HBM QuantumX User manual

Operating Manual | Bedienungsanleitung
English Deutsch
/
CANBus

Hottinger Baldwin Messtechnik GmbH
Im Tiefen See 45
D-64239 Darmstadt
Tel. [phone]
Fax [phone]
[email protected]
www.hbm.com
Mat.: 7-2002.4461
DVS: A4461-2.0 HBM: public
03.2017
EHottinger Baldwin Messtechnik GmbH.
Subject to modifications.
All product descriptions are for general information only.
They are not to be understood as a guarantee of quality or
durability.
Änderungen vorbehalten.
Alle Angaben beschreiben unsere Produkte in allgemeiner
Form. Sie stellen keine Beschaffenheits- oder Haltbarkeits
garantie dar.

Operating Manual | Bedienungsanleitung
English Deutsch
/
CANBus
Receive / Transmit

2A4461-2.0 HBM: public CANBus
English
1 Safety instructions 5........................................
2 Markings used 12............................................
2.1 The markings used in this document 12..........................
3 QuantumX / SomatXR documentation 14......................
4 CANbus 15..................................................
5 QuantumX / SomatXR and CAN 16............................
5.1 General information 16........................................
5.2 CAN bus 18..................................................
5.2.1 LEDs status display 20........................................
5.2.2 Receiving CAN messages 22...................................
6 Functional description 23....................................
6.1 Global parameters 23.........................................
6.1.1 Bit rates 23..................................................
6.1.2 CANBus line termination 23....................................
6.1.3 Error handling 24.............................................
6.2 Error events 25...............................................
6.2.1 Detecting transmit and receive path errors 25.....................
6.2.2 LED and error status behavior 25...............................
6.2.3 Possible error causes in CAN mode 26..........................
6.2.3.1 CANbus warning, CANbus error, CANbus OFF 26..................
6.2.3.2 CAN “Receiver Overrun” 26......................................
6.2.3.3 CAN “Transmitter Overrun” 27...................................
6.2.3.4 CAN decoder “Timeout” 27......................................
6.2.3.5 CAN decoder “Loss of Signal” 27.................................
6.2.3.6 Module resources 28...........................................
6.3 State indication by LED 28.....................................
6.3.1 MX840B 28..................................................
6.3.2 MX471B 29..................................................
6.4 CAN decoder: receiving CAN data 31............................

CANBus A4461-2.0 HBM: public 3
6.4.1 Remote frames (RTR) 31......................................
6.4.2 User-defined data type selection 31.............................
6.4.3 Calculation rule data types 32..................................
6.4.4 Floating point scaling 32.......................................
6.4.6 Integer scaling 36.............................................
6.5 CAN encoder (mappable CAN transmit messages) 39.............
6.5.1 Motivation 39.................................................
6.5.2 Signal source definition 39.....................................
6.5.3 Measured value scaling 40.....................................
6.5.4 Data types and bit positions of a measured value 41...............
6.5.5 Transmit data in the event of an error 42.........................
6.5.6 CAN message parameters 43..................................
6.5.6.1 Data length of the CAN message 43..............................
6.5.7 Example of the different signal sources within a single CAN
message 44..................................................
6.5.8 Transmission type 46..........................................
6.5.8.1 Control 47.....................................................
6.5.8.2 Timer 47......................................................
6.5.8.3 SourceChange 47..............................................
6.5.8.4 IsoEvent 48...................................................
6.5.9 Constraints for MX840B 48.....................................
6.6 Data bit numbering systems according to the vector DBC format 49.
6.6.1 Numbering systems used in QuantumX / SomatXR
parameterization 49............................................
6.6.1.1 INTEL Standard format 50.......................................
6.6.1.2 MOTOROLA Forward MSB format 51.............................
6.6.2 Other numbering systems not used in QuantumX / SomatXR
parameterization 52...........................................
6.6.2.1 MOTOROLA Forward LSB format 53.............................
6.6.2.2 MOTOROLA Backward format 54................................
6.6.2.3 INTEL Sequential format 55.....................................
6.6.2.4 MOTOROLA Sequential format 56................................

4A4461-2.0 HBM: public CANBus
7 QuantumX / SomatXR and CCP / XCP-on-CAN 57..............
7.1 Introduction to CCP and XCP 57................................
7.2 MX471B and CAN / XCP-on-CAN 58............................
7.3 Initialization per XML 60.......................................
7.4 Starting and stopping with the "CANECU" control item 60..........
7.5 General Workflow 61..........................................
8 Glossary 71.................................................

Safety instructions
CANBus A4461-2.0 HBM: public 5
1 Safety instructions
Notice
The safety instructions described here also apply to the
power pack NTX001 and the active backplane BPX001
and BPX002.
Appropriate use
A module integrated into the CANbus by the relevant
connector is to be used exclusively for measurement and
test tasks. Use for any purpose other than the above is
deemed to be non-designated use.
To ensure safe operation, the module must only be ope
rated as described in the general operating manual and in
accordance with the information detailed in this document.
It is also essential to comply with the legal and safety re
quirements for the application concerned during use. The
same applies to the use of accessories.
Each time you start up the module, you must first run a
project planning and risk analysis that takes into account
all the safety aspects of automation technology. This par
ticularly concerns personal and machine protection.
Additional safety precautions must be taken in plants
where malfunctions could cause major damage, loss of
data or even personal injury. In the event of a fault, these
precautions establish safe operating conditions.
This can be done, forexample, by mechanical
interlocking, error signaling, etc.

Safety instructions
6A4461-2.0 HBM: public CANBus
Notice
The module must not be connected directly to a power
supply system. The supply voltage must be 10 V … 30 V
(DC).
General dangers of failing to follow the safety
instructions
Every module is a state of the art device and as such is
failsafe. The module may give rise to residual dangers if
it is inappropriately installed and operated by untrained
personnel. Any person instructed to carry out installation,
commissioning, maintenance or repair of the modules
must have read and understood the Operating Manuals
and in particular the technical safety instructions.
The scope of supply and performance of the modules
only covers a small area of measurement technology. In
addition, equipment planners, installers and operators
should plan, implement and respond to the safety
engineering considerations of measurement technology
in such a way as to minimize residual dangers. On-site
regulations must be complied with at all times. There
must be reference to the residual dangers connected
with measurement technology. After making settings and
carrying out activities that are password-protected, you
must make sure that any controls that may be connected
remain in safe condition until the switching performance
of the module has been tested.

Safety instructions
CANBus A4461-2.0 HBM: public 7
Maintenance and cleaning
The modules are maintenance-free.
SBefore cleaning, disconnect all connections.
SClean the housing with a soft, slightly damp (not wet!)
cloth. Never use solvent, as this could damage the
label or the housing.
SWhen cleaning, ensure that no liquid gets into the
module or connections.
Bus connecting and Outputs
Particular attention must be paid to safety when
connecting to the CANbus and when sending CANbus
messages. Ensure that integration alone, status or
control signals cannot initiate any actions that may pose
a danger to persons or the environment.
Product liability
In the following cases, the protection provided for the
device may be adversely affected. Liability for device
functionality then passes to the operator:
SThe device is not used in accordance with the operat
ing manual.
SThe device is used outside the field of application de
scribed in this section.
SThe operator makes unauthorized changes to the
device.
Warning signs and danger symbols
Important instructions for your safety are specifically
identified. It is essential to follow these instructions in
order to prevent accidents and damage to property.

Safety instructions
8A4461-2.0 HBM: public CANBus
Safety instructions are structured as follows:
WARNING
Type of danger
Consequences of non-compliance
Averting the danger
SWarning sign: draws attention to the danger
SSignal word: indicates the severity of the danger
(see table below)
SType of danger: identifies the type or source of the
danger
SConsequences:describes the consequences of non-
compliance
SDefense: indicates how the danger can be avoided/
bypassed.
Danger classes as per ANSI
Warning sign, signal word Meaning
WARNING This marking warns of a potentially dangerous situ
ation in which failure to comply with safety require
ments may result in death or serious physical injury.
CAUTION This marking warns of a potentially dangerous situ
ation in which failure to comply with safety require
ments may result in slight or moderate physical injury.
Note This marking draws your attention to a situation in
which failure to comply with safety requirements may
lead to damage to property.

Safety instructions
CANBus A4461-2.0 HBM: public 9
Working safely
The supply connection, as well as the signal and sensor
leads, must be installed in such a way that
electromagnetic interference does not adversely affect
device functionality (HBM recommendation: "Greenline
shielding design", downloadable from the Internet at
http://www.hbm.com/Greenline).
Automation equipment and devices must be covered
over in such a way that adequate protection or locking
against unintentional actuation is provided (e.g. access
checks, password protection, etc.).
When devices are working in a network, these networks
must be designed in such a way that malfunctions in
individual nodes can be detected and shut down.
Safety precautions must be taken both in terms of
hardware and software, so that a line break or other
interruptions to signal transmission, e.g. via the bus
interfaces, do not cause undefined states or loss of data
in the automation device.
Error messages should only be acknowledged once the
cause of the error is removed and no further danger
exists.
Conversions and modifications
The module must not be modified from the design or
safety engineering point of view except with our express
agreement. Any modification shall exclude all liability on
our part for any resultant damage.
In particular, any repair or soldering work on
motherboards (exchanging components) is prohibited.
When exchanging complete modules, use only original
parts from HBM.

Safety instructions
10 A4461-2.0 HBM: public CANBus
The module is delivered from the factory with a fixed
hardware and software configuration. Changes can only
be made within the possibilities documented in the
manuals.
Qualified personnel
Important
This device is only to be installed and used by qualified
personnel strictly in accordance with the specifications
and with the safety rules and regulations which follow.
Qualified persons means persons entrusted with the
installation, fitting, commissioning and operation of the
product who possess the appropriate qualifications for
their function. This module is only to be installed and
used by qualified personnel, strictly in accordance with
the specifications and the safety rules and regulations.
This includes people who meet at least one of the three
following requirements:
SKnowledge of the safety concepts of automation tech
nology is a requirement and as project personnel, you
must be familiar with these concepts.
SAs automation plant operating personnel, you have
been instructed how to handle the machinery and are
familiar with the operation of the modules and techno
logies described in this documentation.
SAs commissioning engineers or service engineers,
you have successfully completed the training to qual
ify you to repair the automation systems. You are also
authorized to activate, ground and label circuits and
equipment in accordance with safety engineering
standards.

Safety instructions
CANBus A4461-2.0 HBM: public 11
It is also essential to comply with the legal and safety
requirements for the application concerned during use.
The same applies to the use of accessories.

Markings used
12 A4461-2.0 HBM: public CANBus
2 Markings used
catmanis a registered trademark of Hottinger Baldwin
Messtechnik GmbH.
All trademarks and brands used in this document are
trade names and/or trademarks belonging to the respec
tive product or the manufacturer/owner. Hottinger
Baldwin Messtechnik GmbH does not lay claim to any
other than their own trade names/trademarks.
2.1 The markings used in this document
Important instructions for your safety are specifically
identified. It is essential to follow these instructions, in
order to prevent damage.
Symbol Significance
Note This marking draws your attention to a situation in
which failure to comply with safety requirements can
lead to damage to property.
CAUTION This marking warns of a potentially dangerous situ
ation in which failure to comply with safety require
ments may result in slight or moderate physical injury.
Important
This marking draws your attention to important infor
mation about the product or about handling the prod
uct.
Tip
This marking indicates application tips or other infor
mation that is useful to you.
Device -> New Bold text indicates menu items, as well as dialog and
window titles in the user interfaces. Arrows between
menu items indicate the sequence in which the
menus and sub-menus are opened.

Markings used
CANBus A4461-2.0 HBM: public 13
SignificanceSymbol
Bitrate, 500 Bold text in italics indicates inputs and input fields in
the user interfaces.
Emphasize
See…
Italics are used to emphasize and highlight text and
identify references to sections, diagrams, or external
documents and files.

QuantumX / SomatXR documentation
14 A4461-2.0 HBM: public CANBus
3 QuantumX / SomatXR documentation
The QuantumX / SomatXR family documentation con
sists of
Sthe QuantumX / SomatXR operating manual in PDF
format
Sthe data sheets in PDF format
Sthe operating manuals for the CX22B-W data recorder
Sthe operating manual for the EtherCAT® 1) / Ethernet
gateway CX27B in PDF format
Sthe product descriptions for accessories in PDF‐for
mat
Sa comprehensive online help with index and easy
search options which is available after the installation
of a software package (e.g. MX Assistant, cat
man®EASY). Information about module and channel
configuration can also be found here.
These documents can be found
Son the QuantumX / SomatXR system CD supplied
with the device
SAfter installation of the MX Assistant on the hard drive
of your PC, which can be reached through the Win
dows start menu
SUp-to date versions are always available from our In
ternet site at www.hbm.com
1) EtherCAT® is a registered brand and patented technology, licensed by Beckhoff Automation
GmbH, Germany

CANbus
CANBus A4461-2.0 HBM: public 15
4 CANbus
This manual is intended to support you in connecting
your QuantumX or SomatXR system to a CANbus with
the following modules:
- MX471B(-R)
- MX840B(-R)
In the following we will refer to these modules as
MX471B and MX840B and only state the SomatXR
modules in case of significant differences.
When using the CX23-R data recorder there are some
restrictions related to the CANbus options (see CX23-R
manual).
The catmanEASY or MX Assistant software packages
have extensive online Help and can be used to configure
a CAN port.
This manual shows you:
SHow to parameterize a CANbus node
The following documentation is also available:
SGeneral operating manual
SData sheets MX840B or MX471B
SOnline Help in the catmanEASY and MX-Assistant
software

QuantumX / SomatXR and CAN
16 A4461-2.0 HBM: public CANBus
5 QuantumX / SomatXR and CAN
5.1 General information
The MX471B module provides four independent CAN
bus nodes that are all electrically isolated from each
other and power supply. Module MX840B provides an
electrically isolated CANbus node on channel 1.
Connected devices are not directly addressed during
data transmission on a CAN bus. A unique identifier de
notes the contents of a message (e.g. rotational speed or
engine temperature).
The identifier also signifies the priority of the message.
Message = identifier + signal + additional information
Device connected to the bus = node
Each node on the MX471B can be parameterized either
as a receiver or as transmitter (gateway). The online help
that comes with the respective software package
provides detailed information about parameterization.
Notice
To ensure normal operation, the CAN bus needs to be
terminated at both ends, and only there, using appropri
ate termination resistors.
A 120-ohm termination resistor can be individually con
nected in the module by software. Termination is also
required when short cables with low bit rates are used.
Please refer to the data sheet for the relation between bit
rate and maximum bus line length.

QuantumX / SomatXR and CAN
CANBus A4461-2.0 HBM: public 17
The configuration of a node is retained after switching the
modules off and on.
For decoding signals at a rate greater than 2000/s,
please set up signal inputs 1 to 8 on the MX471B. The
signal buffers of these signal inputs have been expanded
accordingly.

QuantumX / SomatXR and CAN
18 A4461-2.0 HBM: public CANBus
5.2 CAN bus
Receiving CAN signals:
- MX471B, MX840B (channel 1)
Transmitting CAN signals:
- MX471B
- MX840B (measurement signals within the module
only)
- The MX Assistant software can generate a DBC file
from the list of all the messages that have been
sent
Receiving CCP or XCPoverCAN signals:
- MX471B only
7
8
CAN High
CAN Low
1
5
6
10
11
15
MX471B
Channel 1
Sub-HD 15-pin
MX840B
7
2
1
5
6
Sub-D 9-pin
9
6
6
CAN-GND
QuantumX
