Heinner HAC-CLS12WHWIFI User manual

USER MANUAL FOR REMOTE CONTROLLER
For model: HAC-CLS12WHWIFI
www.heinner.ro

1
Rated voltage
3.0V (Dry batteries R03/LR03×2)
Transmission distance
8m
Environment
-5°C ~ 60°C
Before using the appliance, please read carefully this instruction manual and keep it for future
reference.
This instruction manual is designed to provide you with all required instructions related to the
installation, use and maintenance of the appliance.
In order to operate the unit correctly and safety, please read this instruction manual carefully
before installation and usage.
I. INTRODUCTION
II. SPECIFICATIONS

2
°
III. QUICK START GUIDE
Not sure what a function does?
Refer to the How to Use Basic Functions and How to Use Advanced Functions sections of
this manual for a detailed description of how to use your air conditioner.
Special note:
•Button designs on your unit may differ slightly from the example shown.
•
If the indoor unit does not have a particular function, pressing that function’s
button on the remote control will have no effect.
•
When there are wide differentces between “Remote controller Manual” and
“USER’S MANUAL” on function description, the description of “USER’S MANUAL”
shall prevail.

3
Inserting and replacing batteries
Your air conditioning unit may come with two batteries (some units). Put the batteries in
the remote control before use.
1. Slide the back cover from the remote control downward, exposing the battery
compartment.
2. Insert the batteries, paying attention to match up the (+) and (-) ends of the batteries
with the symbols inside the battery compartment.
3. Slide the battery cover back into place.
Batterry notes
For optimum product performance:
•Do not mix old and new batteries, or batteries of different types.
•Do not leave batteries in the remote control.
•If you don’t plan on using the device for more than 2 months.
Batterry disposal
Do not dispose of batteries as unsorted municipal waste. Refer to local laws for proper
disposal of batteries.
Tips for using remote control
•The remote control must be used within 8 meters of the unit.
•The unit will beep when remote signal is received.
•
Curtains, other materials, and direct sunlight can interfere with the infrared signal
receiver.
•Remove batteries if the remote will not be used more than 2 months.
IV. HANDLING THE REMOTE CONTROLLER

4
Before you begin using your new air conditioner, make sure to familiarize yourself with its
remote control. The following is a brief introduction to the remote control itself. For
instructions on how to operate your air conditioner, refer to the How to Use Basic Functions
section of this manual.
V. BUTTONS AND FUNCTIONS

5
Information are displayed when the remote controller is power up.
Note:
All indicators shown in the figure are for the purpose of clear presentation. But during the
actaul operation, only the relative function signs are shown on the display window.
VI. REMOTE DISPLAY

6
VII. HOW TO USE BASIC FUNCTIONS
Attention! Before operation, please ensure the unit is plugged in and power is available.
AUTO mode
Note:
1. In AUTO mode, the unit will automatically select the COOL, FAN, or HEAT function based
on the set temperature.
2. In AUTO mode, fan speed can not be set.
COOL or HEAT mode
DRY mode
Note: In DRY mode, fan speed can not be set since it has already been automatically
controlled.
FAN mode
Note: In FAN mode, you can’t set the temperature. As a result, no temperature displays in
remote screen.

7
Setting the TIMER
TIMER ON/OFF - Set the amount of time after which the unit will automatically turn on/off.
TIMER ON setting
TIMER OFF setting
Note:
1. When setting the TIMER ON or TIMER OFF, the time will increase by 30 minutes
increments with each press, up to 10 hours. After 10 hours and up to 24, it will increase in
1 hour increments. (For example, press 5 times to get 2.5h, and press 10 times to get 5h).
The timer will revert to 0.0 after 24.
2. Cancel either function by setting its timer to 0.0h.
TIMER ON/OFF setting (example)
Keep in mind that the time periods you set for both functions refer to hours after the
current time.
Example: If current timer is
1:00PM, to set the timer as above
steps, the unit will turn on 2.5h
later (3:30PM) and turn off at
6:00PM.

8
Swing function
Airflow direction
Note: When the unit is off, press and hold MODE and SWING buttons together for one
second, the louver will open for a certain angle, which makes it very convenient for
cleaning. Press and hold MODE and SWING buttons together for one second to reset the
louver (model dependent).
LED display
VIII. HOW TO USE ADVANCED FUNCTIONS
If continue to press the SWING
button, five different airflow
directions can be set. The louver
can be move at a certain range each
time you press the button. Press the
button until the direction you
prefer is reached.

9
ECO/GEAR function
ECO operation
Under cooling mode, press this button, the remote controller will adjust the temperature
automatically to 24°C, fan speed of Auto to save energy (only when the set temperature is
less than 24°C). If the set temperature is above 24°C, press the ECO button, the fan speed
will change to Auto, the set temperature will remain unchanged.
Note: Pressing the ECO button, or modifying the mode or adjusting the set temperature to
less than 24°C will stop ECO operation.
Under ECO operation, the set temperature should be 24°C or above, it may result in
insufficient cooling. If you feel uncomfortable, just press the ECO button again to stop it.
GEAR operation
Press the ECO/GEAR button to enter the GEAR operation as following:
75% (up to 75% electrial energy consumption) > 50% (up to 50% electrial energy
consumption) > Previous setting mode.
Under GEAR operation, the display on the remote controller will alternage between
electical energy consumption and set temperature.
Silence function
FP function
Press X-ECO button to enter the energy efficient mode in a
sequence of following:
ECO > GEAR (75%) > GEAR (50%) > Previous setting mode > ECO
Note: This function is only available under COOL mode.
Keep pressing Fan button for more than 2 seconds to activate/disable
Silence function.
Due to low frequency operation of compressor, it may result in
insufficient cooling and heating capacity. Press ON/OFF, Mode, Sleep,
Turbo or Clean button while operating will cancel silence function.
The unit will operate at high fan speed (while compressor on)
with temperature automatically set to 8°C.
