HEIN-WERNER AUTOMOTIVE HW93642 Instructions for use

Operating Instructions & Parts Manual
SFA Companies
10939 N. Pomona Ave. Kansas City, MO 64153
[email protected]
Model Number
HW93642
HW93652
Service Jacks
Capacity
2 Ton
3 Ton
Made in the
U.S.A.
HW93642-M0 rev 04202009
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
!
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.

SAFETY AND GENERAL INFORMATION
Save these instructions. For your safety read, understand, and follow the information provided with and on this jack.
The owner and operator of this equipment shall have an understanding of this jack and safe operating procedures before
attempting to use. The owner and operator shall be aware that use and repair of this product may require special skills
and knowledge. Instructions and safety information shall be conveyed in the operator's native language before use of
this jack is authorized. If any doubt exists as to the safe and proper use of this jack, remove from service immediately.
Inspect before each use. Do not use if broken, bent, cracked, or damaged parts (including labels) are noted. Any jack
that appears damaged in any way, operates abnormally or is missing parts, shall be removed from service immediately
and the manufacturer notied. If you suspect that the jack was subjected to a shock load (a load dropped suddenly,
unexpectedly upon it), immediately discontinue use until the jack has been checked by a factory authorized service
center (contact distributor or manufacturer for list of Authorized Service Centers). It is recommended that an annual
inspection be done by qualied personnel. Replace worn or damaged parts with Hein-Werner Authorized Replacement
Parts only. Labels and owner’s manuals are available from manufacturer.
PRODUCT DESCRIPTION
Hein-Werner Hydraulic Service Jacks are designed to lift, not support, rated capacity loads consisting of one end of a
vehicle. Immediately after lifting, the load must be supported by a pair of appropriately rated jack stands.
Never use hydraulic jack as a stand alone device. After lifting, immediately
support the lifted load with a pair of appropriately rated jack stands.
2
SPECIFICATIONS
!
Model Capacity Min. Height Max. Height Jack Size (L x W)
HW93642 2 Ton 4-1/2" 20" 28-1/2" x 14-7/8"
HW93652 3 Ton 5" 23" 31-1/4" x 15-1/2"
Figure 1 - Typical Service Jack Components
Handle
Handle Fork
Saddle
Front Wheel
Caster
Air Vent Screw
Lift Arm

3
PREPARATION (REFER TO FIGURE 1)
Before Use
1. Verify that the product and application are compatible, if in doubt call Hein-Werner technical service.
2. Before use, read the operator's manual completely and familiarize yourself thoroughly with the product, its components
and recognize the potential hazards associated with its use.
3. Insert handle to handle fork. Tighten the bolt on handle fork to prevent accidental removal of handle while in use.
4. To familiarize yourself with the basic operation of these jacks, locate and turn the release valve (handle):
a. Clockwise until rm resistance is felt to further turning. This is the ‘CLOSED’ release valve position used to
raise the load.
b. Counter-clockwise, but no more than 1/2 full turn from the closed position. This is the ‘OPEN’ release valve
position used to lower the load.
5. With saddle fully lowered, locate and remove air vent screw. Pump the operating handle through 6 to 8 full strokes.
Check the oil level. Ensure the oil level is within ~3/16" from the inner cylinder as viewed from the air vent screw
hole.
6. Reinstall the air vent screw.
7. Check to ensure that the jack rolls freely. Raise and lower the unloaded saddle throughout the lift range before
putting into service to ensure the pump and release valve operate smoothly.
8. Replace worn or damaged parts and assemblies with Hein-Werner Replacement Parts only. Lubricate as instructed
in Maintenance Section.
!WARNING
• Study, understand, and follow all printed materials
provided with/on this product before use.
• Do not exceed rated capacity.
• This is a lifting device only!
• Immediately after lifting, support the load with
a pair of appropriately rated jack stands.
• Use only on hard, level surfaces capable of
supporting rated capacity loads.
• Do not use adapters or accessories that are not
provided by the manufacturer.
• Lift only on areas of the vehicle as specied by the
vehicle manufacturer.
• Do not move or dolly loads with this device.
• No alterations shall be made to this product.
• Failure to heed these markings may result in
personal injury and/or property damage.
• Leer, comprender, y seguir las instrucciónes antes
de utilizar el aparato.
• El manual de instrucciónes y la información de
seguridad deben estar comunicado en lengua del
operador antes del uso.
• No seguir estas indicaciónes puede causar daños
personales o materiales.
!ADVERTENCIA
To avoid crushing and related injuries:
• Never work on, under or around a load supported
only by hydraulic jack.
• Always use adequately rated jack stands.
• Chock each unlifted tire in both directions.
• Do not use this device to lift, level, lower, support nor
move a house, mobile home, travel trailer, camper or
any building structure.
• Be alert and sober when using this product. Do not
operate under the inuence of drugs or alcohol.
!WARNING
X

OPERATION
Lifting
Only attachments and/or adapters supplied by the manufacturer shall be used. Lift only on areas of the
 vehicleasspeciedbythevehiclemanufacturer.
1. Follow the vehicle manufacturer’s recommended guidelines for lifting. Engage the emergency brake and chock each
unlifted wheel in both directions to prevent inadvertent vehicle movement.
2. Locate and close the release valve by turning the handle clockwise until rm resistance is felt.
3. Refer to the vehicle manufacturer owner’s manual to locate approved lifting points on the vehicle. Center jack saddle
under lift point.
4. Verify lift point then use handle pump to contact lift point. To lift, pump handle until load reaches desired height.
5. Transfer the load immediately to appropriately rated jack stands.
NEVER use hydraulic jack as a stand alone device! ALWAYS transfer the lifted load IMMEDIATELY to a
pair of appropriately rated jack stands. Use one pair of jack stands per vehicle. Rated capacity is per pair
only! Do not exceed rated capacity.
Overloading may cause hydraulic system failure.
Lowering
Be sure all tools and personnel are clear before lowering load. Slowly open the release valve! The more
you turn the release valve (handle) counter-clockwise, the faster the load will come down. Maintain control
of the rate of speed at which the load lowers at all times!
1. Raise load high enough to clear the jack stands.
2. Remove jack stands, carefully. (always used in pairs).
3. Slowly turn the release valve (handle) counter-clockwise, but no more than 1/2 full turn. If the load fails to lower:
a. Use another jack to raise the vehicle high enough to reinstall jack stands.
b. Remove the malfunctioning jack and then the jack stands.
c. Using the functioning jack, lower the load by turning the operating handle counter-clockwise, but no more than
1/2 full turn.
4. After removing jack from under the load, push saddle down to reduce ram exposure to rust and contamination.
4
!
!
!
!

TROUBLESHOOTING
5
MAINTENANCE
Important: Use only a good grade hydraulic jack oil. Avoid mixing different types of uid and Never use brake uid,
turbine oil, transmission uid, motor oil or glycerin. Improper uid can cause failure of the jack and the potential for
sudden and immediate loss of load. We recommend Hein-Werner hydraulic jack oil HW93291 or equivalent.
Adding oil
1. Lower saddle fully.
2. Set jack in its upright, level position.
3. Locate and remove air vent screw.
4. Fill with oil until ~3/16" above the inner cylinder as seen from the air vent screw hole.
5. Reinstall the air vent screw.
Changing oil
For best performance and longest life, completely replace hydraulic uid at least once a year.
1. Lower saddle fully.
2. Remove the air vent screw.
3. Lay the jack on its side and drain the uid into a suitable container.
Note: Dispose of hydraulic uid in accordance with local regulations.
4. Fill with oil until ~3/16" above the inner cylinder as seen from the air vent screw hole.
5. Reinstall the air vent screw.
Lubrication
A periodic coating of light lubricating oil to pivot points, axles and hinges will help to prevent rust and assure that wheels,
casters and pump assemblies move freely.
Cleaning
Periodically check the pump piston and ram for signs of rust or corrosion. Clean as needed and wipe with an oily cloth .
Note: Never use sandpaper or abrasive material on these surfaces!
Storage
Lower the saddle to its lowest position when not in use.
REPLACEMENT PARTS (refer to page 6 & 7)
Not all components of the jack are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence. When ordering parts, give model number, part number and parts description.
Call or write for current pricing: Hein-Werner Customer Support, 10939 N. Pomona Ave. Kansas City, MO 64153.
Phone: [phone]; E-mail: [email protected]
Symptom Possible Causes Corrective Action
Jack will not lift load • Release valve not tightly closed
• Overload condition
• Ensure release valve tightly closed
• Remedy overload condition
Jack bleeds off after lift • Hydraulic unit malfunction • Discontinue use, contact Hein-
Werner Technical Service
Jack will not lower after unloading • Reservoir overlled
• Linkages binding
• Fluid level low
• Drain uid to proper level
• Clean and lubricate moving parts
• Ensure proper uid level
Will not lift to full extension • Fluid level low • Ensure proper uid level

Replacement Parts Illustration for Model HW93642 & HW93652 (refer to parts list on page 7)
6
Figure 2 - Parts Illustration for Model HW93642 & HW93652
1
10
678
3
2
11
12
13
5
49
38
35
33 34
37 36
37
15
14
22
17
20
19
18
21
16
32
29 40
23 24
31 30 28
39
25
Frame Section
Hydraulic Unit Cross Section Handle Assembly
Hydraulic Unit Base
One-Piece
Handle

7
Replacement Parts List for Model HW93642 & HW93652 (refer to parts drawing on page 6)
Item Part No. Description Qty.
1 231583 Caster, 2.5”x1.25” 2
2 201115 Lock Washer, 3/4” 2
3 219451 Hex Nut, 3/4”-10 2
4 231584 Caster Assembly (includes item# 1-3) 2
5 201803 Retaining Ring 2
6 214557 Retaining Ring 2
7 204324 Flat Washer, 3/4” 2
8 234678 Wheel, 3.75”x2” 2
9 234677 Front Wheel Assy.(includes item# 6-8) 2
10 234956 Hex. Head Bolt, 3/8”-24 1
11 239304 Saddle 1
12 221408 Cotter Pin, 1/8” 1
13 243618 Return Spring 2
14 N/A Pump Piston 1
15* N/A Retaining Ring 1
16 N/A Pump Sleeve 1
17 N/A Spring 1
18 N/A Pump Cylinder 1
19* N/A Packing 3
20 N/A Flat Washer 1
21 N/A Hex Nut #10-32 1
22 890-021-666 Pump Assembly (includes item# 14-21) 1
23* 230301 Heel Plate 1
24* 221318 Screen 1
25* 221748 Quad Ring 1
28* 228256 U-cup 1
29* 218043 Release Valve 1
30* 233917 Plastic Spring 1
31* 216143 Gland O-ring 1
32 248731 Universal Assembly 1
33* 203196 Ball, 5/32” 1
34* 203198 Ball, 7/32” 1
35* 203201 Ball, 5/16” 1
36* 204842 Gasket 1
37* 201733 Plug 2
38 HW934642 234957 1 pc. Handle Assembly 1
HW93652 234961 1 pc. Handle Assembly
39 HW93642 248721 Power Unit 1
HW93652 890-005-010
40 6420-10000-000 Air Vent Screw Assembly 1
* 248949 Repair Kit for Hydraulic Unit -

TWO YEARS LIMITED WARRANTY
For a period of two (2) years from date of purchase, SFA Companies will repair or replace, at its option, without charge,
any of its products which fails due to a defect in material or workmanship under normal usage. This limited warranty is
a consumer's exclusive remedy.
Performance of any obligation under this warranty may be obtained by returning the warranted product, freight prepaid,
to SFA Companies Warranty Service Department, 10939 N. Pomona Ave., Kansas City, MO 64153.
Except where such limitations and exclusions are specically prohibited by applicable law:
(1) THE CONSUMER'S SOLE AND EXCLUSIVE REMEDY SHALL BE THE REPAIR OR REPLACEMENT OF DEFECTIVE
PRODUCTS AS DESCRIBED ABOVE
(2) SFA COMPANIES SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGE OR LOSS
WHATSOEVER.
(3) ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO TWO YEARS,
OTHERWISE THE REPAIR, REPLACEMENT OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED
WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED.
(4) ANY MODIFICATION, ALTERATION, ABUSE, UNAUTHORIZED SERVICE OR ORNAMENTAL DESIGN VOIDS
THIS WARRANTY AND IS NOT COVERED BY THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you. This warranty gives you specic legal rights, and you may also have other rights which
vary from state to state.
SFA Companies
10939 N. Pomona Ave. Kansas City, MO 64153
816-891-6390
[email protected]
