Software, are
proprietary to us and contain valuable trade secrets developed or acquired at great expense to us or our suppliers. You shall not disclose to
others or utilize any such information except as expressly provided herein, except for information (i) lawfully received by the user from a third
party which is not subject to confidentiality obligations; (ii) generally available to the public without breach of this Agreement; (iii) lawfully known to
the user prior to its receipt of the System; or (iv) required by law to be disclosed.
7. SUPPORT: Updates, upgrades, fixes, maintenance or support for the System (an "Upgrade") after the limited warranty period may be available
at separate terms and fees from us. Any Upgrades shall be subject to this Agreement, except for additional or inconsistent terms we specify.
Upgrades do not extend the limited warranty period.
8. TERM; TERMINATION: The term of this Agreement shall continue unless terminated in accordance with this Section. We may terminate this
Agreement at any time upon default by you of the license provisions of this Agreement, or any other material default by you of this Agreement not
cured with thirty (30) days after written notice thereof. You may terminate this Agreement any time by terminating use of the System. Except for
the first sentence of Section 2 ("License") and for Section 4(a) ("Limited Warranty"), all provisions of this Agreement shall survive termination of
this Agreement. Upon any such termination, you shall certify in writing such termination and non-use to us.
9. EXPORT CONTROL: You agree that the Products and Software will not be shipped, transferred, or exported into any country or used in any
manner prohibited by the United States Export Administration Act or any other export laws, restrictions, or regulations (the "Export Laws"). You
will indemnify, defend and hold us harmless from any and all claims arising therefrom or relating thereto. In addition, if the Products or Software
are identified as export controlled items under the Export Laws, you represent and warrant that you are not a citizen, or otherwise located within,
an embargoed nation (including without limitation Iran, Iraq, Syria, Sudan, Libya, Cuba, North Korea, and Serbia) and that you are not otherwise
prohibited under the Export Laws from receiving the Software. All rights to the Products and Software are granted on condition that such rights
are forfeited if you fail to comply with the terms of this Agreement.
3 MediaStore Component Replacement Guide

10. U.S. GOVERNMENT RIGHTS: The Software and the documentation which accompanies the Software are "Commercial Items," as that term is
defined at 48 C.F.R. §2.101, consisting of "Commercial Computer Software" and "Commercial Computer Software Documentation," as such terms
are used in 48 C.F.R. §12.212 or 48 C.F.R. §227.7202, as applicable. Consistent with 48 C.F.R. §12.212 or 48 C.F.R. §§227.7202-1 through
227.7202-4, as applicable, the Commercial Computer Software and Commercial Computer Software Documentation are being licensed to U.S.
Government as end users (a) only as Commercial Items and (b) with only those rights as are granted to all other end users pursuant to the terms
and conditions herein. Harmonic, 4300 North First Street, San Jose, CA 95134, U.S.A.
11. GENERAL:You shall not assign, delegate or sublicense your rights or obligations under this Agreement, by operation of law or otherwise, without
our prior written consent, and any attempt without such consent shall be void. Subject to the preceding sentence, this Agreement binds and
benefits permitted successors and assigns. This Agreement is governed by California law, without regard to its conflicts of law principles. The
U.N. Convention on Contracts for the International Sale of Goods is disclaimed. If any claim arises out of this Agreement, the parties hereby
submit to the exclusive jurisdiction and venue of the federal and state courts located in Santa Clara County, California. In addition to any other
rights or remedies, we shall be entitled to injunctive and other equitable relief, without posting bond or other security, to prevent any material
breach of this Agreement. We may change the terms, conditions and pricing relating to the future licensing of our Systems and other intellectual
property rights, including this Agreement, from time to time. No waiver will be implied from conduct or failure to enforce rights nor effective unless
in a writing signed on behalf of the party against whom the waiver is asserted. If any part of this Agreement is found unenforceable, the remaining
parts will be enforced to the maximum extent permitted. There are no third-party beneficiaries to this Agreement. We are not bound by additional
and/or conflicting provisions in any order, acceptance, or other correspondence unless we expressly agree in writing. This Agreement is the
complete and exclusive statement of agreement between the parties as to its subject matter and supersedes all proposals or prior agreements,
verbal or written, advertising, representations or communications concerning the System.
Every reasonable attempt has been made to comply with all licensing requirements for all components used in the system. Any oversight is
unintentional and will be remedied if brought to the attention of Harmonic at [email protected].
4

Manual Part No. 006-0206-001
02 2016
Copyright © 2015–2016 Harmonic Inc. All rights reserved. Harmonic, the Harmonic logo, Omneon, the Omneon logo, [all other Harmonic products
mentioned] are trademarks, registered trademarks or service marks of Harmonic Inc. in the United States and other countries. Dolby, Dolby Digital,
Dolby Digital Plus and Dolby E are registered trademarks of Dolby Laboratories. Implementations of AAC and HE-AAC by Fraunhofer IIS. Other
company, product and service names mentioned herein may be trademarks or service marks of their respective owners. All product and application
features and specifications are subject to change at Harmonic's sole discretion at any time and without notice.
In Harmonic documents, special symbols and fonts to call your attention to important information.
DANGER: The Danger symbol indicates information that, if ignored, can cause physical
harm to you.
CAUTION: The Caution symbol indicates information that, if ignored, can adversely affect
the performance of your Harmonic product, or that can make a procedure needlessly
difficult.
NOTE: The Note symbol indicates especially important information you need, or it may
provide additional information that applies in only some carefully delineated circumstances.
IMPORTANT: The Important symbol indicates information that should stand out when you
are reading product details and procedural information.
TIP: The Tip symbol indicates parenthetical information that is not necessary for
performing a given procedure, but which, if followed, makes the procedure easier,
smoother, or more efficient.
In addition to these symbols, this guide may use the following text conventions:
Convention Explanation
Typed Command Indicates the text that you type in at the keyboard prompt.
Ctrl, Ctrl + Shift A key or key sequence to press.
http://www.harmonicinc.com The italics in blue text to indicate Cross-references, and
hyperlinked cross-references in online documents.
Bold Indicates a button to click, or a menu item to select.
Screen Output The text that is displayed on a computer screen.
Emphasis The italics text used for emphasis and document references.
2

Table of Contents
Chapter 1: Introduction......................................................................................................................5
Chapter 2: MediaStore 7200 component replacement................................................................ 6
Replacing the bezel............................................................................................................................6
Removing the bezel......................................................................................................................6
Installing the bezel....................................................................................................................... 8
Replacing a disk drive........................................................................................................................9
About replacement drives............................................................................................................. 9
Failing a drive........................................................................................................................... 10
Drive slot numbers..................................................................................................................... 10
Removing a failed drive............................................................................................................. 11
Installing a replacement drive..................................................................................................... 12
Replacing an expander module.........................................................................................................13
Replacing a fan............................................................................................................................... 15
Replacing a power cooling module................................................................................................... 17
Chapter 3: MediaStore 5000 series component replacement....................................................20
Replacing a disk drive......................................................................................................................20
About replacement drives........................................................................................................... 20
Failing a drive........................................................................................................................... 21
Verifying which drive to remove..................................................................................................21
Removing a failed drive............................................................................................................. 22
Installing a replacement drive..................................................................................................... 22
Replacing an I/O module.................................................................................................................23
Replacing a power cooling module................................................................................................... 25
Chapter 4: Chassis replacement.....................................................................................................27
Replacing the chassis........................................................................................................................27
Verifying functionality....................................................................................................................... 28
Appendix A: Harmonic Technical Assistance Center contact information................................ 29
Harmonic corporate contact information............................................................................................30
Useful information for Technical Support............................................................................................30
Information about your Spectrum system..................................................................................... 30
Information about the SystemManager client PC.......................................................................... 31
Gathering drive failure information............................................................................................. 31
3

Spectrum MediaStore
Appendix B: Safety and regulatory compliance information..................................................... 33
Important safety instructions.............................................................................................................. 33
Safety symbols & safety, warning & caution instructions..................................................................... 34
Symboles de sécurité de sécurité, d'avertissement et Attention Instructions............................................ 36
Sicherheit Symbole und Sicherheit, Achtung & Vorsicht Anleitung........................................................39
Site preparation instructions..............................................................................................................44
Product end-of-life disassembly instructions........................................................................................ 45
Safety rules (English)........................................................................................................................ 46
Règles de sécurité.............................................................................................................................46
EU manufacturer’s Declaration of Conformity.....................................................................................46
Electromagnetic compatibility notices – Class A..................................................................................47
Product regulatory compliance markings............................................................................................49
Product environmental compliance.....................................................................................................51
EU RoHS................................................................................................................................... 51
EU REACH.................................................................................................................................52
China RoHS...............................................................................................................................52
Other RoHS and REACH type regulations....................................................................................53
Waste Electrical and Electronic Equipment (WEEE).......................................................................53
Battery directive......................................................................................................................... 54
WEEE Take-Back Request Program..............................................................................................54
Compliance with country specific environmental, safety and EMC standards.........................................55
4

Chapter 1
Introduction
This guide provides information to help you replace components in your Spectrum device or system.
Make sure that you read all safety warnings and instructions, and that you have received a replacement
component from Harmonic before you begin any of the procedures in this guide.
5

Chapter 2
MediaStore 7200 component replacement
The following components may be replaced in this device: bezel, disk drive, fan, expander module, and
power cooling module. Please contact Harmonic Technical Support when replacing a component.
•Replacing the bezel
•Replacing a disk drive
•Replacing an expander module
•Replacing a fan
•Replacing a power cooling module
Replacing the bezel
Over time, the bezel LEDs can wear out. Replacement bezels are available from Harmonic.
CAUTION: The front panel is susceptible to electrostatic discharge (ESD) when the bezel
is removed. Wear the appropriate ESD protection when you remove the bezel.
Removing the bezel
The bezel may be removed during operation.
1. Press in the release button on the left side of the bezel, and then pull the left side of the bezel away
from the chassis.
Example:
6

Replacing the bezel
2. Pull the right side of the bezel slightly away from the chassis, and then disconnect the bezel cable
from the 4-pin connector from the front panel.
Example:
7 MediaStore Component Replacement Guide

Chapter 2: MediaStore 7200 component replacement
Installing the bezel
Before you install the bezel, ensure that the server is mounted on the rack and that all disk drives are
installed.
NOTE: For optimum airflow, do not obstruct the air vents on the bezel after it is installed.
1. Connect the cable inside the bezel to the 4-pin connector on the right side of the front panel.
2. Fit the two posts on the right side of the bezel into the holes in the rack ear on the right side of the
chassis.
The bezel cable should form a loop that fits inside the metal panel of the bezel.
3. Press in the release button on the left side of the bezel while pushing the left side of the bezel straight
onto the chassis, and then release the button.
The posts on the left side of the bezel will fit into the holes in the rack ear and secure the bezel on the
chassis.
8

Replacing a disk drive
Replacing a disk drive
The MediaStore contains high-performance disk drives that can be hot-swapped during operation.
NOTE: The procedures in this section apply to SystemManager version 6.3. If you
are running a different version of SystemManager, some steps may vary. Refer to the
SystemManager Release Notes for instructions on upgrading.
DANGER: Observe all conventional ESD precautions when handling Spectrum devices
and components.
About replacement drives
Replacement drives must meet certain criteria. In the event of a drive failure, replacement drives are
available from Harmonic.
IMPORTANT: Use ONLY Harmonic-supplied replacement drives. Drives from any other
source will be excluded from coverage under the Harmonic product limited warranty and
maintenance services programs. In addition, any errors or damages caused by the use
of drives provided from any other source will cause the entire product to be excluded
from coverage under the Harmonic product limited warranty and maintenance services
programs.
9 MediaStore Component Replacement Guide

Chapter 2: MediaStore 7200 component replacement
NOTE: Replacement drives should have the same or greater drive capacity as those they
are replacing, and their form factor must match the other drives in the enclosure.
If you wish to install a Harmonic-supplied drive model that is not supported by your current version
of Spectrum firmware, you may need to install a "DDC" configuration file to your video server, which
enables you to install and use the new drive. For details, see "Installing a DDC file" in the Harmonic
SystemManager User Guide.
Be sure that you have a replacement drive on hand before removing the failed drive. You may wish to
have more than one replacement drive on hand in case the first is not responsive.
Failing a drive
Fail a drive that is experiencing a loss of data to remove it from a RAID set. This procedure is a
prerequisite to replacing a drive and is performed on the ContentServer or ContentStore Properties page
in SystemManager.
1. From the Configuration page, click the Servers & Switches icon.
2. On the Servers & Switches page, scroll to the ContentServers/ContentStores section and click the
Name of the required server.
3. On the Properties page, scroll to the Drives section and then select the drive(s) you wish to fail.
4. Click Fail Drives.
The drive Status changes to "Dead" and "Unraided".
5. If replacing the drive, note the Slot number of the failed drive.
Drive slot numbers
Correctly identify the drive slot before removing the drive from the chassis.
Figure 2-1: Drive slots numbers in the MediaStore 7200
10

Replacing a disk drive
Removing a failed drive
Drives may be replaced while the system is powered on. Make sure you have a replacement drive on
hand before removing the failed drive.
NOTE: Damage can occur to a drive if it is removed while it is spinning. After failing a
drive, wait 30 seconds to remove the drive to ensure that it has stopped spinning.
1. Press the blue release button inward to unlatch the drive carrier, and then pull open the lever.
2. Slide the drive carrier out of the drive bay.
Example:
3. Wait an additional 30 seconds, then remove the drive from the MediaStore enclosure.
4. On the Add/Remove Drives screen, click Remove next to the drive to "hide" the drive from view on
the Disk Utilities screen in the future.
TIP: To find each drive view: From the Configuration tab, click the Disk Utilities icon
on the left to access the Disk Utilities screen. Click on the MediaDirector with the
required disk drive(s) to display the associated drive views.
NOTE: You must click the Remove button associated with the disk for each
MediaDirector in an EFS.
11 MediaStore Component Replacement Guide

Chapter 2: MediaStore 7200 component replacement
Installing a replacement drive
Install the replacement drive and then verify that SystemManager reports the drive as alive. The RAID set
rebuild should begin automatically.
1. Press the blue release button on the replacement drive to open the lever.
2. Insert the drive carrier into the bay, sliding the drive until it contacts the backplane.
NOTE: The drive tray is in the correct position when its front edge lines up with the
edge of the drive bay.
3. Close the drive carrier release handle to lock the drive into place.
Example:
Within three minutes, the new drive should appear on the Disk Utilities screen on the
SystemManager application.
4. Verify that each MediaDirector reports the drive as Alive.
If it is reported as Alive by every MediaDirector, an automatic rebuild commences on this drive. Skip
to Step 6.
If the drive is not reported as Alive, bypass the drive. Follow the instructions in "Removing a failed
drive" to bypass the drive. If another drive is available, repeat steps 1- 4 using this drive. If successful,
continue to the next step. If unsuccessful, contact Technical Support for assistance.
12

Replacing an expander module
If you do not have another drive available, contact Technical Support.
5. If there is another drive that is available to configure as a hot spare, decide which drive should be
used as the RAID rebuild target. Configure this drive as a Local Hot Spare for the RAID set.
Refer to "Making a local hot spare drive" in the Harmonic SystemManager User Guide for instructions.
NOTE:
Before configuring a drive as a hot spare, ensure that the drive has the correct
firmware version as determined by the SystemManager and displayed on the Upgrade
Firmware screen. If the drive does not have the correct version, contact Technical
Support for assistance.
Once a drive is configured as a Local Hot Spare, an automatic rebuild commences on this drive.
6. On the RAID Utilities screen, monitor the status for the RAID set.
The status should change from Compromised to Rebuilding immediately. If it does not, start the
rebuild manually by clicking on Start Rebuild.
7. Reconfigure all other hot spare drives as desired.
8. Periodically monitor the rebuild until complete.
Once complete, RAID set status changes to Normal, Attached, Viable.
What to do next
If you replaced a failed drive with a new drive from Harmonic, use the packaging materials (carton,
cushion, and electrostatic sensitive bag) from the replacement disk drive to carefully repackage the failed
drive and return it promptly to Harmonic for analysis. Contact Technical Support for a Return Authorization
Number (RA) before shipping the drive.
Replacing an expander module
Harmonic suggests that you label the SAS cables as you remove them from the expander module. This
will ensure the cables are correctly assigned in the new module.
CAUTION: When replacing an expander module, the entire Spectrum system must be
shut down.
1. Power down the Spectrum system.
Refer to "Powering down a Spectrum System" in the Spectrum System Installation Guide for complete
instructions.
2. Disconnect the SAS cable(s) from the failed expander module.
3. Loosen the thumb screw to release the expander tray handle.
4. Open the tray handle to the left, and then pull the expander module out of the slot.
Example:
13 MediaStore Component Replacement Guide

Chapter 2: MediaStore 7200 component replacement
5. With the tray handle fully extended, slide the replacement expander module into the slot until it is
firmly seated.
6. Close the tray handle, lifting it slightly in order to align the thumb screw with the hole, and then tighten
the thumb screw.
Example:
14

Replacing a fan
7. Attach the SAS cables to the new expander module.
NOTE: Do not twist the SAS cables or bundle them with the power cables.
8. Power on the Spectrum system.
Refer to "Powering up a Spectrum System" in the Spectrum System Installation Guide for complete
instructions.
Replacing a fan
Each fan assembly is designed for tool-less removal and installation.
The MediaStore can remain powered on while you replace the fan.
1. Make sure that you identify the faulty fan module.
15 MediaStore Component Replacement Guide

Chapter 2: MediaStore 7200 component replacement
2. Loosen the two captive thumb screws on both sides of the fan.
3. Grasping both thumb screws, pull the fan gently but firmly until it clears the chassis.
Example:
4. Slide the replacement fan into the bay, aligning the thumb screws with the screw holes on the chassis.
5. Once the fan is fully inserted, tighten the captive thumb screws.
Example:
16

Replacing a power cooling module
Replacing a power cooling module
The MediaStore is equipped with two hot-swappable power cooling modules. If one fails, the load
is transferred to the remaining module without interruption to service. To take full advantage of the
redundancy, Harmonic recommends that you use separate, isolated power sources for each AC input.
DANGER: Observe all conventional ESD precautions when handling Spectrum devices
and components.
CAUTION: Do not remove the faulty power supply unless you have a replacement of the
correct type ready for installation. Do not leave a power supply slot empty for more than ten
minutes. Doing so will cause the MediaStore to overheat, which will result in component
failure.
1. Make sure that you identify the faulty power supply module.
17 MediaStore Component Replacement Guide
