HELGI LIG0350MINI User manual

VGA to HDMI converter User Manual
Thank you for purchasing this device.
VGA to HDMI converter box converts PC VGA and audio to HDMI, allowing
connection of PC to 1080p HDTV. It supports multiple resolution up to
1920x1080@60HZ. It is without scaler,while it supports th most popular resolutions
to ensure high compatibility with wide brands of PCs and HDTVs. It provides cheaper
solution of connecting PC to HDTV.
IMPORTANT SATETY INSTRUCTIONS
1,To reduce the risk of fire or electric shock and damage,do not expose this unit to
rain,moisture and liquid. Do not put heavy stuff on it. Do not put heavy stuff on it.
2, Make sure good ventilation openings to avoid product overheating damage and
fire. Do not install I inside of cabinet or other confined space.
3, It is designed to convert VGA to HDMI. Do not use it for other purpose.
4, Keep this user manual properly for future reference.
I.PACKAGE CONTENTS

II. INSTALLATION REQUIREMENTS
1,VGA signal input
2,3.5mm audio signal input
3,HDMI signal output
4,DC 5V input, this converter can be powered from VGA port,when failure, it can be
powered from PC’s USB port by USB to micro USB cable.
III. PORTS
①VGA signal input ②3.5mm audio signal input
③HDMI signal output ④DC 5V input, this converter can be powered
from VGA port,when failure, it can be powered from PC’s USB port by USB to micro
USB cable.
IV. CONNECTION IMAGES

V. FEATURES
1. Input: VGA x 1, 3.5mm audio x1.
2. Output : HDMI x1
3. Input VGA resoluton supported:
640 x 480@60HZ, 800 x 600@60HZ,
1024 x 768@60HZ, 1280 x 720@60HZ,
1280 x 768@60HZ, 1360 x 768@60HZ,
1440 x 900@60HZ, 1600 x 1200@60HZ,
1680 x 1050@60HZ, 1920 x 1080@60HZ,
4. This is a pass through solution,the output resolution is the same as the resolution
input.
VI. FAQ
Q1:After connecting well, no image output.
A1:Step 1:Please check and make sure there is image output from VGA source
device.
Step 2:Please use a USB to micro USB cable to connect this converter and PC for
extra power supply.
Q2: The output picture is not clear or there is a hint about the resoution non
supported.
A2: Please change the VGA source output resoution to another one.

VII. SPECIFICATIONS
Power supply
Power from VGA port,when failure,please use a USB
to micro USB cable to power from PC’s USB
Input VGA resolution
supported
From 640x480@60HZ up to 1920x1080@60HZ
Audio input signal
3.5mm audio
DDC signal
5Vp-p(TTL)
TMDS signal
0.5-1.0Vp-p
Output HDMI
resolution supported
From 640x480@60HZ up to 1920x1080@60HZ
Consumption
≤2W
Dimension
85.5x45.8x17.5mm
