Hearth & Hand TGT-SCDC-04 User manual

Hearth & Hand
shaker dining chair wood
assembly instructions
Style # TGT-SCDC-04
DPCI # 324-07-5042

Congratulations on your latest purchase
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your
room in no time. Good luck-though we’re confident you won’t need it.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (1-855-698-4846) to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.

hardware
H1 - hex bolt x 6
( M6 x 40 mm )
H2 - hex wrench x 1
( L4 x 114 mm )
H3 - lock washer x 6
( M6 x 1.5 mm )
H4 - flat washer x 6
( M6 x 1 mm )
.............................................................................................................................................................................................................................

exploded diagram
ITEM
DESCRIPTION QTY
ASeater assembly 1
B Leg assembly 1
.............................................................................................................................................................................................................................
A
B

steps 1: attach leg to seater
H1 - hex bolt x 6
( M6 x 40 mm )
H3 - lock washer x 6
( M6 x 1.5 mm )
H4 - flat washer x 6
( M6 x 1 mm )
H2 - hex wrench x 1
( L4 x 114 mm )
1.1 attach leg (B) with seater (A) and secure it by inserting lock washer, flat washer, and bolts then tighten with hex wrench.
.............................................................................................................................................................................................................................
.............................................................................................................................................................................................................................
H2
H1
H3
H4
