Heat Controller AS-W093E7Y0 User manual

Wall Mounted
Mini-Split System
Inverter Single-Zone
Air Conditioning/Heat Pump
AS-W093E7Y0 [VMH09SB-1]
AS-W123E7Y0 [VMH12SB-1]
Before servicing the unit, read the
“safety precautions” in this manual.
Only for authorized service personnel.
HEAT CONTROLLER, INC.

- 2 -
Copyright ©2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
1. Specification
Note:
O
: Applied, - : No relation
* For circuit breaker rating, please conform to local standards wherever necessary.
❈ Some of functions are slightly different depending upon models.
❈ The specification may be subject to change without prior notice for purpose of improvement.
❈Capacity : based on 203V
Cooling Capacity kW
(Min~Rating~Max) Btu/h
Heating Capacity kW
(Min~Rating~Max) Btu/h
Power Input Cooling/Heating W
Running Current Cooling/Heating A
Starting Current Cooling/Heating A
EER W/W
Btu/h.W
COP W/W
Power Supply Ø/ V / Hz
Power Factor %
Air Flow Rate Indoor,Max m3/min(cfm)
Outdoor,Max m3/min(cfm)
Moisture Removal l/h
Sound Level Indoor,H/M/L dB(A)+3
Outdoor,Max dB(A)+3
Refrigerant & Charge(at 7.5m) g(oz)
Additional Refrigerant Charge g/m(oz/ft)
Compressor Type
Model
Motor Type
Oil Type
Oil Charge cc
O.L.P Name
Fan(Indoor) Type
Motor Output W
Fan(outdoor) Type
Motor Type
Motor Output W
Circuit Breaker* A
Power Supply Cable NEC
Power and Transmission Cable NEC
Piping Liquid Side mm(in)
Connections Gas Side mm(in)
Drain Hose O.D , I.D mm(in)
Dimension Indoor(W*H*D) mm
inch
Outdoor(W*H*D) mm
inch
Net Weight Indoor kg(lbs)
Outdoor kg(lbs)
Operation Range Cooling(Outdoor) °C(°F)
Heating(Outdoor) °C(°F)
Max. Piping Length m(ft)
Max. Elevation Difference m(ft)
Tool Code(Chassis) Indoor + Outdoor
Functions Temperature Control
Plasma Filter
Prefilter(washable/anti-fungus)
Auto Clean
CHAOS Wind(Auto Wind)
Steps, Fan/Cool/Heat
Airflow Direction Control(up&down)
Airflow Direction Control(left&right)
Remocon Type
Setting Temperature Cooling [°C(°F)]
Range Heating [°C(°F)]
Auto Operation (Micom Control)
Auto Changeover (Micom Control)
Self Diagnosis
Timer
Sleep Operation
Soft Dry Operation
Restart Delay(minute)
Deice Control(Defrost)
Hot Start
Jet Cool / Heat
Low Ambient Operation
Special Function
Network Functions Dry Contact
Network Solution(LGAP)
PI485
Models
AS-W093E7Y0
[VMH09SB-1]
AS-W123E7Y0
[VMH12SB-1]
0.90~2.70~3.70 0.90~3.52~4.04
3,070~9,200~12,620 3,070~12,000~13,800
0.90~3.52~5.00 0.90~4.54~5.49
3,070~12,000~17,060 3,070~15,500~18,720
690/915 1120/1370
3.2/4.2 5.0/5.9
3.2/4.2 5.0/5.9
3.91 3.14
13.3 10.7
3.85 3.31
1/208-230/60 1/208-230/60
94 97
8.5(300) 9.5(335)
29(1,024) 29(1,024)
0.6 1.3
36/33/30 39/33/30
48 48
R410A, 1,000(35.3) R410A, 1,000(35.3)
20(0.22) 20(0.22)
Rotary Rotary
5RS102XAA21 5RS102XAA21
BLDC BLDC
FV50S FV50S
320 320
--
Cross Flow Fan Cross Flow Fan
20 20
Propeller Propeller
BLDC BLDC
43 43
15 15
14 14
18 18
6.35(1/4) 6.35(1/4)
9.52(3/8) 9.52(3/8)
21.5,16.0(0.85,0.63) 21.5,16.0(0.85,0.63)
895*282*165 895*282*165
35.2*11.1*6.5 35.2*11.1*6.5
770*545*245 770*545*245
30.3*21.5*9.6 30.3*21.5*9.6
8(17.6) 8(17.6)
35(77.2) 35(77.2)
-10 ~ 46 (14.0~114.8)(Low Ambient) -10 ~ 46 (14.0~114.8)(Low Ambient)
-15 ~ 24 (5.0 ~ 75.2) -15 ~ 24 (5.0 ~ 75.2)
15(49) 15(49)
7(23) 7(23)
SE + UL SE + UL
Thermistor Thermistor
--
OO
OO
OO
-/4/4 -/4/4
Auto Auto
Manual Manual
Wireless LCD Wireless LCD
18 ~ 30 (64~86) 18 ~ 30 (64~86)
16 ~ 30 (60~86) 16 ~ 30 (60~86)
--
OO
OO
24h On/Off 24h On/Off
OO
OO
22
OO
OO
O / O O / O
OO
--
--
--
--

- 3 -
Copyright ©2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
2. Piping Diagrams
Indoor Unit Outdoor Unit
Heat
Exchanger
(Evaporator)
Heat
Exchanger
(Condenser)
EEV
Compressor
Accumulator
Gas Side
3-Way Valve
2-Way Valve
Liquid Side
Cooling
Heating
Reversing Valve
Th1
Th2
Th5
Th4
Th3
LOC. Description PCB Connector
Th1 Thermistor for indoor air temperature CN_TH1(INDOOR)
Th2 Thermistor for evaporating temperature
Th3 Thermistor for discharge pipe temperature CN_D_PIPE(Outdoor)
Th4 Thermistor for condensing temperature CN_TH1(OUTDOOR)
Th5 Thermistor for outdoor air temperature
* EEV : Electronic Expansion Valve.

- 4 -
Copyright ©2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
3. Wiring Diagrams
CN_HUB/UV
CN_DISP2(BL)
CN_12V
CN_DISP(WH)
CN_TH1
CN_MOTOR1
CN_TH2
CN_L/R(BL)CN_L/R(BL)
Indoor Unit

- 5 -
Copyright ©2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
CN-SUMP HEATER
CN-4WAY
CN-TEST
CN-PC
CN-EEVCN-D/ACN-FLASH
CN-TH1
CN-D_PIPE
CN-FAN2
RY-SUMP HEATER
Outdoor Unit

- 6 -
Copyright ©2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Indoor Unit
4. Exploded View
152302
342800
263230A
359011
131410 733010
135316
135314
135311
147581 268711A
146811
346810
135516
35211B
352150
354210
249951 268711B 267110
152313
Option Parts
Indoor Air, Evaporater
Thermistor
Note) * Please ensure GCSC since the replacement parts may be changed depending upon the buyer's request.
Please check the correct parts in View RPL(Replacement Part List) on GCSC.
(GCSC Website http://biz.Lgservice.com,)

- 7 -
Copyright ©2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Outdoor Unit
554031
552202
552560
552116
554160
561410
430960A
430960B
550140
552203B
552203A
553000
W49810
649950
437211
661400
435301
559010
349480
546810
549610
261704
447910
55211G
552200
263230E
D-pipe Thermistor
435300
137213B
137213A
435511
268711F
263230D
EEV Coil
Outdoor Air,
Condenser
Thermistor
Note) * Please ensure GCSC since the replacement parts may be changed depending upon the buyer's request.
Please check the correct parts in View RPL(Replacement Part List) on GCSC.
(GCSC Website http://biz.Lgservice.com,)

Specifications and performance data subject to change without notice.
HEAT CONTROLLER, INC.
1900 WELLWORTH AVENUE •JACKSON, MICHIGAN 49203
THE QUALITY LEADER IN CONDITIONING AIR
MFL42286408
