HERKULES AJ2 User manual

Page 1 of 4
PNEUMATIC AIR JACK
Herkules Equipment Corporation
 2760 Ridgeway Court  Walled Lake, MI 48390-1662 USA
248-960-7100  1-800-444-4351  Fax [phone]
Website: www.herkules.us Made in the USA email: [email protected]
Part# 1000719-03
4/30/14
09981017(254) 09981018(254)
This manual contains important information concerning the
installation and operation of the products listed above.
Read manual thoroughly and keep for future reference
INSTRUCTIONS

Page 2 of 4
Model Information:
Model Capacity
(kg) Pressure (bar) Maximum Lift (mm) Weight (kg)
AJ2
4500 lbs
(2041) 100 psi (7) 13.56 in (345) 28 lbs (12.7)
AJ3 4500 lbs
(2041) 100 psi
(7) 19.25 in (490) 37 lbs (16.78)
Installation:
Connecting the Air Line
1. Install a 1/4 in. NPT male couple, that is compatible with the
quick disconnect of your air supply line, into the air inlet of
the air jack. See Figure 1.
2. Connect air line with at least 100 psi (7 bar) pressure to the
quick disconnect coupler.
Operation:
1. Position the air jack under the vehicle to be lifted and press
the Raise Toggle (green arrow) on the air valve.
Note: Lift only at vehicle manufacturer’s specified lift points.
2. Once the repair operations on the vehicle have been
completed, press the Lower Toggle (red arrow) on the
air valve to lower the vehicle. See Figure 1 & 2.
CAUTION: It is critical that the air jack and the vehicle are on
level planes. Furthermore the surface on which the air jack is to be
used has to be free from loose debris and level. See Figure 3.
CAUTION: The AJ-2 and AJ-3 Air Jacks are
not lifts. For this reason never work under the vehicle when using an air jack.
CAUTION: Do not leave vehicle in raised
Position over night.
NOTE: The air jack is equipped with a pressure relief valve to prevent over
inflation.
Figure 1 09981018(251)
Raise
Toggle
Lower
Toggle Air inlet
Figure 3
CORRECT
INCORRECT
Lower Toggle
(Red Arrow) Raise Toggle (Green Arrow)
Figure 2

Page 3 of 4
1. It is critical that the air jack and vehicle are on level planes (see fig.3).
2. The surface under the air jack must be free of debris and level.
3. The AJ2 & AJ3 Air Jacks are NOT a stand. Never work under the vehicle supported by only the Air Jack.
4. DO NOT leave vehicle in raised position over night.
5. The air jack is equipped with a pressure relief valve to prevent over inflation. DO NOT continue to fill the air
bag once raised height is achieved even though pressure relief valve will prevent over-inflation. Maximum air
pressure is 100-110 p.s.i.
6. Do not exceed rated capacity (4,500 lbs)
7. Lift only on areas of the vehicle as specified by the vehicle manufacturer.
8. Avoid contact with petroleum based products or chemicals of any kind.
9. Avoid sharp objects near bag. Bag penetration will result in jack dropping without warning, which will result in
serious injury or property damage.
10. Only attachments and/or adapters supplied by the manufacturer shall be used.
11. Keep hands away from jack base pad at all times.
12. Make sure jack is secure at lift point.
13. With air line disconnected, the air bag can be deflated by pressing either arrow on the handle.
1. On a monthly basis, add a few drops of pneumatic tool oil to air inlet.
2. Visually inspect the Air Jack before each use. Do not use the Air Jack if you detect scars, abrasions, rips, or
punctures in the air bag. If so, the Air Jack should be returned to Herkules for inspection and evaluation.
CAUTION
Maintenance

Page 4 of 4
AIR JACK PARTS LAYOUT
Valve assembly
1000149
Air inlet assembly
10323
Optional Equipment
Height Extender 2.0 inches AJ-X50
Height Extender 4.0 inches AJ-X100
Pinch Weld Adapter 10454
Rubber cap
1000565
Air bag for AJ-3
1000566
Lift Pad
Jack Base Pad
