HEDBOX RP-NPF770 User manual

EN English
Lithium - Ion
DV Battery Pack

# 1
EN English
Battery Pack Operating Instructions
Before operating the unit, please read this manual thoroughly and save it for future reference.
Important Safety Instructions
• If the battery pack is mishandled, the battery pack can burst, cause a fire or even chemical burns.
• Observe the following cautions:
• Do not disassemble.
• Do not crush and do not expose the battery pack to any shock or force such as hammering,
dropping or stepping on it.
• Do not short circuit and do not allow metal objects to come into contact with the battery terminals.
• Do not expose to temperatures higher than 60°C (140°F) direct sunlight or in car parked in the sun.
• Do not incinerate or dispose of in fire.
• Do not handle damaged or leaking lithium ion batteries.
• Be sure to charge the battery pack using a genuine Hedbox battery charger or a device that can
charge the battery pack.
•Keep the battery pack out of the reach of small children.
• Keep the battery pack dry.
• Replace only with the same or equivalent type recommended by Hedbox.
• Dispose of used battery packs according to the instructions.
• Do not use this battery pack near water.
• Clean only with a dry cloth.
• Do not install near any heat sources such as radiators, heat registers, or appliances that produce heat.
• Only use attachments/accessories specified by the manufacturer.
• Unplug this battery from the supply unit during thunderstorms or when unused for long periods.
• Refer all servicing to qualified service personnel. Servicing is required when the battery pack has been
damaged in any way, such as power plug damage, liquid spill or dirt in the battery pack, the battery has
been exposed to rain or moisture, does not operate normally, or has been dropped.
Overview / Features
This battery pack uses Lithium-Ion battery cells.
Use the battery pack only with equipment whose operating instructions recommend its use.
Charging the battery pack
• You don’t have to discharge the battery pack before recharging.
• Charging while some capacity remains does not affect the original battery capacity.
• To charge the battery efficiently, fully charge it in an ambient temperature of 10 °C -30 °C (50 °F - 86 °F).
• The battery pack discharges naturally over time. To extend battery life, it is recommended that you fully
charge the battery pack before using it.
• The battery pack may become warm while used or being charged. This is normal. Battery pack
performance decreases in low-temperature surroundings.
• To conserve battery power, we recommend that you keep the battery pack dry and warm, and only
insert it in your electronic device just before use.
• If the power goes off even though the remaining battery time shows that it has enough power to operate,
charge the battery pack fully again so that the correct remaining battery time is shown. Note that the
remaining battery time is sometimes not restored if used in high temperatures for a long time or left in
a fully charged state, or if the battery pack is frequently used. Also regard that the remaining battery time
is shown as the approximate recording time.
WARNING
• Battery pack shouldn’t be exposed to excessive heat such as sunshine, fire, etc.

# 4
EN English
Caution on Use
CAUTION:
• Never short-circuit the battery pack terminals.
• Never attempt to open the battery pack.
• Avoid mechanical shock.
• Never expose the battery pack to rain or moisture.
• Keep away from children.
• Never expose the battery pack to temperatures above 60°C (140°F)
• Please consult the store where you purchased this battery pack or your sales representative before
using the battery pack in a product whose Operation Manual/Operating Instruction does not explicitly
state that the battery pack can be used, or before using the battery pack in conjunction with another
power supply. Inappropriate use of the battery pack may result in unit misoperation.
• The internal impedance of the battery pack increases as the temperature drops to 5°C (41°F) or below.
This may result in a shorter operating time or the failure of the component to which it is connected to.
This occurs more frequently in battery packs that have been charged many times than in new ones.
• The performance and operating time of the battery may drop under cold conditions.
• Charge the battery pack only with the HEDBOX charger model or any other model dedicated to this
type of battery within a temperature range of 10°C to 30°C (50°F to 86°F).
• A large discharge amount may accelerate the deterioration of the battery pack’s internal cells.
To prevent this, use the battery pack with a discharger amount of about 3 A or less.
• The maximum discharge amount is 3.5 A for this model of battery at 23°C (73°F).
Continuous use at levels beyond the maximum discharge level may cause the protection circuit to shut
off the current to protect the internal cells.
How to store the battery pack
• Store the battery pack in temperatures between 0°C to 23°C (32°F to 73°F).
• If the battery pack is to be stored for a short period (approximately more than 24 hours and a
month or less), discharge it to 90% of its total capacity to prevent deterioration of its internal cells.
• When storing the battery pack for an extended period (more than a month) it is recommended
to discharge it to about 50% of its full capacity. (The two LEDs light up)
While the battery pack is stored, charge it until the capacity reaches 50% once every six months.
• If the battery pack terminals become dirty or dusty, clean them with a soft cloth.
Dispose of Battery Pack
• This product with CE marking complies with the EMC Directive issued by the Commission.
By ensuring that these batteries are disposed of correctly, you will help prevent potentially negative
consequences for the environment and human health which could otherwise be caused by
inappropriate waste handling of the battery. The recycling of the materials will help to conserve natural
resources. To ensure that the battery will be treated properly, hand over the product at the end of its life
to the applicable collection point for the recycling of electrical and electronic equipment.
• Hand the battery over to the applicable collection point for the recycling of waste batteries.
• For more detailed information about recycling of this product or battery, please contact your local Civic
Office, your household waste disposal service or the shop where you purchased the product.

# 5
EN English
Battery life
• Battery life may be shortened due to storage or operation in high temperatures, storage when in full
capacity, and frequent use.
• Replace the battery pack when the operating time with a completely charged battery pack becomes
noticeably short or all LEDs flash because the self-diagnostics function has detected the end of battery life.
• If a Battery pack is deteriorated, not all LEDs will light when the CHECK button is pressed just after
charging is completed.
Self-diagnostic function
• When an abnormality is detected, all the LEDs will flash. If this happens, stop using the battery
pack immediately. Once the LEDs start flashing, the battery pack cannot be recharged.
If you can’t charge the battery:
If you canot charge the battery pack
• The first time you try to recharge this battery, the charger doesn't respond to charging operation.
If this happens, remove the battery from the battery charger and then reconnect it.
- The battery has been left for a long time
- The battery has been left in the camera for a long time
- Immediately after purchase
• If the charging operation fails for the second time, there may be a
fault with the battery or the battery charger. Stop using them and contact your Hedbox dealer.
Battery life
• The battery life is limited. If the remaining battery time is considerably shortened, the battery
pack is reaching the end of its life. Replace with a new one. The battery life varies in each battery
pack according to the storage, operating conditions and environment.
To the purchasers of the battery pack
• This Lithium-Ion Battery Pack can be transported as a non-hazardous lithium-ion battery.
Related laws and regulations are, however, subject to change. For detailed conditions regarding the
transport of battery packs, please consult your chosen air transport company.
European standards:
• EN55103-1: Electromagnetic Interference (Emission)
• EN55103-2: Electromagnetic Susceptibility (Immunity)
This product is intended for use in the following Electromagnetic Environments:
E1 (residential),
E2 (commercial and light industrial),
E3 (urban outdoors),
E4 (controlled EMC environment, ex. TV studio).
• Once the protection circuit activates, the battery pack will not automatically return to normal operational
status. To cancel the effect of the protection circuit, you must charge the battery pack with a charger
dedicated to the lithium-ion battery pack.

# 6
Lithium-ion
Sony NPF
18650 x 4
7.4 V DC
4400mAh
32.6 Wh
approx. 240 min. on charger RP-DC50
–20°C to 45°C (-4°F to 113°F)
Built-in Microprocessor for Sony Data com
40 x 69 x 36 mm | 1.57 x 2.71 x 1.41”
~ 200 g | 7.05 oz.
Cells Framing Construction System
RP-NPF770 Battery Pack
EN English
Specification
Cell Chemistry:
Mount Type:
Internal Battery Cells:
Nominal Volatge:
Battery Capacity (mAh):
Battery Capacity (WH):
Internal Construction:
Charging Time:
Operating Temperature:
Comunication protocol:
Dimensions (W/H/D):
Net Weight:
Model name:
No compensation for contents of the recording
• The content of the recording cannot be compensated if shooting or reproduction are not possible
due to a malfunction of the battery pack or other devices.
• Design and specifications are subject to change without notice.
If you want to know more about HEDBOX Products please visit our
website: www.hedbox.com

# 7
EN English
Note:
Always ensure that the unit is operating properly before use.
HEDBOX WILL NOT BE LIABLE FOR DAMAGES OF ANY KIND
INCLUDING, BUT NOT LIMITED TO, COMPENSATION OR
REIMBURSEMENT ON ACCOUNT OF THE LOSS OF PRESENT
OR PROSPECTIVE PROFITS DUE TO FAILURE OF THIS UNIT,
EITHER DURING THE WARRANTY PERIOD OR AFTER EXPIRATION
OF THE WARRANTY, OR FOR ANY OTHER REASON WHATSOEVER
