Hawking WP251 User manual

WP251
Wireless Connectivity for your
Desktop PC
• Connect Anywhere, Anytime
• Fast, Reliable and Secure
• Compliant with IEEE 802.11b Standard
• Supports most network operating systems
• Easy to install and use
• Free tech support
Connect Anywhere, Anytime
A new generation of wireless LAN solutions is now
allowing dynamic mobile work forces the freedom to be
productive from any location within their business or
home. A wireless LAN standard called IEEE 802.11b has
emerged, delivering speeds up to 11 Mbps and the ability
to create wireless LANs that stretch from one end of the
company to another. This WP251 Wireless LAN PCI Card
with high power external antenna is designed to connect
your Desktop computer to a Wireless LAN. It can work
with Ad-Hoc (Peer to Peer) and Infrastructure (Access
Point) Wireless LAN configurations. The WE110P is
compliant with IEEE 802.11b standard and can work with
a multi-vendor Wireless LAN platform.
Fast, Reliable and Secure
The Hawking WP251 Wireless LAN PCI Card delivers
network speeds up to 11Mbps…. five times faster than
previous wireless LAN products. Using dynamic rate
shifting to create a reliable connection, each wireless
adapter supports up to 32 simultaneous users at a
distance of up to 1000ft (300m) for outdoor use and 328ft
(100m) for indoor use. It also features Wires Equivalent
Privacy (WEP) -compliant data encryption using
encryption keys, MAC Address Control and user
authentication to ensure a fast, reliable and secure
network connection.
Easy to Install, Use and Manage
The Hawking WP251 PCI Card can be easily installed on
your Windows 98/2000, ME, and XP computers. The easy
to use Wireless Utility software allows you to configure
and manage your Wireless network easily.
Package Contents:
• One Wireless PCI Card
• One CD Driver & Utility
• Easy to follows owner's manual

Systems Requirement:
• IEEE 802.11b Wireless LAN
• PCI Slot
• Windows 98/2000/ME/XP
• CD ROM Driver
Network Operations
Systems Support:
Microsoft Windows
98/2000/ME/XP and more!
Ready, Network & Go!
It's easy to install, it's easy to use!
Everyone can do it.
Step 1 –
Insert WP251 PCI Card
Insert WP251 into one of you
computer’s available PCI Slot.
Step 2 –
Install Driver and Utility
Insert Driver & Utility CD,
Windows 98/2000/ME/XP will
automatically detect it. Follow
the Setup Wizard to install.
Step 3 –
Configure WP251 PCI Card
Click Wireless LAN utility, Set
up your Network ID (SSID) and
WEP security and you are ready
to go.
Specification:
Host Interface: PCI
• IEEE 802.11b WLAN Standard
LAN Speed
• Wireless: 11/5.5/2/1 Mbps Adaptive Data Rate
Security: IEEE WEP 128/64/-bit
Network Management: SNMP, MIB, 802.11
Antenna: External Antenna Diversity System 2dB gain
Power: PCI power, No external power required
Frequency Band: 2.4 ~ 2.4835GHz
Channels:
o11 Channels (US, Canada)
o13 Channels (Europe)
o14 Channels (Japan)
Modulation Technique
• DSSS (Direct Sequence Spread Spectrum)
• 1Mbps DBPSK
• 2Mbps DQPSK
• 5.5Mbps CCK
• 11Mbps CCK
Output Power: Peak +20dBm.
Receiver Sensitivity: –70dBm Min.
TYPICAL OPERATION RANGE*
DATA
RATE
INDOOR RANGE OUTDOOR RANGE
11Mbps 120 ft (37 m) 400 ft (122 m)
5.5 Mbps 200 ft (61 m) 600 ft (183 m)
2 Mbps 240 ft (73 m) 750 ft (228 m)
1 Mbps 300 ft (91 m) 1000 ft (305 m)
Roaming: 802.11b compliant
Dimension:
4.72" x 3.54" x 0.78" (120mm x 90mm x 20mm)
EMI Conformance
FCC part 15 Class B, CE Mark Class B
*The range will vary in different operating environments due to
effects such as building construction
Features Benefits
11Mbps Wireless LAN Fast, Reliable and Easy
Connection
IEEE 802.11b Standard Compatible with Industrial
Standard
External Antenna Increased distance and reception
Supports most network
operating systems
Setup is quick and simple
Wireless Network Diagram:
Ordering Information:
WR254S 11M IEEE802.11b Wireless Router
w/ 4-port Switch + 1 Serial Port Backup
WA300 11M IEEE802.11b Wireless Access Point
WP251 11M IEEE802.11b Wireless PCI Card
WE110P 11M IEEE802.11b Wireless PC Card
WU250 11M IEEE802.11b Wireless USB Adapter
WA739P 11M 3Port Wireless Print Server
CF100W 11M Wireless Compact Flash Adapter
