It is a machine with upper drainage,
it can drain even if drain hose is
hung up, but the hose should not be
positioned over 0.9m.
If it is needed,the drain hose can be
laid down on the ground to drain.
Be careful that the end of the
drain hose is not immersed in
water.
The earthing which is indicated by yellow and
green colour must be firmly connected to a special
Earthing. Please call the technician to assemble.
The socket should have assembled the 3A
fuse.
Never try to connect the earthing of the
washing machine together with that of gas
pipe or water pipe, telephone cord or lighten-
ing rod.
Do not use the damaged cord because it could
cause electricity leakage and fire.
In case cord is damaged, please contact the
local service company, because it is re-
moved and replaced with special tools.
NOTE:
Drain model
<0.9m
Connection of the power cord
Change the direction of the drain hose (if necessary)
Lay down the machine on soft objects
Unfasten the screw, and take out the
mice-proof plate
1
Unfasten the secured screw of the drain
hose joint
Take out the drain hose at the bottom of
machine
2
Soft object
Front
Back
Front
Soft object
Mice proof plate
Change the drain hose to another side
Change the place of drain hose chuck and
cover
3
4
Fasten the drain hose chuck and screw
Fix the mice-proof plate and fasten the
screw
Back
Front
Mice proof plate Soft object
Back
Front
Soft object
Mice proof plate
Back
Screw
Mice proof plate
