HETCH H2 User manual
H2 Handheld
Vacuum Cleaner & Mop
Model No. : HVC-1413-HC
Quick Guide
Parts Identifications
English
Handle
Power Cable Hook
Aluminum Tube
Tube Latch
ON/OFF Switch
Dust Tank Release Button
Floor Brush
Main Unit
HEPA Filter
Dust Tank
Water Tank
Mop
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
4
5
6
7
1
2
3
8
9
10
11
12
Assembly
Preparation
Assembling aluminum tube into the main unit.
Assembling floor brush into the dust tank.
Assembling water tank into the floor brush.
1)
2)
3)
1
2
3
Specifications
Model
Rated Voltage
Rated Frequency
Rated Power
HVC-1413-HC
220-240V~
50/60Hz
400W
Attention
Cleaning and Maintenance
1) Do not pull the wire or machine when unplug socket.
2) Do not collect burning cigarettes or hot item with this machine.
3) Do not collect objects carrying liquid with this machine.
4) Do not collect sharp objects with this machine.
image 1 image 2 image 3
Filter
Water Tank
Turn OFF machine and unplug before empty dust.
When the dust tank is dirty or full, please empty it.
Dis-assemble the floor brush. (image 1)
Press dust tank release button then tilt dirt dust tank down and
away from unit. (image 2)
Grasp filter from the center, pull filter out from dust tank than
empty the tank into waste basket.
Wash or refill water tank. (image 3)
1)
2)
3)
4)
5)
6)
Empty and clean the dust tank, filter & water tank
HEPA filter should be rinsed clean at least twice a month or
when it becomes visibly solid.
Always operate the cleaner with filter installed.
Otherwise, this may reduce suction or damage the motor.
Disconnect from electrical outlet before cleaning HEPA filter.
Do not use the washing machine for rinsing filter, or use hair
dryer for drying it.
Clean the HEPA filter in cool water.
Air dry it completely before re-assembling.
If the machine does not operate normally, please contact the
authorized service center.
1)
2)
3)
4)
5)
6)
7)
Cleaning HEPA filter
Troubleshooting
Problem Possible Cause Solution
The suction is not
enough
There is no air at
the air outlet
The filtration
system is blocked.
The accessories
are not firmly
connected.
The air outlet is
blocked
Clear up rubbish in
the dust cup, and
wash HEPA filter.
Connect the
accessories firmly.
Clear up the dust at
air outlet timely.
