Hercules DJ Console Rmx User manual

ITALIANO
DEUTSCH
ESPAÑOL
NEDERLANDS
ENGLISH
FRANÇAIS
CONTENTS
1. INTRODUCTION ...................................................................................................................................2
2. MINIMUM SYSTEM REQUIREMENTS.................................................................................................3
3. INSTALLATION.....................................................................................................................................4
3.1. First installation.............................................................................................................................4
3.2. ConnectinganddisconnectingyourDJConsoleRmx.................................................................5
3.3. Powerconsumption.......................................................................................................................5
4. OVERVIEW............................................................................................................................................6
4.1. The top face ..................................................................................................................................6
4.2. Theconnectors..............................................................................................................................7
5. OUTPUT OPTIONS...............................................................................................................................8
5.1. Connectingspeakersand/oranexternalmixertoyourDJConsoleRmx....................................8
5.2. Connectingheadphones...............................................................................................................9
6. INPUT OPTIONS ...................................................................................................................................9
6.1. Connectingexternalaudiosources...............................................................................................9
6.2. Connectingamicrophone...........................................................................................................10
7. DJ CONSOLE RMX FEATURES ........................................................................................................10
7.1. Jogwheels..................................................................................................................................10
7.2. Faders(sliders)...........................................................................................................................11
7.3. Play/Pause,StopandCuebuttons.............................................................................................12
7.4. BackwardandForwardbuttons..................................................................................................12
7.5. Pitch settings...............................................................................................................................12
7.6. Sourcebuttons............................................................................................................................12
7.7. Effects and loops (buttons 1-6)...................................................................................................12
7.8. LoadDeckbuttons......................................................................................................................13
7.9. Beat Lock buttons .......................................................................................................................13
7.10. CueSelectbuttons......................................................................................................................13
7.11. Browserbuttons..........................................................................................................................13
7.12. Balanceknob...............................................................................................................................14
7.13. MonitorSelectknob....................................................................................................................14
7.14. Equalizationknobs......................................................................................................................14
7.15. Kill buttons...................................................................................................................................14
8. THE TASKBAR ICON AND CONTROL PANEL................................................................................15
8.1. TheDJConsoleRmxtaskbaricon.............................................................................................15
8.2. UsingtheDJConsoleRmxcontrolpanel...................................................................................15
9. USING THE DJ CONSOLE RMX AT A PARTY................................................................................. 19
9.1. Overview .....................................................................................................................................19
9.2. MixinginVirtualDJ......................................................................................................................19
9.3. Scratching ...................................................................................................................................23
10. MIDI STANDARD SUPPORT..............................................................................................................24
11. FREQUENTLY ASKED QUES T I O N S ................................................................................................27
12. TECHNICAL SUPPORT......................................................................................................................29

2/32 – User Manual
1. INTRODUCTION
Your DJ Console Rmx is a powerful and versatile piece of hardware that offers nearly unlimited
possibilities in terms of what you can do with your music. You can use your DJ Console Rmx on
its own or with an external mixer, and you can mix both digital audio files and external analog
audio sources, including turntables. The DJ Console Rmx is easy to learn and also offers many
advanced functionalities, making it perfect for all users from beginners to seasoned professionals.
The DJ Console Rmx functions with digital audio files, including MP3s. We would like to draw
your attention to the fact that musical creations are protected by copyright and that you must
comply with all applicable legislations. We strongly encourage you to support artists by acquiring
their works legally.

ITALIANO
DEUTSCH
ESPAÑOL
NEDERLANDS
ENGLISH
FRANÇAIS
User Manual – 3/32
2. MINIMUM SYSTEM REQUIREMENTS
PC:
Desktop/laptop PC with Intel Pentium III/Athlon 1GHz processor or compatible
512MB RAM
Operating system: Microsoft Windows XP/Vista 32-bit
Available USB port
Headphones or amplified speakers
CD-ROM or DVD-ROM drive
1024x768 video resolution
Microphone, Internet connection + 100MB free hard disk space for some applications
Mac:
Desktop/laptop Mac with 1.5GHz processor
512MB RAM
Operating system: Mac OS 10.4/10.5 or higher Mac OS 10 release
Available USB port
Headphones or amplified speakers
CD-ROM or DVD-ROM drive
1280x800 video resolution
Microphone, Internet connection + 100MB free hard disk space for some applications

4/32 – User Manual
3. INSTALLATION
3.1. First installation
You must install your DJ Console Rmx’s drivers before connecting it to your computer.
Note: Your installation screens and procedure may vary slightly from those described in this
manual.
Because drivers and software are constantly being developed, the ones provided on your
CD-ROM may not be the most recent versions. You can visit the Hercules website to verify this
and, if necessary, download the very latest versions.
3.1.1.Installing drivers and software
- Insert the installation CD-ROMintoyourCD-ROMdrive.
The DJ Console Rmx installation menu automatically appears.
If the installation menu is not launched
automatically:
PC:
- Double-click Computer (Windows Vista)/My Computer
(WindowsXP).
- Double-click the CD-ROMicon.
- Double-click Setup.exe.
Mac:
- OpenyourFinder.
- Double-click the CD-ROMicon.
- Double-click Setup.exe.
- Follow the on-screen instructions to install the drivers and
software.

ITALIANO
DEUTSCH
ESPAÑOL
NEDERLANDS
ENGLISH
FRANÇAIS
User Manual – 5/32
A dialog box appears, prompting you to connect the D J
Console Rmx to your computer’s USB port.
- Connect the DJ Console Rmx to one of yourcomputer’s USB
portsusingtheUSBcableprovided.
We recommend that you connect the DJ Console Rmx to a USB port on your
computer or to a powered USB hub. Don’t connect the console to a non-powered USB hub.
Your computer automatically detects your DJ Console Rmx and installs the required drivers.
A progress bar appears, depicting the progress of the installation. Please note that this may take
up to 30 seconds, depending on your computer.
- Let the installation procedure run its course and do not do anything until you receive a message
indicating that the installation has completed.
You will be prompted to enter your VirtualDJ serial number the first time you run VirtualDJ, found
on the envelope of your DJ Console Rmx installation CD-ROM.
- Enter the serial number and click OK.
VirtualDJ is launched automatically. The VirtualDJ icon now appears on your desktop.
Windows may prompt you to reboot your computer at the end of the driver installation.
The DJ Console Rmx icon appears in the taskbar, indicating that your DJConsole Rmx is ready
for use.
For information on launching the control panel, please see section 8.1. The DJ Console Rmx
taskbar icon.
3.2. Connecting and disconnecting your DJ Console Rmx
The DJ Console Rmx can be used in conjunction with an internal sound card without causing
conflicts on your computer. When you connect the DJ Console Rmx it is automatically recognized
as the main sound card, and once it is disconnected the internal sound card resumes its original
functions.
Consequently, you can connect and disconnect your DJ Console Rmx at any time, even when the
computer is switched on, thanks to its USB connection.
3.3. Power consumption
Your DJ Console Rmx is optimized to achieve low power consumption when connected to your
computer via USB.

6/32 – User Manual
4. OVERVIEW
4.1. The top face
Your DJ Console Rmx has a variety of controls allowing you to interact with DJ software. There
are two sets of these controls, as the left and right sections of the DJ Console Rmx each
correspond to a separate deck in DJ software applications. Descriptions of the default function of
each control are provided below.
1. ¼" microphone input, microphone volume knob and Mic On/Off button
2. Source button: press to select computer music streaming/external audio input device
3. Gain button: increase or decrease the music level on each deck
4. Kill buttons: press to cut out/restore treble, medium and bass frequencies, respectively
5. EQ knobs: adjust treble, medium and bass frequencies
6. Balance knob: adjust the main output balance (1-2) between the left and right channels
7. Scratch button: select whether the jog wheels are used to scratch or seek within tracks
(scratch mode is enabled by default)
8. Up/down/left/right buttons: navigate within menus
9. Buttons 1-6: special effects/looping (please see section 7.7 Effects and loops)
10.Monitor select knob: adjust the mix of what's being played on your headphones - the track
you’re cueing up in relation to the overall mix
11.Headphone volume knob: adjust the volume of your headphones
12.¼" headphone input

ITALIANO
DEUTSCH
ESPAÑOL
NEDERLANDS
ENGLISH
FRANÇAIS
User Manual – 7/32
13.Beat Lock button: use this function to keep the same pitch while manipulating the tempo
14.Reset button: gradually reset the pitch to its original value
15.Pitch slider: adjust the pitch up or down
16.Sync button: synchronize the beat with the beat of the track on the opposite deck
17.Navigation buttons: move the cursor within the track
18.Jog wheels: use to scratch, navigate within tracks or scroll through menus
19.Play/pause button: pause music playback and move the cue point to the current position in the
track
20.Stop button: stop the music and do not change the track’s cue point
21.Cue button: set a cue point in the track
22.Cue Select button: select which deck is played on your headphones
23.Deck volume fader: set the volume for the deck
24.Main volume fader: set the overall volume
25.Cross fader: adjust the proportion of the left and right decks in your mix
26.Load Deck button: load a track on the corresponding deck
Note: These are descriptions of the DJ Console Rmx’s default functions, which may vary
according to the application you are using.
4.2. The connectors
Your DJ Console Rmx features multiple connectors on its front and back faces. Using these
connectors you can connect a variety of devices, as illustrated in the diagrams below:
Back face
StandardRCA Standard RCA Standard RCA Standard RCA
outputconnectors output connectors inputconnectors inputconnectors USB
3-4 (-10dBv) 1-2 (-10dBv) 3-4 1-2 connector
Pro gear ¼" jack Pro gear ¼" jack Phonoground Phonoground
output connectors output connectors connector/ connector/
3-4 (+4dBu) 1-2 (+4dBu) Line-Phono switch Line-Phono switch
unbalanced unbalanced (Deck B) (DeckA)
Front face
Microphone input Headphone connector

8/32 – User Manual
5. OUTPUT OPTIONS
Two types of connectors are available for connecting speakers: RCA and ¼" jack. All of these
connectors are mono outputs, each of which corresponds to one channel (left and right). The
RCA connectors are meant for connecting standard gear, while the ¼" jack connectors are meant
for connecting professional gear, such as a Public Address (PA) system.
Select the type of connector according to the type of equipment you will be connecting. Normally,
outputs 1-2 will be used for your live mix playing in the room, and outputs 3-4 will be used for
monitoring or connecting an external mixer. The outputs 3-4 connectors and the headphone jack
always output the same audio data.
5.1. Connecting speakers and/or an external mixer to your DJ
Console Rmx
With the included VirtualDJ software, the 4 mono RCA connectors (outputs 1, 2, 3, 4) let you play
your mix for the audience at the standard -10dBv level over a hi-fi system connected to outputs 1-
2 on your DJ Console Rmx, for example, and preview upcoming songs on your headphones or
via outputs 3-4.
The 4 mono ¼” unbalanced jack connectors (outputs 1, 2, 3, 4) let you play your mix for the
audience at the professional +4dBu level over a PA system connected to outputs 1-2 on your DJ
Console Rmx, for example, and preview upcoming songs on your headphones or via outputs 3-4.
This choice of outputs gives you the freedom to do more with your music. For example, you can:
Connect the ¼” jack outputs to a PA system to play the mix for the audience while simultaneously
connecting the RCA outputs to the audio line input on another computer to broadcast the mix
online; or
Play Deck A on outputs 1-2 and Deck B on outputs 3-4(withVirtualDJ5PROor another
application) and export the mix to an external mixer.
- Make sure that your computer and other audio equipment is switched off before connecting it.
- Connect your main set of speakers to the Output 1-2RCA plugs (plug 1corresponds to the left
speaker, plug 2to the right speaker) or to the Output 1-2 ¼”jackplugs.
- If you have a second set of speakers (monitoring speakers, for example), connect the speakers
to the Output 3-4RCA plugs (plug 3corresponds to the left speaker, plug 4to the right
speaker) or to the Output 3-4 ¼” jack plugs. You can also connect an external mixer to these
plugs.
Your speakers and/or external mixer are now ready for use with your DJ Console Rmx.

ITALIANO
DEUTSCH
ESPAÑOL
NEDERLANDS
ENGLISH
FRANÇAIS
User Manual – 9/32
5.2. Connecting headphones
Your DJ Console Rmx features 2 headphone connectors: one on the top face, and one on the
front face. The console has been designed to function with DJ headphones (stereo, impedance
from 16 to 64 Ohms).
You can only use one headphone output at a time: if two sets of headphones are connected
simultaneously, the headphone output on the unit's top face will take precedence over the output
on the front face.
6. INPUT OPTIONS
6.1. Connecting external audio sources
Your DJ Console Rmx allows you to connect virtually any kind of audio source you might wish to
use, including vinyl turntables. You can even use time-coded vinyl records or CDs to control
music files stored on your computer, giving you the ultimate hands-on mixing experience and
combining the best that the worlds of analog and digital have to offer. Now you can enjoy using
hybrid mixing, combining computer audio tracks on one deck with an analog source connected to
the other deck.
Your DJ Console Rmx features 4 audio inputs on its back face: 2 stereo audio inputs, for a total of
2 pairs of dual RCA connectors. Simply connect the audio source of your choice to the white (left)
and red (right) RCA connectors: inputs 1-2 for Deck A, and inputs 3-4 for Deck B. This allows you
to replace the computer audio track played on Deck A with the music played on inputs 1-2, and
replace the computer audio track played on Deck B with the music played on inputs 3-4.
You can even equalize your external audio sources and adjust their volume, just as you can with
a computer audio track. This provides for seamless mixing and full control over the sound of your
mix.
To the right of each set of inputs is a Line-Phono switch: this switch allows you to set the preamp
level for each stereo input to the line (CD/MP3 player, for example) or phono (turntable) level.
The reason for this is a turntable outputs a considerably weaker audio signal than a CD or MP3
player, and therefore requires extra pre-amplification in order to achieve a comparable volume.
When connecting a device such as a CD or MP3 player, be sure to set the Line-Phono
switch to the Line position; otherwise, the input signal will be far too loud and you risk damaging
your equipment.
If you are using a turntable:
- Set the Line-Phono switch to the Phono position.
- Connect the ground wire from your turntable to the corresponding ground connector above the
Line-Phono switch. Grounding helps to eliminate the interference which can otherwise occur
with turntables, giving you crystal-clear sound.

10/32 – User Manual
You can use the two Source buttons on your DJ Console Rmx (Source 1 for Deck A, Source 2
for Deck B) to control the audio input for the corresponding deck. By default, the input is set to
computer audio tracks: simply press the Source button to switch to the external audio source.
Press the button again to disable the external source and return to computer audio (please see
section 7.6 Source buttons).
You can use the Gain knobs on your DJ Console Rmx to adjust the volume for each deck.
To connect a CD player with an output in excess of +4dBu to the DJ Console Rmx inputs, you
must attenuate (i.e. reduce) the strength of the CD player’soutput signal using an attenuator such
as the Nano patch from SM Pro Audio.
6.2. Connecting a microphone
Your DJ Console Rmx features 2 microphone connectors: 1 mono ¼" jack plug on the top face,
and one on the front face. You can only use one microphone input at a time: if two microphones
are connected simultaneously, the microphone input on the unit's top face will take precedence
over the input on the front face.
You can use your microphone to talk over the music and communicate with your audience (mix
the microphone input with audio outputs 1-2, for example), or use your microphone to replace the
music on Deck A with your voice.
Press the Mic On/Off button on your DJ Console Rmx to toggle the microphone on or off. You
can use the volume knob beside it to adjust the input volume for your microphone.
The DJ Console Rmx features a talkover function for the microphone input, which automatically
reduces the level of the music that's playing to allow you to be heard when you're speaking. The
music level is restored once the microphone input is disabled.
Please see section 8.2 Using the DJ Console Rmx control panel for more information on adjusting
the talkover attenuation function and using your microphone.
7. DJ CONSOLE RMX FEATURES
7.1. Jog wheels
The jog wheels on your DJ Console Rmx emulate vinyl turntables: turning a jog wheel lets you
scratch or move the cursor backward or forward within music tracks, allowing you to select the
cue point where playback will start for the audience.
The jog wheels feature adjustable resistance: if you wish, you can adjust the screws located on
the underside of the device under each jog wheel to increase or decrease its resistance,
according to your preference.You can also adjust their sensitivity using the control panel: you
can either keep the default sensitivity, or divide it by a factor of 2 or 4 to make them less sensitive.
The jog wheels can also be disabled via the control panel.
You can use the Scratch button to change the function of the jog wheels (scratch mode is
enabled by default): press the button to switch to the seek function, allowing you to move

ITALIANO
DEUTSCH
ESPAÑOL
NEDERLANDS
ENGLISH
FRANÇAIS
User Manual – 11/32
backward or forward within a track. Press the button again to return to the default scratch
function.
You can also use the jog wheels to browse through music lists.When browsing through a
directory containing lots of music files, simply turn the jog wheel while keeping the Up or Down
button on your console pressed down in order to move through the list more quickly.
7.2. Faders (sliders)
Cross fader
Your DJ Console Rmx plays 1 stereo music track per deck (2 stereo music tracks
simultaneously). The cross fader moves between the left and right decks, allowing the DJ to
adjust the mix between the 2 decks, and therefore between the 2 tracks.
Setting the cross fader completely to the right means that the mix (the music the audience hears)
comes 100% from the right deck: the audience doesn’t hear the music played on the left deck.
Setting the cross fader in the center means that the music comes 50% from the left deck and 50%
from the right, and so on.
2 Pitch faders
You can use the pitch faders to adjust the playback speed of a track, increasing or reducing its
BPM (Beats Per Minute) rate, in order to make dancing easy by setting new music tracks at the
same BPM as the previous track so that dancers don’t need to change their rhythm during the
transition from one track to another.
In general, adjusting the pitch changes the music’s speed and tone: faster means a higher tone,
slower means a lower tone. However, you can keep the same pitch and tone by pushing the Beat
Lock button before changing the pitch so that the pitch fader only changes the tempo (i.e. speed)
of the track, and not the pitch itself.This mode is called Master Tempo.
3 Volume faders
The Deck A volume fader controls the volume of the music played on DeckA,whiletheDeck B
volume fader controls the volume of the music played on Deck B. The main volume fader
controls the master volume.
Changing the volume on Deck A or Deck B lets you adjust transitions between the 2 decks.
If the volume on one of the decks is not loud enough when the corresponding volume fader is set
to its maximum level, simply adjust the Gain knob for that deck to increase the deck's maximum
volume.

12/32 – User Manual
7.3. Play/Pause, Stop and Cue buttons
These buttons are available for both decks on your DJ Console Rmx.
- Play:starts music playback, while Pause pauses music playback at the current position in the
track and sets the cue point at this position.
- Cue: places a cue point (a marker where playback should start) at the current position in the
track.
- Stop: halts music playback and doesn’t change the track’s cue point.
7.4. Backward and Forward buttons
These buttons, found just above the jog wheel on each deck, allow you to quickly move the cursor
within music tracks. This is an easy way to quickly get to the exact point in a song that you're
looking for.
7.5. Pitch settings
- Reset: gradually resets the pitch of the music to its original pitch, whatever the pitch fader
position.
- Beat Lock: in VirtualDJ 5 DJC Edition, this button switches the Master Tempo function on/off.
Master Tempo locks the music to its current tone, allowing you to change the tempo without
changing the tone.
- Sync: pushing this button synchronizes the speed (BPM) of the music played on the
corresponding deck to match the BPM rate of the music on the other deck.
7.6. Source buttons
Press the Source 1 or Source 2 buttons to replace the computer music track on Deck A or Deck
B, respectively, with the audio source connected to the corresponding input. Press the button
again to disable the external audio source and return to the computer music track.
Before enabling an external audio source, be sure that you have set the Line-Phono
switch for the input in question to the appropriate level: Line (for CD or MP3 players, for example)
or Phono (for a turntable). You must then adjust the gain using the corresponding Gain knob to
ensure that the input volume is set at the right level.
7.7. Effects and loops (buttons 1-6)
In VirtualDJ, you can use these buttons to apply effects to your music or loop part of a track. You
can modulate the effect by turning the jog wheel while keeping the effect button pressed down.
These effects can be assigned to any of the 6 buttons, so these descriptions of the default
functions are only examples.
- Button 1 (Loop in): places a marker at the start of a loop.

ITALIANO
DEUTSCH
ESPAÑOL
NEDERLANDS
ENGLISH
FRANÇAIS
User Manual – 13/32
- Button 2 (Pitch bend -): "bends" the pitch of the music lower.
- Button 3 (Flanger): applies an audio effect with a slight delay, similar to the sound of a jet
airplane taking off.
- Button 4 (Loop out): places a marker at the end of the loop.
- Button 5 (Pitch bend +): "bends" the pitch of the music higher.
- Button 6 (Beatgrid): adds a beat pattern over the music track, based on the track’s tempo.
Other functions can be assigned to these buttons as well:
- Record Sample: records the music.
- Play Sample: plays the sampled music. This allows you to play a sample stored on the button
where you have recorded the sample.
- Backspin: an effect mimicking the sound DJs make when they quickly pull the disc backward
after having switched off the turntable. Sends one impulse backward.
- Brake: slows down the music until it stops, if you keep on braking.
- Overloop: sets a loop on 1, 2, 4, 8 or 16 beats over the music.
7.8. Load Deck buttons
Use these buttons to load the highlighted music track on Deck A or Deck B.
7.9. Beat Lock buttons
Pressing the Beat Lock button on a deck allows you to keep the same pitch or tone for the music
playing on that deck while you manipulate the tempo: this is known as the Master Tempo function.
When this function is enabled, even if you speed up or slow down the music, the music’s pitchwill
stay the same.
7.10. Cue Select buttons
Use the Cue Select buttons to choose which deck is being monitored on your headphones. Only
one Cue Select button (i.e. one deck) can be enabled at a time.
7.11. Browser buttons
Use the Up, Down, Left and Right buttons to browse through folders and music libraries.
- Up/Down buttons: move to the previous (Up) or next (Down) music file/directory. You can
move through music lists more quickly by pressing the Up or Down button and turning the jog
wheel at the same time.
- Left/Right buttons: switch the root directory (Left) or enter a directory (Right).

14/32 – User Manual
7.12. Balance knob
Use the balance knob to set the balance of the main output (1-2) between the left and right
channels.
7.13. Monitor Select knob
Use the Monitor Select knob to adjust the level of the track you are cueing up in relation to the
overall mix on your headphones or monitoring speakers.The Cue side of the knob’s rotation
represents the selected deck you are cuing up, while the Mix side represents the mix on Deck A +
DeckB.
7.14. Equalization knobs
Use the equalization knobs (Bass, Medium and Treble) for each deck to add color to your music
with custom settings. For example:
- Make dancing easier by enhancing the bass (the bass provides the tempo for dancing).
- Remix songs by boosting the mids (the mids contain the singer’s voice) on one track and
mixing it with another track on the other deck, where you’ve cut the mids.
You can also manipulate the bass to make transitions between two tracks:
- Synchronize the 2 tracks: move the pitch fader to set both tracks at the same BPM.
- Cut out the mids and treble on both decks, keeping only the beat of the bass.
- Move the cross fader from the first deck to the second, while restoring the mids and treble.
7.15. Kill buttons
Use the kill buttons (Bass, Medium and Treble) for each deck to cut off or restore the
corresponding frequency band of the music playing on that deck.
This is a faster way to cut off or restore a frequency band than using the rotary potentiometers,
and allows you to easily create interesting effects for your music with the push of a button.

ITALIANO
DEUTSCH
ESPAÑOL
NEDERLANDS
ENGLISH
FRANÇAIS
User Manual – 15/32
8. THE TASKBAR ICON AND CONTROL PANEL
8.1. The DJ Console Rmx taskbar icon
An icon representing your DJ Console Rmx appears in the right-hand side of your taskbar next to
the clock display. To launch the DJ Console Rmx control panel, simply left-click the icon.
By right-clicking the icon, you can select to open the control panel (an alternative to left-clicking
the taskbar icon as described above), exit the control panel and remove the icon from the taskbar,
or check for updates for your DJ Console Rmx. Please note that in order to check for updates,
you must have an active Internet connection.
This icon consolidates all Hercules DJ products you may have installed on your system. You can
select your DJ Console Rmx by right-clicking the icon and choosing Select Device.
To check for updates for your DJ Console Rmx:
- Right-click the DJ Console Rmx icon in the taskbar and select Check for updates.
- If prompted by your system, allow your computer to access the Guillemot FTP server.
If no new version is available, a message will appear indicating that you already have the latest
version installed. If a new version is available, it will be downloaded and the setup will launch
automatically.
- Follow the on-screen instructions to install the update for your DJ Console Rmx.
8.2. Using the DJ Console Rmx control panel
The control panel allows you to manage your DJ Console Rmx’s various settings.
- Output Channels: There are 2 sets of software sliders (1-2, 3-4), which function as master
volume controls for the corresponding outputs. You can alter the balance (left/right) using the

16/32 – User Manual
balance sliders on top of each set of output channel sliders. You can click the green link icon
underneath the sliders to disable/enable the sliders moving together, as opposed to on their
own. You can also mute the outputs by clicking the volume icon underneath the link icon.
- Input Channels: You can select either the microphone or line/phono input for input channels 1-
2. Please note that when recording your microphone, you temporarily lose the use of inputs 1-2.
When you use the talkover option for your microphone, your voice is mixed via hardware and
you can still use inputs 1/2; however, you cannot record your microphone with this configuration.
You can also select to use either WDM or ASIO audio modes. VirtualDJ switches to ASIO mode
automatically, but if you are using the Traktor software on PC, for example, you must switch to
ASIO mode manually. You can only switch between modes when playback is stopped.
Main tab:
- You can disable/enable or adjust the talkover attenuation level in this tab, meaning the level by
which the music is reduced when you activate the Mic On/Off button totalkon your microphone
(-6dB by default).
- You can disable and re-enable the jog wheels in this tab as well, and set their sensitivity.
ASIO tab (not available on Mac as there is no ASIO mode inMac OS X):
- In ASIO mode, you can adjust the following settings: Sample Rate, Sample Size, ASIO Buffer
Size.
“Audio Stream Input/Output” is a cross-platform, multi-channel protocol for audio transfer
developed by the Steinberg company. It allows a variety of programs to communicate with
different sound cards and recognize all of the inputs and outputs available on the sound card.
The user can then assign these I/O ports for recording or playback when using an ASIO-
compatible software program.
- Your DJ Console Rmx is ASIO 2.0 compliant, allowing you to use ASIO 2.0 VST plug-ins and
thereby add many exciting effects to your music.

ITALIANO
DEUTSCH
ESPAÑOL
NEDERLANDS
ENGLISH
FRANÇAIS
User Manual – 17/32
- The configuration is set to 44100Hz (44.1kHz)/16-bit mode by default.
- Switching to 24-bit mode only lets you use inputs 1-2 (inputs 3-4 are not available).
Advanced tab:
- This tab allows you to set the hardware mix options for output 1-2: USB streaming 1-2 (default),
USB streaming 1-2 plus your microphone, or USB streaming 1-2 plus line in 1-2.
- You can also set the MIDI channel (2 by default), in the event that there is some conflict
between your DJ Console Rmx and another MIDI device. If you have more than one Hercules
device installed on your system, the MIDI channel numbers are assigned by order of connection,
i.e. incrementally.

18/32 – User Manual
About tab:
- This tab provides all of the information about the package, firmware, driver, DJ API and control
panel versions you are using. Please refer to this information when contacting technical
support.

ITALIANO
DEUTSCH
ESPAÑOL
NEDERLANDS
ENGLISH
FRANÇAIS
User Manual – 19/32
9. USING THE DJ CONSOLE RMX A T A P A R T Y
9.1. Overview
You are now about to learn everything a DJ needs to know to host his or her first parties. Let’s
start at the beginning, namely setting up the party: no DJ would allow him/herself to arrive
unprepared, which is why he/she would have organized his/her material and selected his/her
records beforehand.
You should do the same by sorting through your music. Have a good look through your music
collection and select the songs you are going to use. In order to be able to mix tracks effectively,
you must know the pieces perfectly.
Once this is done, make sure that you have all the hardware you will need. Got your computer,
DJ Console Rmx, a pair of speakers, headphones and microphone handy? Perfect, then you’re
ready to go!
You’re probably asking yourself: and now, how do I get started? By way of introduction, here are
the basic principles of DJing: a DJ works with two decks (or turntables). The first deck plays one
part of the musical piece, while the DJ uses the second deck to listen to the next part on his/her
headphones. He/she can then work on this second part (speed it up so that it is at the same
tempo as the rest of the piece, etc.) before playing it out loud. At the end of a part, the DJ plays
the part on the other deck by doing a mix, which is to say a blending of the two parts creating a
perfect transition.
In concrete terms, you will launch the VirtualDJ software provided with your DJ Console Rmx and
program pieces onto each of the decks.
Please read through the following sections to learn more about the art of DJing. We also
recommend that you consult the VirtualDJhelp documentation for additional information.
9.2. Mixing in VirtualDJ
The art of mixing consists of preparing the next piece while a given piece is being played. When
the piece being played reaches its end, the DJ switches from one piece to the other progressively
using the cross fader, which regulates the volume of the two decks. This technique enables you to
avoid empty space between two pieces.
Your DJ Console Rmx allows you to work with both digital and analog audio sources. This
section will give you some practical examples of how you can switch from one musical piece to
another and from one audio source to another using the VirtualDJ software.

20/32 – User Manual
Mixing your songs in VirtualDJ is fun and easy to master. Thanks to the perfect integration of the
controls on your DJ Console Rmx with the included VirtualDJ 5 DJC Edition software, in no time
at all you'll be mixing and scratching your favorite songs, looping and applying amazing effects
just like a pro and making seamless transitions from one song to the next.
Take some time to explore and get to know the VirtualDJ software: a good resource is the
VirtualDJ PDF manual, which should be installed on your system automatically along with the
application itself. You can also download the PDF manual for the VirtualDJ website. In it you will
find tons of information on how to get the most out of the software and all of its various features.
The VirtualDJ website also contains a wealth of information and resources regarding the software,
and you will be able to find links to many user groups and forums which may be of interest to you
as you progress in your understanding of the software and all of the possibilities it opens up.
In this section, we'll give you a brief overview of some of the most common things you might want
to do to get started with your DJ Console Rmx and VirtualDJ 5 DJC Edition.
First off, you'll need to load some music onto each of the decks. To do so, you can either use
your mouse or touchpad to navigate through your files in the lower left-hand side of the VirtualDJ
window, or use the Up, Down, Left and Right buttons in the center of your DJ Console Rmx. Use
the Up/Down buttons to move to the previous (Up) or next (Down) music file/directory. You can
move through music lists more quickly by pressing the Up or Down button and turning the jog
wheel at the same time. Use the Left/Right buttons to switch the root directory (Left) or enter a
directory (Right). Press either of the Load Deck buttons on your Rmx to load the highlighted
track on the corresponding deck. If you're using your mouse or touchpad, simply drag and drop
songs onto the deck in question.
Under normal circumstances, you will probably want to set the Balanceknob at the top of your
Rmx to the center position, which will evenly divide your mix between the left and right channels.
