Hatteras GT54 User manual

Quick Reference Guide
Quick Reference GuideQuick Reference Guide
Quick Reference Guide

GT54
4.51 meters14' 8"Height to Top of Open Flybridge
34,019 kilos75,000 poundsDisplacement
359 liters95 gallonsHolding Capacity
4,542 liters1,200 gallonsFuel Capacity
681 liters180 gallonsFreshwater Capacity
1.28 meters4' 2"Draft
5.26 meters17' 3"Beam
14.53 meters47' 7"Waterline Length
16.18 meters53' 10"Length Overall
Engine Options
–Twin CAT C18A Diesel Engines 1135 BHP
–Twin CAT C32A Diesel Engines 1600 BHP
Key Selling Features
–True Carolina Custom Styling
–Incredible Offshore Performance
•Both Speed and Handling
–Tournament Style Cockpit
–270 Degree Visibility
–Island Style Galley
–Side by Side Guest Stateroom Layout

Hatteras GT 54 I Arrangements
18 I Hatteras GT54
Standard Flybridge
Layout
Standard 3-Stateroom /
2-Head Layout
Standard Layout with
Optional Bow V-Berth

Fuel consumption is based on (2) engines at any given RPM. Speed and ranges are estimates based on
engineering calculations. Range is based on 95% of standard fuel capacity. Actual performance will vary
and be affected by water and weather conditions, load and conditions of boat, engines, and propellers.
Speed will increase as fuel is consumed. All data is illustrative and is not warranted.
GT54 VESSEL SPECIFICATIONS
Standard Fuel: 1,200 Gallons
Displacement: 75,000 Lbs (Full Load)
PERFORMANCE DATA
Engines: (2) C18 ACERT CATERPILLAR DIESELS Rated @ 1135 BHP @ 2300 RPM’s
2300 34-36 120 333 9.5
2100 30-32 90 393 12.7
2000 28-30 81 408 14.1
1800 24-26 62 460 18.4
RPM HOURS @ SPEED
RANGE
(NAUTICAL MILES)
FUEL CONS .
(ENGINES ONLY)
SPEED
(KNOTS)
Engines: (2) C32 ACERT CATERPILLAR DIESELS Rated @ 1600 BHP @ 2300 RPM’s
2300 40-42 170 275 6.7
2100 37-39 135 321 8.4
2000 35-37 120 342 9.5
1800 32-34 100 376 11.4
RPM HOURS @ SPEED
RANGE
(NAUTICAL MILES)
FUEL CONS .
(ENGINES ONLY)
SPEED
(KNOTS)

GT54 (Options)
Packaged Items
–Full Teak Package -Includes Salon Entry Door, Bow Deck Toe Rail, Flybridge Teak
Accent Strip, Flybridge Teak Helm Pod, And Cockpit Package (Covering Boards,
Curved Coaming Boards, Mezzanine Deck, and Cockpit Sole)
–Cockpit Teak Package -Covering Boards, Curved Coaming Boards, Mezzanine
Deck, And Cockpit Sole
Cockpit
–Starboard In-Deck Refrigerated Fishbox
–Circulating Livewellin Fishbox(Port)
–Wing Station
–Wing Board Rod Holders
–Coaming Lights
–Lift Up Coaming Gate
–Swim Platform with ReboardingLadder
–Underwater Lights
–Chipped Ice Machine
–Handheld Shower
–Air Conditioning with Blowers at Overhang
Open Flybridge
–Air Conditioning Blowers
Interior
–PlexiMirrored Ceiling in Head(s)
–Pneumatic Sliding Salon Door
–Salon Privacy Blinds
–Overhead Lockers in Bow Stateroom
–Double Berth Port And Single Berth Starboard in Bow Stateroom
–Rod Storage Locker in Starboard Stateroom
–19 inch LCD with DVD/Stereo in Bow or Starboard Stateroom
–HMC System 3 Mattress Upgrade
Deck / Exterior
–Colored Hull, Various Colors
–Boot Stripe Paint, Various Colors
–Port and Starboard Bow Deck Hatches
–Additional Outlet for the Bow Deck Freshwater Wash Down

GT54 (Options)
Teak
–Teak Curved Coaming Boards with Natural Finish
–Teak Cockpit Sole with Natural Finish
–Teak Covering Boards with Natural Finish
–Teak Mezzanine Deck
–Teak Salon Entry Door
–Teak Toe Rail
–Teak Helm Pod
–Teak Flybridge Accent Strip
Mechanical / Electrical
–Hydraulic Bow Thruster System (8 Inch, 16 HP)
–Electric Bow Thruster System (8 Inch)
–Fiberglass Pulpit with Anchor Chute And Windlass, 1700 Pound, Rope-Chain, with
Deck Mount Control Switches
–Additional Generator (9 KW)
–1400 GPD Watermaker
–Back-Up Sea Water Pump for Air Conditioning System
–Freshwater AC Back-Up Pump
–Prop Removal and Installation Tool
–Wiring and Thru Hulls for Future Installation of the Following Options: Windlass ,
Chipped Ice Machine or Watermaker
–Weatherproof 120V Receptacle
–Water Delivery Kit
–Electrical System -Full 50 HZ 220V
–Electrical System -50/60 HZ
–Air Conditioning Upgrade for Mideast Region
–CE Certification
Tower / Electronics
–Custom Electronics Package by HST
–Custom Tower by Pipewelders

GT54
FUEL TANK
1,200 GALLONS
WATER TANK
180 GALLONS
HOLDING TANK
95 GALLONS

GT60
4.39 meters14' 5”Height to Top of Open Flybridge
946 liters250 gallonsOptional Fuel Capacity
5.26 meters17' 3”Height to Top of Enclosed Flybridge
40,597 kilos89,500 poundsDisplacement
378 liters100 gallonsHolding Capacity
5,678 liters1,500 gallonsFuel Capacity
757 liters200 gallonsFreshwater Capacity
1.44 meters4' 9"Draft
5.78 meters19' 0"Beam
15.62 meters51' 11"Waterline Length
18.20 meters59' 10"Length Overall
Engine Options
–Twin CAT C32A Diesel Engines 1600 BHP
–Twin CAT C32A Diesel Engines 1800 BHP
–Twin CAT C32A Diesel Engines 1900 BHP
Key Selling Features
–True Carolina Custom Styling
–Incredible Offshore Performance
•Both Speed and Handling
–Tournament Sized Cockpit
•Large Mezzanine
•Gaff Storage
–Booth Style Dinette
–Optional 4th Stateroom
–Additional Fuel

Hatteras GT 60 I Arrangements
30 I Hatteras GT60
Optional Flybridge
Layout
Optional Enclosed
Flybridge Layout
Standard Flybridge
Layout
Standard 3-Stateroom /
3-Head Layout
Standard Layout w/
Optional Bow
V-Berth & Bar
Stools
Optional 4-Stateroom /
3-Head Layout
w/ Bar Stools

Fuel consumption is based on (2) engines at any given RPM. Speed and ranges are estimates based on
engineering calculations. Range is based on 95% of standard fuel capacity. Actual performance will vary
and be affected by water and weather conditions, load and conditions of boat, engines, and propellers.
Speed will increase as fuel is consumed. All data is illustrative and is not warranted.
GT60 VESSEL SPECIFICATIONS
Standard Fuel: 1,500 Gallons
Displacement: 89,500 Lbs (Full Load)
PERFORMANCE DATA
Engines: (2) C32 ACERT CATERPILLAR DIESELS Rated @ 1600 BHP @ 2300 RPM’s
2300 36-38 155 340 9.2
2100 32-34 126 377 11.3
2000 30-32 113 391 12.6
1800 26-28 89 432 16.0
RPM HOURS @ SPEED
RANGE
(NAUTICAL MILES)
FUEL CONS .
(ENGINES ONLY)
SPEED
(KNOTS)
Engines: (2) C32 ACERT CATERPILLAR DIESELS Rated @ 1800 BHP @ 2300 RPM’s
2300 39-41 180 317 7.9
2100 35-37 150 342 9.5
2000 33-35 130 373 11.0
1800 29-31 100 428 14.3
RPM HOURS @ SPEED
RANGE
(NAUTICAL MILES)
FUEL CONS .
(ENGINES ONLY)
SPEED
(KNOTS)
Engines: (2) C32 ACERT CATERPILLAR DIESELS Rated @ 1900 BHP @ 2300 RPM’s
2300 40-42 200 292 7.1
2100 36-38 170 310 8.4
2000 34-36 150 333 9.5
1800 30-32 107 413 13.3
RPM HOURS @ SPEED
RANGE
(NAUTICAL MILES)
FUEL CONS .
(ENGINES ONLY)
SPEED
(KNOTS)

GT60 (Options)
Packaged Items
–Full Teak Package -Includes Salon Entry Door, Bow Deck Toe Rail, Flybridge Teak Accent Strip,
Flybridge Teak Helm Pod, And Cockpit Package (Covering Boards, Curved Coaming Boards,
Mezzanine Deck, and Cockpit Sole)
–Cockpit Teak Package -Covering Boards, Curved Coaming Boards, Mezzanine Deck, And Cockpit
Sole
Cockpit
–Starboard In-Deck Refrigerated Fishbox
–Circulating Livewellin Fishbox(Port)
–Transom Fishboxor Livewell
–Wing Station
–Wing Board Rod Holders
–Coaming Lights
–Lift Up Coaming Gate
–Swim Platform with ReboardingLadder
–Underwater Lights
–Chipped Ice Machine
– Additional Mezzanine Seat in Lieu of Bait Center
–Handheld Shower
– Air Conditioning with Blowers at Overhang
Open Flybridge
–Peninsula Console and Twin Helmchairs
– Air Conditioning Blowers
–8 Cubic Feet Top Loading Freezer
–Enclosed Flybridge
Enclosed Flybridge
–Mast with Radar Platform
–Pedestal Stool for Aft Control Station
Interior
–Four Stateroom with Three Head Arrangement
–PlexiMirrored Ceiling in Head(s)
–Single Drawer Dishwasher
–Third Unit, UndercounterAppliances
–Salon Bar Stool with Footrests Upgrade (Pair)
–Pneumatic Sliding Salon Door
–Salon Privacy Blinds
–Overhead Lockers in Bow Stateroom
–Double Berth Port And Single Berth Starboard in Bow Stateroom
–Rod Storage Locker in Starboard Stateroom
–19 inch LCD with DVD/Stereo in Bow Stateroom
–15 inch Flip Down LCD TV with DVD/Stereo in 4th or Bunk Stateroom
–HMC System 3 Mattress Upgrade

GT60 (Options)
Deck / Exterior
–Colored Hull, Various Colors
–Boot Stripe Paint, Various Colors
–Port and Starboard Bow Deck Hatches
Teak
–Teak Curved Coaming Boards with Natural Finish
–Teak Cockpit Sole with Natural Finish
–Teak Covering Boards with Natural Finish
–Teak Mezzanine Deck
–Teak Salon Entry Door
–Teak Toe Rail
–Teak Helm Pod
–Teak Flybridge Accent Strip
Mechanical / Electrical
–Auxiliary Fuel Tank (245 Gallon)
–Hydraulic Bow Thruster System (12 Inch, 22 HP)
–Electric Bow Thruster System (12 Inch)
–Fiberglass Pulpit with Anchor Chute And Windlass, 1700 Pound, Rope-Chain, with
Deck Mount Control Switches
–Additional Generator (21.5 KW)
–1400 GPD Watermaker
–Back-Up Sea Water Pump for Air Conditioning System
–Freshwater AC Back-Up Pump
–Prop Removal and Installation Tool
–Wiring and Thru Hulls for Future Installation of the Following Options: Windlass ,
Chipped Ice Machine or Watermaker
–50 Amp Retractable Shorecordin Lieu of Fixed Cord
–Weatherproof 120V Receptacle
–Water Delivery Kit
–Electrical System -Full 50 HZ 220V
–Electrical System -50/60 HZ
–Air Conditioning Upgrade for Mideast Region
–CE Certification
Tower / Electronics
–Custom Electronics Package by HST
–Custom Tower by Pipewelders

GT60
FUEL TANK
1,500 GALLONS
WATER TANK
200 GALLONS
HOLDING TANK
100 GALLONS
FUEL TANK (OPTIONAL)
250 GALLONS

GT63
4.57 meters15' 0"Height to Top of Open Flybridge
5.49 meters18' 0"Height to Top of Enclosed Flybridge
46,266 kilos102,000 poundsDisplacement
568 liters150 gallonsHolding Capacity
7,192 liters1,900 gallonsFuel Capacity
1,022 liters270 gallonsFreshwater Capacity
1.53 meters5' 0"Draft
6.10 meters20' 0"Beam
17.20 meters56' 5"Waterline Length
19.46 meters63' 10"Length Overall
Engine Options
–Twin CAT C32A Diesel Engines 1600 BHP
–Twin CAT C32A Diesel Engines 1800 BHP
–Twin CAT C32A Diesel Engines 1900 BHP
Key Selling Features
–True Carolina Custom Styling
–Incredible Offshore Performance
•Both Speed and Handling
–Tournament Sized Cockpit
•Large Mezzanine
•Gaff Storage
–Standard 4 S/R Layout
–Large & Open Floor Plan –Salon/Galley
–Optional Tackle Room

Hatteras GT 63 I Arrangements
Optional Flybridge
Arrangement
Standard Flybridge
Arrangement
Optional Arrangement
w/ Office, V-Berth Bow
and Stairwell to the
Enclosed Flybridge
Optional Enclosed
Flybridge Arrangement
Standard 4-Stateroom /
3-Head Arrangement
Enclosed Flybridge
w/ Optional Stairwell
to Salon
42 I Hatteras GT63

Fuel consumption is based on (2) engines at any given RPM. Speed and ranges are estimates based on
engineering calculations. Range is based on 95% of standard fuel capacity. Actual performance will vary
and be affected by water and weather conditions, load and conditions of boat, engines, and propellers.
Speed will increase as fuel is consumed. All data is illustrative and is not warranted.
GT63 VESSEL SPECIFICATIONS
Standard Fuel: 1,900 Gallons
Displacement: 102,000 Lbs (Full Load)
PERFORMANCE DATA
Engines: (2) C32 ACERT CATERPILLAR DIESELS Rated @ 1600 BHP @ 2300 RPM’s
2300 35-37 160 406 11.3
2100 31-33 142 407 12.7
2000 29-31 129 420 14.0
1800 25-27 100 469 18.1
RPM HOURS @ SPEED
RANGE
(NAUTICAL MILES)
FUEL CONS .
(ENGINES ONLY)
SPEED
(KNOTS)
Engines: (2) C32 ACERT CATERPILLAR DIESELS Rated @ 1800 BHP @ 2300 RPM’s
2300 38-40 185 381 9.8
2100 34-36 158 400 11.4
2000 32-34 141 422 12.8
1800 28-30 110 476 16.4
RPM HOURS @ SPEED
RANGE
(NAUTICAL MILES)
FUEL CONS .
(ENGINES ONLY)
SPEED
(KNOTS)
Engines: (2) C32 ACERT CATERPILLAR DIESELS Rated @ 1900 BHP @ 2300 RPM’s
2300 39-41 200 361 9.0
2100 35-37 170 382 10.6
2000 33-35 154 399 11.7
1800 29-31 125 433 14.4
RPM HOURS @ SPEED
RANGE
(NAUTICAL MILES)
FUEL CONS .
(ENGINES ONLY)
SPEED
(KNOTS)

GT63 (Options)
Packaged Items
–Full Teak Package -Includes Salon Entry Door, Bow Deck Toe Rail, Flybridge Teak
Accent Strip, Flybridge Teak Helm Pod, And Cockpit Package (Covering Boards,
Curved Coaming Boards, Mezzanine Deck, and Cockpit Sole)
–Cockpit Teak Package -Covering Boards, Curved Coaming Boards, Mezzanine
Deck, And Cockpit Sole
Cockpit
–Starboard In-Deck Refrigerated Fishbox
–Circulating Livewellin Fishbox(Port)
–Wing Station
–Wing Board Rod Holders
–Coaming Lights
–Lift Up Coaming Gate
–Swim Platform with ReboardingLadder
–Underwater Lights
–Chipped Ice Machine
–Additional Seat in Lieu of Bait Center
–Handheld Shower
–Air Conditioning with Blowers at Overhang
Open Flybridge
–Peninsula Console and Twin Helmchairs
–Air Conditioning Blowers
–8 Cubic Feet Top Loading Freezer
Enclosed Flybridge
–Enclosed Flybridge
–Interior Stairwell
–Pedestal Stool for Aft Control Station
Interior
–PlexiMirrored Ceiling in Head(s)
–Single Drawer Dishwasher
–Salon Privacy Blinds
–Overhead Lockers in Bow Stateroom
–Double Berth Port And Single Berth Starboard in Bow Stateroom
–Rod Storage Locker in Starboard Stateroom
–19 inch LCD with DVD/Stereo in Bow Stateroom
–16 inch Flip Down LCD TV with DVD/Stereo in 4th or Bunk Stateroom
–HMC System 3 Mattress Upgrade

GT63 (Options)
Deck / Exterior
–Colored Hull, Various Colors
–Boot Stripe Paint, Various Colors
–Port and Starboard Bow Deck Hatches
Teak
–Teak Curved Coaming Boards with Natural Finish
–Teak Cockpit Sole with Natural Finish
–Teak Covering Boards with Natural Finish
–Teak Mezzanine Deck
–Teak Salon Entry Door
–Teak Toe Rail
–Teak Helm Pod
–Teak Flybridge Accent Strip
Mechanical / Electrical
–Hydraulic Bow Thruster System (12 Inch, 22 HP)
–Electric Bow Thruster System (8 Inch)
–Fiberglass Pulpit with Anchor Chute And Windlass, 1700 Pound, Rope-Chain, with
Deck Mount Control Switches
–Additional Generator (21.5 KW)
–1400 GPD Watermaker
–Back-Up Sea Water Pump for Air Conditioning System
–Freshwater AC Back-Up Pump
–Prop Removal and Installation Tool
–Wiring and Thru Hulls for Future Installation of the Following Options: Windlass ,
Chipped Ice Machine or Watermaker
–Weatherproof 120V Receptacle
–Water Delivery Kit
–Electrical System -Full 50 HZ 220V
–Electrical System -50/60 HZ
–Air Conditioning Upgrade for Mideast Region
–CE Certification
Tower / Electronics
–Custom Electronics Package by HST
–Custom Tower by Pipewelders

GT63
FUEL TANK
1,900 GALLONS
WATER TANK
270 GALLONS
HOLDING TANK
150 GALLONS

68 Convertible
4.60 meters15' 1"Height to Top of Open Flybridge
5.84 meters19' 2"Height to Top of Enclosed Flybridge
63,503 kilos140,000 poundsDisplacement
473 liters125 gallonsHolding Capacity
7,947 liters2,100 gallonsFuel Capacity
1,514 liters400 gallonsFreshwater Capacity
1.60 meters5' 3"Draft
6.57 meters21' 6"Beam
18.22 meters59' 9"Waterline Length
20.89 meters68' 6"Length Overall
Engine Options
–Twin CAT C32A Diesel Engines 1600 BHP
–Twin CAT C32A Diesel Engines 1800 BHP
–Twin CAT C32A Diesel Engines 1900 BHP
–Twin MTU 16V2000 Diesel Engines 2000 BHP
Key Selling Features
–Extremely Popular Model –Built 52 Units
–Incredible Offshore Ride –Solid/Stable
–Long Range Battle Wagon
–Resin Infused Construction
–Improved Performance –Resin Infusion
–Optional Enclosed Bridge
–Huge Cockpit and Mezzanine Area
–Standard 4 S/R 3 Head Layout
–Optional Built In Interior Stairwell
–Large Open Galley –(3) Under Counter Units
–Full Beam Master Stateroom
–Amazingly Spacious Layout
