Heater Sports Sandlot 2-in-1 User manual

IMPORTANT
DO NOT RETURN THIS PRODUCT TO THE RETAIL STORE WHERE
PURCHASED. CALL TOLL FREE: [phone]
WARNING:
Improper use of this product can result is serious injury. Read and follow the instructions
for the proper and safe use of the Sandlot 2-in-1. Always wear a helmet with a guard.
Adult supervision is required. Inspect the Perfect Swing, rubber bands, base, clamps, etc., before
each use for evidence of any damage. Keep the area clear with-in 24 ft. of the device and
around the swinging area of the batter. Always hit the ball toward an open unoccupied area.
Make sure all knobs and clamps are tightly and securely fastened. Never hit toward
another person. Do not use if damaged or broken.
Instructions
95 West 650 South • St. George, Utah 84770 • PH: 800-492-9334 • PH: 435-656-1756 • Fax: [phone]
®
Follow All Instructions Before Assembling Or Using This Product

Part List
Model# SNDLT2IN1
A - Large Metal Washer
B - Center Pole
C - Rubber Washer (x2)
D - Base Bolt
A
95 West 650 South • St. George, Utah 84770 • PH: 800-492-9334 • PH: 435-656-1756 • Fax: [phone]
®
E - Lock Washer
F - Bolt Wrench
G - Tension Rubber Bands (x10)
H - Base Insert Tube
I - Swivle/Handle Clamp
J - Support Plate
K - Perfect Swing Batting Stick
L - Base Part 1
M - Base Part 2
B
CD
E
F
G
H
I
K
L
M
J

Slide one of the Part C (Rubber Washers) over
the bottom end of Part B (Center Pole). Slide
Part J over the pole end next. Position the
slight bend in Part J towards the top end of the
pole (Part B) as seen in Figure 1.
Then slide Part H (Base Insert Tube) over the
bottom end of the pole (Part B). Insert the
bottom end of Part B into the top of the center
hole of the Base Part L as seen in Figure 2.
1 -
Align Base Part L and Base Part M so that the
Pole and Insert Tube line up. Push the base parts
together. Figure 3. Make sure the Support
Plate (Part J) aligns with the grove in the base.
Now place Part C (Rubber Washer) and Part A
(Large Metal Washer) on the bottom side of the
Base over the center hole as seen in Figure 4.
Place Part E (Lock Washer) on top of Part A and
insert Part D (Base Bolt) through the washers
and into Part B in the bottom of the Base as seen
in Figure 5.
Securely tighten Part D with the supplied Bolt
Wrench (Part F). NOTE:Tighten the Bolt enough
to keep the pole from twisting when the ball is
hit. Do Not Overtighten the Bolt.
The Bolt should not touch the ground when the
base is placed upright.
Assembly Instructions
2 -
3 -
Figure 1
B C H
Figure 2
L
L
M
Figure 3 Figure 4
Figure 6Figure 5
C
A
J

Remove the Rubber Cap on the Center Pole (Part B) and Slide the Swivle/
Handle Clamp (Part I) on to the Center Pole & then replace the Rubber
Cap. Figure 7.
4 -
Assembly Instructions Cont. Figure 7
I
Figure 8
To adjust the height of the Batting Stick loosen the knob on the adjustment collar
attached to the center pole.Then slide the adjustment collar on the B - Center Pole,
into the position you desire. Figure 8.
Tighten the knob securely after selecting the proper height.
Then allow the Swivle/Handle Clamp holder to rest on top of adjustment collar.
As seen in Figure 8.
5 -

Next wrap two Part Gs (Tension Rubber Bands) around Part H. Begin by pulling
one end of the Rubber Band through the loop of the
opposite end as shown in Figure 7.
Note: Make sure to use two Rubber Bands for the necessary spring back strength.
(The Sandlot 2-in-1 comes with ten tension rubber bands, from time to time it may be
necessary to replace worn or broken rubber bands.Just follow the instructions on this
page to replace them as needed.)
6 -
After wrapping the Rubber Band around the pole, pull the free end until you can
hook the Rubber Band over the“S”Hook as shown in Figure 8.
7-
After attaching the Rubber Bands to the“S” Hook make sure the rubber bands
around the pole are pulled tight to keep them from sliding around the pole when hit.
If the rubber bands still slide around the pole you may want to use black tape to
secure the Rubber Bands to the Pole by taping over the Rubber Bands and Pole
where the two join.
This will keep the Rubber Bands in place when the bands are not tight around the
pole. See Figure 9.
8-
Figure 9
Assembly Instructions Cont.
Figure 10
Figure 11

With the two knobs and lock washers removed, slide the “U”shaped
side of the clamp off of the fixed side of the clamp. See Figure 12.
9 -
After removing the clamp place the handle of the Perfect Swing batting stick
into the clamp and replace the “U”shaped side of the clamp.
Note: Make sure the handle of the Perfect Swing is centered so that the
clamp will fit perfectly around the grip and hold securely.
Important: Make sure to position the Perfect Swing so that the safety strap
attached to the ball end of the Perfect Swing is on the back side of the ball
and neck, facing away from the hitter.
10 -
Figure 12
Assembly Instructions Cont.
Figure 13
With the Tension Rubber Bands (Part G) attached, remove both knobs and
lock washers from the“U”shaped clamp on Part 1. See Figure 12.

The Sandlot 2-in-1 can be used on hard surfaces,
grass and dirt. Simply remove the Rubber Stoppers
in the Base and fill the Sandlot 2-in-1 with water,
sand or cement.Water or sand will be sufficient for
most children under 12 years of age. Cement may
be necessary for older children and adults.
This will help to keep the Sandlot 2-in-1 stationary
swing after swing.
12 -
Figure 15
Rubber Stoppers
Assembly Instructions Cont.
Once the clamp is in position with the Perfect Swing batting stick inserted,
replace the lock washers and the knobs and tighten until the batting stick is
securely in place. See Figure 14.
Note: You may wrap the wrist strap of the Perfect Swing through the eye
of the swivel and around the clamp knobs. Keeping the wrist strap away
from the swivel function.
11 -
Figure 14

The batter should take a position where the point of
contact is on the ball of the Perfect Swing batting stick.
Avoid contact to the shaft of the batting stick as this may
cause damage to the device.
•
Multiple Tension Rubber Bands are provided
with the Sandlot 2-in-1. After repeated use the
Rubber Bands may become weak or break.
Simply replace the worn bands when needed.
Do not use the Sandlot 2-in-1 without the neces-
sary Rubber Bands.This may cause undue stress
on the Base and Pole.
•
The Sandlot 2-in-1 is basically two training
devices in one.You can remove the Perfect
Swing batting stick and use it as a two
person training stick.
Hold the Perfect Swing batting stick with
both hands using the strap to secured the
batting stick to the wrist. Position the ball in
the desired location for the batter to hit.The
holder should not fight the momentum of
the contact but rather go with it.
Follow all instructions and warnings
when using these products.
•
Instructions For Use
