HEBE EGP-1000 User manual

2
③Once the charge has been completed, disconnect the connected socket and put the
charging socket cover in the socket to prevent water or soiling from entering to the socket.
④If the orange LED on the front button blinks while using the product, connect the charger to
charge the battery.
※ Notice
Fully charge the battery before the initial use of the product.
Use an adapter with an output voltage of 5V and a current of 1.2A or more.
Blinking orange light
①Connect a USB cable to the socket in a regular cell phone charger, a computer or a portable
battery charger.
②Open the socket cover of the charger connect socket in the bottom of the rear side of the
product and connect the charger cable to the socket.
- While charging the device, the orange LED on the front button will blink.
- Once the charge is complete, the orange LED on the front button is lit until the charging
cable is removed from the product.
How to charge the product
7
7
Product specications
Items Contents
Product name Portable Hydrogen Rich Water Generator
Model name EGT-1000
Size of the main body Ø 70 X H 220mm
Weight 360g
Power Voltage DC 5V / 1.2A
Hydrogen generation
time 5 minutes, 8 minutes
Charging time
Rechargeable battery
90-150 minutes (Use 25-40 times when fully charged)
Available
water temperature Below 60℃
DC 3.7V
• Before requesting the maintenance service, please check the following details.
If the problems are still remained after the inspection, contact the dealer or the
customer service center.
Symptoms
Hydrogen bubbles are
weak or not generated
• Check the power status of the product
and charge the main body.
• Cleaning it by following the instruction of
cleaning hydrogen generation device.
• Move the product so that the oxygen
outlet in downside of the product is not
blocked.
LED does not light • Check the power status of the product
and charge the battery.
• Discharge of battery
• Discharge of battery
• Impurities in the hydrogen
generation device
• Blocked oxygen outlet in
downside of the product
Probable causes What to do
Big bubbles are
produced
Power o after the
orange LED is blinking
• Wet the electrode part with water
thoroughly. Continued use of the
product will stabilize the electrode part.
• Fill up water in the bottle.
• Use water containing adequate amounts
of minerals.
• Operate with the dried
electrode part
• Lack of stabilization time for
the electrode part
• Operate without water in the
bottle
• Use water containing
too much minerals
The orange LED is
continuously blinking,
while generating
hydrogen water
• Charge the battery.
• Battery discharge warning
Not charging
• Check the connection status between
the charging cable and the charging
socket of main body.
• Try another charging cable.
• The connection status of the
charger or the charging USB
cable is poor (contact failure)
• The breakdown of the charger
or the charging cable
Appears in ne mist
form when generating
hydrogen water
• Turning o power and it appears in
clean state instantly.
• The phenomenon of
generating high concentrated
hydrogen bubbles which is
caused by adding extra
hydrogen into hydrogen water
Operating sound
when generating
hydrogen water
• No problem.
• It is sound from generating
hydrogen bubbles
Check before requesting repair service
8
1. This product has been passed the comprehensive inspection through the strict
quality control at the factory.
2. Any defect occurring within the warranty period (one year from the date of
purchase) will be free of charge from the dealer or customer service center.
However, even if it is within the warranty period, if it is covered by the charged
warranty service within this warranty, it will be repaired at a cost.
3. If the product malfunctions, please contact the dealer or customer service center.
4. When requesting the repair service, the warranty should be presented.
5. After purchasing the product, please ll out the form of the warranty and keep it.
Warranty details
1. This product will be repaired free of charge in case of any defect in manufacturing
or normal operation within the warranty period.
2. Even during the warranty period, the following cases will be repaired at a cost.
①Poor performance and failure occurred after the warranty period has expired
②Failure due to incorrect or careless handling of consumer
③Damage caused by intention or negligence of the consumer
④Failure caused by repair or alteration at a place other than our service center or
retail store
⑤Failure due to abnormal power supply or faulty of connected equipment
⑥In case of the part reaches its end-of-life
⑦Failure or defect in the product due to natural disasters
⑧If there is no product warranty, or if there is no item on the date of purchase or
dealer
3. Failure occurs after the expiration of the warranty period will be repaired at a cost.
www.aquacentrum.de & www.aquacentrum.com
Product name Portable Hydrogen
Rich Water Generator Model name EGP-1000
Serial number
Date of purchase
Contact number
of dealer
Dealer
Contact
Customer's
name
Address
Warranty
1
Product Components
Name of each part
Electrode part
(platinum electrode plate)
Charger
connect socket
Socket cover
Front button
Rechargeable
battery
Battery
replacement
cover
Oxygen outlet
Product main body
(hydrogen generator) USB charging cable Bottle and cap Citric acid
Citric
acid
• Product components ··························· 1p
• Name of each part
······························ 1p
• How to charge the product
··················· 2p
• Safety information
······························ 4p
• How to use the product
······················· 5p
• How to clean the product
····················· 6p
• Check before requesting repair service
···· 7p
• Product specications
··························· 7p
• Warranty
··········································· 8p
Portable Hydrogen Rich Water Generator
EGP-1000
User’s Manual
World No.1
Hydrogen Technology
※Color and design of the product may dier
from the image.
HEBE is the goddess of youth in Greek mythology. She is the daughter of Zeus and Hera, She married
Heracles. HEBE developed by EGT is a state-of-the-art energizer that creates fountain of youth.

3
Keep the following instructions which guide users to use the product safely and accurately to
prevent unexpected risks or losses.
There is a possibility of serious injury or death in violation of the
instructions.
There is a possibility of injury or damage to the product when violating
the instructions.
Warning
Caution
Warning
A short circuit or heat can be caused by using damaged charger or USB cable, causing
abnormalities in the hydrogen generation part, such as heat or odor. Immediately stop
the device and disconnect the charger from the outlet. It may cause re, electric shock,
and malfunction. Contact the dealer or the customer service center.
Do not bend the USB cable severely or press it with heavy objects. Otherwise, it may
cause electric shock or re by stopping power supply.
Do not touch the power plug with wet hands. It may cause electric shock, re,
or malfunction.
Do not heat the product in the microwave oven or put it in the dish washer. Do not
freeze it in the freezer. There are risks of breakage of the product, explosion of batteries
or electric shocks.
Do not tie, fold, damage, pull the USB cable or stretch it by putting the heavy object on.
There are risks of re or electric shock.
Do not disassemble, repair, or alter the product when it is malfunctioning. There are
risks of electric shock or re. Contact the dealer if the maintenance is required.
Do not immerse the hydrogen generator in water.
It causes electric shock, re, and malfunction.
Safety information
Do not use the charger or the USB cable in wet conditions, dry it thoroughly and use it.
Do not pull the charger cable while moving the product. It causes re or malfunction
of the product.
Do not inspect or repair the product while it is connected to power.
The hydrogen generator should be activated once in a time. Generating hydrogen
several times with the lid closed may cause damage to the container by the pressure
created from hydrogen generation processes.
Use the charger (cell phone charger/computer/portable battery) with an output
voltage of 5V DC and a current of 1.2A or more to charge the product.
Be aware that using voltages above 5V or higher causes product failure.
Be aware that if the oxygen outlet on the underside of the product is blocked, it will
cause malfunction.
If there are any problems with the product, please contact the dealer or the customer
service center rst. Do not arbitrarily disassemble, alter, or repair the product. It may
cause re, electric shock, malfunction, and abnormal operation.
Use a reliable charger that is certied by the country. Use the USB cable which
is provided by us or reliable and safe product.
Do not use the product in case of heating or unusual smelling from the product.
Disconnect the USB cable and shut o the power immediately and then contact the
customer service center.
Do not allow the battery uid to come into contact with the skin when it comes out.
If it comes in contact with the skin, immediately wash it with water. It may cause skin
damage.
Turn on the device with water in it.The hydrogen generation device can be damaged
if it is operating without water.
4
Use drinkable water. In case of using liquid except water, clean the product with citric
acid within one hour (See Cleaning with citric acid at page 6). It is hard to deodorize
the product if neglect for longer period of time. Also, impurities attach to the electrode,
which cause malfunction of the product.
- Do not use sticky liquid or liquid with sediment, such as carbonated drinks, green tea,
liquor, or fruit juice. It may cause electrode malfunction by impurity. Also, it may cause
trouble in cleaning and discomfort for persisting odor.
Do not apply severe impact on the body of the product. Do not use the product if it is
dropped or damaged. It may cause re, electric shock, or abnormal operation.
Do not let the children use the product alone without parents. When using the product,
keep it out of the reach of children.
Do not use water above 60℃. Using at high temperature may cause burn or abnormal
operation, such as degradation.
Use the product in a at place to prevent the product from fall while the hydrogen
generation process.
Do not move the product while the hydrogen generation process.
Use water to clean the surface of the product. Do not use thinner, benzene, wax, etc.
The product may discolor or the paint may peel o.
Do not completely dry the electrode. Always keep the electrode wet. If the product is
unused for long periods, store the electrode with enough clean water to ll it.
In case of using the product for the rst time or in case of the electrode is completely
dry for long term disuse (more than one week), ll the bottle with water and use it after
about 20 minutes. If the electrode is suciently wet, the eciency of hydrogen
generation is improved.
Do not use water with the performance of the product. It may cause damage to the
electrode and degrades the performance of the product.
Do not clean the inside of the body with chemical detergent. It may cause damage to
the electrode.
Caution
Do not connect the charger cord for long hours (more than 5 hours).
When not in use the product for long periods of time, remove the USB cable from the
product.
When using the product, keep it out of the reach of children.
The charger should be securely connected to the power connector. If it doesn't, it may
cause re or malfunction of the product.
Do not plug in or unplug the charger plug in a row. Spark may occur.
5
How to use the product
①When using the product for the rst time, open the cap in the
upper-side of the product and ll it about half full of room
temperature water and shake it several times to wet the electrode.
Clean the container and throw out water.
①
②Open the upper cap of the product and ll the water.
Only drinkable water should be used.
②
③When pressing the front button for about 1.5 seconds, the blue LED,
on the front button, illuminates. Then, the device generates hydrogen
for 5 minutes and automatically turns o.
④When richer hydrogen content is needed, press the front button once again within
3 seconds after blue LED is on. Then, green LED will be on and blink. The product will
generate hydrogen for 8 minutes and automatically turn o.
⑤Press the front button for about 1.5 seconds. The device will stop functioning and
power o. To add extra hydrogen into water which already has hydrogen, open the
upper-side cap before the generation to decline pressure in the bottle. Then, press the
button to operate hydrogen generation processes. Otherwise it may be dicult to open the
upper-side cap.
⑥Using the product after the long interval, use it after cleaning the hydrogen generation
device (See,‘How to clean’on page 6).
LED color display content
• Blue
• Blue blink
• Green
• Green blink
• Orange blink
• Orange
: Power on and activation of hydrogen generation for 5 minutes
: 5 minutes hydrogen generation start and soon ending notice
: Activation of hydrogen generation for 8 minutes
: 8 minutes hydrogen generation start and soon ending notice
: The battery needs to be charged or the device is charging in case of the
charging cable is connected. Error (operate without water, short, use
water with too much mineral)
: The charging is completed
The front button
LED
③
⑤
④ ⑤
※ Precautions when using the product
• The hydrogen generation electrode is sensitive and its performance can be easily declined
by touch or scratch, so handle it carefully.
• Do not use liquid with other substances, such as sparkling water, liquor, tea, and others.
It may cause malfunction or the product's quality (odor, degradation, cleaning problems,
and others).
• Using water contained too much mineral to generate hydrogen water, the mineral attaches
to the hydrogen generation device, so continuous electrode cleaning is needed.
• Store the product avoiding locations where there is a high temperature or heat source, such
as a heater.
LED
6
• Cleaning the container
- Use the water bottle after cleaning it with a soft cloth or sponge and rinsing it thoroughly.
• Cleaning the surface of the main body
- Be careful not to wet the power socket and the battery when cleaning dirt and debris
outside the body.
• Deodorization
- Prolonged use of the product may cause the hydrogen generating part to smell. Pour hot
water (below 60℃) in the hydrogen generation part, throw out water after about
20 minutes and use the product.
- The odor from the hydrogen generation part is not related to the performance of the
product and does not aect to taste of water.
- Routinely clean the containers of hydrogen generation part to prevent the occurrence of
odor.
· When large amounts of calcareous or minerals are accumulated
- Fill the water bottle with water about two third full and put 5g of citric acid and shake
the bottle multiple times and leave it for about one hour. After then, throw out water and
rinse the bottle 3-4 times with clean water and use the product.
※ At the last rinse after cleaning the bottle, ll it with water and throw out water after about
20 minutes. The remained wash liquid and odor will be removed, so you can use the water
bottle more cleanly.
• In case of using vinegar to clean the product, pour small amount of water to cover the
platinum electrode and put 2-3 drops of vinegar and throw out water after 5-10 minutes
and rinse the bottle 3-4 times with clean water and use the product.
Vinegar
How to clean the product
• When generating hydrogen, the mineral in the water is attached to the electrode and
hydrogen generating part. Routine maintenance is required to maintain product performance
for a long time.
• Cleaning the hydrogen water generation device
Regularly use citric acid or vinegar to clean the product when using it.
- Fill the water bottle with water about two third (about 230ml) full and add about 5g of
citric acid and shake the bottle 4-5 times for 5 minutes. After then, throw out water and
rinse the bottle 3-4 times with clean water and use the product.
· In case of regular cleaning
About two third
Citric acid
