HEIN-WERNER AUTOMOTIVE HW93511 User manual

Heavy Duty Jack Stands
HW93511-M0 rev 02242010
Operating Instructions & Parts Manual
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
SFA Companies
10939 N. Pomona Ave, Kansas City, MO 64153
[email protected]
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
!
!ADVERTENCIA
• Leer, comprender, y seguir las instrucciónes antes
de utilizar el aparato.
• El manual de instrucciónes y la información de
seguridad deben estar comunicado en lengua del
operador antes del uso.
• No seguir estas indicaciónes puede causar daños
personales o materiales.
Model Number Capacity per pair
HW93511 10 Ton
Made in the
U.S.A.
Model Number Capacity per pair
HW93512 10 Ton
!WARNING
• Read, understand and follow all instructions
provided with and on this device before using.
• Failure to heed these warnings may result in
personal injury and/or property damage.

2
SPECIFICATIONS
Model Capacity Base Size Min. Height Max. Height Net Weight
HW93511
10 Ton
18" x 18" 30" 52" 144 lbs.
HW93512 16" x 16" 19-1/2" 31-1/2" 44 lbs.
Figure 1 - Hein-Werner Heavy Duty
Jack Stand Components
(HW93511 shown)
SAFETY AND GENERAL INFORMATION
Save these instructions. For your safety read, understand, and follow the information provided with and on this
pair of jack stands before using. The owner and operator of this equipment shall have an understanding of the jack
stands and safe operating procedures before attempting to use. The owner and operator shall be aware that use of
this product may require special skills and knowledge. Instructions and safety information shall be conveyed in the
operator's native language before use of these jack stands is authorized. If any doubt exists as to the safe and proper
use of these jack stands, remove from service immediately.
Inspect before each use. Do not use if broken, bent, cracked, or damaged parts (including labels) are noted. Any
jack stand that appears damaged in any way, operates abnormally or is missing parts, shall be removed from service
immediately. If you suspect that the jack stand was subjected to a shock load (a load dropped suddenly, unexpectedly
upon it), immediately discontinue use until the stand has been checked by a factory authorized service center (contact
distributor or manufacturer for list of Authorized Service Centers). It is recommended that an annual inspection be
done by qualied personnel. Labels and owner’s manuals are available from manufacturer.
PRODUCT DESCRIPTION
Hein-Werner Heavy Duty Jack Stands are designed to support rated capacity, partial vehicle loads consisting of one
end of a vehicle. Use as a matched pair to support one end of a vehicle only.
NEVER use automotive jack stands to support both ends or one side of a vehicle!
Use only one (1) pair per vehicle. Rated capacity is per pair only!
!
Saddle
Extension Tube
Carrying Handle
Base
Support Pin
Lanyard
Collar
Height Adjustment Holes
Transport Casters
(HW93511 only)
5/16-18 x 3/4
Securing Fastener

3
PREPARATION
Assembly (refer Fig. 1)
1. Make sure all parts are present. If any part is
missing or damaged, do not attempt to assemble,
install or operate the product. Contact Hein-Werner
Customer Service [phone].
2. Insert Extension Tube into the Collar and attach
securing fastener into hole in Collar to prevent
inadvertent removal.
Before Use
1. Verify that the product and the application are
compatible, if in doubt call Hein-Werner Customer
Service [phone].
2. Inspect stands before each use. Do not use if there are
bent, broken or cracked components noted (including
labels). Ensure that all parts move freely.
3. Read the this operator's manual completely and
familiarize yourself thoroughly with the product and
the hazards associated with its improper use before
using this product.
4. Always refer to the vehicle owner's or service manual
for location of proper lift and support points.
OPERATION
Use only on areas of the vehicle as specied by
the vehicle manufacturer. Use ONLY on vehicles
whose support points are compatible with the
saddle of the jack stand. Incompatibility may
result in structural damage to the vehicle and/or
jack stand. Structural damage to either may result
in sudden and unexpected loss of load height!
Only attachments and/or adapters supplied
by the manufacturer shall be used.
1. Change Saddle height by adjusting the Extension
Tube, then insert the Support Pin through both
Adjustment Holes in Extension Tube.
2. Check that Support Pin is securely seated across
cutouts in top of Collar before loading. Ensure that
Support Pin is inserted completely so that bar stop
engages the collar.
3. Carefully position jack stands so that load will be
centered on stand’s saddle.
4. Slowly lower the vehicle onto stands.
5. Check to ensure vehicle is secured before working
on, around or under. Use wheel chocks on all unlifted
wheels in both directions to prevent inadvertent
movement.
To lower load
Be sure that all tools and personnel are clear
before lowering load.
1. With suitable jack, raise vehicle clear of stands.
2. Carefully release Support Pin and adjust Extension
Tube to lowest position.
3. Carefully remove stands, then lower vehicle with lift
device.
MAINTENANCE
To help prevent rust, wipe clean after each use. Do
not apply oil or lubricant to ANY portion of this product.
Always keep Support Pin with base section and replace
Lanyard if necessary.
If rust appears, sand affected area and cover with
suitable utility paint. Please note that there is no
replacement part applicable to this device.
Storage
Store stands in upright position and in a clean, dry
area.
REPLACEMENT PARTS
For replacement partsd, product labels and owners
manual, call or write: Hein-Werner Customer Support,
10939 N. Pomona Ave. Kansas City, MO 64153, U.S.A.
Tel: [phone] Fax: [phone] E-Mail:
[email protected]
Some components of these jack stands are not available
for replacement. Jack stands must be replaced as a
matched set and must never be used singly or with
another make or model stand.
• Rated capacity is PER PAIR! DO NOT exceed
rated capacity.
• Use as a matched pair to support one end of a
vehicle only. Use only ONE (1) PAIR per vehicle.
• Use only on hard, level surface.
• Center load on saddle.
• Jack stands are not to be used to simultaneously
support both ends or one side of a vehicle.
• No alterations shall be made to this device.
!WARNING
!
!
!
!WARNING
To avoid crushing and related injuries:
NEVER work on, under or around a
load supported only by a hydraulic
jack. ALWAYS use adequately rated
jack stands.

SFA Companies
10939 N. Pomona Ave. Kansas City, MO 64153
816-891-6390
[email protected]
4
TWO YEAR LIMITED WARRANTY
For a period of two (2) years from date of purchase, SFA Companies will repair or replace, at its option, without
charge, any of its products, which fails due to a defect in material or workmanship under normal usage. This limited
warranty is a consumer's exclusive remedy.
Performance of any obligation under this warranty may be obtained by returning the warranted product, freight
prepaid, to SFA Companies Warranty Service Department, 10939 N. Pomona Ave., Kansas City, MO 64153.
Except where such limitations and exclusions are specically prohibited by applicable law, (1) THE CONSUMER'S
SOLE AND EXCLUSIVE REMEDY SHALL BE THE REPAIR OR REPLACEMENT OF DEFECTIVE PRODUCTS AS
DESCRIBED ABOVE. (2) SFA Companies SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL
DAMAGE OR LOSS WHATSOEVER. (3) ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE
LIMITED TO TWO YEARS, OTHERWISE THE REPAIR, REPLACEMENT OR REFUND AS PROVIDED UNDER
THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED
IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. (4) ANY MODIFICATION, ALTERATION, ABUSE,
UNAUTHORIZED SERVICE OR ORNAMENTAL DESIGN VOIDS THIS WARRANTY AND IS NOT COVERED BY
THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply
to you. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This warranty gives you specic legal rights, and you may also have
other rights, which vary from state to state.
1
2
3
HW93511 REPLACEMENT PARTS
ITEM PART NO DESCRIPTION QTY
1 928254 SUPPORT PIN AND LANYARD 1
2 928253 CASTER 2
3 928256 HARDWARE KIT* 1
*Includes hardware for both casters and securing fasteners.
HW93512 REPLACEMENT PARTS
ITEM PART NO DESCRIPTION QTY
1 928254 SUPPORT PIN AND LANYARD 1
