PowerWalker BP P240T-40x9Ah Administrator Guide

S.O.P. – How to assemble BP P240T-40x9Ah
Long battery plate
Long battery plate
Cable tie
Insulator
M4*8 screw
2
1
2
3
3
1、Put insulator on battery plates; fix battery plates( wider side is on the top) and
cable tie.
Torque:16kgf-cn
Cross screw torque
4
、
fix BAT+
、
BAT-
、
BAT1+to rear panel by
cable tie.
5
、
Paste the cable tie
as shown in the
picture. The opening
of cable tie is
outward.
6
、
Paste the cable tie
as shown in the
picture.
The opening
of cable tie is
outward.

Battery
Insulator 40
20
2. Put 2 pieces of batteries into insulator as shown below. Totally there are 20
groups of batteries.
3.Put these 20 groups of batteries into the chassis.
Remarks: to avoid short circuit, please be noted that the battery
terminals must not contact the metal parts.
Assy

Long battery plate
Short battery plate
M4*8 screws
Insulator
2
1
3
3
4
、
Put insulator on battery plates; fix battery plates( wider side is on the top)
Torque:16kgf-cm
Cross screw driver
2
、
Insert one side of battery
plate into the slot; fix the
other side to the metal by
M4*8 screws.
(fix into the top screw
holes）
1
、
Insert one side of battery
plate into the slot; fix the
other side to the metal by
M4*8 screws.
(fix into the top screw
holes）
3
、
Insert one side of battery plate into
the slot; fix the other side to the metal
by M4*8 screws.

Cable tie
Short battery wire
Long battery wire
1
34
4
5
、
Ensure that the switch is off, then connect batteries with battery wires.
Measure the voltage of the terminals marked by green circle. The range should be
220V~280V. Last, Insert BAT2+ and BAT1-。
Please be noted of the wiring of red wires.
Pliers
Multimeter
2
、
connect the
long battery
wires*4
3
、
Insert BAT2+
6
、
Insert BAT1-
7, Insert BAT1+
1
、
connect the short battery
wires*34
5
、
Tie BAT2-and
long battery wire
4
、
Insert BAT2-
