HEPER PRIFMA ML EVO 1 Installation and operating instructions

1/3 2022-1 / 27/01/2022
Installation & Maintenance
Instructions
HEPER USA LLC
W227 N546 Westmound Drive Waukesha, 53186
Wisconsin, United States
[phone]
[email protected]
PRIFMA ML EVO 1 Module Duo (LL2044.681-US)
56.27 lbs (10'), 68.35 lbs (13')
https://heperlighting.com/us/ll2044.681-us/

2/3

3/3
English ( USA )
Safety
- The product must be installed in accordance with applicable
NEC standards by a qualified electrician familiar with the
installation of exterior lighting fixtures.
- The product must be operated under specified voltage at all
times.
- Do not install if parts are damaged.
- Power must be disconnected while installing or servicing to
avoid electrical shock.
- Failing to comply with warnings and installation steps in this
document might void warranty.
- Do not touch the light source.
- Make sure that temperature of the product is at a safe level before
touching.
- Do not allow cables to touch sharp edges of metal parts or other sharp
objects to avoid damage or abrasion.
- Check all of the cable connections including grounding before
powering the product.
- Check the proper grounding of the metal housing before powering the
product.
- Only use the product for its intended purposes.
- Do not use accessories not approved or recommended by
HEPER.
- Replace any broken/cracked protective surface with a new
one
Installation
- The surface on which the product will be mounted must be flat and
level
- Assemble the product base using the provided or appropriate
hardware.
- Place the base of the product centered onto the concrete base and
secure the bolts as shown on the visual.
- Make the external power line connection as shown on the visual.
Replacement of the light source
- Disconnect the power coming into the product.
- Remove the light source from the head and unscrew it from the
backplate.
- Reinstall the product following the same steps.
Replacement of the control gear
- Disconnect the power coming into the product.
- Disassemble the product head.
- Remove the plate to gain access to the driver location.
- Remove the driver holder.
- Unscrew the driver holder from the housing to be able to pull it out
from the product.
- Detach the driver and place the new one.
- Reinstall the product following the same steps.
- The completed product installation should be as shown on the visual.
Cleaning - Maintenance
- The product was designed and manufactured to operate for a long
period of time. To ensure maximum lifespan of the product, regular (i.e.
every six months) visual inspection and cleaning with a solvent-free
cleaner using a soft cloth is recommended.
- Do not clean or service while the product is power connected.
Disposal
- In accordance with EU Directive WEEE (Waste Electrical and
Electronic Equipment), luminaires must not be disposed of with
other household waste. At the end of their life, luminaires must
be taken to the appropriate local facility available for the
disposal or recycling of electronic products.
Wiring Color Codes
- Ground - GREEN
- Line - BLACK
- Neutral - WHITE
- Dim(+) - RED/PURPLE
- Dim (-) - GRAY/ORANGE
Disclaimer
- HEPER reserve the right to make technical and design changes.
