HDL HDL-MZBOX-A50B.30 User manual

HDL{ HDL-MZBOX-A50B.30}

Notices
Disclaimer
Any changes or modifications made to the module which have not been expressly approved by HDL will void
the product warranty.
The module can only be serviced by HDL trained technicians, the use of outside agencies to service any HDL
product will void the product warranty.
This module must be installed and used in strict accordance to the HDL instructions, as detailed in the relevant
HDL user documentation.
HDL reserves the right to make changes to any and all parts of HDL hardware, software, and this publication at
any time, without any obligation to notify any person or entity of such changes.
Trademarks
HDL, the HDL logo, Buspro, and Buspro wireless are the trademarks of HDL Automation. Any other trademarks,
registered trademarks, or trade names used in this document refer solely to the entities claiming these marks.
This document was created by the HDL Technical Documentation department:
No.86 LianHuaXi Rd. Lifeng Avenue, Panyu District
Guangzhou, China
Tel: [phone] Fax: [phone]

{ HDL-MZBOX-A50B.30} User Manual
Contents
1. Introduction...................................................................................................................................1
1.1 Functionality...........................................................................................................................1
1.2 Parameters..............................................................................................................................1
1.3 Product Description..............................................................................................................3
2. Setup..............................................................................................................................................4
2.1 Connections...........................................................................................................................4
2.2 Maintenance and Warranty...................................................................................................5
3. System Configuration ..................................................................................................................5
3.1 Basic Programming...............................................................................................................5
3.1.1 KNX Setting..................................................................................................................5
3.1.2 Setting..........................................................................................................................9
3.1.3 Control the HomePlay Network Player with DLP Panel.........................................10
3.1.4 Control the HomePlay Network Player with HDL ON.............................................11
3.2 Advanced Programming.....................................................................................................17
3.2.1 Party Mode..................................................................................................................17
3.2.2 Play the Special Song...............................................................................................18
4. Customer Service and Technical Support..................................................................................21

{ HDL-MZBOX-A50B.30} User Manual
1
1. Introduction
The HomePlay network player has been created to stream crystal clear audio to multiple rooms within a building.
Controlled via an IOS / Android app, or a wall mounted HDL user interface, HomePlay allows you to manage the entirety
of your audio collection from a single point, and stream audio directly from your favorite online providers. With the
ability to directly play files from network attached storage devices (NAS), an onboard micro SD card slot, an onboard USB
port, and your connected IOS & Android devices, total audio control has never been easier. Capable of playing MP3,
WMA, AAC, AAC+, ALAC, FLAC, APE, and WAV file formats all of your music is now just a tap or click away.
1.1 Functionality
✓Multi format support
✓High fidelity audio streaming
✓Simultaneous multi source multi room streaming
✓Simultaneous single source multi room streaming
✓Fully compatible with HDL room scenes and sequences
1.2 Parameters
Audio system ：
Power Amplifier Rated output
32W+32W(8Ω/ohms,1kHz, 0.7%)
Speaker Impedance
4-32Ω
Dynamic Range
>87dB
S/N Ratio:
>88 dB
Stereo Separation
>81.5dB (1KHz)
Frequency Response
20Hz to 20KHz (±3dB)
Music Source ：
Online Music Services Supported
Pandora,Spotfy,vTuner,Tidal,Qobuz,Rhapsody,
iHeartRadio and TuneIn, more coming soon.
Music from Local Storage
Tunes music stored locally on IOS device,
music files on Android device or USB storage
NAS
Play from your home network attached
storage, DLNA compliant
USB
USB storage device
Line in
Audio input
Bluetooth Supported
BQB Approval, BT 4.0, Dual-mode(2.1 BR / EDR

{ HDL-MZBOX-A50B.30} User Manual
2
+ Low Energy Controllers), Compatible with
v2.1 + EDR and Bluetooth 4.0 Low Energy
(BLE), Max
Audio Formats Supported
MP3/ WMA/ AAC/ AAC+/ ALAC/ FLAC/
APE/ WAV
Wi-Fi ：
Standard
802.b/g/n
Speed(Max)
150M
Operating Frequency
2.4G
SAR Value
95dB
Sample Rate
44.1Khz
Antenna
1T1R
Antenna gain
3dBi
NETWORKING ：
Wireless Connectivity:
Supports 802.11 a/b/g/n standards
Wired Connectivity:
Single 10/100M RJ-45 jack
Environmental Conditions：
Working temperature
-5℃~40℃
Working relative humidity
Up to 90%
Storage temperature
-20℃~+60℃
Storage relative humidity
Up to 93%
Approved：
CE，RoHS
Product Information ：
Power supply
AC100-240V, 60/50Hz/DC
Input
DC24V @ 3.3A
Dimensions
144mm(184mm with antenna)x112mmx31mm
Weight
1.3Kg
Housing material
Glass , ABS, steel plate
Installation
Desk/wall hanging/DB Box
Protection rating
IP20

{ HDL-MZBOX-A50B.30} User Manual
3
1.3 Product Description
This chapter is designed to detail the way in which the HomePlay(HDL-MZBOX-A50B.30) can be controlled, its
connections, the functionality of specific buttons, and the purpose of additional module attributes.
SN
Model Attributes
Description
1
Power interface
Working voltage:DC12－26V
2
4P5.08 audio output port
Output the audio
3
Wi-Fi Antenna
Receive and send the signal
4
3.5mm audio jack
Input the audio
5
RJ45 port
LAN port
6
WPS button: Connect button.
Press the button, then get in the HDL ON APP input
the WiFi name and password, will connect to the WiFi
7
USB interface
After insert the U disk into HomePlay, can play the
music in it

{ HDL-MZBOX-A50B.30} User Manual
4
2. Setup
2.1 Connections
HomePlay music player have 2 kinds of connections: wired connection and wireless connection. We recommend you to
use wired connection because it is more stable with wired connection.
Wired Connection:
1-Connect the HomePlay network player and the router with RJ45 cable.
2- Connect the phone to the same router which is connected to the HomePlay network player.
3-Configure the HomePlay network player with HDL ON APP.
Wireless Connection:
1-Connect the device running the HDL On app to your router.
2-Open the HDL ON APP on your iOS or Android device, input the Wi-Fi name and password, and click next step.
3-Press the WPS button of the HomePlay network player, then it will connect to the corresponding Wi-Fi automatically.
4-The HomePlay network player will tip you if it can connect to the Wi-Fi successfully.
HomePlay
Speaker

{ HDL-MZBOX-A50B.30} User Manual
5
2.2 Maintenance and Warranty
The HDL (model number) module is designed to be maintenance free, and has a limited five (5) year warranty on parts
from the date of installation. This warranty will not exceed the purchase price of the device in question. This warranty
does not cover installation, removal, or reinstallation cost. This warranty is not valid in cases where damage was
incurred due to misuse, incorrect installation, or through incorrect repair.
⚫To ensure a long service life the (model number) must be installed as per the instructions in this manual.
⚫The module must only be used for the purpose it was designed for.
3. System Configuration
3.1 Basic Programming
3.1.1 KNX Setting
Connection: If you want to control the HomePlay network player by KNX panel, the HomePlay network and the KNX
panel should connect to the same router. For the connection, please refer to the following wiring diagram.
HomePlay
Speaker

{ HDL-MZBOX-A50B.30} User Manual
6
Physical address: Fill in the physical address of HomePlay network player.
Play/stop: Add a group address for it, the length is 1 bit, ON command is for play, OFF command is for stop.

{ HDL-MZBOX-A50B.30} User Manual
7
Pause: Add a group address for it, the length is 1 bit, ON command is for pause.
Audio Mute: Add a group address for it, the length is 1 bit, ON command is for mute.
Select Song/Channel: Add two group address for it, one group address is for last song, the other one is for next song, ON
command is for last song, OFF command is for next song.

{ HDL-MZBOX-A50B.30} User Manual
8
Volume Step: Add two group address for it, one group address is for increasing volume, the other one is for reducing
volume, ON command is for increasing volume, OFF command is for reducing volume.
Special Song Play: Add a group address for it, the length is 1 bit, ON command is for playing special music. The Index 48
means special song 1, and the index 49 means special song 2, and deduce the rest from this.

{ HDL-MZBOX-A50B.30} User Manual
9
3.1.2 Setting
Test: You can test the function of play, stop, previous song, next song, volume+ and volume-.

{ HDL-MZBOX-A50B.30} User Manual
10
3.1.3 Control the HomePlay Network Player with DLP Panel
Music page setting of DLP: Enable the HomePlay network player, select Z-Audio mode, Zone NO.1, and set the subnet ID
and device ID. After that, you control the HomePlay network player with DLP panel. About the source of the HomePlay
network player, we can select USB, NAS, AUDIO-IN and Bluetooth from DLP.

{ HDL-MZBOX-A50B.30} User Manual
11
USB: Insert the U disk into the USB port of the HomePlay network player, change to SD-CARD source in DLP music page,
then you can play the music in USB disk by DLP.
AUDIO-IN: Connect the music source device to line in port of the HomePlay network player, change to AUDIO-IN source
in DLP music page, then you can play the music on device connect to line in port by DLP.
NAS: After the HomePlay network player and the other Android/iOS device connect to the same router, change to NAS
source in DLP music page, then you can play the music on Android/iOS device by DLP.
Bluetooth: The Bluetooth name of the HomePlay network player is HDL-Audio, you can match the HomePlay network
player with the other Bluetooth device. After matching them, change to SD-CARD source in DLP music page, then you
can adjust the volume of Bluetooth device by DLP.(Attention: for the Bluetooth device now only support the function of
adjusting volume).
3.1.4 Control the HomePlay Network Player with HDL ON
1. After connecting the Android/iOS device and the HomePlay network player to the same router, run HDL ON APP, click
music icon to enter music page.

{ HDL-MZBOX-A50B.30} User Manual
12
2. Click the device on the device list to enter music page, click music source button to select music source.
Music source include local music, USB, DLNA server music, Spotify and QQ music and so on. Now I will introduce them
one by one.
Local Music: The music stored in the Android/iOS device, you can play the local music after click it.
USB: The music stored in the U disk, you can play the USB music after click it.
My List: Create new list, add the favorite music to the list. You can add the music from local music and USB and so on.

{ HDL-MZBOX-A50B.30} User Manual
13
My Favorite: You can add your favorite music and ratio to here from the music page.

{ HDL-MZBOX-A50B.30} User Manual
14
DLNA Server Music: We can control the DLNA server music by two ways.
1. Run DLNA Server on the computer, and connect the computer and the HomePlay network player to the same router.
2. Connect the DLNA Server device and the HomePlay network player to the same router.
Online Ratio: You can select different ratio here.
Pandora: Need to install Pandora APP first, then you can play the Pandora music via HomePlay network player.
Spotify: Need to install Spotify APP first, then you can play the Spotify music via HomePlay network player.
QQ Music: Need to install QQ music APP first, then you can play the QQ music via HomePlay network player.
TIDAL: Need to install TIDAL APP first, then you can play the TIDAL music via HomePlay network player.
Bluetooth: The Bluetooth name of the HomePlay network player is HDL-Audio, you can match the HomePlay network
player with the other Bluetooth device. After matching them, select Bluetooth source from HDL ON, then you can adjust
the volume of Bluetooth device by HDL ON.
Line in: Select the Line in music, then you can play the line in music by HDL ON.
My Setup: In this option, we can mark the HomePlay network player, modify the Bluetooth name, adjust the treble and
bass and get the device information.

{ HDL-MZBOX-A50B.30} User Manual
15
Bluetooth: Click the Bluetooth button and modify the Bluetooth name, need to restart the HomePlay network player
after modify the Bluetooth name.
Equalizer: Adjust the Treble and Bass of the HomePlay network player.

{ HDL-MZBOX-A50B.30} User Manual
16
Device Information: We can get the device information if we click this option.
Delete Current Music Player: Delete the HomePlay network player from device list.

{ HDL-MZBOX-A50B.30} User Manual
17
3.2 Advanced Programming
3.2.1 Party Mode
When there are several HomePlay network players in the system, if we want to all HomePlay network players play music
synchronously, party mode can achieve to this function.
1. Run HDL ON APP, click music icon to enter music page.
2. Drag one HomePlay network player to the other HomePlay network player position, then finish the configuration of
party mode. In the party mode, the slave player will follow the master player to play the same music.
