Heroshi Saisho User manual
SPECIFICATIONS
Voltage: 220-240V~50-60Hz
Power: 130W
Juicing cup capacity: 600ml
Pulp container capacity: 450ml
Juicer size: 98mm x 120mm x 355mm
Weight: 1.58kg
IMPORTANT
1. The Heroshi Juicer is designed for household use only.
2. Commercial users will not obtain the regular warranty as stated in the terms of the warranty card.
3. This is not a toy. Please do not let children play with it or use it.
4. Read all instructions before use carefully.
5. Keep these instructions for ever.
IMPORTANT SAFEGUARDS
1. Make sure the electricity supply is 220-240V.
2. This juicer is intended for household use only. Do not use the juicer outdoors or for other
purposes.
3. Use the Heroshi juicer only as described in this manual.
4. To prevent electrical shock, do not immerse the juicer, cord set and plug into water. Operate the
juicer at a safe distance from water.
5. This is not a toy and not to be used by children. Close supervision is required when the juicer is
used near children.
6. Ensure to unplug the juicer when not in use, when assembling or disassembling, and before
cleaning.
7. The continuous operation time limit for this juicer should be within 20 minutes.
8. Do not touch or move any moving parts during operation of the juicer.
9. Donotusenger,spoonorchopstickstopushfruitsorvegetablesintothechuteofthejuicer.
Only use the pusher provided.
10. Do not open the juicer when it is operating.
11. Do not place the juicer near any heated oven or hot surfaces.
12. OperatetheHeroshijuiceronaatsurface.
13. Do not let the cord hang over the edge of the table or the bench top.
14. Please hold the plug to disconnect from the power socket.
15. If the parts of the juicer are found to be damaged (especially the power cord) please stop using it.
16. This product is not intended to be operated by persons (including children) with weak physical
condition, slow reaction, mental retardation, lack of experience and common sense, unless they
are under supervision or instruction by the person who is responsible for their safety.
17. If the screw press gets obstructed, put the juicer in ‘rev’ mode for about 2 to 3 seconds to let it turn
in the opposite direction and loosen the blockage. After this, revert to using the product as usual.
18. Don’t use the water that is warmer than 65°C to rinse the appliance parts
19. Make sure that the base of the juicer does not get wet.
HINT:ThisJuicerisnotsuitableforjuicingveryhardorbrousandstarchyfruitsorvegetablessuch
as Sugar Cane. There are some fruits which contain too much starch to juice. They include avocado,
bananas,gs,mangoandpapaya,dragonfruit,strawberry,andgrapeswithoutseeds.Theywillclog
up the stainless-steel sieve.
PARTS DIAGRAM
NOTE
To avoid hazard of electric shock, unplug the juicer from power outlet when not in use or before
cleaning. If the power cord is damaged, stop using immediately and have it repaired by an
appropriatelyqualiedtechnician.
1Food Tray
2Chute and Strainer Assembly
3Squeezing Auger
4Juicing Bowl
5Power Base
6Juice Container
7Pulp Container
8Pusher
9Cleaning Brush
10 On/O/ReverseSwitch
11 Juice Spout
12 Drip-stop cover
13 Pulp Spout
14 Power Cord
1
2
3
4
5
10
9 8 7 6 14
11
13
12
FIRST TIME USE
1. Remove all packaging materials, plastic bags and labels.
2. Make sure the electricity supply is 220-240V~ 50-60Hz.
3. Clean the Food Tray / Chute and Strainer Assembly / Squeezing Auger / Juicing Bowl / Pusher with
Soapy water. Then rinse and dry thoroughly.
NOTE: DO NOT IMMERSE THE POWER BASE JUICER IN WATER.
4. Assemble the parts per the instruction in the assembling method section.
5. Connect the power cord to the power source. The Heroshi juicer is ready to use now.
ASSEMBLY
Make sure the juicer is not plugged in and the switch is turned to ‘O’ setting before assembling.
1. Position the squeezing bowl on the Power base, align the position of the spouts and the axle. (Fig 1)
2. Pushthesqueezingaugerrmlyintothecenterofthebowl,makingsurethatittouchesdownthe
bottom, or else the cover cannot be closed. (Fig 2)
3. Position the chute on the bowl to align the
5
to the
and twist it clockwise until it clicks the safety
lock. Please make sure that the arrow
5
on the cover aligns with the Lock graphic on
the Bowl. (Fig 3)
4. Place the juice container and the pulp container under the relevant spouts. (Fig 4 below)
Fig.1 Fig.2 Fig.3 Fig.4
OPERATING GUIDE
1. Connect the juicer with power.
2. Checkandmakesureallpartsarewellassembledandrmlyintheircorrectposition.
3. Makesurethejuicerisato‘O’ position.
4. Make sure the juice and pulp containers are in position.
5. Make sure the juice spout cover is closed.
6. Prepare fruits or vegetables and cut them into pieces max 2cm x 5cm strips or 2cm x 2cm cubes.
7. Feed fruit into the chute.
8. Press the switch to Setting ‘ –‘ to start the juicing operation.
9. Push the food down with the pusher only.
10. In case of food stuck inside the Bowl, please switch to “R” reverse function instantly.
NOTE
Please do not use the juicer continuously for longer than 20 minutes.
DISASSEMBLY METHOD
To disassemble the juicer after using and before cleaning. Please turn the juicer to ‘O’ position and
disconnect the juicer from power source then follow the steps below:
1. Remove the Juice and Pulp containers. (Fig 6)
2. Remove the Chute. Turn the chute anti-clockwise until the
5
aligns with the sign. (Fig 7)
3. Remove the Squeezing Auger by pulling it out upward. If it is very hard, swing gently and pull. (Fig 8)
4. Remove the Squeezing Bowl by lifting it upward vertically. (Fig 9)
Fig.6 Fig.7 Fig.8 Fig.9
NOTE
Ifthejuicergetsoverheated,itwillturnoautomaticallytoprotectthejuicer.Inthiscase,please
turnthejuicero‘O’ then wait 10 minutes to let the juicer cool down and then turn it on again.
Open and Close of Juice Spout Cover
During the juicing process, you could keep the
Drip-stop Cover closed before the juice is full in
the juicing bowl. (Fig 5 below)
Juicer spout
is opened
Juicer spout
is closed
Benets of drip-stop cover
1. To stop dripping at the end of juicing.
2. Mixjuicewithdierentfruitsandveggies.
Usage Tips
1. Remove hard pits or seeds prior to pressing
to prevent damage to the squeezing screw.
2. If making mixed juices, please begin with
harder fruit, and then squeeze the soft fruit.
3. Let the juicer run for 30 seconds after the last
ingredient was fed.
Attention
The juicer is not suitable for juicing very hard or
brousandstarchyfruitsorvegetablessuchas
sugar cane. There are some fruits which contain
too much starch to juice. Some examples are
avocado,bananas,gs,mango,papaya,dragon
fruit, strawberry, grapes without seeds etc. They
will clog up the stainless-steel sieve.
IMPORTANT
Please wash the juicing parts every time immediately after each used, otherwise the pulp might
sticktightlyintheJuicingBowlandontheSqueezingAugerwhichwillthenaectthedisassembly,
cleaning and juicing performance.
CLEANING AND MAINTENANCE
1. Switchoandunplugthejuicer.
2. Wash the disassembled parts (Fig 10 below) with water. If the meshes are clogged with pulp,
please use the cleaning brush provided to remove the dregs.
9 8 7 6 1+2 4 3
Attention:
• Do not use an iron wire brush, abrasive or sharp tool to clean the juicer.
• Please do not use water above 40°C.
• Never clean any parts in dishwasher to avoid damage by hot water.
3. In case there is any residue remaining in the mouth of the pulp spout, please pull out the silicone
valve as shown in (Fig 11 below) and clean under running water.
Silicone Pull to
valve open
Press the silicone valve to close it properly and tightly after cleaning.
4. To Clean the seal ring in the center of the squeezing bowl, please follow the steps as below:
a. Turn the Squeezing Bowl upside down for easier handling, Push the seal ring out with your
thumb (Fig 12a) and clean it with water.
b. After Cleaning, please put it back to the center hole. The small ribbed surface should be facing
upward(Fig.12b)Makesurethegrooveofthesealringtswellinthesqueezingbowl.
c. Thebigatsideofthesealringwillbeinsidewhilethesmallandribbedsideisoutsidethe
Squeezing Bowl. (Fig 12c)
Fig 12a Fig 12b Fig 12c
5. Do not put the Power Base into water for cleaning. Wipe it with damp cloth only.
6. After cleaning, please dry the parts thoroughly and store them in a dry, cool place.
STORAGE
1. Follow cleaning instructions to well maintain the juicer before storage.
2. Tidy up the power cord set.
3. Store the juicer away from easy access by children.
4. Store the juicer and the accessories at a dry, cool place.
USEFUL TIPS
Item Warning Reason
1 Not for Ice cube. The ice cube is too hard. It may damage the
squeezing parts.
2 Ingredientswithlongberneedtobecut Longberfoodmayblockthespout.
to 2-5cm thin strips or 2 x 2cm cubes.
3 The peel, pips and seeds must be The hard pit or seeds may damage the
removed from oranges, lemons, squeezing parts. The peel may block the
grapefruit and melons before use. spout of pulp.
4 Do not use other implements as a pusher. It may damage the juicer and cause injury.
5 Each juicing cycle no longer than 20 mins. Using the juicer beyond 20 minutes may
cause damage to the motor.
6 Never put spoons or chopsticks in the It may damage the juicer.
Chute opening, the juice and pulp spouts.
TROUBLE SHOOTING
Trouble Cause Solutions
The juicer stops running Too many ingredients put into Switch to ‘R’ position instantly
suddenly. the juicer to make the ingredients return
upwards. If the juicer still stops
running, please clean the juicer
before re-use.
Hard fruits or vegetables have Hard fruits and vegetables (such
not been cut in small pieces. as carrot) should be cut into thin
strips or small cubes before
putting into chute.
The juice yield is low or juice The Bowl and the silicone valve Please re-install the Bowl and
owsoutofthemainhousing. arenotinstalledproperly. siliconevalvebyreferringtothe
installation method.
Abnormal noise. Parts cause extrusion sound The sound is caused by extrusion
during squeezing. of fruits and vegetables, which is
normal phenomenon.
NOTE
Please make sure the juicer and parts are dry before storage.
TROUBLE SHOOTING continued...
Trouble Cause Solutions
The Chute and Strainer There is too much pulp inside Press switch to ‘R’ setting to
Assembly cannot be opened. the bowl. eject the pulp backward.
Hard foods stuck inside. Press switch to ‘R’ to eject the
object backward.
The pulp mess is stuck. Pour water into the Chute to
soften the stuck pulp mess
overnight.
The container and accessories Dyed parts are due to natural This is natural color and
aredyedafteruse. colourofspecicfruits/veggies. unavoidable.
5-YEAR WARRANTY
HeroshicertiesthattheHeroshiJuicerisfreefromdefectsinmaterialandworkmanshipfromthe
date of purchase. This warranty does not cover damage caused by misuse or abuse, accident, the
attachment of any unauthorized accessory, alteration to the product, or any other conditions beyond
the control of Heroshi. The Heroshi Juicer is made for household use.
Heroshi shall not be responsible for any type of incidental, consequential, or special damages. This
warrantyprovidesyouwithspeciclegalrights.Youmayhaveadditionalrightswhichmayvaryfrom
state to state. Because of individual state regulations, some of the above limitations and exclusions
may not apply to you.
The Iron
Rejuvenator
Ideal juice when you need a
quick pick me up.
Ingredients: 1 large beetroot,
2 carrots, 1 large apple, 50g baby
spinach and ½ lime.
Mean Grn Juice
A hardy juice to boost the
immune system.
Ingredients: 1 large cucumber,
2 apples, 2 kale leaves,
2 stalks of celery, ½ lemon
and 1cm ginger.
Carrot and Capsicum
Surprise
An amazing juice to make you feel
more energized.
Ingredients: 4 carrots, 1 red capsi-
cum, 1 pear and 1 lemon.
Detox Juice
Kick starts a sluggish system with
this great tasting juice.
Ingredients: 1 small bunch mint,
1 large apple, 2 kale leaves, 50g
pineapple (peeled), ½ cup baby
spinach, ½ lime and 2 stalks
of celery.
Bt me to it
A high energy juice to stimulate
the mind.
Ingredients: 1 beetroot, 1 apple,
2 carrots and ½ cucumber.
A Wonderful Delight
A wonderful juice that will refresh
and revitalize the mind and body
after a late night.
Ingredients: 2 grapefruit, 1 cup
watermelon, 1 carrot and ½ lime.
Ginger and
Coriander Bli
A cleansing and refreshing juice to
tickle your taste buds.
Ingredients: 1 lemon, 1 cup
coriander, ½ cucumber,
1cm ginger and 4 stalks of celery.
Just Breathe
With cool tones of mint this is a
fresh juice you will not want to end
Ingredients: 2 oranges, 2 carrots,
1 large handful mint, 1 tsp ginger,
1 pear and ½ lime.
Summery Herbs
A juice packed of summary herbs
and flavors, perfect for a sunny day.
Ingredients: 10 mint leaves,
1 cucumber, ½ cup basil,
½ cup parsley, 2 apples, ½ lemon
and ½ lime.
Tropical Refresher
Great for a summers day, serve
over ice as a Mocktail.
Ingredients: 1 cup watermelon,
½ cup pineapple, ½ cup mint,
1 lime.
Be Sti Lemonade
All the refreshment you get from
a fizzy lemonade but with a much
healthier approach.
Ingredients: 2 cups spinach,
1 apple, 1 pear, 1 cucumber,
½ lemon and ½ lime.
Regain
Allow this juice to calm down your
entire body and regain your energy.
Ingredients: 1 apple, 2 kale leaves
1 cucumber, ½ cup broccoli
(chopped), 1cm ginger and ½ lime.
notes
PLEASE DO NOT HESITATE TO CONTACT
Heroshi
4 Pirelli Street Southport QLD 4215
Country of Origin: China
Table of contents
