Air Bleeding Instructions for Air / Manual Service Jacks
HEIN-WERNER Models HW9 662 (10 Ton) & HW9 667 (4 Ton)
Hein-Werner Automotive
10939 N. Pomona Avenue, Kansas City, Missouri 64153, USA
Te ephone: [phone], To Free [phone]
heinwerner-automotive.com
Problem: LIFT ARM wi not rise when air pressure is app ied.
Resolution: Fo ow the Air B eeding Procedure in this document.
Models: HW93662 (10 Ton) & HW93667 (4 Ton) Air / Manua Service Jacks.
Tools Required: Hex Wrench for AIR MOTOR VENT PLUG, Open End Wrench, Combination
Wrench, or Socket Wrench for AIR VENT SCREW. Air Compressor, or other Compressed Air
Source [suggested 110 psi (7,6 bar) minimum air pressure].
Procedure:
WARNING!
• Read and understand all information contained in Operating Instruction Manual
(supplied with the equipment), and this document before starting this procedure.
• NO LOAD should be placed on this equipment during this procedure.
• Any persons not involved in the work should leave the area.
• Work area should be clean and free of any hazards such as oil spills.
• Only trained, competent adults should perform this procedure.
• Use ONLY approved Hydraulic Jack Oil when adding or replacing oil in a
hydraulic jack.
• NEVER use brake fluid, turbine oil, transmission fluid, motor oil or glycerin in a
Hydraulic Jack. Improper fluid can cause failure of the jack and the potential for
sudden and immediate loss of load.
Step 1:
• Read and understand a information
contained in the Operating Instruction
Manual for this piece of equipment.
Nomenc ature used in this document
refers to items discussed in the
Operating Instruction Manual.
• Read and understand a information
contained in this document before
starting this procedure.
• P ace the unit in the work area such
that a sides are easi y accessib e, and
such that LIFT ARM can rise to its
maximum height with no obstruction.

Air Bleeding Instructions for Air / Manual Service Jacks
HEIN-WERNER Models HW9 662 (10 Ton) & HW9 667 (4 Ton)
Hein-Werner Automotive
10939 N. Pomona Avenue, Kansas City, Missouri 64153, USA
Te ephone: [phone], To Free [phone]
heinwerner-automotive.com
Step 2:
• Open the COVER PLATE.
Step :
• Locate and remove AIR VENT
SCREW.
Step 4:
• Verify that the Re ease Va ve is in the
CLOSED position, by turning the
RELEASE VALVE KNOB c ockwise
unti resistance is fe t.
Step 5:
• Lift the jack manua y, by pumping the
HANDLE, unti the LIFT ARM has
reached its maximum height.
Approximate Maximum Height:
25-1/2" (648mm) for HW93662 (10 Ton)
25-3/4" (654mm) for HW93667 (4 Ton).

Air Bleeding Instructions for Air / Manual Service Jacks
HEIN-WERNER Models HW9 662 (10 Ton) & HW9 667 (4 Ton)
Hein-Werner Automotive
10939 N. Pomona Avenue, Kansas City, Missouri 64153, USA
Te ephone: [phone], To Free [phone]
heinwerner-automotive.com
Step 6:
• Use a Hex Wrench, to
oosen the AIR MOTOR
VENT PLUG by turning
Counter C ockwise.
• Remove the AIR
MOTOR VENT PLUG.
Retain for ater re-
insta ation.
Step 7:
• Turn the RELEASE
VALVE KNOB
counter-c ockwise to
a ow the LIFT ARM to
ower.
• After making note of
Step 8, manua y pump
the HANDLE, as the
LIFT ARM moves
downward.
Step 8:
• When oi is expe ed
from the AIR MOTOR
VENT PLUG ho e,
quick y re-insta the AIR
MOTOR VENT PLUG.
• Next, secure y tighten
the AIR MOTOR VENT
PLUG.
• If oi is not expe ed, as
shown, repeat Steps 4,
5 and 7.
Step 9:
• Attach an air compressor hose to the AIR
CONTROL VALVE ocated on the HANDLE of the
unit.

Air Bleeding Instructions for Air / Manual Service Jacks
HEIN-WERNER Models HW9 662 (10 Ton) & HW9 667 (4 Ton)
Hein-Werner Automotive
10939 N. Pomona Avenue, Kansas City, Missouri 64153, USA
Te ephone: [phone], To Free [phone]
heinwerner-automotive.com
Step 10:
• Depress Lever on AIR
CONTROL VALVE so LIFT ARM
begins to s ow y rise upward.
• Check that LIFT ARM rises to
maximum height.
• Repeat ifting procedure 2-3
times unti ifting speed increases
and seems consistent.
Approximate Maximum Height: 25-1/2" (648mm) for HW93662 (10 Ton).
25-3/4" (654mm) for HW93667 (4 Ton).
WARNING!
• Use ONLY approved Hydraulic Jack Oil when adding or replacing oil in a
hydraulic jack.
• NEVER use brake fluid, turbine oil, transmission fluid, motor oil or glycerin in a
Hydraulic Jack. Improper fluid can cause failure of the jack and the potential for
sudden and immediate loss of load.
Step 11:
• Add oi to rep ace the expe ed oi using the instructions
supp ied in the Operation Manua . Use ONLY Hein-
Werner hydrau ic jack oi , part number HW93291, or
equa .
• Re-Insta and secure y tighten the AIR VENT SCREW.
Step 12:
• C ose the COVER PLATE.
Step 1 :
• C ean Work Area, Inc uding any oi that was expe ed from the unit during this procedure.
