HART HPCP01 User manual

HPCP01 20V
Air Compressor
Compresseur d’air
Compresor de aire
OPERATOR’S MANUAL
General Safety Rules 3
 SpecificSafetyRules 4-5
Symbols 6
Glossary of Terms 7
Features 7
 Assembly 8
 Operation 8-10
 Maintenance 11
 Troubleshooting 12
 Illustrations 13-14
 Parts/Service
 BackPage
MANUEL D’UTILISATION
 Règlesdesécuritégénérales 3
 Règlesdesécuritéparticulières 4-6
 Symboles 6-7
 Glossaire 7
 Caractéristiques 8
 Assemblage 8
 Utilisation 8-11
 Entretien 11
 Dépannage 12
 Illustrations 13-14
 Commandedepièces/réparation
 Pagearrière
MANUAL DEL OPERADOR
Reglasdeseguridadgenerales 3-4
 Reglasdeseguridadespecíficas 4-6
 Símbolos 6-7
 Glosariodetérminos 7-8
 Características 8
 Armado 8
 Funcionamiento 8-11
 Mantenimiento 11-12
 Solucióndeproblemas 12
 Illustraciones 13-14
 Pedidosdepiezasyservicio
 Pág.posterior
THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
WARNING: TO REDUCE THE RISK
OF INJURY, THE USER MUST READ AND UNDER-
STAND THE OPERATOR’S MANUAL BEFORE
USING THIS PRODUCT.
CE LIVRET D’INSTRUCTIONS CONTIENT DES
CONSIGNES DE SÉCURITÉ IMPORTANTES.
VEUILLEZ LE LIRE ET LE CONSERVER POUR
TOUTE RÉFÉRENCE FUTURE.
AVERTISSEMENT : POUR
RÉDUIRE LES RISQUES DE BLESSURES,
L’UTILISATEUR DOIT LIRE ET VEILLER À BIEN
COMPRENDRE LE MANUEL D’UTILISATION
AVANT D’EMPLOYER CE PRODUIT.
ESTE FOLLETO DE INSTRUCCIONES CONTIENE
INFORMACIÓN DE SEGURIDAD IMPORTANTE.
LÉALO Y CONSÉRVELO PARA REFERENCIA
FUTURA.
ADVERTENCIA:
PARA REDUCIR EL RIESGO DE
LESIONES, EL USUARIO DEBE LEER Y
COMPRENDER EL MANUAL DEL OPERADOR
ANTES DE USAR ESTE PRODUCTO.

DANGER
This compressor/pump is not equipped and should not be used to supply breathing quality air. Additional
equipment would be necessary to properly filter and purify the air to meet minimal specifications for Grade D
breathing as described in Compressed Gas Association Commodity Specification G 7.1 - 1966, OSHA 29 CFR
1910.134.CompressedGasAssociation,4221WalneyRoad,FifthFloor,Chantilly, VA20151-2923,(703)788-2700,
www.cganet.com.Anysuchadditionalequipmenthasnotbeenexaminedandnoimplicationofproperuseforbreathing
airisintendedorimplied.
Ifthiscompressorisalteredinanyway,existingwarrantiesshallbevoided.HartConsumerProducts,Inc.,disclaimany
liabilitieswhatsoeverforanyloss,personalinjury,ordamage.
DISCLAIMER OF WARRANTIES
Intheeventthecompressorisusedforthepurposeofbreathingairapplicationandproperin-linesafetyandalarm
equipmentisnotsimultaneouslyused,existingwarrantiesshallbevoided,andHARTdisclaimsanyliabilitieswhatsoever
foranyloss,personalinjury,ordamage.
DANGER
Cecompresseur/pompe n’est pas équipéetnedoitpasêtreutiliserpour fournirdel’airdequalitérespirable.Un
équipementsupplémentaireestnécessairepourfiltreretpurifierl’airconformémentauxspécificationsminimumd’air
respirabledequalitéDG7.1-1966,OSHA29CFR1910.134delaCompressedGasAssociation,4221WalneyRoad,
FifthFloor,Chantilly,VA20151-2923,(703)788-2700,www.cganet.com.Unteléquipementn’apasétéexaminéetnulle
implacationd’utilisationproprepourl’airrespirablen’estprévueouimplicite.
Sicecompresseurestmodifierdequellequemanièrequecesoit,lesgarantiesenvigueurserontdéclaréesnulleset
nonavenues.HartConsumerProducts,Inc.,déclineronttouteresponsabilitépourlespertes,blessuresetdommages
résultantdesonutilisation.
EXONÉRATION DE GARANTIES
Sicecompresseurestutilisépourdesapplicationsd’airrespirablesansunsystèmedesécuritéetd’alarmeapproprié,
lesgarantiesenvigueurserontdéclaréesnullesetnonavenuesetHARTdéclineratouteresponsabilitépourlespertes,
blessuresetdommagesrésultantdesonutilisation.
PELIGRO
Estecompresor(obomba)noestáequipadoydebeevitarseutilizarloparasuministrarairepararespirar.Esnecesario
equipoadicionalparafiltrarypurificardebidamenteelaireafindequecumplalasespecificacionesmínimasdeGrado
Dpararespiración,segúnseexplicaenlaEspecificacióndeProductosG7.1-1966delaAsociacióndeProveedores
deEquipodeGasComprimido(CompressedGasAssociation),OSHA29CFR1910.134.CompressedGasAssociation,
4221WalneyRoad,FifthFloor,Chantilly,VA20151-2923,(703)788-2700,www.cganet.com.Talequipoadicionalnoha
sidoexaminadoynodebesuponerseodeducirseningunaconclusiónconrespectoalcorrectousodelairederespiración.
Sisealteradecualquierformaestecompresor,quedananuladastodaslasgarantíaspresentes.HartConsumerProducts,
Inc.,seeximendetodaresponsabilidaddecualquiertipoporcualquierpérdida,lesióncorporalodañomaterial.
EXTENCIÓN DE RESPONSABILIDAD DE LAS GARANTÍAS
Encasodeutilizarseloscompresoresparasuministrarairederespiración,ynoutilizarsesimultáneamenteequipoenlínea
deseguridadyalarmaapropiado,seanulantodaslasgarantíaspresentes,yHARTseeximedetodaresponsabilidad
decualquiertipoporcualquierpérdida,lesiónfísicaodañomaterialqueresulte.

3 – English
GENERAL SAFETY RULES
WARNING
Read and understand all instructions.Failuretofollow
allinstructionslistedbelowmayresultinelectricshock,
fire,and/orseriouspersonalinjury.
WARNING:
Risk of bursting. Do not adjust pressure regulator
knobtoresultinoutputpressuregreaterthanmarked
maximumpressureofattachmentand/ortheitembeing
inflated. Never use at pressure greater than 120 psi.
Failure to heed this warning could result in possible
seriouspersonalinjury.
SAVE THESE INSTRUCTIONS
WORK AREA
Keep your work area clean and well lit. Cluttered
benchesanddarkareasinviteaccidents.Floormustnot
beslipperyfromwaxordust.
Do not operate air compressors in explosive
atmospheres, such as in the presence of flammable
liquids, gases, or dust. Powertoolscreatesparkswhich
mayignitethedustorfumes.
Keep bystanders, children, and visitors away while
operating an air compressor. Distractionscancause
youtolosecontrol.
Operate air compressor in an open area at least 18 in.
away from any wall or object that could restrict the
flow of fresh air to ventilation openings.
ELECTRICAL SAFETY
Avoid body contact with grounded surfaces such as
pipes, radiators, ranges, and refrigerators. Thereisan
increasedriskofelectricshockifyourbodyisgrounded.
Don’t expose air compressors to rain or wet conditions.
Waterenteringanaircompressorwillincreasetheriskof
electricshock.
Use this product only with batteries and chargers listed
in tool/appliance/battery pack/charger correlation
supplement 995000850.Useofotherbatterypacksor
chargersmaycreateariskofinjuryorfire.
PERSONAL SAFETY
Eye protection which conforms to ANSI specifications
and provides protection against flying particles both
from the FRONT and SIDE should ALWAYS be worn by
the operator and others in the work area when loading,
operating, or servicing this product.Eyeprotectionis
required to guard against flying fasteners and debris,
whichcouldcausesevereeyeinjury.
The employer and/or user must ensure that proper
eye protection is worn. WerecommendaWideVision
SafetyMaskforuseovereyeglassesorstandardsafety
glasses that provide protection against flying particles
bothfromthefrontandside.Alwaysuseeyeprotection
whichismarkedtocomplywithANSIZ87.1.
Additional safety protection will be required in some
environments. For example, the working area may
include exposure to a noise level which can lead to
hearing damage. The employer and user must ensure
thatany necessary hearingprotection is providedand
usedbytheoperatorandothersintheworkarea.Some
environments will require the use of head protection
equipment.Whenrequired,theemployerandusermust
ensurethatheadprotectionmarkedtocomplywithANSI
Z89.1isused.
Stay alert, watch what you are doing, and use common
sense when operating the air compressor. Do not
use product while tired or under the influence of
drugs, alcohol, or medication. Amomentofinattention
whileoperatinganaircompressormayresultinserious
personalinjury.
Dress properly. Do not wear loose clothing or jewelry.
Contain long hair. Keep your hair, clothing, and gloves
away from moving parts. Looseclothes,jewelry,orlong
haircanbecaughtinmovingparts.
Do not overreach. Keep proper footing and balance
at all times. Properfootingandbalanceenablesbetter
controloftheproductinunexpectedsituations.
Use safety equipment. Always wear eye protection.
Dustmask,nonskidsafetyshoes,hardhat,orhearing
protectionmustbeusedforappropriateconditions.
Do not use on a ladder, rooftop, or any inclined,
elevated, or unstable support. Stablefootingonasolid
surfaceenablesbettercontroloftheaircompressorin
unexpectedsituations.
SERVICE
When servicing a product, use only identical
replacement parts. Follow instructions in the
Maintenance section of this manual. Useofunauthorized
partsorfailuretofollowMaintenanceinstructionsmay
createariskofinjury.
Service must be performed only by qualified repair
personnel. Service or maintenance performed by
unqualifiedpersonnelmayresultinariskofinjury.
Remove the battery pack, open drain valve to
decompress tanks and allow water to drain, and
allow air compressor to become cool to the touch
before servicing. Turn pressure regulator knob fully
counterclockwiseaftershuttingoffaircompressor.

4 – English
SPECIFIC SAFETY RULES
Know your air compressor. Read operator’s manual
carefully.Learnitsapplicationsandlimitations,aswell
asthespecificpotentialhazardsrelatedtothisproduct.
Followingthisrulewillreducetheriskofelectricshock,
fire,orseriousinjury.
Do not exceed the pressure rating of any component
in the system.
Protect material lines and air lines from damage or
puncture.Keephoseawayfromsharpobjects,chemical
spills,oil,solvents,andwetfloors.
Check hoses for weak or worn condition before each
use, making certain all connections are secure. Do not
useifdefectisfound.Purchaseanewhoseornotifyan
authorizedservicecenterforexaminationorrepair.
Release all pressures within the system slowly. Dust
anddebrismaybeharmful.
Store idle air compressors out of the reach of children
and other untrained persons. Air compressors are
dangerousinthehandsofuntrainedusers.
Maintain air compressors with care. Followmaintenance
instructions.Properlymaintainedproductsareeasierto
control.
Check for misalignment or binding of moving parts,
breakage of parts, and any other condition that may
affect the product’s operation. If damaged, have the
air compressor serviced before using. Manyaccidents
arecausedbypoorlymaintainedproducts.
Keep the exterior of the air compressor dry, clean, and
free from oil and grease. Alwaysuseacleanclothwhen
cleaning. Never use brake fluids, gasoline, petroleum-
basedproducts,oranystrongsolventstocleantheunit.
Followingthisrulewillreducetheriskofdeteriorationof
theenclosureplastic.
Drain tanks of moisture after each day’s use.
Ifunitwillnotbeusedforawhile,itisbesttoleavedrain
valveopenuntilsuchtimeasitistobeused.Thiswill
allowmoisturetocompletelydrainoutandhelpprevent
corrosionontheinsideoftanks.
Risk of Fire or Explosion. Whenusedinconjunctionwith
adedicatedspraysystem,donotsprayflammableliquid
inaconfinedarea.Sprayareamustbewellventilated.Do
notsmokewhilesprayingorspraywheresparkorflame
ispresent.Keepcompressorsasfarfromthespraying
areaaspossible,atleast25feetfromthesprayingarea
andallexplosivevapors.
Risk of Bursting. Do not adjust regulator to result in
outputpressuregreaterthanmarkedmaximumpressure
ofattachment.Donotuseatpressuregreaterthan120
psi.
To reduce the risk of electric shock,donotexposeto
rain.Storeindoors.
Inspect tanks yearly for rust, pin holes, or other
imperfections that could cause it to become unsafe.
Neverweldordrillholesintheairtanks.
Make sure the hose is free of obstructions or snags.
Entangledorsnarledhosescancauselossofbalanceor
footingandmaybecomedamaged.
Use the air compressor only for its intended use. Do
not alter or modify the unit from the original design
or function.
Always be aware that misuse and improper handling
of this product can cause injury to yourself and others.
Never leave a tool unattended with the air hose
attached.
Never point any air tool toward yourself or others.
Do not operate this air compressor if it does not
contain a legible warning label.
Do not continue to use a tool or hose that leaks air or
does not function properly.
Always disconnect the air supply, turn the unit off, and
remove the battery pack beforemakingadjustments,
servicingaproduct,orwhenaproductisnotinuse.
Do not attempt to pull or carry the air compressor by
the hose.
Your tool may require more air consumption than this
air compressor is capable of providing.
Always follow all safety rules recommended by the
manufacturer of your air tool, in addition to all safety
rules for the air compressor. Following this rule will
reducetheriskofseriouspersonalinjury.
Never direct a jet of compressed air toward people or
animals. Take care not to blow dust and dirt towards
yourself or others. Followingthisrulewillreducetherisk
ofseriousinjury.
Do not use this air compressor to spray chemicals
or paint. Your lungs can be damaged by inhaling
toxic fumes. A respirator may be necessary in dusty
environments.
Inspect hoses periodically. Replace damaged hoses.
Followingthisrulewillreducetheriskofseriouspersonal
injury.

5 – English
SPECIFIC SAFETY RULES
Check damaged parts. Before further use of the air
compressor or air tool, a guard or other part that is
damaged should be carefully checked to determine
that it will operate properly and perform its intended
function. Check for alignment of moving parts, binding
of moving parts, breakage of parts, mounting, and
any other conditions that may affect its operation. A
guard or other part that is damaged should be properly
repaired or replaced by an authorized service center.
Followingthisrulewillreducetheriskofshock,fire,or
seriousinjury.
This equipment incorporates parts, such as snap
switches, receptacles, and the like that tend to
produce arcs or sparks and,therefore,whenlocated
inagarage,itshouldbeinaroomorenclosureprovided
forthepurpose,orshouldbe18in.ormoreabovethe
floor.
Never store a tool with air connected. Storingthetool
withairconnectedcan result in unexpectedfiringand
possibleseriouspersonalinjury.
Protect your lungs. Wear a face or dust mask if the
operationisdusty.Followingthisrulewillreducetherisk
ofseriouspersonalinjury.
Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
ofbatterypackmaycreateariskoffirewhenusedwith
anotherbatterypack.
Use power tools only with specifically designated
battery packs. Useofanyotherbatterypacksmaycreate
ariskofinjuryandfire.
When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make a
connection from one terminal to another. Shortingthe
batteryterminalstogethermaycauseburnsorafire.
Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquidejectedfromthe
batterymaycauseirritationorburns.
Battery tools do not have to be plugged into an
electrical outlet; therefore, they are always in
operating condition. Be aware of possible hazards
when not using your battery tool or when changing
accessories. Followingthisrulewillreducetheriskof
electricshock,fire,orseriouspersonalinjury.
Do not place battery tools or their batteries near fire
or heat. Thiswillreducetheriskofexplosionandpossibly
injury.
Do not crush, drop or damage battery pack. Do not
use a battery pack or charger that has been dropped
or received a sharp blow. Adamagedbatteryissubject
toexplosion.Properlydisposeofadroppedordamaged
batteryimmediately.
Batteries can explode in the presence of a source
of ignition, such as a pilot light. Toreducetheriskof
seriouspersonalinjury,neveruseanycordlessproduct
inthepresenceofopenflame.Anexplodedbatterycan
propeldebrisandchemicals.Ifexposed,flushwithwater
immediately.
Do not charge battery tool in a damp or wet location.
Followingthisrulewillreducetheriskofelectricshock.
Under extreme usage or temperature conditions,
battery leakage may occur. If liquid comes in contact
with your skin, wash immediately with soap and water.
If liquid gets into your eyes, flush them with clean
water for at least 10 minutes, then seek immediate
medical attention. Followingthisrulewillreducetherisk
ofseriouspersonalinjury.
Do not use a battery pack that is damaged or modified.
Damagedormodifiedbatteriesmayexhibitunpredictable
behaviorresultinginfire,explosionorriskofinjury.
Do not modify or attempt to repair a battery pack that
has been damaged.
Do not expose a battery pack or appliance to fire or
excessive temperature. Exposuretofireortemperature
above265°Fmaycauseexplosion.
Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature
range specified in the instructions. Chargingimproperly
orattemperaturesoutsideofthespecified range may
damagethebatteryandincreasetheriskoffire.
Have servicing performed by a qualified repair person
using only identical replacement parts. Thiswillensure
thatthesafetyoftheproductismaintained.
Save these instructions. Refertothemfrequentlyand
usethemtoinstructotherswhomayusethisproduct.
If you loan someone this product, loan them these
instructionsalso.

6 – English
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert Indicatesapotentialpersonalinjuryhazard.
Read
Operator’s
Manual
Toreducetheriskofinjury,usermustreadandunderstandoperator’smanualbefore
usingthisproduct.
Eye Protection AlwaysweareyeprotectionwithsideshieldsmarkedtocomplywithANSIZ87.1.
Wet
Conditions
Alert
Donotexposebattery,batterycompartment,orelectroniccomponentstorain,water,
orliquids.Donotchargebatteryorexposeproducttorainordamplocations.
Recycle
Symbol
Thisproductuseslithium-ion(Li-ion)batteries.Local,stateorfederallawsmayprohibit
disposalofbatteriesinordinarytrash.Consultyourlocalwasteauthorityforinformation
regardingavailablerecyclingand/ordisposaloptions.
Risk of
Bursting
Donotadjustregulatortoresultinoutputpressuregreaterthanmarkedmaximumpres-
sureofattachment.Donotuseatpressuregreaterthan120PSI.
Risk of Fire or
Explosion
Donotsprayflammableliquidinaconfinedarea.Sprayareamustbewellventilated.Do
notsmokewhilesprayingorspraywheresparkorflameispresent.Keepcompressors
asfarfromthesprayingareaaspossible,atleast25feetfromthesprayingareaandall
explosivevapors.
Hot Surface Toreducetheriskofinjuryordamage,avoidcontactwithanyhotsurface.
Risk to
Breathing
Airobtained directly fromthe air compressor should never be used tosupply air for
humanconsumption.
VVolts Voltage
Direct Current Typeoracharacteristicofcurrent
n
o
No Load
Speed Rotationalspeed,atnoload
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicatesahazardoussituation,which,ifnotavoided,willresultindeathorseriousinjury.
WARNING: Indicatesahazardoussituation,which,ifnotavoided,couldresultindeathorseriousinjury.
CAUTION: Indicatesahazardoussituation,that,ifnotavoided,mayresultinminorormoderateinjury.
NOTICE: (WithoutSafetyAlertSymbol)Indicatesinformationconsideredimportant,butnotrelated
toapotentialinjury(e.g.messagesrelatingtopropertydamage).

7 – English
GLOSSARY OF TERMS
Air Filter
Porouselementcontainedwithinametalorplastichousing
attachedtothecompressorcylinderheadwhichremoves
impuritiesfromtheintakeairofthecompressor.
Air Tank
Cylindricalcomponentwhichcontainsthecompressedair.
Auto On/Off Switch
Control which turns the air compressor on or off. The
pressureswitchwillnotautomaticallystartandcontrolthe
compressorunlessthemanualAutoOn/Offswitchisinthe
AutoOnposition.
Check Valve
Devicethatpreventscompressedairfromflowingbackfrom
theairtanktothecompressorpump.
Cut-In Pressure
The low pressure at which the motor will automatically
restart.
Cut-Off Pressure
The high pressure at which the motor will automatically
shutoff.
Electric Motor
Device which provides the rotational force necessary to
operatethecompressorpump.
NPT (National Pipe Thread)
Asealthreadtapemustbeusedtoprovidealeak-freeseal
onpipethreadedconnections.
Overload Switch (Internal)
Automaticallyshutsoffthecompressorifthetemperatureof
theelectricmotorexceedsapredeterminedlimit.Pressing
theresetbuttonwillresettheswitch.
Pressure Regulator Knob
Regulatestheoutgoingpressurefromtheairoutlettothe
tool.Itispossibletoincreaseordecreasethepressureat
theoutletbyadjustingthiscontrolknob.
Pressure Switch
Automaticallycontrolstheon/offcyclingofthecompressor.
Itstopsthecompressorwhenthecut-offpressureinthe
tank is reached and starts the compressor when the air
pressuredropsbelowthecut-inpressure.
PSI (Pounds Per Square Inch)
Measurementofthepressureexertedbytheforceofthe
air.Theactualpsiismeasuredbyapressuregaugeonthe
compressor.
Pump
Producesthecompressedairwithareciprocatingpiston
containedwithinthecylinder.
Regulator Pressure Gauge
Displaysthecurrentlinepressure.Linepressureisadjusted
byrotatingthepressureregulatorknob.
Safety Valve
Prevents air pressure in the air tank from rising over a
predeterminedlimit.
SCFM (Standard Cubic Feet Per Minute) or CFM
(Cubic Feet Per Minute)
Aunitofmeasureofairdelivery.
Tank Pressure Gauge
Indicatesthepressureintheairtank.
PRODUCT SPECIFICATIONS
AirTankCapacity....................................................... 2gal.
AirPressure.................................................... 120psimax.
FEATURES
AirDelivery.................................... Upto.8SCFM@40psi
Upto.5SCFM@90psi
TestedperISO1217
Gauges....................................................... 1.7in.diameter
Motor......................................................................18VDC

8 – English
ASSEMBLY
DANGER:
Donotdisassemblecheckvalve,tankdrainvalvesor
safetyreliefvalvewithairintank—bleedtanks.Failure
to depressurize tank could result in explosion and/or
seriouspersonalinjury.
WARNING:
Do not allow familiarity with products to make you
careless.Rememberthatacarelessfractionofasecond
issufficienttoinflictsevereinjury
WARNING:
Alwaysweareyeprotectionwithsideshieldsmarkedto
complywithANSIZ87.1.Failuretodosocouldresultin
objectsbeingthrownintoyoureyesresultinginpossible
seriousinjury.
WARNING:
Do not use any attachments or accessories not
recommendedbythemanufacturerofthisproduct.The
useof attachments or accessoriesnot recommended
canresultinseriouspersonalinjury.
WARNING:
This equipment incorporates parts, such as snap
switches,receptacles,andthelikethattendtoproduce
arcsorsparksand,therefore,whenlocatedinagarage,
it should be in a room or enclosure provided for the
purpose,orshouldbe18in.ormoreabovethefloor.
WARNING:
Donotattachanytoolstotheopenendofthehoseuntil
start-uphasbeencompleted.
WARNING:
Donotusethisproductifitisnotcompletelyassembled
orifanypartsappeartobemissingordamaged.Useof
aproductthatisnotproperlyandcompletelyassembled
orwithdamagedormissingpartscouldresultinserious
personalinjury.
WARNING:
Do not attempt to modify this product or create
accessoriesorattachmentsnotrecommendedforuse
withthisproduct.Anysuchalterationormodificationis
misuseandcouldresultinahazardousconditionleading
topossibleseriouspersonalinjury.
Ifanypartsaredamagedormissing,pleasecall1-800-776-5191forassistance.
OPERATION
WARNING:
Always remove battery pack from the tool when you
are assembling parts, making adjustments, cleaning,
orwhennotinuse.Removingbatterypackwillprevent
accidental starting that could cause serious personal
injury.
NOTICE:
Donotuseinanenvironmentthatisdustyorotherwise
contaminated.Usingtheaircompressorinthistypeof
environmentmaycausedamagetotheunit.
APPLICATIONS
Aircompressorsareutilizedinavarietyofairsystemappli-
cations.Matchhoses,connectors,airtools,andaccessories
tothecapabilitiesoftheaircompressor.
Youmayusethisproductforthepurposeslistedbelow:
Operatinglight-tomedium-dutyair-poweredtools
Operating air accessories such as air nozzles and
automotivetirechucks
INSTALLING/REMOVING BATTERY PACK
See Figure 1, page 13.
Makesuretheaircompressoristurnedoff.
Inserta fullychargedbatterypack intotheproductas
shown.
NOTE: For best performance, a 4.0 Ah battery pack is
recommended.
Makesurethelatchonthebatterypacksnapsintoplace
andthe battery pack is secured in the productbefore
beginningoperation.
Depress the latch and pull to release and remove the
batterypack.
For complete charging instructions, see the operator’s
manualsforyourbatterypackandcharger.

9 – English
OPERATION
CONNECTING/DISCONNECTING AIR HOSE
(HOSE NOT PROVIDED)
See Figure 2, page 13.
WARNING:
Never exceed the air tool’s pressure rating as
recommended by the manufacturer. When using this
aircompressorasaninflationdevice,alwaysfollowthe
maximuminflationguidelinesstatedbythemanufacturer
oftheitembeinginflated.
Makesuretheaircompressoristurnedoffandthebattery
packisnotinstalled.
Rotate pressure regulator knob fully in the counter-
clockwise direction so that the outlet pressure is at
zero(0)psi.
Attachhosewithquickconnectairfittingto1/4in.quick
coupleronaircompressor.Makesuretopushthehose
adaptorendfullyintothecoupleruntilthesleevesprings
forwardtolockitinplace.
To disconnect an air hose or an air tool:
Confirmthattheoutletpressureisatzero(0)psi.
Whendisconnectingahosefrom1/4-in.quickcoupler,
alwaysfirmlyholdreleaseendofhose.
Pull back on the release sleeve on the 1/4-in. quick
coupler.
Withafirmgrip,pulloutthequick-connectairfittingthat
isattachedtothequickcoupler.
BREAK-IN PERIOD
Beforefirstuse,installafullycharged4.0Ahbatterypack,
thenruntheaircompressoratzerotankpressurewiththe
drainvalvefullyopenfor30minutesoruntilthebatterypack
iscompletelydischarged,whicheverhappensfirst.
TURNING THE AIR COMPRESSOR ON/OFF
See Figure 3, page 14.
Installthebatterypack.
MovetheAutoOn/OffswitchtotheAUTO ON (I) position
topowerthecompressoron.
To turn the air compressor off, move the Auto On/Off
switchtotheOFF (O) position.
NOTE: Whenthecompressorisinthe AUTO ON (I) position,
the air compressor will automatically turn back on when
thedesignatedtankair pressure drops below thepreset
pressurelimit.Itwillalsoshutoffagainwhenthecut-off
pressureisreached.
WARNING:
Never exceed the air tool’s pressure rating as
recommended by the manufacturer. When using this
aircompressorasaninflationdevice,alwaysfollowthe
maximuminflationguidelinesstatedbythemanufacturer
oftheitembeinginflated.
WARNING:
AlwaysensuretheswitchisintheOFF (O) positionand
theregulatorpressuregaugereadszerobeforechanging
airtoolsordisconnectingthehosefromtheairoutlet.
Failuretodosocouldresultinpossibleseriouspersonal
injury.
USING THE AIR COMPRESSOR
See Figure 4, page 14.
WARNING:
Risk of bursting. Do not adjust pressure regulator
knobtoresultinoutputpressuregreaterthanmarked
maximumpressureofattachmentand/ortheitembeing
inflated. Never use at pressure greater than 120 psi.
Failure to heed this warning could result in possible
seriouspersonalinjury.
WARNING:
Air powered tools may require more air consumption
thanthisaircompressoriscapableofproviding.Check
thetoolmanualtoavoiddamagetothetoolorriskof
personalinjury.
Ensure that the Auto On/Off switch is in the OFF (O)
positionandthebatterypackisnotinstalled.
AttachairhosefollowingtheinstructionsinConnecting/
Disconnecting Air Hose(hosenotprovided).
Attach 1/4 in. NPT quick-connect air fitting to the
accessoryortoolyouintendtouse.
Inserttheotherendofthequick-connectairfittingtothe
quickcouplerontheopenendofhose.
Installthebatterypack.
MovetheAutoOn/OffswitchtotheAUTO ON (I) position.
Settheamountofairpressuredesiredusingthepressure
regulatorknob.Turntheknobclockwisetoincreaseor
counterclockwisetodecreasetheairpressurethrough
thehose.
NOTE: Alwaysusetheminimumamountofpressurenec-
essaryforyourapplication.Usingahigherpressurethan
neededwilldrainairfromthetankmorerapidly,causethe
unittocycle on more frequently,and reduce battery run
timebetweencharges.
Followingallsafetyprecautionsinthismanualandthe
manufacturer’s instructions in the air tool manual, you
maynowproceedtouseyourair-poweredtool.

10 – English
OPERATION
NOTE: Theaircompressorwillshutoffduringanelectrical
overload.Toresettheinternaloverloadswitch,turnoffthe
aircompressorandallowtheunittocool.Removeandthen
reinstallthebatterypacksbeforeresumingoperation.
Whenfinished,alwaysdrainthetank,turntheunitoff,
andremovethebatterypacks.Neverleavetheuniton
and/orrunningunattended.
DRAINING THE TANK
See Figures 5 - 6, page 14.
To help prevent tank corrosion and keep moisture out
oftheairused,theairtankofthecompressorshouldbe
draineddaily.
To drain:
Turntheaircompressoroffandremovethebatterypacks.
Pulltheringonthesafetyvalvetoreleaseairuntiltank
pressuregaugereadslessthan20psi.
Releasethering.
Rotatedrainvalvescounterclockwisetoopen.
Tilt tank to drain moisture from tank into a suitable
container.
NOTE: Condensateisapollutingmaterialandshouldbe
disposedofincompliancewithlocalregulations.
Ifadrainvalveisclogged,releaseallairpressure,remove
andcleanvalve,thenreinstall.
WARNING:
Turnofftheaircompressor,removebatterypacks,and
releaseallairfromthetankbeforeservicing.Failureto
depressurize tank before attempting to remove valve
couldcauseseriouspersonalinjury.
Rotatedrainvalveclockwiseuntiltightlyclosed
WARNING:
RISK OF BURSTING. All compressed air tanks have
a limited lifespan. The lifespan can be affected by a
number of factors, including operating conditions of
the air compressor, proper maintenance of the tank,
and unauthorized repairs and modifications. Since
deterioration of the tank can occur internally with no
outwardsigns,theairtank(s)onthiscompressorMUST
beremovedfromservicebytheendoftheyearshown
onthedatalabel.Useoftheaircompressorafterthis
dateincreasestheriskofanairtankrupture,whichcould
resultinseriouspersonalinjury.
CHECKING THE SAFETY VALVE
See Figure 5, page 14.
DANGER:
Donotattempttotamperwiththesafetyvalve.Anything
loosenedfromthisdevicecouldflyupandhityou.Failure
to heed this warning could result in death or serious
personalinjury.
Thesafetyvalvewillautomaticallyreleaseairiftheairtank
pressureexceedsthecut-outpressure.Thevalveshouldbe
checkedbeforeeachdayofusebypullingtheringbyhand.
Installthebatterypack.
Turntheaircompressoronandallowthetanktofill.The
compressorwillshutoffwhenthepressurereachesthe
cut-outpressure.
Turntheaircompressoroff.
Pulltheringonthesafetyvalvetoreleaseairforthreeto
fivesecondstoallowpressurizedairtoescape.Release
thering. The safety release valve must reset and hold
pressurebeforeallcompressedairisexhaustedfromthe
tank/pressurevessel.
Anycontinuedlossofairafterperformingtheabovesteps
indicatesa problem with the safety valve. Discontinue
use and seek service before continued use of the air
compressor.
WARNING:
Ifairleaksaftertheringhasbeenreleasedorifthevalve
is stuck and cannot be actuated by the ring, do not
usetheaircompressoruntilthesafetyvalvehasbeen
replaced. Use of the air compressor in this condition
couldresultinseriouspersonalinjury.
RESET BUTTON
See Figure 7, page 14.
Whenamperageintotheaircompressorexceedsthespec-
ifiedamperage,theinternaloverloadswitchwillcausethe
aircompressortoautomaticallyshutoff.
To reset the air compressor:
Turntheaircompressoroff.
Removethebatterypack.
Presstheresetbutton.
Installthebatterypack.
Turntheaircompressoron.
