HearthSong Rainbow Flag Swing Quick setup guide
This swing is intended solely for family and domestic use, not for a commercial
playground or daycare.
Ideally, the Rainbow Flag Swing should be hung over grass, sand, wood chips, or
other soft surfaces. Under no circumstances should it be hung over concrete,
asphalt, or other hard surfaces. Distance from the ground should not exceed 18".
Hang equipment in such a way that there is at least 6' of clearance on all sides.
May be hung on an A-frame or swing set, on a tree limb of at least 10"–12"
diam., or from a swing stand. To use as a swing (figure A), use two of our Mega
Tree Hangers (731926; sold separately). To hang as a spinning swing (figure B),
aachonecarabinertotheO-ringatthetopofeachstrap,clipbothofthe
carabiners into the swivel (included), and hang using one Mega Tree Hanger.
Please be sure to examine the ropes regularly to check for wear. Rope will, in
time, degrade. Discontinue use if the color of the rope has become pale, frays
easily, or gives off a powdery material when rubbed between the fingers.
We hope you have lots of fun with this swing!
What You Get:
•8connecngtubeswithrubbercovers
•UV-coatedpolyestercanvasswingseat
•2seconsof4strapsin4colors
(red, yellow, blue, green)
•1 swivel
•8bolts
•Allenwrench
•2carabiners
#732707 | Ages 5+.
Adultinstallaonandsupervisionrequired.
Hanging ropes are 58" long; swing is approx. 58" diam.
Straps at top of ropes adjust from 5" to 8".
Takes two adults 20 minutes to assemble.
Weightcapacity:400lbs.
Rainbow Flag Swing
Safety and Assembly Instructions
•8connecngtubeswithrubbercovers
•UV-coatedpolyestercanvasswingseat
A
B
732707_RainbowFlagSwing_instructions.indd 1 8/7/18 12:52 PM
Step 1
Each of the (8) tube
seconshasafemaleand
a male end. Each of the
(2)seconsof(4)straps
corresponds in color (red,
yellow, blue, or green) to
stripesstchedintoplace
on the seat canvas. Lay
thecanvasatwiththe
colorstchingfacingup.
Step 2
Slideoneseconof
tubingatameinto
the outer pocket of the
swing, lining it up with
the correctly colored
stchingontheswing.
Connect a strap in the
matching color onto the
seconandthenaddthe
nextseconoftubing.
Step 8
For use as a spinner,
aachonecarabiner
totheO-ringatthetop
of each strap, clip both
of the carabiners into
the swivel (included),
and hang using one
Mega Tree Hanger (sold
separately).
Step 3
Repeattheprocessunl
you have four connected
tubes (a semi-circle),
taking care not to tangle
the straps.
Step 5
Click the two semi-circles
intoplace,compleng
the swing’s seat frame.
Step 4
Connect the second set
of four tubes in the same
way, once again making
sure to match colors
and keep straps from
tangling.
Step 6
Oncethecircleis
complete, insert one bolt
ateachtubeconnecon
(underneath each strap)
andghtenwithAllen
wrench (included).
Step 7
For use as
a swing,
aachthe
top of each
strap to a
carabiner
and then
hang using
two tree hangers; tree
hangers are not included.
•Double-ringstrapat
top of colored strap
seconsadjustsfrom
5�to 8�.
#732707ConformstoASTMF1148MadeinChina.©HearthSong®2018.Madison,VA22727.1-800-533-4397hearthsong.com
Instructions:
732707_RainbowFlagSwing_instructions.indd 2 8/7/18 12:52 PM
Clearance distance should be 6' around the swing.
A fall onto a hard surface can result in serious injury
to the equipment user.
Do not use the equipment until properly installed.
This swing is not to be used in any other manner other
than its intended use.
Adult supervision is required.
Adults should verify that the hanging ropes are secured
and cannot be looped back on the swing.
Do not use this equipment in a manner other than intended.
It is important for adults to instruct children to:
• Dress appropriately while using the swing
(avoidponchos,scarves,andotherloose-ng
clothingthatispotenallyhazardous).
• Instruct children when swinging alone to put their full
weight in the center of the swing.
• Warning!Pleasebesurechildrenwearwell-ng
footwear that fully encloses the foot when using this
swing.Clogs,ip-ops,andsandalsareconsidered
inappropriate footwear.
It is important for adults to instruct children NOT to:
•Walk close to, in front of, behind, or between
moving items.
• Twist ropes or loop them over the top support bar
sincesuchaconmayreducethestrengthoftherope.
• Getooftheswingwhileitisinmoon.
• Climb on the swing when it is wet.
• Aachaddionalitemstotheswingthatmightcause
astrangulaonhazard.
• Wear a bicycle or sport helmet while on the swing.
Maintaining the Swing
At the beginning of each play season, adults should:
• Tighten all hardware.
• Checkallprotecvecoveringsonpipes,edges,and
corners. Replace if they are loose, cracked, or missing.
• Check all moving parts including the swing seat and
ropesforwear,rust,orotherdeterioraon.Ifdamage
isfound,disconnueuse.
• Check metal parts for rust. If found, sand and
repaintusinganon-lead-basedpaintmeengthe
requirements of 16 CFR 1303.
• Lubricate all metallic moving parts per
manufacturer’sinstrucons.
• If the swing is hung from a swing set frame, lubricate
allmetallicmovingpartsthatareaachedbya
metalconnecon.
• If the swing is hung from a tree branch, rake and
checkdepthofloose-llprotecvesurfacingmaterials
(suchasmulchorsand)topreventcompaconandto
maintain appropriate depth (minimum amount is 9").
Replace as needed.
Twice a month during play season, adults should:
• Tighten all hardware.
• Checkallprotecvecoveringsonpipes,edges,and
corners. Replace if they are loose, cracked, or missing.
• If the swing is hung from a tree branch, rake and
checkdepthofloose-llprotecvesurfacingmaterials
(suchasmulchorsand)topreventcompaconandto
maintain appropriate depth (minimum amount is 9").
Replace as needed.
Once a month during play season, adults should:
• Check all moving parts including ropes for wear
orotherdeterioraon.Ifdamageisfound,
disconnueuse.
• Lubricate all metallic moving parts per
manufacturer’sinstrucons.
• If the swing is hung from a tree branch, rake and
checkdepthofloose-llprotecvesurfacingmaterials
(suchasmulchorsand)topreventcompaconandto
maintain appropriate depth (minimum amount is 9").
Replace as needed.
At the end of each play season or when the temperature
falls below 40°F, adults should:
• Removetheswingfromitsoutdoorlocaon.
• Store the swing in a dry environment.
• To clean, spot clean.
Disposing of the Swing
To dispose of the swing, first disassemble it. Dispose of it in
suchawaythatnounreasonablehazardswillexistatthe
time that the swing is discarded.
ThisconformstoASTMF1148,Consumer
Safety Performance Specification for Home
Playground Equipment.
Please retain these instructions for future use.
Safety Guidelines
#732707 Conforms to ASTM F1148 Made in China. ©HearthSong®2018. Madison, VA 22727. 1-800-533-4397 hearthsong.com
732707_RainbowFlagSwing_instructions.indd 3 8/7/18 12:52 PM
