Heitronics KT15 II User manual

INFRARED RADIATION
PYROMETER
KT15 II
Operating Instructions
95582944
13/08/06e
All rights reserved! The reproduction, transmission or use
of this document or its contents is not permitted without
express written authority. Offenders will be liable for
damages. All rights, including rights created by patent
grant or registration of a utility model or design, are
reserved. Heitronics GmbH reserves the right to make
modifications and improvements in their design without
prior notice.
(c) HEITRONICS Infrarot Messtechnik GmbH
HEITRONICS
Infrarot Messtechnik GmbH
Kreuzberger Ring 40
D-65205 Wiesbaden
Tel. ++49 (0)611 9 73 93-0
Fax ++49 (0)611 9 73 93-26
eMail [email protected]
internet: www.HEITRONICS.com

95582944 SAFETY INSTRUCTIONS KT 15 II
1/01/04e HEITRONICS Infrarot Messtechnik GmbH
SAFETY INSTRUCTIONS
General
Please read carefully the instructions given in TECHNICAL SPECIFICATIONS, espe-
cially the connection and operating instructions as well as the connection instructions
and configurations dealt with in SYSTEM START-UP.
The Infrared Radiation Pyrometer is an optical measuring instrument.
Dirty lenses will lead to measuring errors.
Please pay attention to the instruction given in MAINTENANCE AND CALIBRATION.
HEITRONICS production meets the latest technical development thereby applying so-
phisticated components. Nevertheless, functional errors may occur in exceptional
cases. The failure of an instrument may cause a measuring value being issued which
seems to be correct, but is wrong. Please pay attention to the instructions given in
MAINTENANCE AND CALIBRATION.
Only when using a female connector with cable or a dummy plug attached to the plug
of the device - in addition to the equipment sealing -, the specified system of protection
can be achieved.
Operation with laser
Devices completely mounted and equipped with integrated laser meet the safety
requirements of Laser class 2.
Before handling the lens in any way, the voltage supply is to be switched off or the
connecting plug is to be pulled out to ensure that the laser will not switch on automati-
cally.
The integrated laser can not operate up to the upper limit of the ambient temperature of
60 °C.
ATTENTION
In case of wrong connection,
the device might be destroyed.
ATTENTION
The Laser must not be switched on, if the lens
of the radiation pyrometer is removed.
ATTENTION
The Laser will be switched off at ≥40 °C
to defend it from destruction.

Erklärung über die Konformität
DECLARATION OF CONFORMITY
Diese Erklärung gilt für folgende Erzeugnisse:
This declaration is valid for the following products:
Geräteart: Infrarot Strahlungspyrometer
Type of instrument: Infrared Radiation Pyrometer
Typenbezeichnung: KT15 II Serie
Designation of model: KT15 II Series
Diese Erklärung wird abgegeben durch
This declaration is issued by
HEITRONICS Infrarot Messtechnik GmbH
Kreuzberger Ring 40
65205 Wiesbaden, Germany
Hiermit wird bestätigt, dass die Produkte gemäß den Richtlinien des Rates
zur Angleichung der Rechtsvorschriften der Mitgliedsstaaten über die
elektromagnetische Verträglichkeit (89/336/EWG) mit den unten genannten
Normen übereinstimmen:
In accordance with the EU-Directive of Electro-magnetic-compatibility (89/336/EWG)
the manufacturer declare, that the device described above is conform to the
essential requirements of the EU-Directives:
EN 55011 Class B
EN 61326
Wiesbaden, 15. Juli 2003
Wiesbaden, July 15, 2003

95582944 PREFACE KT15 II
1/01/04e HEITRONICS Infrarot Messtechnik GmbH
PREFACE
The remarkable features of the HEITRONICS devices are a design
suitable for specific application as well as an uncomplicated opera-
tion. Nevertheless, it is recommended to read the entire instruction
manual before putting the instruments into operation.
Please observe the safety instructions as well as the particularly
emphasized annotations when reading the pertinent instruction to
the operation.
The operating instructions are primarily directed to the user. They
contain the information and instructions necessary to successfully
use the instruments including all options.
If you still have any questions after having read this instruction
manual, please contact us. Our staff will be at your disposal.

0-1
95582944 CONTENTS KT15 II
3/07/05e HEITRONICS Infrarot Messtechnik GmbH
CONTENTS
SAFETY INSTRUCTIONS
DECLARATION OF CONFORMITY
PREFACE
CONTENTS................................................................................................. 0-1
DATA SHEET.............................................................................................. 1-1
GENERAL................................................................................................... 2-1
Measuring temperatures using Infrared Radiation Pyrometers.............. 2-1
Infrared Radiation Pyrometers for GENERAL APPLICATION....................... 2-2
Infrared Radiation Pyrometers for measuring METALS ........................... 2-3
Infrared Radiation Pyrometers for measuring PLASTICS ......................... 2-3
Infrared Radiation Pyrometers for measuring GLASS ............................. 2-4
Infrared Radiation Pyrometers for measuring GASES............................. 2-4
TECHNICAL SPECIFICATIONS................................................................. 3-1
Basics .................................................................................................... 3-1
Technical Information Cooling Jacket .................................................... 3-3
Assignment for 12-pin connector for RS232-Interface ........................... 3-4
Assignment for 12-pin connector for RS485-Interface ........................... 3-5
Assignment for 7-pin connector ............................................................ 3-6
Legend table "Temperature resolution".................................................. 3-7
Temperature resolution
KT15.01 II / KT15.02 II......................................................................... 3-7
KT15.21 II .............................................................................................. 3-8
KT15.23 II / KT15.24 II......................................................................... 3-9
KT15.25 II ............................................................................................ 3-10
KT15.41 II / KT15.42 II....................................................................... 3-11
KT15.43 II ............................................................................................ 3-12
KT15.62 II ............................................................................................ 3-13
KT15.63 II ............................................................................................ 3-14
KT15.69 II ............................................................................................ 3-15
KT15.81 II / KT15.82 II....................................................................... 3-16
KT15.83 II / KT15.85 II....................................................................... 3-17
START-UP................................................................................................... 4-1
Mounting................................................................................................ 4-1
Fig. Mounting KT15 II Protective Cooling Jacket ................................... 4-1
Electrical Connection ............................................................................. 4-2
Assignment for 12-pin connector ........................................................... 4-3
Assignment for 7-pin connector ............................................................. 4-4
Operation without serial interface .......................................................... 4-5
Operation with serial interface ............................................................... 4-5
Optical Adjustment................................................................................. 4-5
Aiming via focus laser............................................................................ 4-5
Aiming via pilot laser.............................................................................. 4-5
Aiming via Laserpointer LP15................................................................ 4-6
Aiming by means of adjusting rods ........................................................ 4-6

0-2
95582944 CONTENTS KT15 II
2/04/05e HEITRONICS Infrarot Messtechnik GmbH
OPERATION AND APPLICATION ............................................................. 5-1
General information ............................................................................... 5-1
Application ........................................................................................... 5-1
Check routines....................................................................................... 5-1
Continuous measurement of ambient temperature................................ 5-2
Remote control with digital input ............................................................ 5-3
Monitoring the device function during operation .................................... 5-4
Operation via keyboard....................................................................... 5-5
Operation of the Menu ........................................................................... 5-5
Main Menu............................................................................................. 5-6
Submenu: Temp / Info / Emi ................................................................ 5-7
Submenu: Tamb ................................................................................... 5-8
Submenu: Resp / Memo ....................................................................... 5-9
Submenu: HiAI / LoAI ......................................................................... 5-10
Submenu: Laser / Unit ........................................................................ 5-11
Submenu: Aout ................................................................................... 5-12
Submenu: Uart.................................................................................... 5-13
Submenu: Cal ..................................................................................... 5-14
Submenu: Conf................................................................................... 5-15
Submenu: Test ................................................................................... 5-16
Communication via interface............................................................ 5-17
Preparing the device for operation with interface RS232C .................. 5-17
Using the interface .............................................................................. 5-18
Control of communication .................................................................... 5-18
Data transfer from KT15 II for evaluation purposes ............................. 5-18
Commands ....................................................................................... 5-18
Delimiter ....................................................................................... 5-18
Input buffer ....................................................................................... 5-18
Description of commands .................................................................... 5-19
Legend................................................................................................. 5-19
List of commands................................................................................. 5-19
Emissivity............................................................................................. 5-19
Ambient temperature ........................................................................... 5-19
Memory functions ................................................................................ 5-20
Parameter-storing into EEprom ........................................................... 5-20
Alarm configuration.............................................................................. 5-20
Interrogating the alarm status .............................................................. 5-21
Temperature unit ................................................................................. 5-21
Time factor........................................................................................... 5-21
Configuration of analog output............................................................. 5-22
Configuration of the ambient temperature............................................ 5-22
Configuration of digital input ................................................................ 5-23
Repeating measured temperature value.............................................. 5-23
Interrogating the measured value ........................................................ 5-23
Interrogate software version ............................................................... 5-23
Pilot lamp............................................................................................. 5-24
Interrogating laser configuration .......................................................... 5-24
Laser enable/disable............................................................................ 5-24
Laser beam.......................................................................................... 5-24
Laser operation.................................................................................... 5-24
Lock keyboard ..................................................................................... 5-24

0-3
95582944 CONTENTS KT15 II
4/11/05e HEITRONICS Infrarot Messtechnik GmbH
Calibration............................................................................................ 5-25
Serial Interface..................................................................................... 5-25
Availability............................................................................................ 5-26
Acknowledge ....................................................................................... 5-26
Interrogation of device parameters ...................................................... 5-26
Change over between standard emissivity mode and
reflectivity transmissivity mode ............................................................ 5-27
Reflectivity ........................................................................................... 5-27
Transmissivity ...................................................................................... 5-27
Reflected ambient temperature............................................................ 5-27
Transmitted ambient temperature........................................................ 5-27
Change over between standard operation and SC12 operation .......... 5-28
Error messages ................................................................................... 5-29
Bus operation with Interface RS485 .................................................... 5-30
MAINTENANCE AND CALIBRATION........................................................ 6-1
General information ............................................................................... 6-1
Cleaning the lens ................................................................................... 6-1
Checking the display accuracy .............................................................. 6-1
FIGURES AND TABLES............................................................................. 8-1
Spectral emissivity of various materials ................................................. 8-2
Total emissivity of some materials at 20 °C ........................................... 8-2
Emissivity of foils ................................................................................... 8-3
Spectral emissivity of radiation pyrometers and
transmission curves of various synthetic materials ................................ 8-4
Spectral emissivity ε, transmissivity τand
reflectivity ρof glass .............................................................................. 8-5
Housing dimensions KT15II ................................................................... 8-6
Spectral emissivity of KT15.81 II / KT15.82 II ........................................ 8-7
Adjustmentrod........................................................................................ 8-8
Field of view........................................................................................... 8-9
TABLES
Assignment for 12-pin connector ........................................................... 3-5
Assignment for 7-pin connector ........................................................... 3-6
"Temperature resolution" ..................................................................... 3-7ff
Minimum temperatures .......................................................................... 6-1
COOLING JACKET WK200L
WARRANTY CONDITIONS
SERVICE ADDRESSES

1-1
95582944 DATA SHEET KT15 II
1/01/04e HEITRONICS Infrarot Messtechnik GmbH
1 DATA SHEET
Type ..........................................................................................................
Serial No.
.......................................................
Spectral response
.......................................................
Temperature range
...............................................
Calibration factor
........................................................
Lens................................................
Spacer............................................
Detector..........................................
Digital Interface...............................
Options
....................................................................................................................................
....................................................................................................................................
Accessories
....................................................................................................................................
....................................................................................................................................
Code ...........................................................................................................................
Further data.................................................................................................................
....................................................................................................................................
Hereby it is confirmed that the Infrared Radiation Pyrometer specified above
keeps the data indicated in the specifications.
Tester: Wiesbaden,

2-1
95582944 GENERAL KT15 II
1/01/04e HEITRONICS Infrarot Messtechnik GmbH
2 GENERAL
2.1 Measuring temperatures using Infrared Radiation Pyrometers
Above a temperature of absolute zero, which is approx. - 273 °C or 0 K, all bodies
emit electromagnetic radiation, the wavelength and density of which depend on the
temperature. Up to a temperature of approx. 600 °C, the wavelength of the radiation
can be found exclusively within the infrared range (thermal radiation). It is only at
higher temperatures where part of this radiation is emitted in the form of visible light.
The radiation emitted by the body (radiation density) also depends on the surface of
the individual body. At a fixed temperature, the maximum radiation density is emitted
by a "blackbody" source of radiation. All real bodies only emit a fraction of this radia-
tion density at the same temperature. The ratio of this fractional part to the maximum
radiation density is called the emissivity ε. Naturally, the emissivity is always < 1. It
depends on the nature of the surface of the material, on the material itself and on the
wavelength. If the emissivity is known, the temperature of the object can be deter-
mined by measuring the infrared radiation emitted by the very object.
Devices used to measure this kind of radiation are called Infrared Radiation Pyro-
meters.
As the measurement is effected without the Infrared Radiation Pyrometer being in
contact with the object, no distortion of the temperature field due to heat dissipation
need to be feared, as is the case, e.g., with probe-type thermometers.
The Infrared Radiation Pyrometer is a measuring transducer, which receives the in-
frared radiation emitted by the measuring object itself and transforms it into a stan-
dardized output signal.
All optic and electronic components are located in a small housing of a solid con-
struction, which is made from die-cast metal so that the installation of a radiation py-
rometer is possible even in narrow spaces.
By selecting a number of various lenses and detectors, it is possible to generously
modify the measuring field, if the measuring distance is given.
For the application of the Infrared Radiation Pyrometer under high ambient tem-
perature, water-cooling, air purge fittings and vacuum tight lenses can be delivered
as accessories.

2-2
95582944 GENERAL KT15 II
1/01/04e HEITRONICS Infrarot Messtechnik GmbH
2.2 Infrared Radiation Pyrometers for GENERAL APPLICATION
The Infrared Radiation Pyrometers series KT15.81 II / KT15.82 II /KT15.83 II are
used to measure surface temperatures within a temperature range of - 50 °C to
1000 °C. The spectral sensitivity can be found within the range of the atmospheric
window, which is between 8 and 14 µm. As the atmospheric transmissivity is very
high in this spectral range, no weakening of the infrared radiation due to CO2or to
water vapor contained in the air is to be expected.
To meet especially high requirements as to the transmission of the atmosphere as it
is a case e.g. when carrying out meteorological measurements radiation pyrometer
KT15.85 II is suitable.
The KT15.81 II / KT15.82 II / KT15.83 II can be employed in the measuring of tem-
peratures during the production and processing of plastics, rubber, paper, textiles,
paint, ceramics etc. The emissivity of various metals is shown in figure 10 (chapter 8:
Illustrations).
The devices can also be used to measure the temperature of objects exposed to in-
frared radiation, since the radiation maximum of infrared radiators is within the range
of shorter wavelengths, which do not cause the Infrared Radiation Pyrometers
KT15.81 II / KT15.82 II / KT15.83 II to react.
The Infrared Radiation Pyrometer KT15.81 II is used in the spectral range of 8 to
10 µm. Besides being used for large-surface measurement, this pyrometer type is
also suitable for measuring thick foils.
The Infrared Radiation Pyrometer KT15.82 II is applied for the standard measuring
range of 8 to 14 µm thereby guaranteeing a good signal resolution.
The radiation pyrometer KT15.83 II provides a particularly high signal resolution ow-
ing to its large spectral range. Therefore, it is very well suited for measuring low tem-
peratures.
For high requirements on the transmission of the atmosphere, such as found in me-
teorological measurements, the KT15.85 II type is available. This device type oper-
ates within the spectral ranges of 9.6 to 11.5 µm, where the transmission of the at-
mosphere is extremely high.

2-3
95582944 GENERAL KT15 II
1/01/04e HEITRONICS Infrarot Messtechnik GmbH
2.3. Infrared Radiation Pyrometers for measuring METALS
The spectral emissivity of the Infrared Radiation Pyrometers KT15.01 II / KT15.02 II
is 2 to 2.7 µm and 2 to 4.5 µm. Within this spectral range, metals and metal-oxides
show a relatively high spectral emissivity. This is why the device is particularly well
suited to measure the temperatures of these materials. Since the atmospheric trans-
missivity is high within the spectral range of 2 to 2.7 µm, distortions of the measured
value owing to absorption of water vapor and CO2in the air can be ignored
(Fig. 11, ILLUSTRATIONS).
The Infrared Radiation Pyrometer type KT15.01 II is used for measuring tempera-
tures from 300 °C onwards; the radiation pyrometer type KT15.02 II is suitable for
measuring temperatures from 200 °C onwards. Temperatures from 500 °C respec-
tively 700 °C onwards are preferably measured by means of the spectral pyrometers
of the series KT18S or the quotient pyrometers of the series KT18R.
2.4 Infrared Radiation Pyrometers for measuring PLASTICS
These types of pyrometers are employed for the measuring of surface temperatures
of plastics within a temperature range of 0 to 600 °C.
These Infrared Radiation Pyrometers are equipped with narrow-band infrared filters.
KT15.21 II measures radiation at 3.43 µm,
KT15.23 II measures radiation at 6.8 µm,
KT15.24 II measures radiation at 7.93 µm,
KT15.25 II measures radiation at 8.05 µm.
Within these spectral ranges, virtually all synthetic materials have strong absorption
bands so that even thin foils show high emissivity.
The Infrared Radiation Pyrometer KT15.21 II is suitable for most foils from 100 °C
onwards.
The Infrared Radiation Pyrometer KT15.23 II measures thin foils made from polyeth-
ylene, polypropylene, polyisobutane, polynitrile, polystyrene and similar materials
from 0 °C onwards.
The Infrared Radiation Pyrometer KT15.24 II and KT 19.25 II measure thin foils poly-
ester as well as foils made from
- acrylic,
- cellulose,
- fluorine compounds,
- polycarbonate,
- polyamide,
- polyurethane,
- polyvinylchloride
and similar materials after analysis from 0 °C onwards.

2-4
95582944 GENERAL KT15 II
1/01/04e HEITRONICS Infrarot Messtechnik GmbH
2.5 Infrared Radiation Pyrometers for measuring GLASS
KT15.42 II is suitable for measuring glass and quartz. The spectral sensitivity is 4.9
to 5.5 µm. The emissivity of glass is very similar to the emissivity of a blackbody ra-
diator within this spectral range. Furthermore, this spectral range eliminates any dis-
turbing influences resulting from the strong absorption bands of water vapor at 6.2
µm.
The radiation pyrometers KT15.01 II and KT15.41 II are not measuring the surface
but the average value of temperatures up to a certain penetration depth (glass vol-
ume). The lower limits are 300 °C for KT15.01 II and 400 °C for KT15.41 II. The types
KT15.42 II and KT15.43 II measure the surface temperature from 100 °C respectively
from 0 °C onwards.
2.6 Infrared Radiation Pyrometers for measuring GASES
By means of narrow-band filters, the selective measurement of temperature of cer-
tain gases is possible. A rather long response time is to be chosen since the radiation
energy is very low.
KT15.21 II measures hydrocarbon from 100 °C onwards.
KT15.62 II measures materials within the absorption range of carbon dioxide and car-
bon monoxide,
KT15.63 II measures carbon monoxide selectively,
KT15.64 II is provided for nitrogen oxide and
KT15.69 II has been especially developed for determination of combustion tempera-
tures.
Using KT15.41 II, objects can be measured through gases and flames from 400 °C
onwards.

3-1
95582944 TECHNICAL SPECIFICATIONS KT15 II
4/02/05e HEITRONICS Infrarot Messtechnik GmbH
3 TECHNICAL SPECIFICATIONS
Spectral sensitivity: àDATA SHEET
Temperature measuring range: àDATA SHEET
Temperature resolution: àTables (Page 3-7ff)
Accuracy (provided that the emissivity has been correctly set, after a warm-up period of 15 min.):
± 0.5 °C plus 0.7 % of the temperature difference
between the housing containing the measuring in-
struments and the object to be measured
or: value of temperature resolution.
The higher value shall prevail.
Long-time stability: better than 0.1 ‰ of the absolute measuring tem-
perature in Kelvin/month
Lens used: àDATA SHEET
Possible lenses: àOPTIONS AND ACCESSORIES
Target diameter (95 %): The target diameter depends on the lens and the
detector used in each individual case.
When short-focus lenses are used, the distance
within which the minimum measuring field can be
found varies by ± 4%.
Field of view: Marking the field of view is carried out by means of
different accessories.
àOPTICAL ADJUSTMENT (chapter 4.5)
Radiation detector: HEITRONICS pyroelectric detector
Permissible ambient temperature: - 20 ... + 60 °C
For higher ambient temperatures, cooling and pro-
tecting jackets are available.
àOPTIONS AND ACCESSORIES and
àTECHNICAL INFORMATION TDI/W001a (below)
Storage temperature: - 20 … + 70 °C
Weight: approx. 0.55 kg
Dimensions: àFIGURES: Fig. 15

3-2
95582944 TECHNICAL SPECIFICATIONS KT15 II
9/10/05e HEITRONICS Infrarot Messtechnik GmbH
Analog output: possible signal outputs (variable by programming)
0 ... 20 mA, 4 ... 20 mA
0 ... 1 V, 0 ... 10 V
Lower temperature value (T.low): minimum temp. value for analog signal
Upper temperature value (T.end): maximum temp. value for analog output
Minimum temperature difference: depends on final temperature (T.end)
The following values will result:
Final temperature
Minimum temperature
difference
≤150 °C 50 °C
≤200 °C 100 °C
≤1000 °C 200 °C
> 1000 °C 400 °C
Load of analog output: current output: load ≤550 Ohm
voltage output: load ≥10 kOhm
Resolution of analog output: 12 bit
Digital interface V24 (RS232C): 9.6 ... 115.2 kBaud
Response time (90 %): variable by programming
KT15 IIP: 0,005; 0,01; 0,03; 0,1; 0,3; 1; 3; 10; 30;
60; 120; 240; 360, 480 und 600 s
KT15 IID: 0,03; 0,1; 0,3; 1; 3; 10 s
Operating voltages: alternating voltage 24 V ± 10 %, 48 ... 400 Hz
direct voltage 22 ... 30 V
Current consumption: ≤150 mA RMS
Type of protection: IP65
Protection against oscillation: DIN 40046 Bl. 8; test: Fc
vibration strength: A B1 E
frequency range: 10 to 55 Hz
amplitude: +/- 0.2 mm
duration of test/position: 30 min
Connector type: miniature circular connector, Franz Binder GmbH,
type 99-5630-15-12, series 423, 12 pin and
type 99-5626-15-07, series 423, 7 pin
Options:
Laser: ÆSAFETY INSTRUCTIONS
The integrated laser can not operate up to the
upper limit of the ambient temperature of 60°C.
Thermal switch: switching temperature: > 70 °C
load: voltage: ≤48 V, current: ≤0.5 A
alternative:
Analog input: 0 … 10 V
alternative:
Digital input: floating contact or 0 … 30 V (low 1 V, high 4 V)

3-3
95582944 TECHNICAL SPECIFICATIONS KT15 II
13/08/06e HEITRONICS Infrarot Messtechnik GmbH
Technical Information
Cooling Jacket WK15
The HEITRONICS Infrared Radiation Pyrometers can be operated at an environmental
temperature of up to 60°C without any additional coolants. If the environmental tempera-
tures are higher than that mentioned above, cooling fittings can be used.
Basically, the cooling jacket WK15 can be cooled with air or water. The possible maximum
environmental temperatures are higher for water cooling than for air cooling (Æindividual
data sheet).
If the cooling process is too strong, i.e. if the cooling air / cooling water is too cold, this
may result in condensate as soon as cooling medium falls below the dew point. To pre-
vent this from occurring, the cooling air / cooling water must have a minimum temperature
as a function of the relative humidity.
The following table specifies the minimum temperature of the cooling air / cooling water as
a function of the environmental temperature and the relative humidity of the environmental
air.
Minimum temperature of the cooling air / cooling water
Relative air humidity (of the environmental air)
Environmental
air temperature
/°C 2% 4% 10% 20% 30% 50% 70%
30,0 5,0 5,0 5,0 6,0 11,0 19,0 25,0 °C
40,0 5,0 5,0 5,0 13,0 20,0 28,0 34,0 °C
50,0 5,0 5,0 10,0 21,0 28,0 38,0 45,0 °C
60,0 5,0 5,0 18,0 28,0 38,0 47,0 54,0 °C
70,0 5,0 9,0 24,0 38,0 45,0 57,0 nm °C
80,0 5,0 15,0 32,0 45,0 55,0 nm nm °C
90,0 10,0 21,0 38,0 52,0 nm nm nm °C
>100,0 15,0 27,0 45,0 60,0 nm nm nm °C
Legend: nm * Operation not possible since the minimum temperature is above 60°C
Table: Minimum temperature of the coolant

3-4
95582944 TECHNICAL SPECIFICATIONS KT15 II
8/07/05e HEITRONICS Infrarot Messtechnik GmbH
Assignment for 12pin connector - for RS232-Interface
ATTENTION
In case of wrong connection,
the device might be destroyed.
Note 1: Hardware-Programming see data sheet page 1-1
Note 2: Valid for Interface map with isolation and open-collector-output.
Note 3: Valid for Interface map with isolation and 2 open-collector-output.
Cores
color
Code
DIN IEC 757
plug-in
contacts Function RS232
9 pin
RS232
25 pin
red RD A CTS 7 4
white
WH B
−supply voltage
(AC or DC)
+ thermal switch
analog input
digital input (note 1)
isolated digital
input (DI)
24V-logic / 5V-logic (note 2)
green/white
- alternative:
grey/pink
or colorless
GNWH
GYPK
colorless
C
open-collector
output 2 (DO 2) (note 3)
- thermal switch
analog input
digital input (note 1)
DI/DO-zero (Gnd) (note 2)
grey GY D
DI/DO/DO2-zero (Gnd) (note 3)
yellow YE E + analog output
DTR 6 6
brown/white
- alternative:
red/blue
or orange
BNWH
RDBU
OR
F
open-collector
output (DO) (note 2)
pink PK G TXD 2 3
violet VT H RTS 8 5
blue BU J RXD 3 2
black BK K −Datacom (data ground) 5 7
brown BN L + supply voltage
(AC or DC)
green GN M - analog output

3-5
95582944 TECHNICAL SPECIFICATIONS KT15 II
10/02/06e HEITRONICS Infrarot Messtechnik GmbH
Assignment for 12pin connector - for RS485-Interface
ATTENTION
In case of wrong connection,
the device might be destroyed.
Note 1: Hardware-Programming see data sheet page 1-1
Note 2: Valid for Interface map with isolation and open-collector-output.
Note 3: Valid for Interface map with isolation and 2 open-collector-output.
Note 4: Valid for RS485, Full-Duplex
Note 5: Valid for RS485, Half-Duplex
Cores
color
Code
DIN IEC 757
plug-in
contacts Function
BUS + input (note 1, 4)
red RD A
not connected (note 1, 5)
white
WH B −supply voltage (AC or DC)
+ thermal switch
analog input
digital input
(note 1)
isolated digital input (DI)
24V-logic / 5V-logic (note 1, 2)
green/white
- alternative:
grey/pink
or colorless
GNWH
GYPK
colorless
C
open-collector
output 2 (DO 2) (note 1, 3)
- thermal switch
analog input
digital input
(note 1)
DI/DO-zero (Gnd) (note 1, 2)
grey GY D
DI/DO/DO2-zero (Gnd) (note 1, 3)
yellow YE E + analog output
brown/white
- alternative:
red/blue
or orange
BNWH
RDBU
OR
F open-collector output (DO) (note 1, 2)
BUS - output (note 1, 4)
pink PK G
BUS - input / BUS - output (note 1, 5)
BUS + output (note 1, 4)
violet VT H
BUS + input / BUS + output (note 1, 5)
BUS - input (note 1, 4)
blue BU J
not connected (note 1, 5)
black BK K BUS-GND
brown BN L + supply voltage (AC or DC)
green GN M - analog output

3-6
95582944 TECHNICAL SPECIFICATIONS KT15 II
1/01/04e HEITRONICS Infrarot Messtechnik GmbH
Assignment for 7pin connector
ATTENTION
When connecting the Infrared Radiation Pyrometer to the
transformer T14 the connection diagram in
the cover of the transformer must be considered.
Note 1: Hardware-Programming see data sheet page 1-1
The load resistors for the analog outputs are:
►for voltage output 0 to 1 V ≥10 kOhm,
►for voltage output 0 to 10 V ≥10 kOhm,
►for current output 0 to 20 mA ≤550 Ohm
►for current output 4 to 20 mA ≤550 Ohm
For the signal evaluation, differential inputs are recommended.
Cores
color
Code
DIN IEC 757
plug-in
contacts
brown BN 4
white WH 2
+ supply voltage
(AC or DC)
−
yellow YE 5
green GN 1
+
analog output
−
blue BU 3 housing
pink PK 6 + thermal switch
analog input
digital input (note 1)
grey GR 7 - thermal switch
analog input
digital input (note 1)

3-7
95582944 TECHNICAL SPECIFICATIONS KT15 II
5/03/05e HEITRONICS Infrarot Messtechnik GmbH
Temperaturauflösung/Temperature resolution KT15.01 II / KT15.02 II
Temperature resolution (NET) in ± K (emissivity-setting = 1; σ= 2) for standard lenses.
When using lenses with spacer and special lenses the temperature resolution will increase up to
double.
** Value is > 20 °C. This setting is not recommended.
Table: Temperature resolution Infrared Radiation Pyrometer KT15.01 II / KT15.02 II
KT15.01 II KT15.02 II
Detektortyp
Detector type
Detektortyp
Detector type
Strahler-
temperatur
Radiation
temperature
Einstell-
zeit
Response
time
A B C G
Einstell-
zeit
Response
time
A B C G
5 ms ** ** ** ** 5 ms 4.50 16.70 ** **
10 ms ** ** ** ** 10 ms 3.65 13.55 ** **
30 ms ** ** ** ** 30 ms 1.35 4.95 12.10 **
100 ms 10.00 ** ** ** 100 ms 0.55 2.05 4.95 16.45
300 ms 6.70 ** ** ** 300 ms 0.35 1.35 3.30 11.00
1 s 2.80 10.30 ** ** 1 s 0.15 0.55 1.35 4.60
3 s 1.65 6.20 15.00 ** 3 s 0.10 0.35 0.80 2.75
200 °C
10 s 1.10 4.10 10.00 ** 10 s 0.05 0.25 0.55 1.85
5 ms 13.30 ** ** ** 5 ms 1.35 4.85 11.80 **
10 ms 10.80 ** ** ** 10 ms 1.05 3.95 9.60 **
30 ms 3.95 14.65 ** ** 30 ms 0.40 1.45 3.50 11.70
100 ms 1.60 6.00 14.55 ** 100 ms 0.15 0.60 1.45 4.80
300 ms 1.10 4.00 9.70 ** 300 ms 0.10 0.40 0.95 3.20
1 s 0.45 1.65 4.05 13.50 1 s 0.05 0.15 0.40 1.35
3 s 0.25 1.00 2.45 8.10 3 s 0.05 0.10 0.25 0.80
300 °C
10 s 0.20 0.65 1.60 5.40 10 s 0.05 0.05 0.15 0.55
5 ms 1.45 5.25 12.80 ** 5 ms 0.50 1.15 2.60 8.60
10 ms 1.15 4.25 10.40 ** 10 ms 0.30 0.90 2.10 7.00
30 ms 0.45 1.55 3.80 12.70 30 ms 0.20 0.35 0.80 2.55
100 ms 0.20 0.65 1.55 5.20 100 ms 0.05 0.15 0.30 1.05
300 ms 0.10 0.45 1.05 3.45 300 ms 0.05 0.10 0.20 0.70
1 s 0.05 0.20 0.45 1.45 1 s 0.05 0.05 0.10 0.30
3 s 0.05 0.10 0.25 0.85 3 s 0.05 0.05 0.05 0.15
500 °C
10 s 0.05 0.05 0.15 0.60 10 s 0.05 0.05 0.05 0.10
5 ms 0.65 1.60 3.80 12.55 5 ms 0.60 0.75 1.20 3.50
10 ms 0.40 1.30 3.05 10.15 10 ms 0.35 0.45 0.90 2.80
30 ms 0.20 0.50 1.15 3.75 30 ms 0.25 0.25 0.40 1.05
100 ms 0.05 0.20 0.45 1.50 100 ms 0.05 0.10 0.15 0.40
300 ms 0.05 0.15 0.30 1.00 300 ms 0.05 0.05 0.10 0.30
1 s 0.05 0.05 0.15 0.40 1 s 0.05 0.05 0.05 0.10
3 s 0.05 0.05 0.10 0.25 3 s 0.05 0.05 0.05 0.05
700 °C
10 s 0.05 0.05 0.05 0.15 10 s 0.05 0.05 0.05 0.05
5 ms 0.80 0.95 1.55 4.45 5 ms 0.95 1.00 1.05 1.80
10 ms 0.45 0.60 1.15 3.55 10 ms 0.50 0.50 0.60 1.35
30 ms 0.30 0.35 0.50 1.35 30 ms 0.35 0.35 0.40 0.60
100 ms 0.10 0.10 0.20 0.55 100 ms 0.10 0.10 0.10 0.20
300 ms 0.05 0.05 0.10 0.35 300 ms 0.05 0.05 0.10 0.15
1 s 0.05 0.05 0.05 0.15 1 s 0.05 0.05 0.05 0.05
3 s 0.05 0.05 0.05 0.10 3 s 0.05 0.05 0.05 0.05
1000 °C
10 s 0.05 0.05 0.05 0.05 10 s 0.05 0.05 0.05 0.05

3-8
95582944 TECHNICAL SPECIFICATIONS KT15 II
5/03/05e HEITRONICS Infrarot Messtechnik GmbH
Temperaturauflösung/Temperature resolution KT15.21 II
Temperature resolution (NET) in ± K (emissivity-setting = 1; σ= 2) for standard lenses.
When using lenses with spacer and special lenses the temperature resolution will increase up to
double.
** Value is > 20 °C. This setting is not recommended.
Table: Temperature resolution Infrared Radiation Pyrometer KT15.21 II
KT15.21 II
Detektortyp
Detector type
Strahler-
temperatur
Radiation
temperature
Einstell-
zeit
Response
time
A B C G
5 ms ** ** ** **
10 ms ** ** ** **
30 ms ** ** ** **
100 ms ** ** ** **
300 ms ** ** ** **
1 s ** ** ** **
3 s ** ** ** **
20 °C
10 s ** ** ** **
5 ms ** ** ** **
10 ms ** ** ** **
30 ms ** ** ** **
100 ms ** ** ** **
300 ms ** ** ** **
1 s 9.10 ** ** **
3 s 5.45 ** ** **
100 °C
10 s 3.65 13.50 ** **
5 ms ** ** ** **
10 ms ** ** ** **
30 ms 12.55 ** ** **
100 ms 5.15 19.00 ** **
300 ms 3.40 12.65 ** **
1 s 1.45 5.25 12.85 **
3 s 0.85 3.15 7.70 **
200 °C
10 s 0.55 2.10 5.15 17.10
5 ms 13.10 ** ** **
10 ms 10.60 ** ** **
30 ms 3.90 14.40 ** **
100 ms 1.60 5.90 14.30 **
300 ms 1.05 3.90 9.55 **
1 s 0.45 1.65 4.00 13.25
3 s 0.25 1.00 2.40 7.95
300 °C
10 s 0.20 0.65 1.60 5.30
5 ms 6.05 ** ** **
10 ms 4.90 18.15 ** **
30 ms 1.80 6.65 16.20 **
100 ms 0.75 2.75 6.65 **
300 ms 0.50 1.80 4.40 14.75
1 s 0.20 0.75 1.85 6.15
3 s 0.10 0.45 1.10 3.70
400 °C
10 s 0.10 0.30 0.75 2.45
