Hartzell HC-D2MV20-3 Series User manual

Manual No. 140
61-00-40
Revision 5
April 2023
Hartzell Propeller Inc.
One Propeller Place
Piqua, OH 45356-2634 U.S.A.
Ph: 937-778-4200 (Hartzell Propeller Inc.)
Ph: 937-778-4379 (Product Support)
Product Support Fax: [phone]
Propeller Owner's Manual
and Logbook
Series: HC-D2(MV,V)20-3
HC-D3(MV,V)20-6L
HC-D2(MV,V)20-7( )
HC-D2(MV,V)20-8( )
HC-D3MV20-8D
Hydro-Selective Propellers with Aluminum Blades

© 2002, 2011, 2012, 2014, 2021, 2023 -
Hartzell Propeller Inc. - All rights reserved
HARTZELL PROPELLER OWNER'S MANUAL
140
Inside Cover
Rev. 5 Apr/23
COVER 61-00-40
HARTZELL PROPELLER OWNER'S MANUAL
140

61-00-40
MESSAGE
Page 1
Rev. 5 Apr/23
HARTZELL PROPELLER OWNER'S MANUAL
140
As a fellow pilot, I urge you to read this Manual thoroughly. It
contains a wealth of information about your new propeller.
The propeller is among the most reliable components of your
airplane. It is also among the most critical to ight safety. It therefore
deserves the care and maintenance called for in this Manual. Please
give it your attention, especially the section dealing with Inspections
and Checks.
Thank you for choosing a Hartzell propeller. Properly maintained it
will give you many years of reliable service.
Joe Brown
Chairman, Hartzell Propeller Inc.

61-00-40
MESSAGE
Page 2
Rev. 5 Apr/23
HARTZELL PROPELLER OWNER'S MANUAL
140
People who y should recognize that various types of
risks are involved; and they should take all precautions to
minimize them, since they cannot be eliminated entirely.
The propeller is a vital component of the aircraft. A
mechanical failure of the propeller could cause a forced
landing or create vibrations su󰀩ciently severe to damage
the aircraft, possibly causing it to become uncontrollable.
Propellers are subject to constant vibration stresses
from the engine and airstream, which are added to high
bending and centrifugal stresses.
Before a propeller is certied as being safe to operate
on an airplane, an adequate margin of safety must be
demonstrated. Even though every precaution is taken in
the design and manufacture of a propeller, history has
revealed rare instances of failures, particularly of the
fatigue type.
It is essential that the propeller is properly maintained
according to the recommended service procedures and
a close watch is exercised to detect impending problems
before they become serious. Any grease or oil leakage,
loss of air pressure, unusual vibration, or unusual
operation should be investigated and repaired, as it could
be a warning that something serious is wrong.
WARNING(Rev. 3)

61-00-40
MESSAGE
Page 3
Rev. 5 Apr/23
HARTZELL PROPELLER OWNER'S MANUAL
140
For operators of uncertied or experimental aircraft
an even greater level of vigilance is required in the
maintenance and inspection of the propeller. Experimental
installations often use propeller-engine combinations that
have not been tested and approved. In these cases, the
stress on the propeller and, therefore, its safety margin is
unknown. Failure could be as severe as loss of propeller
or propeller blades and cause loss of propeller control
and/or loss of aircraft control.
Hartzell Propeller Inc. follows FAA regulations for propeller
certication on certicated aircraft. Experimental aircraft
may operate with unapproved engines or propellers or
engine modications to increase horsepower, such as
unapproved crankshaft damper congurations or high
compression pistons. These issues a󰀨ect the vibration
output of the engine and the stress levels on the propeller.
Signicant propeller life reduction and failure are real
possibilities.
Frequent inspections are strongly recommended if
operating with a non-certicated installation; however,
these inspections may not guarantee propeller reliability,
as a failing device may be hidden from the view of the
inspector. Propeller overhaul is strongly recommended to
accomplish periodic internal inspection.
Inspect the propeller/blades in accordance with the
applicable operation/maintenance documents.

61-00-40
MESSAGE
Page 4
Rev. 5 Apr/23
HARTZELL PROPELLER OWNER'S MANUAL
140
(This page is intentionally blank.)

61-00-40
REVISION HIGHLIGHTS
Page 1
Rev. 5 Apr/23
HARTZELL PROPELLER OWNER'S MANUAL
140
Revision 5, dated April 2023, incorporates the following:
Front matter (Cover, Revision Highlights, etc.), has been revised to
match this revision.
Updated the Hartzell Propeller Inc. logo on the cover and revised the
header on all pages.
Minor language/format changes and renumbering are marked with a
revision bar but not listed in this section.
• INSTALLATION AND REMOVAL
• Added the section "Spinner Adapter Ring Installation
(if applicable)"
• Added Figure 3-2, "Spinner Adapter Ring"
• Added the section "Spinner Dome Installation"
• Added Table 3-4, "Spinner Dome and Spinner Cap Mounting
Hardware"
• TESTING AND TROUBLESHOOTING
• Revised the section, "Hunting and Surging (Governing
Propeller Only)"
• Revised the section, "Engine Speed Varies with Flight
Altitude (or Airspeed)"
• INSPECTION AND CHECK
• Revised Figure 5-2, "Blade Play"
• Revised the section, "Loose Blades"
• MAINTENANCE PRACTICES
• Revised the section "A-38( )Thrust Bearing Lubrication"
REVISION 5HIGHLIGHTS

Page 2
Rev. 5 Apr/23
REVISION HIGHLIGHTS 61-00-40
HARTZELL PROPELLER OWNER'S MANUAL
140
(This page is intentionally blank.)

61-00-40
REVISION HIGHLIGHTS
Page 3
Rev. 5 Apr/23
HARTZELL PROPELLER OWNER'S MANUAL
140
REVISION 5HIGHLIGHTS
1. Introduction
A. General
(1) This is a list of current revisions that have been issued
against this manual. Please compare it to the RECORD
OF REVISIONS page to make sure that all revisions
have been added to the manual.
B. Components
(1) Revision No. indicates the revisions incorporated in this
manual.
(2) Issue Date is the date of the revision.
(3) Comments indicates the level of the revision.
(a) New Issue is a new manual distribution. The manual
is distributed in its entirety. All the page revision
dates are the same and no change bars are used.
(b) Reissue is a revision to an existing manual that
includes major content and/or major format
changes. The manual is distributed in its entirety. All
the page revision dates are the same and no change
bars are used.
(c) Major Revision is a revision to an existing manual
that includes major content or minor content
changes over a large portion of the manual. The
manual is distributed in its entirety. All the page
revision dates are the same, but change bars are
used to indicate the changes incorporated in the
latest revision of the manual.
(d) Minor Revision is a revision to an existing manual
that includes minor content changes to the
manual. Only the revised pages of the manual are
distributed. Each page retains the date and the
change bars associated with the last revision to that
page.

Page 4
Rev. 5 Apr/23
REVISION HIGHLIGHTS 61-00-40
HARTZELL PROPELLER OWNER'S MANUAL
140
Revision No. Issue Date Comments
Original Nov/02 New Issue
Revision 1 May/11 Minor Revision
Revision 2 Jun/12 Minor Revision
Revision 3 Feb/14 Minor Revision
Revision 4 Mar/21 Major Revision
Revision 5 Apr/23 Major Revision

Page 1
Rev. 5 Apr/23
61-00-40
RECORD OF REVISIONS
RECORD OF REVISIONS
This is a record of revisions inserted into this manual.
Revision 5 includes all prior revisions.
HARTZELL PROPELLER OWNER'S MANUAL
140
Revision Number Issue Date Date Inserted Inserted By
5 Apr/23 Apr/23 HPI

Page 2
Rev. 5 Apr/23
61-00-40
RECORD OF REVISIONS
(This page is intentionally blank.)
HARTZELL PROPELLER OWNER'S MANUAL
140

RECORD OF TEMPORARY REVISIONS 61-00-40 Page 1
Rev. 5 Apr/23
HARTZELL PROPELLER OWNER'S MANUAL
140
RECORD OF TEMPORARY REVISIONS
TR
Issue
Date
Date
Inserted
Inserted
By
Date
Removed
Removed
By
TR-001 Nov/03 Nov/03 HPI May/11 HPI
TR-002 Feb/06 Feb/06 HPI May/11 HPI

Page 2
Rev. 5 Apr/23
RECORD OF TEMPORARY REVISIONS 61-00-40
HARTZELL PROPELLER OWNER'S MANUAL
140
(This page is intentionally blank.)

61-00-40
SERVICE DOCUMENTS LIST
Page 1
Rev. 5 Apr/23
SERVICE DOCUMENTS LIST
CAUTION 1: DO NOT USE OBSOLETE OR OUTDATED
INFORMATION. PERFORM ALL INSPECTIONS
OR WORK IN ACCORDANCE WITH THE MOST
RECENT REVISION OF A SERVICE DOCUMENT.
INFORMATION CONTAINED IN A SERVICE
DOCUMENT MAY BE SIGNIFICANTLY CHANGED
FROM EARLIER REVISIONS. FAILURE TO
COMPLY WITH INFORMATION CONTAINED
IN A SERVICE DOCUMENT OR THE USE OF
OBSOLETE INFORMATION MAY CREATE AN
UNSAFE CONDITION THAT MAY RESULT IN
DEATH, SERIOUS BODILY INJURY, AND/OR
SUBSTANTIAL PROPERTY DAMAGE.
CAUTION 2: THE INFORMATION FOR THE DOCUMENTS
LISTED INDICATES THE REVISION LEVEL AND
DATE AT THE TIME THAT THE DOCUMENT WAS
INITIALLY INCORPORATED INTO THIS MANUAL.
INFORMATION CONTAINED IN A SERVICE
DOCUMENT MAY BE SIGNIFICANTLY CHANGED
FROM EARLIER REVISIONS. REFER TO THE
APPLICABLE SERVICE DOCUMENT INDEX FOR
THE MOST RECENT REVISION LEVEL OF THE
SERVICE DOCUMENT.
HARTZELL PROPELLER OWNER'S MANUAL
140
Service Document Number Incorporation Rev/Date
HC-SB-61-241 Original, Nov/02
HC-SL-61-48A, Rev. 1 Rev. 1, May/11
SB 82 (June 2, 1965) Rev. 1, May/11
HC-SL-61-320 Rev. 2, Jun/12
HC-SL-61-324 Rev. 2, Jun/12
HC-SL-61-185 Rev. 4, Mar/21
HC-SL-61-364 Rev. 4, Mar/21
HC-SL-61-366 Rev. 4, Mar/21

Page 2
Rev. 5 Apr/23
SERVICE DOCUMENTS LIST 61-00-40
(This page is intentionally blank.)
HARTZELL PROPELLER OWNER'S MANUAL
140

Page 1
Rev. 5 Apr/23
61-00-40
AIRWORTHINESS LIMITATIONS
HARTZELL PROPELLER OWNER'S MANUAL
140
AIRWORTHINESS LIMITATIONS
Rev.
No. Description of Revision
1Relocated Airworthiness Limitations pages from Manual 100E
The Airworthiness Limitations section is FAA approved and species
maintenance required under 14 CFR §§ 43.16 and 91.403 of the
Federal Aviation Regulations unless an alternative program has
been FAA approved.
FAA APPROVED
by: date:
Manager, Chicago Aircraft Certication
O󰀩ce,
ACE-115C
Federal Aviation Administration

Page 2
Rev. 5 Apr/23
61-00-40
AIRWORTHINESS LIMITATIONS
HARTZELL PROPELLER OWNER'S MANUAL
140
AIRWORTHINESS LIMITATIONS
1. The FAA establishes specic life limits for certain component
parts as well as the entire propeller. Such limits require
replacement of the identied parts after a specied number of
hours of use.
2. The following data summarizes all current information concerning
Hartzell life limited parts, as related to propeller models
a󰀨ected by this manual. These parts are not life limited on other
installations; however, time accumulated toward life limit accrues
when rst operated on aircraft/engine/propeller combinations
listed and continues regardless of subsequent installations (that
may or may not be life limited).
A. Propeller models a󰀨ected by this manual currently do not
have any life limited parts.
B. There are no new (or additional) Airworthiness Limitations
associated with this equipment and/or installation.
FAA APPROVED
by: date:
Manager, Chicago Aircraft Certication
O󰀩ce,
ACE-115C
Federal Aviation Administration

Page 1
Rev. 5 Apr/23
LIST OF EFFECTIVE PAGES
Chapter Page Revision Date
LIST OF EFFECTIVE PAGES 61-00-40
HARTZELL PROPELLER OWNER'S MANUAL
140
Cover/Inside Cover Cover/Inside Cover Rev. 5 Apr/23
Message 1 thru 4 Rev. 5 Apr/23
Revision Highlights 1 thru 4 Rev. 5 Apr/23
Record of Revisions 1 and 2 Rev. 5 Apr/23
Record of Temporary Revisions 1 and 2 Rev. 5 Apr/23
Service Documents List 1 and 2 Rev. 5 Apr/23
Airworthiness Limitations 1 and 2 Rev. 5 Apr/23
List of E󰀨ective Pages 1 and 2 Rev. 5 Apr/23
Table of Contents 1 and 2 Rev. 5 Apr/23
Introduction 1-1 thru 1-32 Rev. 5 Apr/23
Description and Operation 2-1 thru 2-26 Rev. 5 Apr/23
Installation and Removal 3-1 thru 3-82 Rev. 5 Apr/23
Testing and Troubleshooting 4-1 thru 4-12 Rev. 5 Apr/23
Inspection and Check 5-1 thru 5-24 Rev. 5 Apr/23
Maintenance Practices 6-1 thru 6-32 Rev. 5 Apr/23
Anti-ice and De-ice Systems 7-1 and 7-2 Rev. 5 Apr/23
Records 8-1 thru 8-4 Rev. 5 Apr/23

Page 2
Rev. 5 Apr/23
LIST OF EFFECTIVE PAGES 61-00-40
HARTZELL PROPELLER OWNER'S MANUAL
140
(This page is intentionally blank.)
