Heatilator ECO-ADV-PS35 User manual

1 7058-206I August 21, 2018
NOTICE: DO NOT DISCARD THIS MANUAL
Owner’s Manual
Operation & Care
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
PELLET BURNING STOVES
MODEL(S):
ECO-ADV-PS35
ECO-ADV-PS50
ECO-CAB50
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
CAUTION
Check building codes prior to installation.
• Installation MUST comply with local, regional, state
and national codes and regulations.
• Consult local building, re ofcials or authorities
having jurisdiction about restrictions, installation
inspection, and permits.
If the information in these instructions is not
followed exactly, a re could result causing
property damage, personal injury, or death.
WARNING
• Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any other
appliance.
• Do not over re - If appliance or chimney connector
glows, you are over ring. Over ring will void your
warranty.
• Comply with all minimum clearances to combustibles
as specied. Failure to comply may cause
house re.
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
WARNING
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
replace.
• Alert children and adults to hazards of high
temperatures
• High temperatures may ignite clothing or other
ammable materials.
• Keep clothing, furniture, draperies and other
ammable materials away.
CAUTION
Tested and approved for wood pellets, Burning of any
other type of fuel voids your warranty.
NOTE
To obtain a French translation of this manual, please
contact your dealer or visit www.heatilator.com.
Pour obtenir une traduction Francaise de ce manuel, s’il
vous plait contacter votre revendeur ou visitez
www. heatilator.com.

2 7058-206I August 21, 2018
HEATILATOR ECO CHOICE
CONFIDENTIAL PROPERTY OF HEARTH & HOME TECHNOLOGIES INC.
PART NAME:
DRAWN BY: SCALE: MATERIAL:
SHEET:
PART NUMBER: REV:
THIS PRINT IS CHECKED AND CONTROLLED BY THE ENGINEERING
DEPARTMENTS OF HEARTH & HOME TECHNOLOGIES INC.
ECO # DATE BYREV
UNLESS OTHERWISE SPECIFIED DIMS ARE INCHES[MM] & : TOLERANCES ARE: (2) PLACE DEC : ± 0.03 (3) PLACE DEC: ± 0.005 ANGLE: ± 2° FRACTION: ± 1/16
OUTSIDE MATERIAL. NORMAL DIM & INSIDE MATERIAL. OUTSIDE APEX INSIDE APEX - DIMS ENCLOSED BY AN OVAL ARE CRITICAL DIMENSIONS
REVISIONS
ITEM PART NUMBER PART NAME QTY
9.88
U.S. ENVIRONMENTAL PROTECTION AGENCY
Certified to comply with 2015 particulate emission standards at 2.1 g/hr EPA method 28 and 5G. Not approved for sale after May 15, 2020.
This wood heater needs periodic inspection and repair for proper operation. Consult the owner’s manual for further information. It is against federal
regulations to operate this wood heater in a manner inconsistent with the operating instructions in the owner’s manual.
7058-143_R7
* Non-combustible floor protection must extend 2 inches
(51mm) beneath the flue pipe when installed with horizontal
venting or under the Top Vent Adapter with vertical installation.
RECOMMENDED IN USA; REQUIRED IN CANADA.
*Un protecteur incombustible de plancher doit s'étendre 2 inches (51mm)
sous le conduit de cheminée pour une installation de ventilation horizontale
ou sous un adapteur de ventilation de dessus pour une installation verticale.
ÉTATS-UNIS - RECOMMANDÉ; CANADA - REQUIRENT.
Floor protector must be non-combustible material, extending
beneath heater and to the front/sides/rear as indicated.
Measure front distance (I) from the surface of the glass door.
Le poêle doit être placé sur une assise non combustible s’étendant tout
autour de lui, comme les schémas l’indiquent. Mesurez la distance du
devant (I) de la surface de la porte vitrée.
2017 2018 2019 JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC
34,400 34,400
ECO-ADV-PS35
Conforms to ASTM STD E1509, Certified to ULC STD S627, ULC/ORD-C1482-M1990 Room
Heating Pellet Burning Type, (UM) 84-HUD FOR USE ONLY WITH PELLETIZED WOOD
FUEL. Do not use any other type of fuel.
Manufactured by: Fabriqué par:
352 Mountain House Road
Halifax, Pa 17032
www.heatilator.com
4001508 Serial No.
N° de série HF BARCODE LABEL
A. Sample of Serial Number / Safety Label
LOCATION: On chain behind right access panel & Behind left access panel
NOTE: Clearances may only be reduced by means approved
by the regulatory authority having jurisdiction
and Welcome to the Quadra-Fire Family!
Test Lab
and Report
Number
Model Name
Serial Number
Manufacturer
Date
SAMPLE

August 21, 2018 7058-206I 3
HEATILATOR ECO CHOICE
A. Sample of Serial Number / Safety Label ......... 2
B. Warranty Policy ............................ 4
C. Quick Start Guide .......................... 6
1 Listing and Code Approvals ..............7
A. Appliance Certication....................... 7
B. BTU & Efciency Specications ............... 7
C. Glass Specications ........................ 8
D. Electrical Rating (on high) .................... 8
E. Mobile Home Approved ...................... 8
F. Sleeping Room ............................ 8
G. California - Prop65 ......................... 8
2 Operating Instructions .......................9
A. Fire Safety ................................ 9
B. Non-Combustible Materials ................... 9
C. Combustible Materials....................... 9
D. Fuel Material and Fuel Storage................ 9
E. General Operating Information ............... 10
F. Before Your First Fire ....................... 10
G. Hopper Lid Latch and Hopper Switch .......... 11
H. Starting Your First Fire ..................... 11
I. Fire Characteristics......................... 12
J. Feed Rate Adjustment Instructions ............ 12
K. Ignition Cycles ............................ 12
L. Clear Space .............................. 12
M. Frequently Asked Questions................. 13
3 Maintenance and Service.................15
A. Proper Shutdown Procedure ................. 15
B. Quick Reference Maintenance Chart .......... 15
C. General Maintenance ...................... 16
D. High Ash Fuel Content Maintenance........... 20
E. Soot or Creosote Fire ...................... 20
4 Troubleshooting Guide.....................21
5 Service Parts Replacement..............24
A. Convection Blower Replacement ............. 24
B. Exhaust Blower Replacement ................ 25
C. Snap Disc Replacements ................... 25
D. Igniter Replacement ....................... 26
E. Bafe Removal & Replace .................. 26
F. Glass Replacement ........................ 27
6 Reference Materials..........................28
A. Component Functions ..................... 28
B. Component Locations ...................... 30
C. Maintenance and Service Log................ 31
D. Exploded Drawings & Service Parts - PS35 ..... 32
E. Exploded Drawings & Service Parts - PS50 ..... 36
F. Exploded Drawings & Service Parts - CAB50 .... 40
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
Heatilator is a registered trademark of Hearth & Home Technologies.
