HAWK-I Security 157SVXIRCB User manual

HAWK-157SVXIRCB
1/3”Color High Resolution Bullet Camera. 36 Infrared
LED’s, Camera sees up to 90 ft away in complete darkness
outdoors! Comes complete with a Auto Iris 2.8mm –12mm
lens. Smart LED’s, which prevent blooming as the object
comes nearer to the camera. 24VAC/12V DC. Controls are
external and on the bottom of the camera, for easy access. On
Screen Display allows flexibility to change different aspects
due to the scenes illumination.
Key Features;
700 Lines of Resolution
2.8mm—12mm lens
Auto Iris
Dual Voltage
Cable through the mounting bracket
Weather and Tamperproof
HAWK-I Security—355 Oser Ave, Hauppauge, NY, 11788 631-656-1056 www.hawkisecurity.com

Image Sensor 1/3”Vertical Double Interline CCD
Resolution 700 TV Lines, High Resolution
Synchronizing System Internal
Video Output 1.0 Vp-p Composite 75 ohms
S/N >52db
Minimum Illumination 0 lux with Infrared on
OSD Controllable Functions;
Shutter 1/60 -1/100,000
White Balance ATW/AWB/AWC –Set/Manual
Back Light Low/Medium/High/Off
Gain Control Off/Low/Medium/High
Mirror Rotate/V-Flip/Mirror/Off
Motion On/Off
Power Supply 12V DC/ 24V AC
Lens 2.8mm—12mm Auto Iris
Weight 1.75 lbs
Dimensions 2 3/4”(W) x 3”(H) x 5 3/4”(L)
HAWK-157SVXIRCB
HAWK-I Security—355 Oser Ave, Hauppauge, NY, 11788 631-656-1056 www.hawkisecurity.com
Zoom & Focus
Adjustment Functions
Second Video
OSD Control
