Installation, Operation
& Mainenance Manual
Commercial Horizontal & Vertical
Packaged Water-Source Heat Pumps:
HBH/V Compact

IOM Instructions HBH/V CompaCt Heat Controller, Inc.
Model Nomenclature ..................................................2
General Information.................................................3-4
Physical Data..............................................................5
Horizontal Installation...........................................6-7,9
Field Conversion of Air Discharge..............................8
Vertical Installation...............................................10-11
Piping Installation .....................................................12
Water Loop Applications...........................................13
Open Loop - Ground Water Systems ..................14-17
Water Quality Standards ..........................................18
Electrical - Line Voltage............................................19
Electrical Data .....................................................20-21
Electrical - Power & Low Voltage Wiring .............22-24
Electrical - Thermostat Wiring ..................................25
CXM Controls...........................................................26
CXM Control - Safety Features ...........................27-28
Unit Starting & Operating Conditions........................29
Piping System Cleaning & Flushing .........................30
Unit & System Checkout...........................................31
Unit Start-Up Procedure......................................32-33
Unit Operating Procedures & Temperatures........34-37
Preventive Maintenance...........................................38
Functional Troubleshooting .................................39-42
TABLE OF CONTENTS

Heat Controller, Inc. HBH/V CompaCt IOM Instructions
7 May, 2009
Page 10
HEAT CONTROLLER OEM PRICE LIST
HBH & HBV Model Structure
HBH & HBV COMPACT Horizontal & Vertical HFC-410a Units
The basic unit price includes sealed heat pump refrigerant circuit and
air handler within cabinetry, lter, and a factory installed hanger kit on
horizontal units.
• Cabinetry - Compact design - galvanized steel construction -
powder coat nish on front access panels - controls access panel
- compressor access panels - FPT water connections - high and low
voltage knockouts - 1” (25mm), air lter and lter rack. All vertical
units have a left or right return air option, sizes 015 - 030 have a front
return option. All horizontal units have eld convertible discharge air
patterns with no extra parts required.
• Standard Controls - CXM Controller, loss of charge switch, high
pressure switch, water coil low temperature cutout, lockout safety
circuit resetable at thermostat or disconnect, LED fault indication,
ve minute anti-short cycle protection, random start, high and low
voltage protection, condensate overow protection, dry contact for
alarm.
• Compressor - High efciency hermetic scroll or rotary, overload
protected - internally sprung & externally isolated using dual vibration
dampening system for extra quiet operation. Mounting system
incorporates rubber grommet isolation under the compressor and
rubber grommet isolation between the compressor mounting tray and
unit base.
• Reversing Valve - 4-way, pilot operated, solenoid activated in the
cool mode.
• Refrigerant Circuit - Utilizes expansion valve metering device -
copper tubing interconnecting all components - sealed & tested
non-ozone depleting, HFC-410A refrigerant circuit with high & low
side schraeder ports.
• Water to Refrigerant Coil - Tube-in-tube, convoluted copper inner
water tube.
• Refrigerant to Air Coil - Lanced aluminum ns on ried copper
tubes.
• Blower Motor - Three-speed PSC direct drive, permanently
lubricated (Two-speed on 575 volt applications).
• UltraQuiet Option - Compressor incorporates spring mounting
system, 015-060 include compressor discharge mufer, blower
housing is covered with high density noise suppression material.
• Application - Units can be applied in WLHP, GWHP, or GLHP
applications.
Basic Unit Description:
HB H A036 C3 3 0 A L B
1 2 3 4 5 6 7
8
9 10 11 12 13 14
HB= HEATCONTROLLERCOMPACT410A
MODELTYPE
H= HORIZONTAL(NONPAINTED)
CONFIGURATION
V= VERTICAL(PAINTEDPOLARICE)
UNITSIZE
018- 1,8
024- 1,3,4,8
030- 1,3,4,8
036- 1,3,4,8
042- 1,3,4,5
048- 1,3,4,5
060- 1,3,4,5
REVISION LEVEL
A= CURRENTREVISIONFORSIZES006 -060
VOLTAGE
C= CXM
CONTROLS
3= STANDARDRANGE
CABINETINSULATION
0= NONE
FUTUREUSE
A= CopperWaterCoilw/E-CoatedAirCoil
HEATEXCHANGEROPTIONS
C= CopperWaterCoilw/Non-CoatedAirCoil
L=LEFTRETURN
RETURNAIROPTIONS
R= RIGHTRETURN
F= FRONTRETURN,VERTICAL 009-030
B= BACKDISCHARGE,HORIZONTALONLY
SUPPLYAIROPTIONS
Y=BACKDISCHARGE,HIGHSTATIC
HORIZONTAL018- 060
T=TOPDISCHARGE,VERTICALONLY
V=TOPDISCHARGE,HIGHSTATIC
VERTICAL018-060
S= STRAIGHTDISCHARGE,HORIZONTALONLY
Z= STRAIGHTDISCHARGE,HIGHSTATIC
HORIZONTAL018- 060
J= Cupro-NickelWaterCoilw/E-CoatedAirCoil
N= Cupro-NickelWaterCoilw/Non-CoatedAirCoil
4= STANDARDRANGE,WITH ULTRAQUIET
015- 1,8
1= 208-230/60/1
8= 265/60/1
3= 208-230/60/3
4= 460/60/3
5= 575/60/3
C= STANDARDRANGE,COOLINGONLY,VERTICALUNITS
3= DISCHARGEPRESSUREWATERREGULATINGVALVE(COOLINGONLY)
NOTAVAILABLEONUNITSIZES006,009AND012
V= LEFTRETURN,S.SDRAINPAN
W= RIGHTRETURN,S.SDRAINPAN
Z= FRONTRETURN,S.S.DRAIN PAN009-030
}VoltageCode
Entering Water Temperature Range: 20 - 120°F (-6.7 - 48.9°C)
Vertical Water Source Heat Pump
Sizes 015-060
Horizontal Water Source Heat Pump
Sizes 015-060
006-060 006-060
006
R-410A refrigerant circuit with high & low
• Cabinetry – Compact design - galvanized steel construction - controls
access panel - compressor access panels - FPT water connections -
high and low voltage knockouts - 1” (25mm), air lter and lter rack. All
vertical units have a left or right return air option, sizes 006-030 have a
front return option. All horizontal units have eld convertible discharge air
patterns with extra parts required.

General Information
WARNING! To avoid the release of refrigerant into the
atmosphere, the refrigerant circuit of this unit must be
serviced only by technicians who meet local, state, and
federal prociency requirements.
WARNING! All refrigerant discharged from this unit must be
recovered WITHOUT EXCEPTION. Technicians must follow
industry accepted guidelines and all local, state, and federal
statutes for the recovery and disposal of refrigerants. If a
compressor is removed from this unit, refrigerant circuit oil will
remain in the compressor. To avoid leakage of compressor oil,
refrigerant lines of the compressor must be sealed after it is
removed.
CAUTION! To avoid equipment damage, DO NOT use
these units as a source of heating or cooling during the
construction process. The mechanical components and
lters will quickly become clogged with construction dirt and
debris, which may cause system damage.
WARNING!
WARNING!
WARNING!
CAUTION!
Safety
Warnings, cautions and notices appear throughout this manual.
Read these items carefully before attempting any installation,
service or troubleshooting of the equipment.
DANGER: Indicates an immediate hazardous situation, which
if not avoided will result in death or serious injury. DANGER
labels on unit access panels must be observed.
WARNING: Indicates a potentially hazardous situation, which if
not avoided could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation or an
unsafe practice, which if not avoided could result in minor or
moderate injury or product or property damage.
NOTICE: Notication of installation, operation or maintenance
information, which is important, but which is not hazard-related.
WARNING! The Refrigerant Application and Service Manual
should be read and understood before attempting to service
refrigerant circuits with HFC-410A.
Inspection
Upon receipt of the equipment, carefully check the shipment
against the bill of lading. Make sure all units have been received.
Inspect the packaging of each unit, and inspect each unit for
damage. Insure that the carrier makes proper notation of any
shortages or damage on all copies of the freight bill and completes
a common carrier inspection report. Concealed damage not
discovered during unloading must be reported to the carrier within
15 days of receipt of shipment. If not led within 15 days, the
freight company can deny the claim without recourse. Note: It is
the responsibility of the purchaser to le all necessary claims with
the carrier. Notify your equipment supplier of all damage within
fteen (15) days of shipment.
Storage
Equipment should be stored in its original packaging in a clean,
dry area. Store units in an upright position at all times. Stack
units a maximum of 3 units high.
Unit Protection
Cover units on the job site with either the original packaging or an
equivalent protective covering. Cap the open ends of pipes stored
on the job site. In areas where painting, plastering, and/or spraying
has not been completed, all due precautions must be taken to
avoid physical damage to the units and contamination by foreign
material. Physical damage and contamination may prevent proper
start-up and may result in costly equipment clean-up.
Examine all pipes, ttings, and valves before installing any of
the system components. Remove any dirt or debris found in or
on these components.
Pre-Installation
Installation, Operation, and Maintenance instructions are
provided with each unit. Horizontal equipment is designed for
installation above false ceiling or in a ceiling plenum. Other
unit congurations are typically installed in a mechanical room.
The installation site chosen should include adequate service
clearance around the unit. Before unit start-up, read all manuals
and become familiar with the unit and its operation. Thoroughly
check the system before operation.
IOM Instructions HBH/V CompaCt Heat Controller, Inc.
R-410A.

CAUTION! All three phase scroll compressors must have
direction of rotation veried at start-up. Verication is achieved by
checking compressor Amp draw. Amp draw will be substantially
lower compared to nameplate values. Additionally, reverse rotation
results in an elevated sound level compared to correct rotation.
Reverse rotation will result in compressor internal overload trip
within several minutes. Verify compressor type before proceeding.
CAUTION! DO NOT store or install units in corrosive
environments or in locations subject to temperature or
humidity extremes (e.g., attics, garages, rooftops, etc.).
Corrosive conditions and high temperature or humidity can
signicantly reduce performance, reliability, and service life.
Always move and store units in an upright position. Tilting
units on their sides may cause equipment damage.
NOTICE! Failure to remove shipping brackets from spring-
mounted compressors will cause excessive noise, and
could cause component failure due to added vibration.
CAUTION!
CAUTION!
CAUTION!
CAUTION! CUT HAZARD - Failure to follow this caution
may result in personal injury. Sheet metal parts may have
sharp edges or burrs. Use care and wear appropriate
protective clothing, safety glasses and gloves when
handling parts and servicing heat pumps.
General Information
Prepare units for installation as follows:
1. Compare the electrical data on the unit nameplate with
ordering and shipping information to verify that the correct
unit has been shipped.
2. Keep the cabinet covered with the original packaging until
installation is complete and all plastering, painting, etc. is
nished.
3. Verify refrigerant tubing is free of kinks or dents and that it
does not touch other unit components.
4. Inspect all electrical connections. Connections must be
clean and tight at the terminals.
5. Remove any blower support packaging (water-to-air units
only).
6. Loosen compressor bolts on units equipped with
compressor spring vibration isolation until the compressor
rides freely on the springs. Remove shipping restraints.
7.
Some airow patterns are eld convertible (horizontal units
only). Locate the airow conversion section of this IOM.
8. Locate and verify any hot water generator (HWG), hanger,
or other accessory kit located in the compressor section or
blower section.
Heat Controller, Inc. HBH/V CompaCt IOM Instructions

Unit Physical Data
HBH/V Series
HB Series 006 009 012 015 018 024 030 036 042 048 060
Compressor (1 Each) Rotary Scroll
Factory Charge R410A (oz) 17 18.5 23 32 43 43 47 50 70 74 82
PSC Fan Motor & Blower
Fan Motor Type/Speeds PSC/3 PSC/3 PSC-3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3
Fan Motor (hp) 1/25 1/10 1/10 1/6 1/6 1/4 3/4 1/2 3/4 3/4 1
Blower Wheel Size (Dia x w) 5x5 5x5 6x5 8x7 8x7 9x7 9x7 9x8 9x8 10x10 11x10
Water Connection Size
IPT 1/2” 1/2” 1/2” 1/2" 1/2" 3/4" 3/4" 3/4" 3/4" 1" 1"
Vertical
Air Coil Dimensions (H x W) 10x15 10x15 10x15 20x17.25 20x17.25 20x17.25 20x17.25 24x21.75 24x21.76 24x28.25 24x28.25
Filter Standard - 1" Throwaway 10x18 10x18 10x18 20x20 20x20 20x20 20x20 24x24 24x24 1-14x24, 1-18x24 1-14x24, 1-18x24
Weight - Operating (lbs.) 103 105 114 153 158 189 197 203 218 263 278
Weight - Packaged (lbs.) 113 115 124 158 163 194 202 209 224 270
285
Horizontal
Air Coil Dimensions (H x W) 10x15 10x15 10x15 16x22 16x22 16x22 16x22 20x25 20x25 20x35 20x35
Filter Standard - 1" Throwaway 10x18 10x18 10x18 16x25 16x25 18x25
18x25 20x28 or 2-20x14 20x28 or 2-20x14 1-20x24, 1-20x14 1-20x24, 1-20x14
Weight - Operating (lbs.) 103 105 114 153 158 174 182 203 218 263 278
Weight - Packaged (lbs.) 113 115 124 158 163 179 187 209 224 270 285
Notes:
Models 006-012 have spring compressor mounts, all others have grommets,TXV expansion device, and 1/2” & 3/4” electrical knockouts.
Unit Maximum Water Working Pressure
Options Max Pressure PSIG [kPa]
Base Unit 500 [3,445]
Discharge Pressure
Water Regulating Valve 140 [965]
Use the lowest maximum pressure rating when multiple options are combined.
IOM Instructions HBH/V CompaCt Heat Controller, Inc.

Heat Controller, Inc. HBH/V CompaCt IOM Instructions
Horizontal Installation
Mounting Horizontal Units
Horizontal units have hanger kits pre-installed from the factory
as shown in Figure 1. Figure 3 shows a typical horizontal unit
installation.
Horizontal heat pumps are typically suspended above a ceiling
or within a soft using eld supplied, threaded rods sized to
support the weight of the unit.
Use four (4) eld supplied threaded rods and factory provided
vibration isolators to suspend the unit. Hang the unit clear of the
oor slab above and support the unit by the mounting bracket
assemblies only. DO NOT attach the unit ush with the oor
slab above.
Pitch the unit toward the drain as shown in Figure 2 to improve
the condensate drainage. On small units (less than 2.5
tons/8.8kW) ensure that unit pitch does not cause condensate
leaks inside the cabinet.
Figure 1: Hanger Bracket
Figure 2: Horizontal Unit Pitch
3/8" [10mm] Threaded
Rod (by others)
Vibration Isolator
(factory supplied)
Washer
(by others)
Double Hex Nuts
(by others)
Varilla Roscada de 3/8"
(fabricada por terceros)
Arandela
(fabricada por terceros)
Tuercas Hexagonales
Dobles (por terceros)
Instale losTornillos como
se Indica en el Diagrama
La longitud de este tornillo
debe ser de solamente 1/2”para evitar daños
Aislador deVibraciones
(para codificación por color y
notas de instalación, consulte
las instrucciones de
instalación del soport
e colgador)
1/4" [6.4mm] pitch
for drainage
Drain
Connection
Horizontal Unit Location
Units are not designed for outdoor installation. Locate
the unit in an INDOOR area that allows enough space
for service personnel to perform typical maintenance or
repairs without removing unit from the ceiling. Horizontal
units are typically installed above a false ceiling or in a
ceiling plenum. Never install units in areas subject to
freezing or where humidity levels could cause cabinet
condensation (such as unconditioned spaces subject
to 100% outside air). Consideration should be given to
access for easy removal of the lter and access panels.
Provide sufcient room to make water, electrical, and
duct connection(s).
If the unit is located in a conned space, such as a closet,
provisions must be made for return air to freely enter the
space by means of a louvered door, etc. Any access panel
screws that would be difcult to remove after the unit is
installed should be removed prior to setting the unit. Refer
to Figure 3 for an illustration of a typical installation. Refer
to unit engineering design guide for dimensional data.
In limited side access installations, pre-removal of the
control box side mounting screws will allow control box
removal for future servicing (HB units only).
Conform to the following guidelines when selecting
unit location:
1. Provide a hinged access door in concealed-spline
or plaster ceilings. Provide removable ceiling
tiles in T-bar or lay-in ceilings. Refer to horizontal
unit dimensions for specic series and model in
unit submittal data. Size the access opening to
accommodate the service technician during the
removal or replacement of the compressor and the
removal or installation of the unit itself.
2. Provide access to hanger brackets, water valves
and ttings. Provide screwdriver clearance to access
panels, discharge collars and all electrical connections.
3. DO NOT obstruct the space beneath the unit with
piping, electrical cables and other items that prohibit
future removal of components or the unit itself.
4. Use a manual portable jack/lift to lift and support the
weight of the unit during installation and servicing.
The installation of water source heat pump units and all
associated components, parts and accessories which
make up the installation shall be in accordance with
the regulations of ALL authorities having jurisdiction
and MUST conform to all applicable codes. It is the
responsibility of the installing contractor to determine and
comply with ALL applicable codes and regulations.

IOM Instructions HBH/V CompaCt Heat Controller, Inc.
Horizontal Installation
Figure 3: Typical Horizontal Unit Installation
Air Coil
To obtain maximum performance, the air coil should be cleaned
before start-up. A 10% solution of dishwasher detergent and
water is recommended for both sides of the coil. A thorough
water rinse should follow. UV based anti-bacterial systems
may damage e-coated air coils.
NOTICE! Installation Note - Ducted Return: Many horizontal
WSHPs are installed in a return air ceiling plenum application
(above ceiling). Vertical WSHPs are commonly installed in a
mechanical room with free return (e.g. louvered door). Therefore,
lter rails are the industry standard and are included on Heat
Controller, Inc., commercial heat pumps for the purposes of
holding the lter only. For ducted return applications, the lter rail
must be removed and replaced with a duct ange or lter rack.
Canvas or exible connectors should also be used to minimize
vibration between the unit and ductwork.
HORIZONTAL INSTALLATION
(by others)
(by others)
Cableado
del termostato
Válvula compensadora opcional
Salida de agua
Entrada de agua
Válvula invertida opcional para
control de baja presión de agua
(puede montarse en forma interna)
Válvula a bola con tapón
P/T integrado opcional
Manguera trenzada de
acero inoxidable con accesorio
giratorio en “J”
Circuito
de edificación
Disyuntor de
energía de la unidad
(fabricado por terceros)
Alimentación
de energía de
la unidad
Conducto de alimentación
aislado con un codo (mínimo)
de 90 grados para reducir el
ruido del aire
Retorno de
aire
Aire de alimentación
Cableado de
alimentación
de energía
Varillas Roscadas de 3/8"
(fabricadas por terceros)
Colgador
de la unidad
Thermostat
Wiring
Optional Balancing Valve
Water In
Water Out
Optional Low Pressure Drop Water
Control Valve
(can be internally mounted
on some models)
Ball Valve with optional
integral P/T plug
Stainless steel braid hose
with integral "J" swivel
Building
Loop
Unit Power
Disconnect
Power Wiring
Insulated supply duct with
at least one 90 deg elbow
to reduce air noise
Return Air
Supply Air
Unit Hanger
3/8" [10mm] threaded rods
Unit Power
Flexible Duct
Connector
Figure 3: Typical Horizontal Unit Installation
Stainless steel braided hoses with
threaded connections
and one swivel end

Heat Controller, Inc. HBH/V CompaCt IOM Instructions
Field Conversion of Air Discharge
Water
Connection End
Return Air
Remove Screws
Water
Connection End
Return Air
Rotate
Move to Side
Side Discharge
Return Air
Water
Connection End
Discharge Air
Drain
Back Discharge
Replace Screws
Extremo de Con
Conducto de Alimentación
Retorno de Aire
Extremo de Conexión deAgua
Drenaje
Retorno de Aire
Descarga de Aire
Descarga Lateral
Descarga Posterior
Water
Connection End
Supply Duct
Return Air
Water
Connection End
Drain
Return Air
Discharge Air
Side Discharge
Back Discharge
Overview
Horizontal units can be eld converted between side (straight)
and back (end) discharge using the instructions below.
Note: It is not possible to eld convert return air between
left or right return models due to the necessity of
refrigeration copper piping changes.
Preparation
It is best to eld convert the unit on the ground before hanging.
If the unit is already hung it should be taken down for the eld
conversion.
Side to Back Discharge Conversion
1. Place unit in well lit area. Remove the screws as shown in
Figure 4 to free top panel and discharge panel.
2. Lift out the access panel and set aside. Lift and rotate
the discharge panel to the other position as shown, being
careful with the blower wiring.
3.
Check blower wire routing and connections for tension or
contact with sheet metal edges. Reroute if necessary.
4. Check refrigerant tubing for contact with
other components.
5. Reinstall top panel and screws noting that the location for
some screws will have changed.
6. Manually spin the fan wheel to insure that the wheel is not
rubbing or obstructed.
7. Replace access panels.
Back to Side Discharge Conversion
If the discharge is changed from back to side, use above
instruction noting that illustrations will be reversed.
Left vs. Right Return
It is not possible to eld convert return air between left or right
return models due to the necessity of refrigeration copper
piping changes. However, the conversion process of side to
back or back to side discharge for either right or left return
conguration is the same. In some cases, it may be possible
to rotate the entire unit 180 degrees if the return air connection
needs to be on the opposite side. Note that rotating the unit will
move the piping to the other end of the unit.
Figure 5: Right Return Side to Back
Figure 4: Left Return Side to Back

IOM Instructions HBH/V CompaCt Heat Controller, Inc.
Horizontal Installation
*3/4" IPT
Trap Depth
1.5" [38mm]
Min 1.5"
[38mm]
1/4" per foot
(21mm per m)
drain slope
3/4" PVC or
Copper by others
Rev.: 6/26/09S
Vent
* Some units include a painted drain
connection. Using a threaded pipe or
similar device to clear any excess paint
accumulated inside this fitting may
ease final drain line installation.
Figure 6: Horizontal Condensate Connection
CAUTION! Ensure condensate line is pitched toward drain
1/4” per foot [21mm per m] of run.
Condensate Piping – Horizontal Units
CAUTION!
Pitch the unit toward the drain as shown in Figure 2 to
improve the condensate drainage. On small units (less
than 2.5 tons/8.8 kW), insure that unit pitch does not
cause condensate leaks inside the cabinet.
Install condensate trap at each unit with the top of the trap
positioned below the unit condensate drain connection as
shown in Figure 6.
Each unit must be installed with its own individual trap
and connection to the condensate line (main) or riser.
Provide a means to ush or blow out the condensate line.
DO NOT install units with a common trap and/or vent.
Always vent the condensate line when dirt or air can
collect in the line or a long horizontal drain line is
required. Also vent when large units are working against
higher external static pressure than other units connected
to the same condensate main since this may cause
poor drainage for all units on the line. WHEN A VENT
IS INSTALLED IN THE DRAIN LINE, IT MUST BE
LOCATED AFTER THE TRAP IN THE DIRECTION OF
THE CONDENSATE FLOW.
Duct System Installation
Proper duct sizing and design is critical to the
performance of the unit. The duct system should be
designed to allow adequate and even airow through
the unit during operation. Air ow through the unit MUST
be at or above the minimum stated airow for the unit
to avoid equipment damage. Duct systems should
be designed for quiet operation. Refer to Figure 3 for
horizontal duct system details or gure 8 for vertical duct
system details. A exible connector is recommended
for both discharge and return air duct connections on
metal duct systems to eliminate the transfer of vibration
to the duct system. To maximize sound attenuation of
the unit blower, the supply and return plenums should
include internal berglass duct liner or be constructed
from ductboard for the rst few feet. Application of the
unit to uninsulated ductwork in an unconditioned space
is not recommended, as the unit’s performance will be
adversely affected.
At least one 90° elbow should be included in the supply
duct to reduce air noise. If air noise or excessive air ow
is a problem, the blower speed can be changed. For
airow charts, consult submittal data for the series and
model of the specic unit.
If the unit is connected to existing ductwork, a previous
check should have been made to insure that the
ductwork has the capacity to handle the airow required
for the unit. If ducting is too small, as in the replacement
of a heating only system, larger ductwork should be
installed. All existing ductwork should be checked for
leaks and repaired as necessary.
DUCT SYSTEM INSTALLATION

Heat Controller, Inc. HBH/V CompaCt IOM Instructions
Vertical Installation
Flexible canvas duct
connector to reduce
noise and vibration
Use turning vanes in
supply transition
Internally insulate supply
duct for first 4’ [1.2 m] each way
to reduce noise
Internally insulate return
transition duct to reduce
noise
Rounded return
transition
Flexible canvas duct
connector to reduce
noise and vibration
Use turning vanes in
supply transition
Internally insulate supply
duct for first 4’[1.2m] each
way to reduce noise
Internally insulate return
transition duct to reduce
noise
Rounded return
transition
Rev.: 6/2/09S
Rev.: 6/2/09S
Figure 7: Vertical Unit Mounting
Figure 8: Typical Vertical Unit Installation Using
Ducted Return Air
bloque o del ladrillo o sacado
Coj’n del aire o sacado
Bloque o ladrillo concreto
Air Pad or Extruded
polystyrene insulation board
Vertical Unit Location
Units are not designed for outdoor installation. Locate
the unit in an INDOOR area that allows enough space
for service personnel to perform typical maintenance
or repairs without removing unit from the mechanical
room/closet. Vertical units are typically installed in a
mechanical room or closet. Never install units in areas
subject to freezing or where humidity levels could cause
cabinet condensation (such as unconditioned spaces
subject to 100% outside air). Consideration should be
given to access for easy removal of the lter and access
panels. Provide sufcient room to make water, electrical,
and duct connection(s).
If the unit is located in a conned space, such as a closet,
provisions must be made for return air to freely enter
the space by means of a louvered door, etc. Any access
panel screws that would be difcult to remove after the
unit is installed should be removed prior to setting the
unit. Refer to Figures 7 and 8 for typical installation
illustrations. Refer to unit submittal data or engineering
design guide for dimensional data.
1. Install the unit on a piece of rubber, neoprene or
other mounting pad material for sound isolation. The
pad should be at least 3/8” [10mm] to 1/2” [13mm] in
thickness. Extend the pad beyond all four edges of
the unit.
2. Provide adequate clearance for lter replacement
and drain pan cleaning. Do not block lter access
with piping, conduit or other materials. Refer to
unit submittal data or engineering design guide for
dimensional data.
3. Provide access for fan and fan motor maintenance
and for servicing the compressor and coils without
removing the unit.
4. Provide an unobstructed path to the unit within the
closet or mechanical room. Space should be sufcient
to allow removal of the unit, if necessary.
5. In limited side access installations, pre-removal of the
control box side mounting screws will allow control box
removal for future servicing (TC units only).
6. Provide access to water valves and ttings and
screwdriver access to the unit side panels, discharge
collar and all electrical connections.
HB

IOM Instructions HBH/V CompaCt Heat Controller, Inc.
Vertical Installation
Sound Attenuation for Vertical Units
Sound attenuation is achieved by enclosing the unit within a
small mechanical room or a closet. Additional measures for
sound control include the following:
1. Mount the unit so that the return air inlet is 90° to the
return air grille. Refer to Figure 9. Install a sound bafe as
illustrated to reduce line-of sight sound transmitted through
return air grilles.
2.
Mount the unit on a rubber or neoprene isolation pad to mini-
mize vibration transmission to the building structure.
Figure 9: Vertical Sound Attenuation
Condensate Piping – Vertical Units
Vertical units utilize a condensate hose inside the cabinet as
a trapping loop; therefore an external trap is not necessary.
Figure 10a shows typical condensate connections. Figure 10b
illustrates the internal trap for a typical vertical heat pump.
Each unit must be installed with its own individual vent (where
necessary) and a means to ush or blow out the condensate
drain line. Do not install units with a common trap and/or vent.
Vent
*3/4" IPT
3/4"PVC
Alternate
Condensate
Location
Water
Connections
(21mm per m)
* Some units include a painted drain connection. Using a
threaded pipe or similar device to clear any excess paint
accumulated inside this fitting may ease final drain line installation.
Figure 10a: Vertical Condensate Drain
Figure 10b: Vertical Internal Condensate Trap
NOTICE! Units with clear plastic drain lines should have
regular maintenance (as required) to avoid buildup of debris,
especially in new construction.

Heat Controller, Inc. HBH/V CompaCt IOM Instructions
Piping Installation
CAUTION! Corrosive system water requires corrosion resis-
tant ttings and hoses, and may require water treatment.
Table 1: Metal Hose Minimum Bend Radii
Hose Diameter Minimum Bend Radii
1/2" [12.7mm] 2-1/2" [6.4cm]
3/4" [19.1mm] 4" [10.2cm]
1" [25.4mm] 5-1/2" [14cm]
1-1/4" [31.8mm] 6-3/4" [17.1cm]
CAUTION! Do not bend or kink supply lines or hoses.
NOTICE! Do not allow hoses to rest against structural
building components. Compressor vibration may be
transmitted through the hoses to the structure, causing
unnecessary noise complaints.
Figure 11: Supply/Return Hose Kit
CAUTION!
CAUTION!
CAUTION!
Rib Crimped
Length
(2 ft [0.6m] Length Standard)
Swivel
Brass
Fitting
Brass
Fitting
EPT
Reborde Acanalado
Longitud
(Long. Estándar de 2 pies)
Accesorio
Giratorio
de Bronce
Accesorio
de Bronce
MPT
CAUTION! Piping must comply with all applicable codes.
Installation of Supply and Return Piping
Follow these piping guidelines.
1. Install a drain valve at the base of each supply and
return riser to facilitate system ushing.
2. Install shut-off / balancing valves and unions at each
unit to permit unit removal for servicing.
3. Place strainers at the inlet of each system
circulating pump.
4. Select the proper hose length to allow slack between
connection points. Hoses may vary in length by +2%
to -4% under pressure.
5. Refer to Table 1. Do not exceed the minimum bend
radius for the hose selected. Exceeding the minimum
bend radius may cause the hose to collapse, which
reduces water ow rate. Install an angle adapter to
avoid sharp bends in the hose when the radius falls
below the required minimum.
Insulation is not required on loop water piping except
where the piping runs through unheated areas, outside
the building or when the loop water temperature is
below the minimum expected dew point of the pipe
ambient conditions. Insulation is required if loop water
temperature drops below the dew point (insulation is
required for ground loop applications in most climates).
Pipe joint compound is not necessary when Teon®
thread tape is pre-applied to hose assemblies or when
ared-end connections are used. If pipe joint compound
is preferred, use compound only in small amounts on
the external pipe threads of the tting adapters. Prevent
sealant from reaching the ared surfaces of the joint.
Note: When anti-freeze is used in the loop, insure that it
is compatible with the Teon tape or pipe joint compound
that is applied.
Maximum allowable torque for brass ttings is 30 ft-lbs
[41 N-m]. If a torque wrench is not available, tighten
nger-tight plus one quarter turn. Tighten steel ttings
as necessary.
Optional pressure-rated hose assemblies designed
specically for use with Heat Controller units are available.
Similar hoses can be obtained from alternate suppliers.
Supply and return hoses are tted with swivel-joint ttings
at one end to prevent kinking during installation.
Refer to Figure 11 for an illustration of a typical supply/
return hose kit. Adapters secure hose assemblies to the
unit and risers. Install hose assemblies properly and
check regularly to avoid system failure and reduced
service life.
A backup wrench is required when tightening water
connections on HB series to prevent water line damage.

IOM Instructions HBH/V CompaCt Heat Controller, Inc.
Water-Loop Heat Pump Applications
Commercial Water Loop Applications
Commercial systems typically include a number of
units connected to a common piping system. Any unit
plumbing maintenance work can introduce air into the
piping system; therefore air elimination equipment is
a major portion of the mechanical room plumbing. In
piping systems expected to utilize water temperatures
below 60°F [16°C], 1/2” (13mm) closed cell insulation is
required on all piping surfaces to eliminate condensation
(extended range units required). Metal to plastic threaded
joints should never be used due to their tendency to leak
over time. A backup wrench must be used for HB series
equipment ttings.
Teon tape thread sealant is recommended to minimize
internal fouling of the heat exchanger. Do not over tighten
connections and route piping so as not to interfere with
service or maintenance access. Hose kits are available
from Heat Controller in different congurations as shown
in Figure 12 for connection between the unit and the
piping system.
The piping system should be ushed to remove dirt,
piping chips, and other foreign material prior to operation
(see “Piping System Cleaning and Flushing Procedures”
in this manual). The ow rate is usually set between 2.25
and 3.5 gpm per ton [2.9 and 4.5 l/m per kW] of cooling
capacity. Heat Controller recommends 3 gpm per ton
[3.9 l/m per kW] for most applications of water loop heat
pumps. To insure proper maintenance and servicing, P/T
ports are imperative for temperature and ow verication,
as well as performance checks.
Water loop heat pump (cooling tower/boiler) systems
typically utilize a common loop, maintained between 60 -
90°F [16 - 32°C]. The use of a closed circuit evaporative
cooling tower with a secondary heat exchanger between
the tower and the water loop is recommended. If an
open type cooling tower is used continuously, chemical
treatment and ltering will be necessary.
Figure 12: Typical Water-Loop Application
3/8" [10mm] threaded rods
(by others)
Low Water Temperature Cutout Setting - CXM Control
When antifreeze is selected, the FP1 jumper (JW3) should
be clipped to select the low temperature (antifreeze 13°F
[-10.6°C]) set point and avoid nuisance faults (see “Low
Water Temperature Cutout Selection” in this manual). NOTE:
Low water temperature operation requires extended range
equipment.
Stainless steel braided hoses
with threaded connections
and one swivel end

Heat Controller, Inc. HBH/V CompaCt IOM Instructions
Ground-Loop Heat Pump Applications
Pre-Installation
Prior to installation, locate and mark all existing
underground utilities, piping, etc. Install loops for new
construction before sidewalks, patios, driveways, and other
construction has begun. During construction, accurately
mark all ground loop piping on the plot plan as an aid in
avoiding potential future damage to the installation.
Piping Installation
The typical closed loop ground source system is shown
in Figure 13. All earth loop piping materials should be
limited to polyethylene fusion only for in-ground sections
of the loop. Galvanized or steel ttings should not be
used at any time due to their tendency to corrode. All
plastic to metal threaded ttings should be avoided due
to their potential to leak in earth coupled applications. A
anged tting should be substituted. P/T plugs should be
used so that ow can be measured using the pressure
drop of the unit heat exchanger.
Earth loop temperatures can range between 25 and
110°F [-4 to 43°C]. Flow rates between 2.25 and 3 gpm
per ton [2.41 to 3.23 l/m per kW] of cooling capacity is
recommended in these applications.
Test individual horizontal loop circuits before backlling.
Test vertical U-bends and pond loop assemblies prior to
installation. Pressures of at least 100 psi [689 kPa] should
be used when testing. Do not exceed the pipe pressure
rating. Test entire system when all loops are assembled.
Flushing the Earth Loop
Upon completion of system installation and testing, ush
the system to remove all foreign objects and purge to
remove all air.
Antifreeze
In areas where minimum entering loop temperatures drop
below 40°F [5°C] or where piping will be routed through
areas subject to freezing, antifreeze is required. Alcohols
and glycols are commonly used as antifreeze. Freeze
protection should be maintained to 15°F [9°C] below the
lowest expected entering loop temperature. For example,
if 30°F [-1°C] is the minimum expected entering loop
temperature, the leaving loop temperature would be 25 to
22°F [-4 to -6°C] and freeze protection should be at 15°F
[-10°C]. Calculation is as follows:
30°F - 15°F = 15°F [-1°C - 9°C = -10°C].
All alcohols should be premixed and pumped from
a reservoir outside of the building when possible or
introduced under the water level to prevent fumes.
Calculate the total volume of uid in the piping system.
Then use the percentage by volume shown in table
2 for the amount of antifreeze needed. Antifreeze
concentration should be checked from a well mixed
sample using a hydrometer to measure specic gravity.
CAUTION! The following instructions represent industry
accepted installation practices for closed loop earth coupled
heat pump systems. Instructions are provided to assist the
contractor in installing trouble free ground loops. These
instructions are recommendations only. State/provincial
and local codes MUST be followed and installation MUST
conform to ALL applicable codes. It is the responsibility of
the installing contractor to determine and comply with ALL
applicable codes and regulations.
Table 2: Antifreeze Percentages by Volume
Low Water Temperature Cutout Setting - CXM Control
When antifreeze is selected, the FP1 jumper (JW3) should
be clipped to select the low temperature (antifreeze 13°F
[-10.6°C]) set point and avoid nuisance faults (see “Low
Water Temperature Cutout Selection” in this manual). NOTE:
Low water temperature operation requires extended range
equipment.
CAUTION!
CAUTION!
Type Minimum Temperature for Low Temperature Protection
10°F [-12.2°C] 15°F [-9.4°C] 20°F [-6.7°C] 25°F [-3.9°C]
Methanol
100% USP food grade Propylene Glycol
Ethanol*
25%
38%
29%
21%
25%
25%
16%
22%
20%
10%
15%
14%
* Must not be denatured with any petroleum based product
CAUTION! Ground loop applications require extended range
equipment and optional refrigerant/water circuit insulation.

IOM Instructions HBH/V CompaCt Heat Controller, Inc.
Ground-Loop Heat Pump Applications
Figure 13: Typical Ground-Loop Application

IOM Instructions HBH/V CompaCt Heat Controller, Inc.
Figure 14: Typical Open Loop/Well Application
Tanque de
Presi—n
V‡lvula
de Retenci—n
Drenajes
de Caldera
Regulador
de Flujo
Entrada
de Agua
Salida de Agua
V‡lvula
Filtro
Opcional
Tapones P/T
Air Pad or
Extruded
polystyrene
insulation board
Unit Power
Disconnect
Thermostat
Wiring
Pressure
Tank
Shut-Off
Valve
Boiler
Drains
Flow
Regulator
Water In
Water Out
Water
Control
Valve
Optional
Filter
P/T Plugs
Ground-Water Heat Pump Applications
Water Coil Low Temperature Limit Setting
For all open loop systems the 30°F [-1.1°C] FP1 setting
(factory setting-water) should be used to avoid freeze
damage to the unit. See “Low Water Temperature Cutout
Selection” in this manual for details on the low limit setting.

Heat Controller, Inc. HBH/V CompaCt IOM Instructions
Water Quality Standards
Table 3: Water Quality Standards
WaterÊQuality
Parameter
HX
Material
Closed
Recirculating OpenÊLoopÊandÊRecirculatingÊWell
ScalingÊPotentialÊ-ÊPrimaryÊMeasurement
pH/CalciumÊHardness All -pHÊ<Ê7.5ÊandÊCaÊHardnessÊ<100ppm
Method
IndexÊLimitsÊforÊProbableÊScalingÊSituationsÊ-Ê(OperationÊoutsideÊtheseÊlimitsÊisÊnotÊrecommended)
Ryznar All - 6.0Ê-Ê7.5
StabilityÊIndex IfÊ>7.5ÊminimizeÊsteelÊpipeÊuse.
Langelier All --0.5ÊtoÊ+0.5
SaturationÊIndex IfÊ<-0.5ÊminimizeÊsteelÊpipeÊuse.ÊBasedÊuponÊ150¡FÊ[66¡C]ÊHWGÊand
DirectÊwell,Ê85¡FÊ[29¡C]ÊIndirectÊWellÊHX
IronÊFouling
IronÊFe 2+ (Ferrous) All -<0.2ÊppmÊ(Ferrous)
(BacterialÊIronÊpotential) IfÊFe2+Ê(ferrous)>0.2ÊppmÊwithÊpHÊ6Ê-Ê8,ÊO2<5ÊppmÊcheckÊforÊironÊbacteria
IronÊFouling All -<0.5ÊppmÊofÊOxygen
AboveÊthisÊlevelÊdepositionÊwillÊoccur.
CorrosionÊPrevention
pH All
6Ê-Ê8.5 6Ê-Ê8.5
Monitor/treatÊas
needed MinimizeÊsteelÊpipeÊbelowÊ7ÊandÊnoÊopenÊtanksÊwithÊpHÊ<8
HydrogenÊSulfideÊ(H2S) All
- <0.5Êppm
AtÊH2S>0.2Êppm,ÊavoidÊuseÊofÊcopperÊandÊcopperÊnickelÊpipingÊorÊHX's.
RottenÊeggÊsmellÊappearsÊatÊ0.5ÊppmÊlevel.
CopperÊalloyÊ(bronzeÊorÊbrass)ÊcastÊcomponentsÊareÊOKÊtoÊ<0.5Êppm.
AmmoniaÊionÊasÊhydroxide,Êchloride,Ê
nitrateÊandÊsulfateÊcompounds All -<0.5Êppm
Maximum
MaximumÊAllowableÊatÊmaximumÊwaterÊtemperature.
ChlorideÊLevels
50¡FÊ(10¡C) 75¡FÊ(24¡C) 100ϒF (38ϒC)
Copper -<20ppm NR NR
CuproNickel -<150Êppm NR NR
304ÊSS -<400Êppm <250Êppm <150 ppm
316ÊSS -<1000Êppm <550Êppm < 375 ppm
Titanium ->1000Êppm >550Êppm >375 ppm
ErosionÊandÊClogging
ParticulateÊSizeÊand
Erosion
All
<10ÊppmÊofÊparticles
andÊaÊmaximum
velocityÊofÊ6ÊfpsÊ[1.8Êm/s].
FilteredÊforÊmaximum
800ÊmicronÊ[800mm,
20Êmesh]Êsize.
<10ÊppmÊ(<1ÊppmÊ"sandfree"ÊforÊreinjection)ÊofÊparticlesandÊaÊmaximum
velocityÊofÊ6ÊfpsÊ[1.8Êm/s].ÊFilteredÊforÊmaximumÊ800ÊmicronÊ[800mm,
20Êmesh]Êsize.AnyÊparticulateÊthatÊisÊnotÊremovedÊcanÊpotentially
clogÊcomponents.
Notes: Rev.: 01/21/09B
• NR - Application not recommended.
• "-" No design Maximum.
• Closed Recirculating system is identified by a closed pressurized piping system.
• Recirculating open wells should observe the open recirculating design considerations.
AboveÊtheÊgivenÊlimits,ÊscalingÊisÊlikelyÊtoÊoccur.ÊÊScalingÊindexesÊshouldÊbeÊcalculatedÊusingÊtheÊlimitsÊbelow
ScalingÊindexesÊshouldÊbeÊcalculatedÊatÊ150¡FÊ[66¡C]ÊforÊdirectÊuseÊandÊHWGÊapplications,ÊandÊatÊ90¡FÊ[32¡C]ÊforÊindirectÊHXÊuse.Ê
AÊmonitoringÊplanÊshouldÊbeÊimplemented.

IOM Instructions HBH/V CompaCt Heat Controller, Inc.
Electrical - Line Voltage
Electrical - Line Voltage
All eld installed wiring, including electrical ground, must
comply with the National Electrical Code as well as all
applicable local codes. Refer to the unit electrical data for
fuse sizes. Consult wiring diagram for eld connections
that must be made by the installing (or electrical)
contractor. All nal electrical connections must be made
with a length of exible conduit to minimize vibration and
sound transmission to the building.
General Line Voltage Wiring
Be sure the available power is the same voltage and
phase shown on the unit serial plate. Line and low voltage
wiring must be done in accordance with local codes or the
National Electric Code, whichever is applicable.
WARNING! To avoid possible injury or death due to
electrical shock, open the power supply disconnect switch
and secure it in an open position during installation.
CAUTION!
Use only copper conductors for eld installed electrical
wiring. Unit terminals are not designed to accept other types of
conductors.
WARNING!
CAUTION!
Transformer
All 208/230 voltage units are factory wired for 208
volt. If supply voltage is 230 volt, installer must rewire
transformer. See wire diagram for connections.
