Haws 3670 Guide

05/23 Models 3670 Page 1 of 6
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [email protected]  website: www.hawsco.com
No. 0510000703 (5)
MODEL 3670
DOG BOWL, STAINLESS STEEL
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS warrants that all of its products are guaranteed against defective material or poor workmanship for
a period of one year from the date of shipment. The foregoing notwithstanding, HAWS warrants certain
specific products or components thereof for an adjusted period. A list of these excepted products and
components and a description of their respective warranty terms may be found here:
www.hawsco.com/warranty. HAWS’liability under this warranty shall be discharged by furnishing without
charge F.O.B. HAWS factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first-class workmanship, provided that a claim is made in
writing to Company within a reasonable period after receipt of the product. Where claims for defects are
made, the defective part or parts shall be delivered to the Company, prepaid, for inspection. HAWS shall
not be liable for the cost of repairs, alterations or replacements, or the labor required to implement them, or
for any expense connected therewith made by the owner or owner’s agents, except upon written authority
from HAWS. HAWS shall not be liable for any damages caused by defective materials or poor
workmanship, except for replacements, as provided above. Buyer agrees that HAWS has made no other
warranties either express or implied in addition to those above stated, except that of title with respect to
any of the products or equipment sold hereunder and that HAWS shall not be liable for general, special,
incidental, or consequential damages claimed to arise under the contract of sale.
Equipment manufactured by HAWS is warranted to function if installation and maintenance instructions
provided are adhered to. The units also must be used for the purpose for which they were intended. Any
HAWS emergency equipment is intended to supplement first-aid treatment. Due to widely varying
conditions, HAWS cannot guarantee that the use of this emergency equipment will prevent serious injury
or the aggravation of existing or prior injuries.
EXCEPT AS EXPRESSLY STATED HEREIN, HAWS HEREBY DISCLAIMS ALL WARRANTIES,
WHETHER EXPRESS OR IMPLIED, ARISING BY LAW OR OTHERWISE, INCLUDING WITHOUT
LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. THIS WARRANTY MAY NOT BE MODIFIED OR EXTENDED WITHOUT THE
WRITTEN CONSENT OF HAWS. REMEDIES AND REPLACEMENTS STATED HEREIN ARE
EXCLUSIVE. IN NO EVENT SHALL HAWS BE LIABLE FOR ANY SPECIAL, PUNITIVE,
CONSEQUENTIAL OR INCIDENTAL DAMAGES TO ANY PERSON INCLUDING BUT NOT LIMITED
TO DAMAGES FOR LOSS OF USE OR PROFITS, SUBSTITUTE PRODUCTS OR COSTS, PROPERTY
DAMAGE, OR OTHER MONETARY LOSS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

05/23 Models 3670 Page 2 of 6
RECOMMENDED TOOLS:
- Measuring Tape
- PVC Pipe Cutter
- PVC Solvent Weld Glue
- PVC Primer
- Plastic Tubing Cutter
- Level
- Adjustable Plier
- 5/32”Pinned Hex Key Wrench (supplied)
- 9/16”Box/Open Combination Wrench, 8”Max Length
- 9/16”Deep Socket
- 3/8”Socket Wrench/Rachet, 8”Max Length
LOCATION OF UNIT: The Model 3670 Dog Bowl Accessory is designed to be used with
Haws Model 36XX Outdoor Bottle Filler/Fountain pedestal. The Dog Bowl can be mounted in
any lower side pedestal opening (except 36XXF series pedestals which have 6477 water filter
mounted on left-hand side of pedestal). When installing this unit, local, state and federal
(including ADA) codes must be adhered to. CAUTION!: This Dog Bowl Accessory is not
freeze resistant! To prevent damage to the unit and a potential flooding hazard, do not install
in locations that have the potential to freeze.
SUPPLY LINE: The minimum recommended line size is 1/2“IPS with 30-90 psi (2-6 ATM)
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Water supply inlet connection is a 3/8“O.D. compression fitting.
Waste outlet is 1-1/2” O.D. tube.
MAINTENANCE: Periodically clean the pushbutton valve strainer. Refer to 5874 Series Valve
Operation and Maintenance Manual for more information.
INSTALLATION PROCEDURE
GENERAL NOTES:
1. For all compression fitting connections, only connect NSF-61 copper or plastic
3/8”outside diameter tubing. The following assembly instructions must be
followed to ensure a watertight connection:
a. Cut tubing square and clean. Deburr if necessary.
b. Place compression nut and ferrule over end of tubing.
c. For plastic tubing (must be ¼” inside diameter), insert supplied tubing
insert into end of tubing.
d. Push tube into the fitting until it bottoms out.
e. Thread nut onto fitting and tighten snugly with 5/8”wrenches.

05/23 Models 3670 Page 3 of 6
For more information about Haws products, see our website: www.hawsco.com
© 2023 Haws®Corporation –All Rights Reserved
HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
Tube Sizes
O.D.
Tolerance
Insertion Depth
3/8”
±.005”
3/4”
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
Insufficient bubbler flow.
1a.
Check that inlet screwdriver stop valve
is wide open.
b.
Verify minimum 30 psi flowing supply
pressure.
c.
Clean inlet strainer. See 5874 Series
Valve Manual.
d.
Adjust valve to increase flow. Use front
adjust screw or see 5874 Series Valve
Manual.

A
2
3
4
1
PARTS BREAKDOWN
NOTES:
1
5874PB, ITEM 2, INCLUDES
VRK5874 CARTRIDGE ASSEMBLY,
ITEM 3, AND PBA7 PUSH BUTTON,
ITEM 4.
2
ENSURE TUBE IS DISCONNECTED
FROM VALVE BODY PRIOR TO
REMOVAL. APPLY A DROP OF
LOCTITE 222MS ON NOZZLE
THREADS PRIOR TO REASSEMBLING
BACK ONTO BUBBLER HEAD.
REATTACH TUBE TO VALVE BODY
DETAIL A
SCALE 1:2
ROTATED INTO VIEW
1
2
REMOVE INSERT
WITH 5/16" HEX SOCKET
(NOT SUPPLIED)
ITEM PART NUMBER DESCRIPTION
1 5703M BUBBLER HEAD
2 5874PB PUSH BUTTON VALVE
3 VRK5874 VALVE REPAIR KIT
4 PBA7 PUSH BUTTON
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT
IMPROVEMENTS MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
APPROVED:
DRAWN:
PART NUMBER
SCALE:
REVISION
MH
05/16/17
5
MODEL 3670 PET BOWL ACCESSORY
1:4
FV
05/31/23
DRAWING TYPE:
SIZE: A
5226
BY:
JC
PARTS BREAKDOWN
DATE:
DATE:
REV. ECN:
5925
CHK'D.:
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
FV
ECN:
WHEN ORDERING PARTS, PLEASE
SPECIFY PART NUMBER
SHEET 1 OF 1
0510000703
© 2023 Haws Corporation - All Rights Reserved.
HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
PAGE 4 OF 6

4X 3/8"-16 FLANGE NUT (PROVIDED) THREADS ONTO BOLT
FROM INSIDE OF PEDESTAL (NOT AS SHOWN)
"LOW" POSITION:
OPENING TOWARD
THE BOTTOM
1-1/2" TEE
4X 3/8"-16 X 1-1/8"
HEX BOLT (SUPPLIED)
4X 1/4"-20 FLAT HEAD
TAMPER RESISTANT
SCREW
(SUPPLIED)
6 1
4
"
159mm
9"
226mm
10"
254mm
10"
254mm
NOTE: STANDARD CONFIGURATION FOR MODEL 3670 ON A PEDESTAL IS
SHOWN. IT IS RECOMMENDED THAT THE ASSEMBLY IS PLACED AT THE
LOWEST OPENING ON THE PEDESTAL. THE MOUNTING PLATE CAN BE
ROTATED SO THE DOG BOWL CAN BE IN A "HIGH" OR "LOW" POSITION.
IT IS RECOMMENDED TO USE THE "LOW" POSITION AS SHOWN.
NOTES
1. WHEN INSTALLING THIS UNIT, LOCAL, STATE, OR FEDERAL CODES SHOULD BE
ADHERED TO. FOR INSTALLATION HEIGHTS OTHER THAN SHOWN, DIMENSIONS
MARKED (*) MUST BEADJUSTED ACCORDINGLY. INSTALL A TRAP IN THE WASTE
LINE AND A SCREWDRIVER STOPIN THE SUPPLY LINE IF REQUIRED.
2. IF NECESSARY FOR INSTALLATION, BOWL CAN BE REMOVED BY REMOVING
THE SCREW IN THE CENTER OF THE BOWL.
© 2023 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT
IMPROVEMENTS MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
APPROVED:
DRAWN:
PART NUMBER
SCALE:
REVISION
MH
05/16/17
5
1:8
FV
05/31/23
DRAWING TYPE:
SIZE: A
5226
BY:
JC
INSTALLATION
DATE:
DATE:
REV. ECN:
5925
CHK'D.:
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
FV
ECN:
SHEET 1 OF 2
0510000703.D
MODEL 3670 PET BOWL ACCESSORY
PAGE 5 OF 6
PAGE 5 OF 6

BOWL ASSEMBLY
TRIM RING
MOUNTING PLATE
4 COVER PLATE SCREWS
4 MOUNTING BOLTS & NUTS
(ARM TO PEDESTAL)
4 MOUNTING BOLTS AND NUTS
(BOWL TO ARM)
TRAP ADAPTER FITTING,
COMPRESSION NUT, AND
COMPRESSION WASHER
1-1/2" PVC TEE
WASTE BEND
COMPRESSION NUT AND
RED COMPRESSION
WASHER
ARM
BOTTOM COVER
PLATE W/ THREE
BUTTON HEAD SCREWS
(NOT SEEN HERE)
NOTES:
3. WHEN INSTALLING THIS UNIT, LOCAL, STATE,
OR FEDERAL CODES SHOULD BE ADHERED TO.
4. THIS PET ACCESSORY INCLUDES A SLOW DRAIN
DISC UNDER THE STRAINER TO FACILIATE BOWL
FILLING AND IMPROVE EASE OF DRINKING FOR
PETS.
5. MANUALLY CENTER TRIM RING BETWEEN
BOWL AND ARM BEFORE TIGHTENING
BOWL TO ARM MOUNTING BOLTS. TRIM RING
SHOULD BE SLIGHTLY RECESSED ON ALL SIDES.
© 2023 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT
IMPROVEMENTS MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
APPROVED:
DRAWN:
PART NUMBER
SCALE:
REVISION
MH
05/16/17
5
1:8
FV
05/31/23
DRAWING TYPE:
SIZE: A
5226
BY:
JC
INSTALLATION
DATE:
DATE:
REV. ECN:
5925
CHK'D.:
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
FV
ECN:
SHEET 2 OF 2
0510000703.D
MODEL 3670 PET BOWL ACCESSORY
PAGE 6 OF 6
PAGE 6 OF 6
