Hartzell HC-Y-1 Series User manual

Manual No. 115N
61-00-15
Revision 24
December 2020
Propeller Owner's Manual
and Logbook
“Compact” Models with Aluminum Blades
Constant Speed, Non-Counterweighted
( )HC-( )( )Y( )-1( )
Constant Speed, Counterweighted
( )HC-( )( )Y( )-4( )
Constant Speed and Feathering
( )HC-( )( )Y( )-2( )
Constant Speed and Feathering, Turbine
( )HC-( )( )Y( )-5( )
Hartzell Propeller Inc.
One Propeller Place
Piqua, OH 45356-2634 U.S.A.
Ph: 937-778-4200 (Hartzell Propeller Inc.)
Ph: 937-778-4379 (Product Support)
Product Support Fax: [phone]

Propeller Owner's Manual
115N
61-00-15
COVER
Inside Cover
Rev. 24 Dec/20
© 1999, 2000, 2002, 2003, 2004, 2005, 2006, 2009, 2012, 2013, 2014, 2015, 2016,
2018, 2020 - Hartzell Propeller Inc. - All rights reserved

Page 1
Rev. 24 Dec/20
Propeller Owner's Manual
115N
MESSAGE 61-00-15
As a fellow pilot, I urge you to read this Manual thoroughly. It
contains a wealth of information about your new propeller.
The propeller is among the most reliable components of your
airplane. It is also among the most critical to ight safety. It therefore
deserves the care and maintenance called for in this Manual. Please
give it your attention, especially the section dealing with Inspections
and Checks.
Thank you for choosing a Hartzell propeller. Properly maintained it
will give you many years of reliable service.
Jim Brown
Chairman, Hartzell Propeller Inc.

Page 2
Rev. 24 Dec/20
MESSAGE 61-00-15
Propeller Owner's Manual
115N
People who y should recognize that various types of
risks are involved; and they should take all precautions to
minimize them, since they cannot be eliminated entirely.
The propeller is a vital component of the aircraft. A
mechanical failure of the propeller could cause a forced
landing or create vibrations su󰀩ciently severe to damage
the aircraft, possibly causing it to become uncontrollable.
Propellers are subject to constant vibration stresses from
the engine and airstream, which are added to high bending
and centrifugal stresses.
Before a propeller is certied as being safe to operate
on an airplane, an adequate margin of safety must be
demonstrated. Even though every precaution is taken in the
design and manufacture of a propeller, history has revealed
rare instances of failures, particularly of the fatigue type.
It is essential that the propeller is properly maintained
according to the recommended service procedures and
a close watch is exercised to detect impending problems
before they become serious. Any grease or oil leakage,
loss of air pressure, unusual vibration, or unusual operation
should be investigated and repaired, as it could be a
warning that something serious is wrong.
WARNING(Rev. 2)

Page 3
Rev. 24 Dec/20
Propeller Owner's Manual
115N
MESSAGE 61-00-15
For operators of uncertied or experimental aircraft
an even greater level of vigilance is required in the
maintenance and inspection of the propeller. Experimental
installations often use propeller-engine combinations that
have not been tested and approved. In these cases, the
stress on the propeller and, therefore, its safety margin is
unknown. Failure could be as severe as loss of propeller
or propeller blades and cause loss of propeller control
and/or loss of aircraft control.
Hartzell Propeller Inc. follows FAA regulations for propeller
certication on certicated aircraft. Experimental aircraft
may operate with unapproved engines or propellers or
engine modications to increase horsepower, such as
unapproved crankshaft damper congurations or high
compression pistons. These issues a󰀨ect the vibration
output of the engine and the stress levels on the propeller.
Signicant propeller life reduction and failure are real
possibilities.
Frequent inspections are strongly recommended if
operating with a non-certicated installation; however,
these inspections may not guarantee propeller reliability,
as a failing device may be hidden from the view of the
inspector. Propeller overhaul is strongly recommended to
accomplish periodic internal inspection.
Inspect the propeller/blades in accordance with the
applicable operation/maintenance documents.

Page 4
Rev. 24 Dec/20
MESSAGE 61-00-15
Propeller Owner's Manual
115N
(This page is intentionally blank.)

Propeller Owner's Manual
115N
Page 1
Rev. 24 Dec/20
REVISION HIGHLIGHTS 61-00-15
REVISION 24 HIGHLIGHTS
Revision 24, dated December 2020, is issued in its entirety.

Page 2
Rev. 24 Dec/20
REVISION HIGHLIGHTS 61-00-15
Propeller Owner's Manual
115N
REVISIONS 24 HIGHLIGHTS
1. Introduction
A. General
(1) This is a list of current revisions that have been issued
against this manual. Please compare it to the RECORD
OF REVISIONS page to make sure that all revisions have
been added to the manual.
B. Components
(1) Revision No. indicates the revisions incorporated in this
manual.
(2) Issue Date is the date of the revision.
(3) Comments indicates the level of the revision.
(a) New Issue is a new manual distribution. The manual
is distributed in its entirety. All the page revision dates
are the same and no change bars are used.
(b) Reissue is a revision to an existing manual that
includes major content and/or major format changes.
The manual is distributed in its entirety. All the page
revision dates are the same and no change bars are
used.
(c) Major Revision is a revision to an existing manual
that includes major content or minor content
changes over a large portion of the manual. The
manual is distributed in its entirety. All the page
revision dates are the same, but change bars are
used to indicate the changes incorporated in the
latest revision of the manual.
(d) Minor Revision is a revision to an existing manual
that includes minor content changes to the
manual. Only the revised pages of the manual are
distributed. Each page retains the date and the
change bars associated with the last revision to that
page.

Propeller Owner's Manual
115N
Page 3
Rev. 24 Dec/20
REVISION HIGHLIGHTS 61-00-15
Revision No. Issue Date Comments
Rev. 5 Jan/99 Major Revision
Rev. 6 Sep/00 Minor Revision
Rev. 7 Oct/02 Major Revision
Rev. 8 Jun/03 Minor Revision
Rev. 9 Aug/03 Minor Revision
Rev. 10 Nov/03 Minor Revision
Rev. 11 Dec/04 Minor Revision
Rev. 12 Apr/05 Minor Revision
Rev. 13 Aug/06 Minor Revision
Rev. 14 Jan/09 Minor Revision
Rev. 15 Jul/09 Minor Revision
Rev. 16 Oct/09 Minor Revision
Rev. 17 Jul/12 Minor Revision
Rev. 18 Feb/13 Minor Revision
Rev. 19 Nov/13 Minor Revision
Rev. 20 Mar/14 Minor Revision
Rev. 21 Mar/15 Minor Revision
Rev. 22 Jul/16 Minor Revision
Rev. 23 Feb/18 Minor Revision
Rev. 24 Dec/20 Major Revision

Page 4
Rev. 24 Dec/20
REVISION HIGHLIGHTS 61-00-15
Propeller Owner's Manual
115N
(This page is intentionally blank.)

RECORD OF REVISIONS
Rev. No. Issue Date Date Inserted Inserted By
Propeller Owner's Manual
115N
Page 1
Rev. 24 Dec/20
RECORD OF REVISIONS 61-00-15
7 Oct/02 Oct/02 HPI
8 Jun/03 Jun/03 HPI
9 Jul/03 Jul/03 HPI
10 Nov/03 Nov/03 HPI
11 Dec/04 Dec/04 HPI
12 Apr/05 Apr/05 HPI
13 Aug/06 Aug/06 HPI
14 Jan/09 Jan/09 HPI
15 Jul/09 Aug/09 HPI
16 Oct/09 Oct/09 HPI
17 Jul/12 Jul/12 HPI
18 Feb/13 Feb/13 HPI
19 Nov/13 Nov/13 HPI
20 Mar/14 Mar/14 HPI
21 Mar/15 Mar/15 HPI
22 Jul/16 Jul/16 HPI
23 Feb/18 Feb/18 HPI
24 Dec/20 Dec/20 HPI

Page 2
Rev. 24 Dec/20
RECORD OF REVISIONS 61-00-15
RECORD OF REVISIONS
Rev. No. Issue Date Date Inserted Inserted By
Propeller Owner's Manual
115N

Page 1
Rev. 24 Dec/20
RECORD OF TEMPORARY REVISIONS
TR Issue Date Inserted Date Removed
No. Date Inserted By Removed By
Propeller Owner's Manual
115N
RECORD OF TEMPORARY REVISIONS 61-00-15

Page 2
Rev. 24 Dec/20
RECORD OF TEMPORARY REVISIONS 61-00-15
RECORD OF TEMPORARY REVISIONS
TR Issue Date Inserted Date Removed
No. Date Inserted By Removed By
Propeller Owner's Manual
115N

Page 1
Rev. 24 Dec/20
SERVICE DOCUMENTS LIST 61-00-15
Propeller Owner's Manual
115N
SERVICE DOCUMENTS LIST
CAUTION 1: DO NOT USE OBSOLETE OR OUTDATED
INFORMATION. PERFORM ALL INSPECTIONS
OR WORK IN ACCORDANCE WITH THE MOST
RECENT REVISION OF A SERVICE DOCUMENT.
INFORMATION CONTAINED IN A SERVICE
DOCUMENT MAY BE SIGNIFICANTLY CHANGED
FROM EARLIER REVISIONS. FAILURE TO
COMPLY WITH INFORMATION CONTAINED
IN A SERVICE DOCUMENT OR THE USE OF
OBSOLETE INFORMATION MAY CREATE AN
UNSAFE CONDITION THAT MAY RESULT IN
DEATH, SERIOUS BODILY INJURY, AND/OR
SUBSTANTIAL PROPERTY DAMAGE.
CAUTION 2: THE INFORMATION FOR THE DOCUMENTS
LISTED INDICATES THE REVISION LEVEL AND
DATE AT THE TIME THAT THE DOCUMENT WAS
INITIALLY INCORPORATED INTO THIS MANUAL.
INFORMATION CONTAINED IN A SERVICE
DOCUMENT MAY BE SIGNIFICANTLY CHANGED
FROM EARLIER REVISIONS. REFER TO THE
APPLICABLE SERVICE DOCUMENT INDEX FOR
THE MOST RECENT REVISION LEVEL OF THE
SERVICE DOCUMENT.
Service Document Number Incorporation Rev/Date
Service Bulletins:
HC-SB-61-286 Rev. 11, Dec/04
HC-SB-61-244 Rev. 17, Jul/12
HC-SB-61-267 Rev. 21, Mar/15
HC-SB-61-325 Rev. 17, Jul/12
HC-SB-61-353 Rev. 21, Mar/15

Page 2
Rev. 24 Dec/20
SERVICE DOCUMENTS LIST 61-00-15
Propeller Owner's Manual
115N
SERVICE DOCUMENTS LIST
Service Document Number Incorporation Rev/Date
Service Letters:
HC-SL-61-185, R3 Rev. 23, Feb/18
HC-SL-61-187, R3 Rev. 21, Mar/15
HC-SL-61-217 Rev. 17, Jul/12
HC-SL-61-230 Rev. 21, Mar/15
HC-SL-61-324 Rev. 17, Jul/12
HC-SL-61-354 Rev. 22, Jul/16
HC-SL-61-364 Rev. 24, Dec/20

Propeller Owner's Manual
115N
Page 1
Rev. 24 Dec/20
AIRWORTHINESS LIMITATIONS 61-00-15
FAA APPROVED
by: ______________________________ date: ____________
AIRWORTHINESS LIMITATIONS
The Airworthiness Limitations section is FAA approved and species
maintenance required under 14 CFR § 43.16 and 91.403 of the
Federal Aviation Regulations unless an alternative program has
been FAA approved.
Manager, Chicago Aircraft Certication
O󰀩ce,
ACE-115C
Federal Aviation Administration
Rev.
No. Description of Revision
15
Adds airworthiness limitation information from Hartzell
Overhaul Manual 113B (61-10-13) and Hartzell Overhaul
Manual 117D (61-10-17)
16 Added cylinder life limits for propeller model
HC-C(2,3)YR-4(B,C)F/FC8477-4R and corrected the engine
model number for Aviatt Pitts S-2S,S-2B
19 Added blade life limits for propeller models
HC-(C,F,M)2YR-1BFP/F7499 and HC-C2YR-1BF/F7666A-2
22 Corrected the engine model number for propeller model
HC-(C,F,M)2YR-1BFP/F7499

Page 2
Rev. 24 Dec/20
AIRWORTHINESS LIMITATIONS 61-00-15
Propeller Owner's Manual
115N
AIRWORTHINESS LIMITATIONS
1. Replacement Time (Life Limits)
A. The FAA establishes specic life limits for certain component
parts, as well as the entire propeller. Such limits require
replacement of the identied parts after a specied number
of hours of use.
B. The following data summarizes all current information
concerning Hartzell life limited parts as related to propeller
models a󰀨ected by this manual. These parts are not life
limited on other installations; however, time accumulated
toward life limit accrues when rst operated on aircraft/
engine/propeller combinations listed, and continues
regardless of subsequent installations (which may or
may not be life limited).
FAA APPROVED
by: ______________________________ date: ____________
Manager, Chicago Aircraft Certication
O󰀩ce,
ACE-115C
Federal Aviation Administration

Propeller Owner's Manual
115N
Page 3
Rev. 24 Dec/20
AIRWORTHINESS LIMITATIONS 61-00-15
AIRWORTHINESS LIMITATIONS
(1) The following list species life limits for blades only.
Associated hub parts are not a󰀨ected. Blade models
shown are life limited only on the specied applications.
Aircraft/Engine/Propeller Blade Life Limit
Aircraft: Aviat Pitts S-2S
Engine: Lycoming AEIO-540-D4A5
Propeller: HC-C2YR-4CF/FC8477A-4
2,000 hours
Aircraft: Aviat Pitts S-2B
Engine: Lycoming AEIO-540-D4A5
Propeller: HC-C2YR-4CF/FC8477A-4
2,000 hours
Aircraft: SOCATA TB-30
Engine: Lycoming AEIO-540-L1B5D
Propeller: HC-C2YR-4CF/FC8475-6
4,000 hours
Aircraft: Twin Commander Aircraft
Models 500(B,S,U) as modied
by Merlyn Products, Inc.
Engine: Lycoming Models TIO-540-J2B
and -J2BD
Propeller: HC-C4YR-2/FC6660(K)
10,500 hours
Aircraft: Aerostar aircraft Models PA60-601(P), 602P
as modied by Machen
Engine: Lycoming (T)IO-540Series Models
Propeller: HC-C4YR-2(L)/F(J)C6660(B,K)
10,500 hours
FAA APPROVED
by: ______________________________ date: ____________
Manager, Chicago Aircraft Certication
O󰀩ce,
ACE-115C
Federal Aviation Administration

Page 4
Rev. 24 Dec/20
AIRWORTHINESS LIMITATIONS 61-00-15
Propeller Owner's Manual
115N
Propeller/Engine Blade Life Limit
Propeller: HC-(C,F,M)2YR-1BFP/F7499
Engine: Engine Components, Inc. (ECI)
(I)OX-360-( )
8.5:1 to 10.2:1 Compression Ratio
Max Diameter 74 inches
Min. Diameter 72 inches
Operating
Restriction: “Do not operate above
24” manifold pressure below 2450 RPM”
10,000 hours
Propeller: HC-(C,F,M)2YR-1BFP/F7499
Engine: Engine Components, Inc. (ECI)
(I)OX-370-( )
8.5:1 Compression Ratio
Max Diameter 74 inches
Min. Diameter 72 inches
Operating
Restriction: “Do not operate above
24” manifold pressure below 2450 RPM”
10,000 hours
FAA APPROVED
by: ______________________________ date: ____________
Manager, Chicago Aircraft Certication
O󰀩ce,
ACE-115C
Federal Aviation Administration
AIRWORTHINESS LIMITATIONS
(2) The following list species life limits for blades only.
Associated hub parts are not a󰀨ected. Blade models
shown are life limited only on the specied engine.
