Helvex MB-1011 User manual

Secador de Manos con Botón / Hand
Dryer with Button
Requerimientos de
Instalación
Hola soy Fluxy, te
ayudaré a instalar
tu producto.
INSTALLATION GUIDE
GUÍA DE INSTALACIÓN
1-08-0825-3
Hi I'm Fluxy, I'll
help you to install
your product.
Installation Requirements
ADVERTENCIA / WARNING
Para disminuir el riesgo de lesiones o daños a la propiedad, lea todas las instrucciones antes de instalar el
producto. Utilice gafas de seguridad. En obras de construcción, instalación, modificación, ampliación y
reparación deben cumplir con el reglamento de construcción y obras de su localidad. El producto ilustrado
puede sufrir cambios de aspecto como resultado de la mejora continua a la que está sujeto.
Agradecemos su elección por los productos HELVEX.
Estamos seguros de que su confiabilidad por el producto excederá sus más altas expectativas, cuya
funcionalidad, estética, durabilidad, respaldo integral y alta calidad le otorgarán plena satisfacción por años,
reflejando el compromiso con la calidad, innovación y el medio ambiente que forman parte de Helvex.
Thank you for choosing HELVEX products.
We are confident that the product reliability will exceed your highest expectations, whose functionality,
aesthetics, durability, high quality and comprehensive support grant him full satisfaction for years, reflecting
the commitment to quality, innovation and the environment as part Helvex.
To reduce the risk of injury or property damage, read all instructions before installing the product. Use safety
glasses. In construction, installation, alteration, extension and repair must comply with the rules of
construction an your local. The illustrated product may change in appearance as a result of continuous
improvement to which it is subject.
Herramienta Requerida / Required Tools
phillips screwdriver
drill with 5/16”
76
A
CD
B
E
F
N
L
5 4 3 2 1
taladro con
broca de 5/16”
A Resistencia / Resistance
B Fusible / Fuse
C Motor / Motor
D Capacitor / Capacitor
E Micro Interruptor / Micro Switch
F Termostato / Thermostat
destornillador
de cruz
phillips screwdriver
destornillador
plano
Diagrama eléctrico / General Installation
Datos Técnicos / Technical Data
Voltaje / Voltage
Frecuencia / Frequency
Corriente / Current
Potencia / Power
Dimensiones / Dimensions
120 V~
60 Hz
16 A
1800 W
A:230mm L:267mm Prof:172mm
MB-1011
El aparato no debe utilizarse por personas (incluyendo niños) con capacidades físicas sensoriales o mentales
reducidas, o carezcan de experiencia o conocimiento, a menos que reciban supervisión o capacitación.
Los niños deben supervisarse para que no jueguen con el aparato.
The device should not be used by persons (including children) with reduced physical sensory or mental
capabilities, or lack of experience and knowledge, unless they receive supervision or training.
Children should be supervised to not play with the appliance.
[email protected]
Original Spare Parts:
Consultancy and Technical
(52) 55 53 33 94 31
(52) 55 53 33 94 00
Refacciones Originales:
Asesoría y Servicio Técnico:
Ext. 5913, 5068 y 4815
Service:
(52) 55 53 33 94 21
[email protected]
www.refaccioneshelvex.com.mx
Esta guía de instalación aplica al producto en cualquier acabado. / This installation
guide applies to the product in any finish.
Inserte los taquetes y fije la base. / Tap the wall and secure the base.
Barrenos
en muro
Holes in wall
Afloje la abrazadera
para el paso del cable.
Loosen the clamp over cable.
4
3
2
Plantilla
Template
Coloque la plantilla, marque y
barrene. / Place the template,
mark and drill.
2
Plantilla / Template
Instalación Base / Installation Base
Instalación Cubierta / Cover Installation
Conecte los cables, y coloque la cubierta, apretando los tornillos laterales para asegurarla. / Connect the cables, and replace the cover,
tightening the side screws to secure it.
Antes de conectar,
asegúrese de bajar el
interruptor. / Before
connecting, be sure to
turn the switch.
1
utilice broca para
concreto de Ø 5/16”
use concrete drill Ø 5/16 "
Plantilla de instalación / Installation template
NPT
altura recomendada 130 cm
recommended height 130 cm FP
Final de Pared
(End Wall)
*36 cm
(14,1”)
20,1 cm
(7,91”)
18,3 cm
(7,2”)
2,4 cm
(0,9”)
2,2 cm
(0,87”)
Ø
Nivel de Piso Terminado
(Finished Floor Level)
*Recommended Actions
*Medidas Recomendadas
Antes de la instalación,
se debe tener la
preparación del ducto
eléctrico en el muro. /
Before installation, you
must have the
preparation of electrical
conduit in the wall.
Requerimientos de Instalación / Installation Requirements
6
5
Operación / Operation
Despiece / Exploded
Presione el botón para accionar el secador. / Press the button to operate the dryer.
1 Base / Base
2 Termostato / Temperature
3 Micro Interruptor / Micro switch
4 Resistencia / Resistance
5 Motor / Engine
6 Cubierta / Cover
1
2
3
4
5
6
3
4
Posibles Causas y Soluciones / Possible Causes and Solutions
Problema Causa Solución
Alimentación eléctrica sin corriente. / Without power
supply.
Verifique que esté conectado a la corriente eléctrica. / Verify
that you are connected to the mains.
Cables de conexión sueltos y rotos. / Broken wires and
loose connections.
Verifique el paso de corriente con un detector de CA. / Check
current flow detector with CA.
Esta obstruido el sensor óptico. / This obstructed the
optical sensor. Retire lo que obstruye al sensor. / Remove that hinders sensor.
El secador se encuentra muy cerca de un objeto que
refleja la señal, y vuelve arrancar. / The dryer is very
close to an object reflecting the signal, and start again.
Colocar en otro sitio el secador o el objeto reflejante. / Place in
the dryer or else the reflecting object.
No se activa. / No active.
No se apaga. / Not off.
“Si el cordón de alimentación es dañado, éste debe sustituirse por el fabricante, por su agente de servicio autorizado o por personal calificado con el fin de
evitar un peligro.”/ "If the power cord is damaged, it must be replaced by the manufacturer, its authorized service agent or a similarly qualified in order to avoid
hazard.”
Recomendaciones / Recommendations
1. Este aparato no se destina para utilizarse por personas (incluyendo niños) cuyas capacidades físicas, sensoriales o mentales sean diferentes o
estén reducidas, o carezcan de experiencia o conocimiento, a menos que dichas personas reciban una supervisión o capacitación para el
funcionamiento del aparato por una persona responsable de seguridad.
2. Los niños deben supervisarse para asegurar que ellos no empleen los aparatos como juguete.
1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities may be different or
reduced, or lack of experience or knowledge, unless such persons are supervision or training to operate the appliance by a person responsible for
security.
2. Children should be supervised to ensure they do not use the devices as a toy.
HELVEX, S. A. DE C. V. Calzada Coltongo # 293, Col. Industrial Vallejo, Alcaldía Azcapotzalco, C. P. 02300, Ciudad de México.
Es muy importante seguir las siguientes instrucciones para conservar los
acabados de los productos HELVEX, con brillo y en perfecto estado:
1. Utilice únicamente agua y un paño limpio.
2. No utilice fibras, polvos, abrasivos, ni productos químicos.
3. No utilice objetos punzo-cortantes para limpiar los acabados.
4. Se recomienda realizar la limpieza de su producto diariamente.
Visite nuestras páginas www.helvex.com.mx para México y www.helvex.com
para el mercado Internacional
It is very important to follow the instructions below to preserve HELVEX products
finishes, shiny and in perfect condition:
1. Use only water and a clean cloth.
2. Do not use fibers, powders, abrasives, or chemicals.
3. Do not use sharp objects to clean the finish.
4. It is recommended to clean your product daily.
Visit our pages www.helvex.com.mx for Mexico and www.helvex.com
for the International market.
Recomendaciones de Limpieza / Cleaning Recommendations
In Guadalajara:
Contact:
Enter our free
training courses.
In Monterrey:
En la Ciudad de México:
In Mexico City:
En Monterrey: En Guadalajara:
(52) 55 53 33 94 00
Ext. 5806, 5805 y 5804
33 36 19 01 13
Comunícate:
Participa en nuestros
cursos gratuitos
de capacitación.
81 83 33 57 67
81 83 33 61 78
