Heat & Glo LCOR-HVB-CE Assembly instructions

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/07 1
- Do not store or use gasoline or other flam-
mablevaporsandliquidsinthevicinityofthis
oranyotherappliance.
-What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Donot useany phonein yourbuilding.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
thefiredepartment.
- Installationandservicemustbeperformedbya
qualified installer, service agency, or the gas
supplier.
Models:
PIER-HVB-CE
ST-HVB-CE
LCOR-HVB-CE
RCOR-HVB-CE
Installers Guide
Please contact your Heat & Glo dealer with any
questions or concerns. For the number of your nearest
Heat & Glo dealer, please call 1-888-427-3973.
Printed in U.S.A. Copyright 2005
Heat& Glo,abrand ofHearth& HomeTechnologiesInc.
20802KensingtonBoulevard,Lakeville,MN55044
WARNING: IF THE INFORMATION
IN THESE INSTRUCTIONS IS NOT
FOLLOWED EXACTLY, AFIRE OR
EXPLOSION MAY RESULT CAUS-
ING PROPERTY DAMAGE, PER-
SONAL INJURY, OR DEATH.
This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;
4,852,548; 4,875,464; 5,000,162; 5,016,609; 5,076,254 5,191,877; 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia)
543790; 586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending.
WARNING: IMPROPER INSTALLATION,
ADJUSTMENT, ALTERATION, SERVICE
OR MAINTENANCE CAN CAUSE INJURY
OR PROPERTY DAMAGE. REFER TO
THIS MANUAL. FOR ASSISTANCE ORAD-
DITIONAL INFORMATION CONSULT A
QUALIFIED INSTALLER OR COMPETENT
PERSON.
READ THIS MANUAL BEFORE INSTALLING OR
OPERATING THIS APPLIANCE. THIS INSTALLERS
GUIDE MUST BE LEFT WITH APPLIANCE FOR
FUTUREREFERENCE.
Theseinstructionsareonlyvalidifthefollowing
country symbol is on the appliance. If this
symbol is not present on the appliance, it is
necessarytorefertothetechnicalinstructions
which will provide the necessary information
concerning the modification of the appliance
to the conditions of use for the country.
These instructions are valid for the following
countries: GB, IE
0087

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/072
These units MUST use one of the flue systems
described in the Installing the Fireplace section of
the Installers Guide. NO OTHER flue systems or
components MAY BE USED.
This gas fireplace and flue assembly MUST flue
directly to the outside and MUST NEVER be
attached to a chimney serving a separate solid fuel
burning appliance. Each gas appliance MUST USE
a separate flue system. Common flue systems are
PROHIBITED.
INSPECT the external flue cap on a regular basis to
make sure that no debris is interfering with the air
flow.
The glass door assembly MUST be in place and
sealed, and the trim door assembly MUST be in
place on the fireplace before the unit can be placed
into safe operation.
DO NOT OPERATE this appliance with the glass
door removed, cracked, or broken. Replacement of
the glass door should be performed by a licensed
or qualified service person. DO NOT strike or slam
the glass door.
The glass door assembly SHALL ONLY be
replaced as a complete unit, as supplied by the gas
fireplace manufacturer. NO SUBSTITUTE material
may be used.
DO NOT USE abrasive cleaners on the glass door
assembly. DO NOT ATTEMPT to clean the glass
door when it is hot.
Turn off the gas before servicing this appliance. It is
recommended that a qualified service technician
perform an appliance check-up at the beginning of
each heating season.
Any safety screen or guard removed for servicing
must be replaced before operating this appliance.
DO NOT place furniture or any other combustible
household objects within 36 inches of the fireplace
front.
This appliance is intended for use on a gas installation
with a governed meter.
READ and UNDERSTAND all instructions carefully
before starting the installation. FAILURE TO
FOLLOW these installation instructions may result
in a possible fire hazard and will void the warranty.
Prior to the first firing of the fireplace, READ the
Using Your Fireplace section of the Owners Guide.
DO NOT USE this appliance if any part has been
under water. Immediately CALL a qualified service
technician to inspect the unit and to replace any part
of the control system and any gas control which has
been under water.
THIS UNIT IS NOT FOR USE WITH SOLID FUEL.
Installation and repair should be PERFORMED by a
qualified service person. The appliance and flueing
system should be INSPECTED before initial use
and at least annually by a professional service
person. More frequent cleaning may be required
due to excessive lint from carpeting, bedding
material, etc. It is IMPERATIVE that the unit’s
control compartment, burners, and circulating air
passageways BE KEPT CLEAN to provide for
adequate combustion and ventilation air.
Always KEEP the appliance clear and free from
combustible materials, petrol, and other flammable
vapors and liquids.
NEVER OBSTRUCT the flow of combustion and
ventilation air. Keep the front of the appliance
CLEAR of all obstacles and materials for servicing
and proper operations.
Due to the high temperature, the appliance should
be LOCATED out of traffic areas and away from
furniture and draperies. Clothing or flammable
material SHOULD NOT BE PLACED on or near the
appliance.
Children and adults should be ALERTED to the
hazards of high surface temperature and should
STAY AWAY to avoid burns or clothing ignition.
Young childrenshould be CAREFULLYSUPERVISED
when they are in the same room as the appliance.
!
!
!
!
!
!
!
!!
!
!
!
!
!
!
!
!
Safety and Warning Information
!
!
!

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/07 3
Table of Contents
Safety and Warning Information.................................................. 2
Service Parts List .........................................................................4
Section 1: Approvals and Regulations .................................... 13
ApplianceCertification ................................................................................. 13
InstallationRegulations ................................................................................ 13
Section 2: Getting Started......................................................... 13
Introducingthe Heat& GloGas Fireplaces .................................................. 13
Pre-installPreparation ................................................................................. 13
Section 3: Installing the Fireplace............................................ 17
Step 1. Locating the Fireplace .................................................................... 17
Step 2. Framing the Fireplace..................................................................... 17
Step 3. Installing the Flue System .............................................................. 20
A. Flue SystemApprovals.......................................................... 20
B. Installing Flue Components ................................................... 27
C. FlueTermination .................................................................... 29
Step 4. Positioning, Leveling,and Securingthe Fireplace ........................... 32
Step 5. The Gas Control System ................................................................ 32
Step 6. The Gas Supply Line ...................................................................... 33
Step 7. Gas Pressure Requirements........................................................... 33
Step 8. Wiring the Fireplace........................................................................ 34
Step 9. Finishing......................................................................................... 34
Step 10. Installing Trim,Logs &Ember Material .......................................... 35
Installing theTrim .......................................................................... 35
Positioningthe Logs...................................................................... 35
Attachmentof LowerDoorAssembly............................................. 35
Placingthe EmberMaterial ........................................................... 38
Step 11. Before Lighting the Fireplace........................................................ 41
Step 12. Lighting the Fireplace ................................................................... 41
After theInstallation ..................................................................................... 41
Section 4: Maintaining and Servicing Your Fireplace............. 42
Section 5: Troubleshooting ...................................................... 43
Î= Containsupdated information.

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/074
*Partnumber list on following page.
5 Log Assembly
Service Parts Diagram
Service Parts List PIER-HVB-CE
Beginning Manufacturing Date: 6-04
Ending Manufacturing Date: ______
21
3
4
8
6
7
9

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/07 5
(NG, LP) Exploded Parts Diagram
IMPORTANT: THISIS DATEDINFORMATION.Themostcurrent information islocated onyour dealersVIPsite. Whenordering,
supplyserial andmodel numbersto ensurecorrect serviceparts.
ITEM COMMON PART SERIAL # PART NUMBER
Burner Orifice NG (#33DMS) 582-833
Burner Orifice LP (#51DMS) 582-851
Burner Orifice Butane (#53DMS) 582-853
1 End Glass Assembly GLA-MS
2 Glass Door Assembly GLA-6TROC
3 Burner Assembly (NG) 2068-011
3 BurnerAssembly(LP & Butane) 2068-013
4LogGrate 2068-020
5 Log Set Assembly(Sold as set only) LOGS-ST-CE
6 Dress Guard Assembly 2068-040
7 Lower Door 2068-041
8 End Panel Assembly 2069-042
9 Side Refractory SRV2005-730
Non-Combustible Board (Side) 2006-136
Non-Combustible Board (End) 2006-137
Door Stop 2068-144
Lava Rock Bag 2005-790
Junction Box 546-250A
Mesh Assembly, Small End 561-330A
Mesh Assembly 537-300
Fiber Glass Rope 060-455
Mineral Wool 050-721
Glass Latch Assembly 386-122A
Bracket, Junction Box 2068-106
ACCESSORIES
Hood, black SRV2005-190
Hood End, black SRV2006-194
Fan Kit GFK-240V
Wall Thermostat Kit MV-STAT
Wall Switch Kit, Off White WSK-21
Wall Switch Kit, White WSK-21-W
Conversion Kit, NG NGK-ST-CE
Conversion Kit, LP LPK-ST-CE
Conversion Kit, Butane BGK-ST-CE
Regulator, NG 230-1570
Regulator, LP, Butane 230-4520
Pilot Orifice NG 529-512
Pilot Orifice LP 200-2630
PIER-HVB-CE

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/076
Service Parts Diagram
Service Parts ST-HVB-CE
Beginning Manufacturing Date: 6-04
Ending Manufacturing Date: ______
*Partnumber list on following page.
4 Log Assembly
2
3
1
6
5
7

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/07 7
(NG, LP) Exploded Parts Diagram
IMPORTANT: THISIS DATEDINFORMATION.Themostcurrent information islocated onyour dealersVIPsite. Whenordering,
supplyserial andmodel numbersto ensurecorrect serviceparts.
ST-HVB-CE
ITEM COMMON PART SERIAL # PART NUMBER
Burner Orifice NG (#33DMS) 582-833
Burner Orifice LP (#51DMS) 582-851
Burner Orifice Butane (#53DMS) 582-853
1 Glass Door Assembly GLA-6TROC
2 Burner Assembly (NG) 2068-011
2 BurnerAssembly(LP & Butane) 2068-013
3LogGrate 2068-020
4 Log Set Assembly (Sold as set only) LOGS-ST-CE
5 Dress Guard Assembly 2068-040
6 Lower Door 2068-041
7 Side Refractory SRV2005-730
Non-Combustible Board (Side) 2006-136
Door Stop 2068-144
Lava Rock Bag 2005-790
Junction Box 546-250A
Mesh Assembly, Small End 561-330A
Mesh Assembly 537-300
Fiber Glass Rope 060-455
Mineral Wool 050-721
Glass Latch Assembly 386-122A
Bracket, Junction Box 2068-106
ACCESSORIES
Hood, black SRV2005-190
Hood End, black SRV2006-194
Fan Kit GFK-240V
Wall Thermostat Kit MV-STAT
Wall Switch Kit, Off White WSK-21
Wall Switch Kit, White WSK-21-W
Conversion Kit, NG NGK-ST-CE
Conversion Kit, LP LPK-ST-CE
Conversion Kit, Butane BGK-ST-CE
Regulator, NG 230-1570
Regulator, LP, Butane 230-4520
Pilot Orifice NG 529-512
Pilot Orifice LP 200-2630

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/078
*Partnumber list on following page.
5 Log Assembly
Service Parts Diagram
Service Parts LCOR-HVB-CE
Beginning Manufacturing Date: 6-04
Ending Manufacturing Date: ______
8
2
3
4
6
7
19

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/07 9
(NG, LP) Exploded Parts Diagram
IMPORTANT:THISISDATEDINFORMATION.The mostcurrent informationis locatedon yourdealers VIPsite.Whenordering,
supplyserial andmodel numbersto ensurecorrect serviceparts.
LCOR-HVB-CE
ITEM COMMON PART SERIAL # PART NUMBER
Burner Orifice NG (#33DMS) 582-833
Burner Orifice LP (#51DMS) 582-851
Burner Orifice Butane (#53DMS) 582-853
1 End Glass Assembly GLA-MS
2 Glass Door Assembly GLA-6TROC
3 Burner Assembly (NG) 2068-011
3 BurnerAssembly(LP & Butane) 2068-013
4LogGrate 2068-020
5 Log Set Assembly(Sold as set only) LOGS-ST-CE
6 Dress Guard Assembly 2068-040
7 Lower Door 2068-041
8 End Panel Assembly 2069-042
Non-Combustible Board (Side) 2006-136
Non-Combustible Board (End) 2006-137
Door Stop 2068-144
Lava Rock Bag 2005-790
Junction Box 546-250A
Mesh Assembly, Small End 561-330A
Mesh Assembly 537-300
Fiber Glass Rope 060-455
Mineral Wool 050-721
Glass Latch Assembly 386-122A
Bracket, JunctionBox 2068-106
Side Refractory SRV2005-730
Back Refractory SRV2005-731
ACCESSORIES
Hood, black SRV2005-190
Hood End, black SRV2006-194
Fan Kit GFK-240V
Wall Thermostat Kit MV-STAT
Wall Switch Kit, Off White WSK-21
Wall Switch Kit, White WSK-21-W
Conversion Kit, NG NGK-ST-CE
Conversion Kit, LP LPK-ST-CE
Conversion Kit, Butane BGK-ST-CE
Regulator, NG 230-1570
Regulator, LP, Butane 230-4520
Pilot Orifice NG 529-512
Pilot Orifice LP 200-2630

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/0710
*Partnumber list on following page.
5 Log Assembly
Service Parts Diagram
Service Parts RCOR-HVB-CE
Beginning Manufacturing Date: 6-04
Ending Manufacturing Date: ______
1
3
2
4
6
7
8
11
10
9
12

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/07 11
(NG, LP) Exploded Parts Diagram
IMPORTANT: THISIS DATEDINFORMATION.Themostcurrent information islocated onyour dealersVIPsite. Whenordering,
supplyserial andmodel numbersto ensurecorrect serviceparts.
RCOR-HVB-CE
ITEM COMMON PART SERIAL # PART NUMBER
Burner Orifice NG (#33DMS) 582-833
Burner Orifice LP (#51DMS) 582-851
Burner Orifice Butane (#53DMS) 582-853
1 End Glass Assembly GLA-MS
2 Glass Door Assembly GLA-6TROC
3 Burner Assembly (NG) 2068-011
3 BurnerAssembly(LP & Butane) 2068-013
4LogGrate 2068-020
5 Log Set Assembly(Sold as set only) LOGS-ST-CE
6 Dress Guard Assembly 2068-040
7 Lower Door 2068-041
8 End Panel Assembly 2069-042
Side Refractory SRV2005-730
Back Refractory SRV2005-731
Non-Combustible Board (Side) 2006-136
Non-Combustible Board (End) 2006-137
Door Stop 2068-144
Lava Rock Bag 2005-790
Junction Box 546-250A
Mesh Assembly, Small End 561-330A
Mesh Assembly 537-300
Fiber Glass Rope 060-455
Mineral Wool 050-721
Glass Latch Assembly 386-122A
Bracket, JunctionBox 2068-106
ACCESSORIES
Hood, black SRV2005-190
Hood End, black SRV2006-194
Fan Kit GFK-240V
Wall Thermostat Kit MV-STAT
Wall Switch Kit, Off White WSK-21
Wall Switch Kit, White WSK-21-W
Conversion Kit, NG NGK-ST-CE
Conversion Kit, LP LPK-ST-CE
Conversion Kit, Butane BGK-ST-CE
Regulator, NG 230-1570
Regulator, LP, Butane 230-4520
Pilot Orifice NG 529-512
Pilot Orifice LP 200-2630

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/0712
ValveAssembly
Service Parts
Beginning Manufacturing Date: 6-04
Ending Manufacturing Date: ______
Standing Pilot
ValveAssembly
ITEM DESCRIPTION SERIAL # PART NUMBER
1 Shut Off Valve Assembly 302-330A
2 ON/OFF Wire Assembly 060-521A
3SITValveNG 060-524
3SITValveNG 060-526
4 Elbow Flex Assembly 530-302A
5 Burner Neck Gasket 438-407
6 Valve Plate Gasket 2005-140
7PiezoIgnitor 219-513
8PilotAssemblyNG 529-540A
8PilotAssemblyLP 529-541A
9 Pilot Bracket 2068-114
10 Valve Bracket 2068-115
11 Offset Bracket 2068-111
11 Burner Leg 2068-113
12 Pilot Support 2068-112
20" Wire Harness 107-559A
9
8
4
5
12
6
2
13
11
10
8
1
3
PIER-HVB-CE,ST-HVB-CE
L&RCOR-HVB-CE Í

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/07 13
Appliance Certification
TheHeat& Glofireplacemodelsdiscussed inthisInstallers
Guidehave beentestedtocertification standardsandlisted
bythe applicablelaboratories.
Certification
MODELS: PIER-HVB-CE, ST-HVB-CE,
LCOR-HVB-CE, RCOR-HVB-CE
LABORATORY: Advantica
TYPE: Gas Fireplace
STANDARD: BS EN 613:2001
DIRECTIVE: GAD90/396/EEC
1Approvals and Regulations
2Getting Started
Introducing the Heat & Glo Gas Fireplaces
Heat& Glo direct flue gasfireplaces aredesigned tooper-
ate with all combustion air siphoned from outside of the
building and all exhaust gases expelled to the outside.
The information contained in this Installers Guide, unless
noted otherwise, applies to all models and gas control
systems.Gasfireplacediagrams, includingthe dimensions,
are shown in this section.
Pre-install Preparation
Thisgas fireplace andits componentsare testedand safe
when installed in accordance with this Installers Guide.
Report to your dealer any parts damaged in shipment,
particularly the condition of the glass. Do not install any
unit with damaged, incomplete, or substitute parts.
Thefluesystem components areshippedinseparate pack-
ages. The gas logs are packaged separately and must be
fieldinstalled.
Read all of the instructions before starting the instal-
lation. Follow these instructions carefully during the
installation to ensure maximum safety and benefit.
Failure to follow these instructions will void the own-
er’s warranty and may present a fire hazard.
TheHeat &Glo Warranty willbe voidedby, andHeat &Glo
disclaims any responsibility for, the following actions:
• Installationofanydamagedfireplace or fluesystem com-
ponent.
• Modification of the fireplace or direct flue system.
• Installation other than as instructed by Heat & Glo.
• Improper positioning of the gas logs or the glass door.
• Installationand/or useofany componentpartnot manu-
factured and approved by Heat & Glo, not withstanding
anyindependenttestinglaboratoryorotherpartyapproval
of such component part or accessory.
ANY SUCH ACTION MAY POSSIBLY CAUSE A FIRE
HAZARD.
When planning a fireplace installation, it’s necessary
to determine:
•Where the unit is to be installed.
•The flue system configuration to be used.
•Gas supply piping.
•Electricalwiring.
•Framingand finishingdetails.
•Whether optional accessories—devices such as a fan,
wallswitch, or remotecontrol—are desired.
If the fireplace is to be installed on carpeting, tile or
any combustible material other than wood flooring, it
should be installed on a metal or wood panel that
extends the full width and depth of the fireplace.
Installation Regulations
Before installation check that local distribution conditions,
natureofgasandpressure,andadjustmentof the appliance
arecompatible.
Thisappliance mustbeinstalled withtherules in force,and
used only in a sufficiently ventilated space. Consult
instructions before installation and use of this appliance.

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/0714
Figure 1. Diagram of the PIER-HVB-CE
REAR FLUE
COLLARS
ELECTRICAL
ACCESS
GAS LINE
ACCESS
GAS CONTROLS
& LABELS
TOP STANDOFFS
TOP FLUE
COLLARS
5-14
(133mm)
12
(306mm)
1/2
(13mm)
(2)
42-5/8
(1082mm)
42
(1067mm) 17-15/16
(456mm)
32-1/8
(816mm)
2-5/16
(58mm)
4-3/4
(121mm)
4-1/16
(102mm)
4-1/2
(114mm)
ELECTRICAL
ACCESS
GAS LINE
ACCESS
12
(305mm)
17-3/4
(451mm)
9-5/8
(245mm)
24
(610mm)
9-11/16
(245mm)
34-3/4
(882mm)
Ø8
(204mm)
Ø8
(204mm)
37-7/16
(950mm)
17-3/4
(451mm)

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/07 15
Figure 2. Diagram of the ST-HVB-CE
REAR FLUE
COLLARS
ELECTRICAL
ACCESS
GAS LINE
ACCESS
GAS CONTROLS
& LABELS
TOP STANDOFFS
TOP FLUE
COLLARS
5-14
(133mm)
12
(306mm)
1/2
(13mm)
(4)
46-5/8
(1183mm)
42
(1067mm) 32-5/16
(820mm)
21
(533mm)
36-3/16
(919mm)
2-5/16
(58mm)
4-3/4
(121mm)
4-1/16
(102mm)
4-1/2
(114mm)
ELECTRICAL
ACCESS
GAS LINE
ACCESS
12
(305mm)
4-1/2
(114mm)
2-9/16
(64mm)
24
(610mm)
8-1/2
(216mm)
34-3/4
(882mm)
Ø8
(204mm)
Ø8
(204mm)

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/0716
Figure 3. Diagram of the LCOR-HVB-CE and RCOR-HVB-CE
5-14
(133mm)
12
(306mm)
1/2
(13mm)
(4)
42-5/8
(1082mm)
42
(1067mm)
17-15/16
(456mm)
32-1/8
(816mm)
2-5/16
(58mm)
7-1/4
(184mm)
10
(254mm)
4-3/4
(121mm)
ELECTRICAL
ACCESS
GAS LINE
ACCESS
12
(305mm)
29-1/4
(743mm)
9-11/16
(245mm)
24-1/8
(612mm)
9-11/16
(245mm)
34-3/4
(882mm)
Ø8
(204mm)
Ø8
(204mm)
37-7/16
(950mm)
17-3/4
(451mm)
17-15/16
(456mm)
2-9/16
(64mm)
REAR FLUE
COLLARS
ELECTRICAL
ACCESS
GAS LINE
ACCESS
GAS CONTROLS
& LABELS
TOP STANDOFFS
TOP FLUE
COLLARS

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/07 17
3Installing the Fireplace
Step 1. Locating the Fireplace
The diagram below shows space and clearance require-
ments for locating a fireplace within a room.
Minimum Clearances
from the Fireplace to Combustible Materials
Figure 4. Fireplace Dimensions and Locations
Clearance Requirements
The top, back, and sides of the fireplace are defined by
stand-offs.The minimumclearanceto aperpendicular wall
extending pastthe faceof the fireplaceis 25 mm (1 in.). The
metal ends of the fireplace may NOT be recessed into
combustible construction.
For minimum clearances, see the direct flue termination
clearance diagrams on pages 30 and 31 in this manual.
Step 2. Framing the Fireplace
Fireplaceframingcan bebuiltbefore orafter thefireplaceis
set in place. Framing should be positioned to accommo-
date wall coverings and fireplace facing material. The dia-
grambelowshows framingreferencedimensions.
CAUTION: MEASURE FIREPLACE DIMENSIONS AND
VERIFY FRAMING METHODS AND WALL COVERING
DETAILS BEFORE FRAMING.
Minimum Clearances
from the Flue Pipe to Combustible Materials
* Theclearancetotheceilingismeasuredfromthetopof
theunit,excludingthestandoffs(seeFigures 37 & 38).
Thedistance fromtheunit tocombustible construction isto
be measured from the unit outer wrap surface to the com-
bustible construction, NOT from the screw heads that se-
curethe unittogether.
!
WARNING: FRAMING DIMENSIONS ASSUME
USE OF 1/2 INCH THICK WALL COVERING
MATERIALSON EXTERIOROF FRAMING ONLYAND
NO SHEETROCK ON INTERIOR OF FRAMING.
914 mm
GLASS
GLASS
GLASS
914 mm
GLASS
GLASS
914 mm
GLASS
914 mm
GLASS
GLASS
GLASS
914 mm
914 mm
914 mm
PIER-HVB-CE
TOP VIEW RCOR-HVB-CE
TOP VIEW
LCOR-HVB-CE
TOP VIEW
ST-HVB-CE
TOP VIEW
mm inches
Glass Sides or Ends......... 914..................... 36
Floor ................................... 0 ....................... 0
Rear Flue ........................... 13 .....................1/2
Metal Sides or Ends .......... 13 .....................1/2
Top..................................... 64 ................... 2 1/2
Ceiling* ............................. 787..................... 31
mm Inches
Vertical Sections. ............ 25 ................ 1
Horizontal Sections
Top.................................... 75 ................ 3
Bottom .............................. 25 ................ 1
Sides ................................ 25 ................ 1
At Wall Firestops
Top...................................63.7 ............ 2 1/2
Bottom .............................. 13 ...............1/2
Sides ................................ 25 ................ 1

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/0718
Framingshould beconstructed
of 51mm x 102mm (2” x 4”)
lumberorheavier.
Model A B C D E
PIER-HVB-CE 107(42-1/8) 108(42-1/2) 58(23) 91(35-3/4) 122(48)
ST-HVB-CE 121(47-5/8) 108(42-1/2) 58(23) 91(35-3/4) 122(48)
L&RCOR-HVB-CE 107(42-1/8) 108(42-1/2) 73(28-3/4) 91(35-3/4) 122(48)
Figure 5. Framing Dimensions
NOTE:DIMENSIONS SHOWN IN CENTIMETERSAND (INCHES).
Shows center of 254mm x 305mm (10”x12”) flue framing holes for top and rear flueing.
The center of the hole is 25.4mm (one inch) above the center of the horizontal flue pipe.
PIER-HVB-CE
ST-HVB-CE L & R-COR-HVB-CE
A
C
B
D
B
C
A
A
C
B
E

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/07 19
NOTE: PIPES OVERLAP 32mm (1-1/4”)
AT EACHJOINT.
Figure 6. DVP-Series Direct Flue Component Specifications (127mm (5”) inner pipe / 203mm (8”) outer pipe)
DVP90ST
320mm
(12-9/16 in.)
286mm
(11-1/4 in.)
185mm
(7-1/4 in.)
32mm (1-1/4 in.) TYP
18mm
(1/2 in.) TYP
218mm
(8-9/16 in.)
DVP36
DVP48
1219mm
(48 in.)
610mm
(24 in.)
914mm
(36 in.)
102mm
(4 in.)
152mm
(6 in.)
DVP4
DVP6
305mm
(12 in.)
DVP12
51mm (2 in.)
MIN.
DVP12A
310mm
(12-3/16 in.)
MAX.
DVP24
251mm
(9-7/8 in.) 45.0
O
261mm
(10-1/4 in.)
DVP45
362mm
(14-1/4 in.)

Heat & Glo • PIER/ST/L&RCOR-HVB-CE • 2068-900 Rev. H • 6/0720
Figure 7. Flue System Components and Termination Kits
Step 3. Installing the Flue System
A. Flue System Approvals
These models are approved to use DVP series direct flue
pipe components and terminations (see Figures 6 and 7).
Approvedflue system components are labeledfor identifi-
cation. This pipe is tested and listed as an approved com-
ponent of the fireplace. The pipe is tested to be run inside
an enclosed wall. There is no requirement for inspection
openingsat eachjoint within the wall. There is norequired
pitch for horizontal flue runs.NO OTHER FLUEING SYS-
TEMS OR COMPONENTS MAYBE USED.
Detailedinstallationinstructions areincludedwith eachflue
termination kit and should be used in conjunction with this
InstallersGuide.
The flame and ember appearance may vary based on the
typeof fuelburned andthe flueingconfiguration used.
Identifying Flue Components
The flue systems installed on this gas fireplace may in-
clude one, two, or three 90°elbow assemblies. The rela-
tionships of vertical rise to horizontal run in flue configura-
tions using 90° elbows MUST BE strictly adhered to. The
rise to run relationships are shown in the flueing drawings
andtables.Refertothediagrams on thenextseveral pages.
NOTE: Two 45° elbows may be used in place of one
90° elbow. Rise to run ratios in the flue system must
be followed if 45° elbows are used.
This model has a 450elbow built into it. It may be posi-
tionedto flueeitherhorizontal orvertical.Depending on the
installation,decidewhich directiontheelbow shouldbe fac-
ing.Remove the8 screwsfrom thecorner coverplate. Po-
sitionthe 450elbowas desiredand replacethe corner cov-
er plate with the 8 screws.
HORIZONTAL
TERMINATION
WALL FIRESTOP
90 DEGREE
ELBOW
PIPE LENGTH
CEILING
FIRESTOP
VERTICAL
TERMINATION STORM COLLAR
ROOF FLASHING
Terminations Kits
DVP-TVHW
DVP-TRAP
SERIES
