Hartmann TROVE T1RHC3 User manual

Rev. T1RHC3-033022
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
Installation Guide
All registered trademarks are property of their respective owners.
T1RHC3
Fully assembled kit includes:
- Trove1R rack enclosure with Altronix and Hartmann backplane (THC1R)
- (1) AL600ULXB - Power Supply/Charger
All components of this Trove kit are UL Listed sub-assemblies.
Please refer to the included corresponding
Sub-Assembly Installation Guides for further information.
Access & Power Integration

- 2 - T1RHC3 Installation Guide
Overview:
Altronix T1RHC3 rack kit is pre-assembled and consist of Trove1HC1R enclosure/backplane with factory
installed Altronix power supply/charger. These kits also accommodate various combinations of Hartmann boards
for up to eight (8) doors in a single enclosure.
Configuration Chart:
Altronix
Model Number
115VAC 60Hz
Input
(current draw)
Power Supply
Board Input
Fuse Rating
Maximum
Battery
Charge Current
12VDC Total
Output Current
24VDC Total
Output Current
T1RHC3 3.5A 5A/250V 0.7A 6A 6A
Hardware and Accessories:
Specifications:
Agency Listings:
• CE European Conformity.
Mechanical:
• Black enclosure with ample knockouts for
convenient access.
• Includes: tamper switch, cam lock and
mounting hardware.
• Modular 2U standard EIA 19” drawer with
extendable slides up to 48”.
• Dimensions (H x W x D): 3.375” x 19.0” x 26.5”
(85.8mm x 482.6mm x 673.1mm)
Included Accessories:
• One (1) tamper switch
(Altronix Model TS112 or equivalent).
• Cam lock.
Available Accessories (not included):
• RE2: Rack Mount Battery Enclosure accommodates
up to four (4) 12VDC/7AH batteries.
• WM5, WM25, WM100: Magnetic Cable Tie Mounts
(5, 25, 100 counts).
Spacer | 5/16” Pan Head Screw | Lock Nut
Installation Instructions for T1RHC3:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local
codes and authorities having jurisdiction. These products are for indoor use only and must be installed within
the protected premises.
Note: First assemble and Install Z Bracket Wire Management Accesory
(refer to Z Bracket Installation pg. 4)
1. Remove backplane from enclosure prior to installing into rack cabinet
(do not discard hardware).
2. In order to mount included UL Listed tamper switch (Altronix Model TS112 or
equivalent) turn the enclosure upside down. Punch out the knockout in
designated location, on the back of the unit, from outside of the drawer
(Fig. 1, pg. 3). Insert the tamper switch into the knockout from outside of the
drawer with the button facing outwards and spaded connectors inside the drawer.
Connect tamper switch wiring to the Access Control Panel input or the
appropriate UL Listed reporting device.
To activate alarm signal open the rack drawer.
3. Slide the rack enclosure into an open 2U location in the four post rack cabinet.
4. Utilizing proper fasteners attach front ears to the rack rails.
5. Attach the rear of the adjustable slides to the rear rails of the rack cabinet with the proper fasteners.
6. Secure the rack cover (Fig. 2a, pg. 3) and rack drawer to earth ground (Fig. 2b, pg. 3).
7. Make sure that all internal cofigurations (wiring, voltage selection, switch settings, etc.) are
complete before mounting backplane back into enclosure.
8. Refer to the ULXB Power Supply/Charger Installation Guide AL600ULXB for further instructions.
Fig. 1
Back of the drawer,
viewed from outside.
Tamper Switch
mounting location

T1RHC3 Installation Guide - 3 -
Fig. 2
Fig. 2a
Fig. 2b
Assembling and Attaching
Z Bracket Wire Management Accessory (included):
Altronix Trove Rack enclosures include Z Bracket, a convenient and reliable wire management accessory.
Hardware (included):
Ten (10) bolts and eight (8) lock nuts.
1. Carefully unpack Z Bracket. Do not discard hardware
(included) (Fig. 3, pg. 4).
2. Attach arms to each other using bolts and
lock nuts (Fig. 3a, pg. 4).
3. Attach the hinge brackets to the ends of
arms using bolts and nuts positioning
them as shown on (Fig. 3b, pg. 4).
4. Make sure that all nuts are tightened.
5. Attach the hinge bracket on the longer side of Z Bracket to the adjustable slide using bolts and lock nuts
(included) (Fig. 4, 4a, pg. 4).
6. Attach the hinge bracket on the shorter side of Z Bracket to the rear of the rack enclosure using bolts
(included).
Fig. 4
Fig. 4a
Fig. 3b
Two (2)
Fig. 3
Fig. 3a

- 4 - T1RHC3 Installation Guide
T1RHC3: Configuration of Hartmann Boards:
1. Align the Hartmann Controls boards on the backplane to match the boards’ mounting holes with
corresponding pems.
2. Fasten spacers (provided) to pems that match the hole pattern for Hartmann Control boards
(Fig. 2, 2a, pg. 3).
Note: Hartmann Controls boards must be properly grounded.
Please use provided metal spacers for the lower right mounting holes (Fig. 5, pg. 3).
3. Mount Hartmann Controls boards to spacers utilizing provided 5/16” pan head screws (Fig. 2a, pg. 3).
4. Fasten backplane to Trove1 enclosure utilizing lock nuts (provided).
Fig. 5
Altronix
AL600ULXB
BAT FAIL NC C NO NC C NO AC FAIL
AC DC BAT
+BAT- + DC -
L G N
OFF - 24V ON - 12V
ON
To IEC connector
To LED lense
PRS_MASTER
Metal Spacer
PRS_TDM
or
PRS_IO8
Metal Spacer
PRS_TDM
or
PRS_IO8
Metal Spacer
PRS_TDM
or
PRS_IO8
Metal Spacer
PRS_TDM
or
PRS_IO8
Metal Spacer
Pem
Spacer
Backplane
Pan Head Screw
Hartmann Board
Fig. 5a

T1RHC3 Installation Guide - 5 -
Notes:

- 6 - T1RHC3 Installation Guide
Notes:

T1RHC3 Installation Guide - 7 -
Notes:

- 8 - T1RHC3 Installation Guide
Trove1R Enclosure Dimensions:
3.375” x 19.0” x 26.5” (85.8mm x 482.6mm x 673.1mm). Shown with Z Bracket attached.
0.1”
2.5mm
1.5”
38.1mm
11.175” (283.8mm)
Tamper
Switch
3/4” Conduit
1” Conduit
Conduit
3/4”
1/2”
2.4”
61mm
4.57”
116.1mm
3.375”
85.8mm
26.5”
673.1mm
19” (482.6mm)
R 1.27” (32.3mm)
1” (25.4mm)
0.55” (14mm)
3.62”
92mm
