USE AND CARE GUIDE
3GALLONPORTABLEAIRCOMPRESSOR
Questions, problems, missing parts?
Before returning to the store, call
HDX Customer Service
8 a.m - 6 p.m., EST, Monday-Friday
800-514-6729
figure
`
THANK YOU
We appreciate the trust and confidence you have placed in HDX through the purchase of this 3 gallon portable air compressor. W strive to
continually create qualityproducts designed to enhance yourhome. Visit us online to see our full line of products availablefor
your homeimprovement needs. Thank youforchoosingHDX!

Table of Contents
TableofContents........................................................................... . 2
Package Contents......................................................................... . 6
SafetyInformation................................................................... .. 2
CompressorOperation ................................................................... 7
Work AreaSafety............................................................................ . 2
Drainingthetank ................................................................... 7
PersonalSafety............................................................................... . 2 Checkingthesafety valve....................................................... 7
PersonalSafety(Continued).......................................................... . 3 Troubleshooting .............................................................................. 8
AirCompressorandPneumaticToolSafety................................ . 3 ExplodedView ..................................................................... ... 9
SafetyInformation(continued)............................................... . 4 PartsList............................................................................................. 10
Electrical Safety.............................................................................. . 4
Electrical Safety(ExtensionCords)................................................ . 4
Electrical Safety(Electrical Connection)........................................ . 4
Electrical Safety(SpeedandWiring) ............................................. . 4
Electrical Safety(GroundingInstructions)..................................... . 5
Warranty .......................................................................................... . 5
HDX AirCompressorLimitedTwo-YearWarranty.................... .. 5
Additional Limitations................................................................ . 5
Specifications................................................................................ . 6
AirCompressor................................................................................ . 6
Safety Information
WORK AREA SAFETY
1. Keep yourwork area clean andwelllit. Ensurefloorsare
notslippery from waxordust.
2. Do notoperate powertoolsinexplosive atmospheres,
such as in the presence of flammable liquids, gases, or
dust. Power tools create sparks which may ignite the
dustorfumes.Keep bystanders,children,and visitors
awaywhileoperatingtools.Distractions can cause you tolose
control.
3. Operate air compressor inan openareaatleast18 in.
away from any wall or object that could restrict the flow of
fresh air to ventilationopenings.
4. Always disconnectthe airsupplyand power supply
before making adjustments,servicing a tool, or when a tool is
not inuse.
5. This compressor/pump is notequipped and should not
be used to supplybreathing qualityair. Additional
equipment wouldbenecessarytoproperly filter and
purify theair tomeet minimalspecificationsforGradeD
breathingasdescribedinCompressedGas Association
CommoditySpecificationG7.1- 1966,OSHA29CF9
1910.134. CompressedGas Association, 4221Walney
Road, Fifth Floor, Chantilly, VA 20151-2923, (703) 788-
2700, www.cganet.com. Any such additional equipment
hasnotbeenexamined andnoimplicationofproper use for
breathingairisintended orimplied.
PERSONALSAFETY
WARNING: Operatingany power tool can result in
foreignobjectsbeingthrownintoyoureyes,which
canresultinsevereeyedamage.Beforebeginning
operation, always wear safetygoggles,safety
glasseswith side shields, ora full faceshield when
needed.Alwaysuseeyeprotectionmarkedto
complywithANSIZ87.1
WARNING: Thisproductcontains chemicalsknown
to the Stateof Californiatocausecancerandbirth
defects orotherreproductiveharm. Wash hands
afterhandling.
1. Use safety equipment. Always wear eye protection with
side shields when operating power tools. Dustmask,
nonskid safety shoes, hard hat, or hearing protection
mustbeusedforappropriateconditions.
2. Stayalertwhenoperatingapower tool. Donotusethe
tool while tired or under the influence of drugs, alcohol, or
medication.
2

Safety Information (continued)
PERSONAL SAFETY (CONTINUED)
3. Do not wear loose clothing or jewelry. Containlong
hair. Keep your hair, clothing, and gloves away from moving
parts. Loose clothes, jewelry, or long hair can be caught in
movingparts.
4. Keepproperfootingandbalanceatalltimes.Proper
footing and balance enables better control of the tool in
unexpected situations
5. Donotuse onaladderorunstablesupport
AIR COMPRESSOR AND PNEUMATIC TOOL
SAFETY
WARNING: Do not attempt to modify this tool or
createaccessoriesnotrecommended foruse with
thistool.Anysuchalteration ormodificationis
misuseandcouldresult inahazardous condition
leadingtopossibleseriouspersonalinjury.
CAUTION:Donot useinanenvironmentthat is
dusty or otherwisecontaminated.Using theair
compressorin thistypeofenvironment may cause
damage tothe unit.
1. Keepcompressorsasfarfromthesprayingarea as
possible, at least 15ft. from the spraying area and all
explosive vapors.
2. RiskofBursting. Donotadjust regulator toresultin
output pressure greaterthanmarked maximumpressure
ofattachment. Donotuseatpressuregreaterthan the
ratedmaximumpressure of thiscompressor.
3. If connected to a circuit protected by fuses, use time-
delayfuseswiththisproduct.
4. Toreducetherisk ofelectric shock,donot exposeto
rain.Storeindoors.
5. Ensure the hoseisfree ofobstructionsorsnags.
Entangledorsnarledhosescancause loss ofbalanceor
footingandmaybecome damaged.
6. Usethe aircompressoronlyforitsintended use. Donot
alter ormodifythe unitfrom theoriginaldesignor
function.Neverweldordrillholesinthe airtank.
7. Never leave a tool unattended with the air hose
attached.
8. Do not operate this tool if it does not contain a legible
warninglabel.
9. Do not continue to use a tool or hose that leaks air or
doesnot function properly.
10. Do not attempt to pull or carry the air compressor by
thehose.
11. Your tool may require more air consumption than this
air compressoriscapable of providing.
12. Never direct a jet of compressed air toward people or
animals.
13. Protect your lungs. Wear a face or dust mask if the
operation isdusty.
14. Do notuse this air compressortospray chemicals. Your
lungscanbe damagedbyinhalingtoxicfumes.A
respirator may be necessary in dustyenvironments or
when spraying paint.
3 Please contact 800-514-6729 for further assistance.

Safety Information (continued)
ELECTRICALSAFETY
1. Avoid body contact with groundedsurfaces such as
pipes,radiators,ranges,andrefrigerators.Thereisan
increased riskofelectric shockifyourbody isgrounded.
2. Do not expose power tools to rain or wet conditions.
Waterentering apowertool willincrease theriskof
electric shock.
3. Donotabusethecord. Neverusethecordtocarrythe
tool or pull the plug from an outlet. Keep cord away
fromheat, oil,sharpedges, and movingparts.
4. Replace damaged cords immediately. Damaged cords
increase the riskofelectric shock.
ELECTRICALSAFETY (EXTENSION CORDS)
WARNING: Keep theextension cord clear of the
working area. Position the cord sothat it will not
getcaughton lumber,tools,orotherobstructions
whileyouareworkingwithapowertool.Failureto
dosocan resultinserious personalinjury.
WARNING: Checkextensioncords before each use.
If damaged,replaceimmediately. Never usethe air
compressorwith a damaged cordsincetouchingthe
damagedarea couldcauseelectricalshockresulting
in serious personalinjury.
WARNING: Improperlyconnecting theequipment-
grounding conductorcanresultin arisk ofelectrical
shock
1. Useonly 3-wireextension cords that have 3-prong
grounding plugs and 3-pole receptacles that accept the air
compressor’s plug.
2. Whenusingtheair compressor ata considerable
distance from the power source, use an extension cord
heavy enough to carry the current that the compressor will
draw.Anundersized extensioncordwill causea
drop in line voltage, resulting in a loss of power and
causing the motor to overheat. Use the following chart to
determine the minimum wire size required in an
extension cord.
3. Onlyuse 100feetorlessroundjacketed cordslistedby
Underwriter’s Laboratories (UL).
4. When operating apower tool outside, use anoutdoor
extension cord marked “W-A” or “W”. These cords are
rated for outdoor use and reduce the risk of electric
shock
Ampere rating (on air compressor data plate)
0-2.0 2.1- 3.5- 5.1- 7.1- 12.1-16.0
3.4 5.0 7.0 12.0
Cord Wire Size (A.W.G.)
Length
25’ 16 16 16 16 14 14
50’ 16 16 16 14 14 12
100’ 16 16 14 12 10 -
Used on 12 gauge - 20 amp circuit.
NOTE:Use longerairhosesinsteadoflongextension
cords. Yourair compressorwill runbetterandlast
longer
ELECTRICAL SAFETY (ELECTRICAL
CONNECTION)
1. This air compressor ispoweredbya precision built
electricmotor. It should be connectedtoa powersupply
thatis120volts,60 Hz, AConly(normal household
current).
2. Donotoperatethis toolondirect current(DC).A
substantial voltage drop will cause a loss of power and
the motor will overheat. If the air compressor does not
operate when plugged into anoutlet,double checkthe
power supply.
ELECTRICAL SAFETY (SPEED AND WIRING)
1. The no-load speed of the electric motor varies by model
andspecification.Themotorspeedisnotconstant and
decreases under a load or with lower voltage. For
voltage, the wiring in a shop is as important as the
motor’s horsepower rating.
2. Alineintended onlyforlights cannot properlycarrya
powertoolmotor.Wire thatisheavyenoughfor a short
distancewillbetoolightfora greaterdistance.Aline
thatcansupportone powertoolmaynotbeableto
supporttwoor three tools.
4

Safety Information (continued)
ELECTRICALSAFETY(GROUNDING
INSTRUCTIONS)
1. Thisproductmustbe grounded. Intheeventofan
electricalshortcircuit,grounding reducestheriskof
electricshockbyprovidinganescapewire for the
electric current. Thisaircompressorisequippedwithan
electric cord having an equipment-grounding conductor
and a grounding plug. The plug must be plugged into a
matching outletthat is properly installed andgrounded
in accordancewith alllocalcodesandordinances.
2. Do notmodifytheplug provided.Ifit willnot fitthe
outlet,havetheproperoutletinstalledbyaqualified
electrician.
Warranty
3. Theconductorwith insulation havinganoutersurface
that is green with or without yellow stripes is the
equipment grounding conductor.Ifrepairor
replacementofthe electriccord or plugis necessary,do
not connect the equipment grounding conductor to a
liveterminal.
4. Checkwitha qualified electrician or servicepersonnelif
you do not completelyunderstand the grounding
instructions,or ifyouare indoubtastowhether the
toolisproperlygrounded.Thisproductisforuseona
nominal120-V.Donotuse anadapterwiththisproduct.
HDX AIRCOMPRESSOR LIMITED TWO-YEAR WARRANTY
This warranty covers defects in workmanship or materials in this HDX air compressor for the two-yearperiod from the date of
purchase. This warrantyis specific to this air compressormodel. Warrantiesfor other HDX products may vary.
This warranty appliesonly to the originalretail purchaser and maynot be transferred. This warranty does notcover normal
wearand tearor any malfunction, failure or defect resulting from misuse, abuse, neglect, alteration, modification or repair byotherthan a service center
authorizedtorepairHDX brandedaircompressors.Expendablematerials,suchasmotorbrushes,seals,etc.are notcoveredbythiswarranty.
This warranty does not apply to this compressor used in industrial applications or for rental purposes. HDX makes no warranties,
representations or promises as to the quality or performance of its air
compressorsotherthanthosespecificallystatedin thiswarranty.
ADDITIONAL LIMITATIONS
To the extent permitted by applicable law, all implied warranties, including warranties of merchantability or fitness for a
particular purpose, are disclaimed. Any implied warranties,including warranties of merchantability or fitness for a particular
purpose, that cannot be disclaimed under state law are limited to two years fromthe dateof purchase. HDXis notresponsible
for direct, indirect, incidental, special or consequential damages. If thisair compressor is used for commercial purposes, the
warranty will apply for ninety (90) days fromthe date of purchase. Some states do not allow limitations on how long an implied
warranty lasts and/or do not allow theexclusion or limitation of incidental or consequential damages, so the above limitations
maynot applyto you. This warrantygives youspecific legal rights, and you may also have otherrights, whichvary from state to
state.
5
Pleasecontact 800-514-6729 for further assistance.

Specifications
AIRCOMPRESSOR
Running horsepower 0.25 HP
Air tank capacity 2 gal.
Air pressure 100 PSI max.
Air delivery 0.6 SCFM at 40 PSI
0.7 SCFM at 90 PSI
Lubrication Oil -Free
Gauges (2) gauge 1.5 in. diameter
Input 120 V, 60 Hz, AC only, 2.3 Amps.
Net weight 14.3 lbs.
6

Package Contents
figure
H
Part Description
A Handle
B Manual on/off switch
C Safety valve
D Rubberfoot
E Tank
F Quick coupler
G Pressureregulatorknob
H Tank pressure gauge
I Regulator pressuregauge
J Drain valve
6
Please contact 800-514-6729 for further assistanc

2
Compressor Operation
1
□
□
□
□
□
Draining the tank
Turn off the compressor.
Position a suitable container below the drain valve.
Note: Because condensate is a pollutant, dispose of it in
compliance with local regulations.
Fully openthedrainvalve(K).
Keep the compressor tilted until all moisture has
beenremoved.
If the drainvalve (K)isclogged, unplug the
compressor and pull the safety valve (C) to remove all air
pressure. Remove and clean the safety valve (C) and then
reinstall it.
Completelyclosethe drainvalve(K).
NOTE: Because condensate is a pollutant, dispose of it in
compliance withlocalregulations.
WARNING: Failure to unplug the air compressor and
depressurize the tank before removing the valve may
cause serious personalinjury.
figure
Checking the safety valve
□Turnontheaircompressorand waitforthetankto
fill. Thecompressor automaticallyshutsoff whenthe
pressurereachesthe presetmaximum.
□Turnofftheaircompressor.
□Pull the ringonthesafetyvalve (C) for 20secondsto
releasetheair.
□Release the ring. Air stops escapingatapproximately
40-100 psi.If the safetyvalve dosenotresetstop
Dispellingail between40-100Psi discontinue use andseek
servicebeforeusing the aircompressoragain.
DANGER:Donottamperwith thesafetyvalve. Items
loosened from this devicecould flyupandhit you.
Failuretoheedthiswarningcouldresultin deathor
serious personal injury.Thesafetyvalve automatically
releasesair whenthereceiverpressure exceedsthe
presetmaximum. Checkthe valve before each day of
usebypullingtheringbyhand.
WARNING: Ifair leaksafterreleasingthesafetyvalve
ringorif the valveisstuck,do notuse theair
compressoruntilthe safety valve has been replaced.
Usingthe aircompressor in thiscondition could result in
serious personalinjury.
7
Please contact 800-514-6729 forfurtherassistanc

Troubleshooting
Problem
Compressor doesnot run.
Motor hums but does not run or
runs slowly.
Fuses blow or circuit breaker trips
repeatedly.
Possible Cause
□ Tankhasinsufficientpressure.
□No electricalpower.
□ Blown stop/house fuse.
□Trippedshop/home breaker.
□ Thermal overload isopen.
□Lossofpoweroroverheating.
□ Pressure switch is bad.
□Lowvoltage.
□Wrong gaugewire orlength
of extension cord.
□Shorted or open motor
winding.
□ Defective check valveor
unloader.
□ Incorrect fuse size, circuit
overload.
□Wrong gaugewire orlength
of extension cord.
□ Defective check valveor
unloader.
Solution
□ Whenthe tank pressuredrops, the
compressor willturn on tocut-in
pressure.
□ Ensure the compressorispluggedinto a
good outlet.
□ Replacetheshop/housefuse.
□ Resetthe shop/home breaker and
determine theunderlying cause.
□Unplug the compressorandwaitforitto
cool.Thentry using again.
□ If usinganextensioncord,checkfor
proper use.
□ Replace the pressure switch.
□Check voltage with a voltmeter.
□Verifypropergaugewire and cord
length areused.
□ Bring the compressor to a service
center.
□ Bring the compressor to a service
center.
□ Verify properfuse size isbeing used.
□ Usetime-delay fuses.
□ Disconnect otherelectricalappliances
fromthecircuitoroperatecompressor
on itsownbranchcircuit.
□Verifypropergaugewire andcord
length areused.
□ Bring the compressor to a service
center.
8

Questions,problems,missingparts?Beforereturningtothestorecall
HuskyCustomerService
8a.m.-6p.m.,EST,Monday-Friday
t800-514-6729 f
Retainthismanualforfutureuse.
R E V.0 4 0 3 2 0 1 2
PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
