Hearth & Hand shaker TGT-SCDT-01 User manual

Hearth & Hand
shaker dining table
assembly instructions
Style # TGT-SCDT-01
DPCI # 324-07-7434

Congratulations on your latest purchase
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your
room in no time. Good luck-though we’re confident you won’t need it.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (1-855-698-4846) to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
tools needed
philips head
screwdriver

hardware
H1 - hex bolt x 8
( M6 x 60 mm )
H2 - screw x 4
( Ø8 x 2 ")
H3 - hex wrench x 1
( L4 x 114 mm )
H4 - lock washer x 8
( M6 x 1.5 mm )
H5 - flat washer x 8
( M6 x 1 mm )
.............................................................................................................................................................................................................................

exploded diagram
ITEM
DESCRIPTION QTY
A
top table
1
B legs 4
C stretcher 1
.............................................................................................................................................................................................................................
C
B
B
B
B
A

steps 1: attach leg to top table
H1 - hex bolt x 4
( M6 x 60 mm )
H4 - lock washer x 4
( M6 x 1.5 mm )
H5 - flat washer x 4
( M6 x 1 mm )
H3 - hex wrench x 1
( L4 x 114 mm )
1.1 attach leg (B) with top table (A) and secure it by inserting lock washer, flat washer, and bolts then tighten with hex wrench.
.............................................................................................................................................................................................................................
.............................................................................................................................................................................................................................
H5 H4 H1 H3

step 2 : attach leg to appron & stretcher to legs
H1 - hex bolt x 4
( M6 x 60 mm )
H4 - lock washer x 4
( M6 x 1.5 mm )
H5 - flat washer x 4
( M6 x 1 mm )
H3 - hex wrench x 1
( L4 x 114 mm )
2.1 attach the other legs (B) to top table (A), attached the stretcher (C) to legs (B) as shown above picture secure the legs (B) to top table by inserting lock washer,
flat washer, and bolts then tighten with hex wrench.
.............................................................................................................................................................................................................................
.............................................................................................................................................................................................................................
H5 H4 H1 H3

step 3 : attach stretcher to legs
H2 - screw x 4
( Ø8 x 2 " )
3.1 secure the stretcher to leg (B) by insterting screw (H2) and tigthen by screwdriver
.............................................................................................................................................................................................................................
.............................................................................................................................................................................................................................
H2
