Hembry Creek BLOX Combo User manual

TM
INSTALLATION INSTRUCTIONS
BLOX Combo
VANITY
HCK-BLOX-DRG30DWVC1
THANK YOU FOR CHOOSING HEMBRY CREEK
Please take a few minutes to review this manual before you start installation. If you encounter any installation problems, please don’t
hesitate to contact us. Before you begin, please observe all local building codes. Unpack the new product and inspect for damage.
The appearance of your vanity may differ from the illustrations in this guide.This instructions still apply. Please ensure the finished wall
is straight and plumb and the floor is flat and perpendicular to the finished wall.
ROUGH-IN DIMENSIONS
SUGGESTED TOOLS AND MATERIALS
Philips Screwdriver Level Drill Tape Measure Safety Glasses
10'
BLOX-DRG30XX 30”
Model # X (inch)
20” (508mm)
21.5” (546mm)
FLOOR
FINISHED
WALL
X (inch)
Y (inch)
Undermount
Application Y (inch)
14”
SUGGESTED HEIGHT:
3-7/8” (100mm)

2” x 12”
Header
WALL PREPARATION
Undermount
Application Z (inch)
35”
SUGGESTED HEIGHT:
Finished Wall
Z
Notch studs 1-1/2" (38mm) to
provide support for header.
Extend the header beyond the
countertop to the nearest stud.
INSTALLATION INSTRUCTIONS
1. 2.
Remove wood supports from the back of vanity.

• To maintain the beauty of the finish, avoid placing the furniture in direct sunlight, as sunlight causes fading.Also avoid extreme
changes in temperature by arranging furniture away from radiators, heat and air vents, and air conditioning units. Avoid placing furniture
directly under windows.
• Dust the vanity frequently with a clean, soft, dry or lint-free cloth. Clean the surface by rubbing in the direction of the grain using damp
lint-free cloth. Avoid using silicone cleaners and waxes.
• Clean up excess water and spills immediately. Use blotting rather than a wiping action. Water left over a long period of time will cause
white spots in the finish. Please note that some chemicals may damage the finish.
CARE AND CLEANING
3.
Level the vanity with a leveler and attach the brackets to the 2 x 12 header using screws provided.
INSTALLATION INSTRUCTIONS
BLS01
HARDWARE INCLUDED
x 8

For customer support please email [email protected] or call 866 395 8112 weekdays 8:00 to 5:00 EST or fax [phone] any time
Rev 2/10
SIDE
CAM HEIGHT
TILT
ADJUSTMENT
1
21
2

For customer support please email [email protected]or call 866 395 8112 weekdays 8:00 to 5:00 EST or fax [phone] any time
INSTALLATION INSTRUCTIONS
CHINA VANITY TOP
SQUARE BOWL
(all sizes)
SUGGESTED TOOLS AND MATERIALS
Silicone Sealant Level Tape Measure Safety Glasses
1 0 '
VANITY TOP INSTALLATIONS
Optional Leveling
Spacer (included)
Silicone Sealant
1. Install the cabinet / vanity according to the cabinet / vanity manufacturer
2. Check to make sure the vanity top sits level on top of the vanity
3. If all four corners of the vanity top do not sift flush on the vanity, use the optional leveling spacers (included)
to help level the vanity top
4. Apply silicone sealant to the top of cabinet / vanity as shown above
5. Install faucet and and drain assembly per the manufacturers' instructions
** NOTE: top style, shape, cutout on top,
vanity may vary from the picture above.
Instructional purposes only.
CARE AND CLEANING
For best results in caring for your vitreous china top, we suggest:
- Always wipe off spills immediately.
- Never use strong / abrasive cleaner. Always test your cleaning solution on unnoticeable areas before applying to
the entire surface.
- Wipe surfaces clean, immediately after applying cleaner.
- Do not allow cleaner to sit or soak. Never let cleaners sit on the surface of the vitreous china for long periods of time.
- Use a soft, dampened sponge and cloth. Never use an abrasive material such as brush or scouring pad to clean
surfaces. They will scratch the surface of the vitreous china top and lavatory.
- Always rinse and wipe clean the fixtures to prevent soap buildup.
