Hewlett Packard Enterprise Aruba 2530 Programming manual

Aruba 2530 Advanced Trac
Management Guide for ArubaOS-
Switch 16.09
Part Number: 5200-5889a
Published: September 2019
Edition: 2

© Copyright 2019 Hewlett Packard Enterprise Development LP
Notices
The information contained herein is subject to change without notice. The only warranties for Hewlett
Packard Enterprise products and services are set forth in the express warranty statements accompanying
such products and services. Nothing herein should be construed as constituting an additional warranty.
Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
Condential computer software. Valid license from Hewlett Packard Enterprise required for possession, use,
or copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software
Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under
vendor's standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard
Enterprise has no control over and is not responsible for information outside the Hewlett Packard Enterprise
website.
Acknowledgments
Intel®, Itanium®, Optane®, Pentium®, Xeon®, Intel Inside®, and the Intel Inside logo are trademarks of Intel
Corporation in the U.S. and other countries.
Microsoft® and Windows® are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
Adobe® and Acrobat® are trademarks of Adobe Systems Incorporated.
Java® and Oracle® are registered trademarks of Oracle and/or its aliates.
UNIX® is a registered trademark of The Open Group.

Chapter 1 About this guide.............................................................................12
Applicable products..................................................................................................................................... 12
Switch prompts used in this guide............................................................................................................. 12
Chapter 2 VLANs............................................................................................... 13
Understanding VLANs .................................................................................................................................13
Static VLAN operation.................................................................................................................................. 14
VLAN environments.......................................................................................................................... 16
VLAN operation................................................................................................................................. 17
General VLAN operation....................................................................................................... 17
Types of static VLANs available in the switch..................................................................... 17
Multiple port-based VLANs...................................................................................................18
Protocol VLAN environment................................................................................................. 19
Routing options for VLANs...............................................................................................................19
802.1Q VLAN tagging........................................................................................................................ 19
Introducing tagged VLANs into legacy networks running only untagged VLANs...........20
VLAN tagging rules.................................................................................................................21
Applying VLAN tagging.......................................................................................................... 23
Additional VLAN tagging considerations.............................................................................25
Multiple VLAN considerations......................................................................................................... 27
Single forwarding database operation................................................................................28
Switch performance is unreliable........................................................................................ 28
Connecting the Switch to another switch with a multiple forwarding database
(Example)................................................................................................................................ 29
Conguring VLANs........................................................................................................................................30
The number of VLANs allowed on a switch................................................................................... 30
Per-port static VLAN conguration options example................................................................... 31
Conguring port-based VLAN parameters.....................................................................................32
Using the CLI to congure port-based and protocol-based VLAN parameters.........................32
Creating a new static VLAN (port-based or protocol-based) (CLI) ...................................32
Conguring or changing static VLAN per-port settings (CLI)............................................ 34
Converting a dynamic VLAN to a static VLAN (CLI)............................................................ 35
Deleting a static VLAN (CLI)...................................................................................................36
Deleting multiple VLANs....................................................................................................... 36
Using IP enable/disable for all VLANs.............................................................................................37
Interaction with other features............................................................................................ 37
Interactions with DHCP......................................................................................................... 38
Changing the Primary VLAN (CLI).................................................................................................... 39
Conguring a secure Management VLAN (CLI)..............................................................................40
Preparation............................................................................................................................. 40
Conguring an existing VLAN as the Management VLAN (CLI)........................................ 40
Obtaining an IP address using DHCP (CLI)..........................................................................41
Disabling the Management feature (CLI)............................................................................ 43
Changing the number of VLANs allowed on the switch (CLI).......................................................44
Displaying a switch VLAN conguration.................................................................................................... 44
Viewing the VLAN membership of one or more ports (CLI).........................................................45
Viewing the conguration for a particular VLAN (CLI).................................................................. 47
Customizing the show VLANs output (CLI).....................................................................................49
Using pattern matching with the show VLANs custom command.................................. 50
Contents
Contents 3

Creating an alias for show VLAN commands (CLI)........................................................................ 51
Conguring a VLAN MAC address with heartbeat interval......................................................................51
Displaying a VLAN MAC address conguration (CLI).....................................................................51
Using voice VLANs........................................................................................................................................ 52
Operating rules for voice VLANs..................................................................................................... 52
Components of voice VLAN operation........................................................................................... 52
Voice VLAN access security.............................................................................................................. 52
Prioritizing voice VLAN QoS (Optional)........................................................................................... 52
Special VLAN types....................................................................................................................................... 53
VLAN support and the default VLAN.............................................................................................. 53
The primary VLAN............................................................................................................................. 53
The secure Management VLAN....................................................................................................... 54
Operating notes for Management VLANs...................................................................................... 55
VLAN operating notes.................................................................................................................................. 56
Eects of VLANs on other switch features................................................................................................ 57
Spanning Tree operation with VLANs............................................................................................. 57
Spanning Tree operates dierently in dierent devices.............................................................. 58
IP interfaces............................................................................................................................ 58
VLAN MAC address................................................................................................................ 58
Port trunks..............................................................................................................................58
Port monitoring......................................................................................................................58
Jumbo packet support...........................................................................................................58
VLAN restrictions...............................................................................................................................58
Migrating Layer 3 VLANs using VLAN MAC conguration....................................................................... 59
VLAN MAC address reconguration................................................................................................59
Handling incoming and outgoing VLAN Trac..............................................................................59
Incoming VLAN data packets and ARP requests................................................................ 59
Outgoing VLAN trac ...........................................................................................................60
Sending heartbeat packets with a congured MAC Address.......................................................60
Displaying a VLAN MAC address conguration (CLI).....................................................................60
Chapter 3 GVRP..................................................................................................62
About GVRP................................................................................................................................................... 62
GVRP operational rules.................................................................................................................... 62
Example of GVRP operation................................................................................................. 62
Options for a GVRP-aware port receiving advertisements.......................................................... 63
Options for a port belonging to a Tagged or Untagged static VLAN...........................................63
IP addressing..................................................................................................................................... 63
Per-port options for handling GVRP "unknown VLANs"...............................................................64
Per-port options for dynamic VLAN advertising and joining....................................................... 64
Initiating advertisements...................................................................................................... 64
Enabling a port for dynamic joins........................................................................................65
Parameters for controlling VLAN propagation behavior.................................................. 65
GVRP and VLAN access control....................................................................................................... 67
Advertisements and dynamic joins..................................................................................... 67
Port-Leave from a dynamic VLAN........................................................................................ 68
Using GVRP....................................................................................................................................................68
Planning for GVRP operation...........................................................................................................69
Displaying switch current GVRP conguration (CLI)..................................................................... 69
Displaying switch current GVRP conguration (CLI)..................................................................... 70
Enabling and disabling GVRP on the switch (CLI)..................................................................................... 70
Controlling how individual ports handle advertisements for new VLANs (CLI).................................... 71
Listing static and dynamic VLANs on a GVRP-enabled switch (CLI)........................................................72
Converting a Dynamic VLAN to a Static VLAN (CLI).................................................................................. 73
4Aruba 2530 Advanced Trac Management Guide for
ArubaOS-Switch 16.09

Chapter 4 Multiple VLAN Registration Protocol........................................ 74
Multiple VLAN Registration Protocol overview......................................................................................... 74
MVRP operating notes................................................................................................................................. 74
Listing static and dynamic VLANs on an MVRP-enabled switch............................................................. 75
Converting a dynamic VLAN to a static VLAN........................................................................................... 76
Viewing the current MVRP conguration on a switch..............................................................................76
show mvrp......................................................................................................................................... 76
show mvrp cong.................................................................................................................. 76
show mvrp state.................................................................................................................... 77
show mvrp statistics.............................................................................................................. 77
clear mvrp statistics.......................................................................................................................... 78
debug mvrp........................................................................................................................................78
Conguring MVRP........................................................................................................................................ 79
Enabling MVRP globally.................................................................................................................... 79
Enabling MVRP on an interface....................................................................................................... 79
MVRP timers..................................................................................................................................................80
Join Timer........................................................................................................................................... 80
mvrp join-timer...................................................................................................................... 80
Leave Timer........................................................................................................................................81
mvrp leave-timer....................................................................................................................81
LeaveAll Timer................................................................................................................................... 82
mvrp leaveall-timer................................................................................................................82
Periodic Timer................................................................................................................................... 83
mvrp periodic timer...............................................................................................................83
mvrp periodic-timer-enable................................................................................................. 83
MVRP registration modes............................................................................................................................84
mvrp registration...............................................................................................................................84
show tech mvrp ........................................................................................................................................... 84
MVRP limitations.......................................................................................................................................... 87
MVRP statistics..............................................................................................................................................88
Chapter 5 Multimedia trac control with IP multicast (IGMP).............89
Operation and features............................................................................................................................... 89
IGMP devices .....................................................................................................................................89
IGMP operating features.................................................................................................................. 90
CLI: Conguring and displaying IGMP........................................................................................................90
Web: Enabling and disabling IGMP............................................................................................................ 94
How IGMP operates..................................................................................................................................... 94
Message types................................................................................................................................... 94
IGMP multicasting............................................................................................................................. 94
Displaying IGMP data........................................................................................................................95
Supported standards and RFCs.......................................................................................................95
Operation with or without IP addressing ...................................................................................... 95
Automatic Fast-Leave IGMP............................................................................................................. 96
Using delayed group ush ................................................................................................... 97
Forced Fast-Leave IGMP................................................................................................................... 98
Setting Fast-Leave and Forced Fast-Leave from the CLI................................................... 98
Setting Forced Fast-Leave using the MIB............................................................................ 98
Listing the MIB-Enabled Forced Fast-Leave conguration................................................99
Conguring per-port Forced Fast-Leave IGMP.................................................................100
Using the switch as querier.......................................................................................................................101
Querier operation........................................................................................................................... 101
Excluding multicast addresses from IP multicast ltering ................................................................... 101
Contents 5

Chapter 6 Multiple instance spanning tree operation...........................103
Overview of MSTP...................................................................................................................................... 103
MSTP structure................................................................................................................................ 105
How MSTP operates........................................................................................................................105
802.1s Multiple Spanning Tree Protocol (MSTP).....................................................................................105
MST regions..................................................................................................................................... 106
How separate instances aect MSTP........................................................................................... 107
Regions, legacy STP and RSTP switches, and the Common Spanning Tree (CST)................... 108
MSTP operation with 802.1Q VLANs.............................................................................................108
MSTP compatibility with RSTP or STP...................................................................................................... 109
Preconguring an MSTP regional topology.............................................................................................109
Preconguring VLANs in an MST instance................................................................................... 110
Conguring MSTP instances with the VLAN range option (Example).......................................111
Saving the current conguration before a software upgrade................................................... 112
Types of Multiple Spanning Tree Instances.............................................................................................113
Planning an MSTP application.................................................................................................................. 113
Conguring MSTP at a glance................................................................................................................... 114
Conguring MSTP operation mode and global settings........................................................................116
Selecting MSTP as the spanning tree mode................................................................................ 116
Clearing spanning tree debug counters.......................................................................................116
Resetting the conguration name of the MST region in which a switch resides.................... 116
Designating the revision number of the MST region for a switch.............................................116
Setting the spanning tree compatibility mode............................................................................ 117
Setting the time interval between listening, learning, and forwarding states.........................117
Setting spanning tree to operate in 802.1D legacy mode..........................................................118
Setting spanning tree to operate with 802.1D legacy path cost values................................... 118
Specifying the time interval between BPDU transmissions.......................................................118
Setting the hop limit for BPDUs.................................................................................................... 118
Setting the maximum age of received STP information............................................................ 119
Manipulating the pending MSTP conguration.......................................................................... 119
Setting the bridge priority for a region and determining the root switch............................... 119
Enabling SNMP traps...................................................................................................................... 120
Conguring MSTP per-port parameters..................................................................................................120
Enabling immediate transition to forwarding on end nodes.................................................... 120
Identifying edge ports automatically............................................................................................121
Specifying the interval between BPDU transmissions............................................................... 121
Forcing a port to send RST/MST BPDUs....................................................................................... 122
Determining which ports are forwarding ports by assigning port cost................................... 122
Informing the switch of the device type to which a port connects ..........................................122
Determining which port to use for forwarding........................................................................... 122
Denying a port the role of root port............................................................................................. 123
Denying a port propagation change information....................................................................... 123
Congure MST instance ports parameters............................................................................................. 124
Create a new instance or map VLAN(s) to an existing one................................................................... 124
Enable event logging..................................................................................................................................124
Deleting an instance.................................................................................................................................. 124
Congure an existent instance................................................................................................................. 124
MSTP Cong example.....................................................................................................................125
Downgrading to lower version build........................................................................................................125
Operating notes for the VLAN conguration enhancement................................................................. 125
Conguring MST instance parameters.................................................................................................... 126
Setting the bridge priority for an instance.............................................................................................. 126
Assigning a port cost for an MST instance.............................................................................................. 127
Setting the priority for a port in a specied MST instance....................................................................127
6Aruba 2530 Advanced Trac Management Guide for
ArubaOS-Switch 16.09

Setting the priority for specied ports for the IST..................................................................................128
Enabling or disabling spanning tree operation...................................................................................... 128
Enabling an entire MST region at once or exchanging one region conguration for
another.............................................................................................................................................129
Creating a pending MSTP conguration...................................................................................... 129
Viewing MSTP statistics..............................................................................................................................130
Viewing global MSTP status........................................................................................................... 130
Viewing detailed port information................................................................................................131
Viewing status for a specic MST instance.................................................................................. 132
Viewing the MSTP conguration...............................................................................................................133
Viewing the global MSTP conguration........................................................................................133
Viewing per-instance MSTP congurations................................................................................. 134
Viewing the region-level conguration.........................................................................................135
Viewing the pending MSTP conguration.................................................................................... 136
MSTP operating rules.................................................................................................................................136
Troubleshooting an MSTP conguration.................................................................................................137
Viewing the change history of root bridges................................................................................. 138
Enabling traps and viewing trap conguration........................................................................... 140
Viewing debug counters for all MST instances............................................................................140
Viewing debug counters for one MST instance ..........................................................................141
Viewing debug counters for ports in an MST instance...............................................................142
Field descriptions in MSTP debug command output................................................................. 143
Troubleshooting MSTP operation................................................................................................. 148
BPDU............................................................................................................................................................148
About BPDU protection..................................................................................................................148
Viewing BPDU protection status........................................................................................ 149
Conguring BPDU ltering.............................................................................................................150
Viewing BPDU ltering....................................................................................................................151
Conguring and managing BPDU protection.............................................................................. 151
Viewing BPDU protection status........................................................................................ 153
Re-enabling a port blocked by BPDU protection............................................................. 153
Enabling and disabling BPDU protection..................................................................................... 153
Overview of MSTP BPDU throttling...............................................................................................154
Conguring MSTP BPDU throttling....................................................................................155
PVST............................................................................................................................................................. 156
PVST protection and ltering.........................................................................................................156
PVST protection....................................................................................................................156
PVST ltering........................................................................................................................ 157
Enabling and disabling PVST protection on ports.......................................................................157
Enabling and disabling PVST lters on ports............................................................................... 157
Re-enabling a port manually......................................................................................................... 158
Viewing ports congured with PVST protection and ltering....................................................158
Listing ports to see which have PVST protection or ltering enabled......................................158
Chapter 7 Loop protection............................................................................160
Conguring loop protection......................................................................................................................160
Enabling loop protection in port mode........................................................................................ 161
Enabling loop protection in VLAN mode...................................................................................... 162
Changing modes for loop protection........................................................................................... 162
Viewing loop protection status in port mode.............................................................................. 162
Viewing loop protection status in VLAN mode............................................................................ 163
STP loop guard................................................................................................................................ 163
Operating notes..........................................................................................................................................167
Contents 7

Chapter 8 Quality of Service (QoS): Managing bandwidth eectively
.............................................................................................................................168
Introduction to Quality of Service (QoS)..................................................................................................168
Using QoS to classify and prioritize network trac....................................................................168
Applying QoS to inbound trac at the network edge.................................................... 169
Preserving QoS in outbound trac in a VLAN................................................................. 169
Using QoS to optimize existing network resources.........................................................169
Overview of QoS settings.......................................................................................................................... 170
Classiers for prioritizing outbound packets.............................................................................. 172
Packet classiers and evaluation order........................................................................................172
Preparation for conguring QoS.............................................................................................................. 173
Preserving 802.1p priority..............................................................................................................173
Steps for conguring QoS on the switch......................................................................................174
Using classiers to congure QoS for outbound trac........................................................................ 175
Viewing the QoS conguration...................................................................................................... 175
No override...................................................................................................................................... 176
Global TCP/UDP classier.............................................................................................................. 177
Global QoS classier precedence: 1.................................................................................. 177
Global IP-device classier...............................................................................................................183
Global QoS classier precedence: 2.................................................................................. 183
Options for assigning priority............................................................................................ 183
QoS IP Type-of-Service (ToS) policy and priority..........................................................................183
Global QoS classier precedence: 3.................................................................................. 183
Assigning an 802.1p priority to IPv4 packets on the basis of the ToS precedence
bits......................................................................................................................................... 184
Assigning an 802.1p priority to IPv4 packets on the basis of incoming DSCP............. 185
Assigning a DSCP policy on the basis of the DSCP in IPv4 packets received from
upstream devices.................................................................................................................187
Details of QoS IP ToS........................................................................................................... 189
Global Layer-3 protocol classier..................................................................................................192
Global QoS classier precedence: 4.................................................................................. 192
Assigning a priority for a global Layer-3 protocol classier............................................192
QoS VLAN-ID (VID) priority............................................................................................................. 193
Global QoS classier precedence: 5.................................................................................. 193
Options for assigning priority............................................................................................ 193
Assigning a priority based on VLAN-ID............................................................................. 193
Assigning a DSCP policy based on VLAN-ID......................................................................195
QoS source-port priority................................................................................................................ 196
Global QoS classier precedence: 6.................................................................................. 196
Options for assigning priority on the switch.................................................................... 196
Options for assigning priority from a RADIUS server......................................................197
Assigning a priority based on source-port........................................................................197
Assigning a DSCP policy based on the source-port......................................................... 198
Dierentiated Services Codepoint (DSCP) mapping.............................................................................. 200
Default priority settings for selected codepoints........................................................................201
Quickly listing non-default codepoint settings.................................................................201
Note on changing a priority setting.............................................................................................. 202
Changing the priority setting on a policy when one or more classiers are
currently using the policy (example)................................................................................. 203
IP Multicast (IGMP) interaction with QoS................................................................................................ 203
Outbound queue monitor.........................................................................................................................204
Displaying per-queue counts....................................................................................................................204
Conguring trac templates....................................................................................................................204
Displaying trac template information....................................................................................... 205
8Aruba 2530 Advanced Trac Management Guide for
ArubaOS-Switch 16.09

Creating a trac template............................................................................................................. 205
Conguring trac groups within a trac template........................................................ 207
Moving a priority from one trac group to another.......................................................207
Applying a trac template.............................................................................................................208
Port QoS Trust Mode................................................................................................................................. 209
Conguration commands.............................................................................................................. 209
qos trust................................................................................................................................209
qos dscp-map.......................................................................................................................210
Show commands.............................................................................................................................210
show qos trust......................................................................................................................210
QoS queue conguration.......................................................................................................................... 211
Mapping of outbound port queues.............................................................................................. 212
Conguring the number of priority queues................................................................................ 212
Viewing the QoS queue conguration..........................................................................................213
QoS operating notes and restrictions......................................................................................................213
Chapter 9 Rapid per-VLAN spanning tree (RPVST+) operation.............215
Overview of RPVST+................................................................................................................................... 215
General steps for conguring RPVST+..................................................................................................... 215
Conguring RPVST+ at a glance................................................................................................................216
Selecting RPVST+ as the spanning tree mode............................................................................. 217
Conguring global spanning tree..................................................................................................217
Conguring per-VLAN spanning tree............................................................................................218
Conguring per-port per-VLAN spanning tree............................................................................ 219
Conguring per-port spanning tree..............................................................................................220
Enabling or disabling RPVST+ spanning tree............................................................................... 221
Allowing trac on VLAN ID (PVID) mismatched links............................................................................ 222
Conguring STP loop guard...................................................................................................................... 223
About RPVST+............................................................................................................................................. 226
Comparing spanning tree options................................................................................................ 226
Understanding how RPVST+ operates..........................................................................................227
Working with the default RPVST+ conguration.............................................................. 229
RPVST+ operating notes.................................................................................................................229
Viewing RPVST+ statistics and conguration.......................................................................................... 231
Viewing global and VLAN spanning tree status...........................................................................231
Viewing status for a specic VLAN................................................................................................ 231
Viewing status for a specic port list............................................................................................ 232
Viewing status per-port per-VLAN ................................................................................................233
Viewing the global RPVST+ conguration.................................................................................... 233
Viewing the global RPVST+ conguration per port..................................................................... 234
Viewing the global RPVST+ conguration per port per VLAN....................................................234
Viewing the global RPVST+ conguration per VLAN................................................................... 235
Viewing BPDU status and related information............................................................................236
Viewing RPVST+ VLAN and vPort system limits................................................................237
Troubleshooting an RPVST+ conguration..............................................................................................240
Viewing the change history of root bridges................................................................................. 240
Enabling traps and Viewing trap conguration........................................................................... 241
Viewing debug counters for all VLAN instances..........................................................................242
Viewing debug counters per-VLAN............................................................................................... 242
Viewing debug counters per-port per-VLAN................................................................................243
Field descriptions for RPVST+ debug command output............................................................ 244
RPVST+ event log messages.......................................................................................................... 245
Using RPVST+ debug.......................................................................................................................246
Contents 9

Chapter 10 Switch Stack Management......................................................248
Introduction to switch management....................................................................................................... 248
Conguring stack management............................................................................................................... 248
Options for conguring a commander and candidates.............................................................248
Creating a stack (Overview).......................................................................................................................250
Viewing stack status (CLI).......................................................................................................................... 251
Viewing the status of an individual switch.............................................................................................. 251
Viewing the status of candidates the Commander has detected (CLI)................................................251
Viewing the status of all stack-enabled switches discovered in the IP subnet (CLI)...........................252
Viewing the status of the Commander and current members of the Commander’s stack (CLI)..... 252
Conguring a Commander switch (CLI)...................................................................................................252
Making a switch a Commander (CLI)....................................................................................................... 253
Using a Member’s CLI to make the Member Commander of a new stack..........................................254
Adding to a stack, or moving switches between stacks (CLI)................................................................ 254
Using auto join on a Candidate (CLI)........................................................................................................256
Using a Candidate CLI to push the Candidate into a stack................................................................... 256
Using the destination Commander CLI to pull a member from another stack..................................257
Using a Member CLI to push the Member into another stack............................................................. 258
Converting a Commander to a Member of another stack (CLI)........................................................... 258
Removing a Member from a stack (CLI)...................................................................................................259
Removing a stack Member using the Commander’s CLI............................................................259
Removing a stack Member using the Member’s CLI...................................................................259
Accessing Member switches for conguration changes and trac monitoring (CLI)....................... 260
Disabling or re-enabling stacking (CLI).................................................................................................... 261
Setting the transmission interval (CLI).....................................................................................................261
Using the Commander to manage the stack.......................................................................................... 261
About stack management......................................................................................................................... 261
Components of Switch stack management.................................................................................262
General stacking operation............................................................................................................262
Interface options..................................................................................................................263
Operating rules for stacking.......................................................................................................... 263
General rules........................................................................................................................ 263
Specic rules for commander, candidate, and member switch.................................... 265
Stacking operation with multiple VLANs congured.................................................................. 266
Status messages..............................................................................................................................266
SNMP community operation in a stack........................................................................................ 267
Community Membership....................................................................................................267
SNMP management station access to members via the Commander......................... 268
Chapter 11 BYOD-redirect.............................................................................269
Introduction to BYOD-redirect..................................................................................................................269
BYOD features............................................................................................................................................ 270
Interoperability with other switch features................................................................................. 271
Interoperability with other vendors.................................................................................. 272
Restrictions...................................................................................................................................... 272
Conguring BYOD...................................................................................................................................... 272
Creating a BYOD server..................................................................................................................272
Associating a BYOD server..................................................................................................272
Creating a BYOD ACL rule................................................................................................... 273
Implementing BYOD-redirect conguration.....................................................................274
Show commands.............................................................................................................................278
Show portal server.............................................................................................................. 278
Associating with the BYOD server on a specied VLAN............................................................. 280
10 Aruba 2530 Advanced Trac Management Guide for
ArubaOS-Switch 16.09

Chapter 12 Smart link....................................................................................281
Overview of smart link...............................................................................................................................281
Smart link conguration commands....................................................................................................... 282
Create a smart link group.............................................................................................................. 282
Congure VLANs............................................................................................................................. 282
Enable debug...................................................................................................................................282
Conguration example...................................................................................................................283
Show smart link group...............................................................................................................................283
Show smart link ush-statistics................................................................................................................ 284
Show receive control..................................................................................................................................284
Show tech smart link..................................................................................................................................284
Clear command.......................................................................................................................................... 285
Event Log..................................................................................................................................................... 285
Chapter 13 Websites...................................................................................... 286
Chapter 14 Support and other resources..................................................287
Accessing Hewlett Packard Enterprise Support..................................................................................... 287
Accessing updates......................................................................................................................................287
Customer self repair.................................................................................................................................. 288
Remote support......................................................................................................................................... 288
Warranty information................................................................................................................................ 288
Regulatory information............................................................................................................................. 289
Documentation feedback..........................................................................................................................289
Contents 11

This guide provides information on how to congure trac management features.
Applicable products
This guide applies to these products:
Aruba 2530 Switch Series (J9772A, J9773A, J9774A, J9775A, J9776A, J9777A, J9778A, J9779A, J9780A, J9781A,
J9782A, J9783A, J9853A, J9854A, J9855A, J9856A, JL070A)
Switch prompts used in this guide
Examples in this guide are representative and may not match your particular switch/environment. Examples
use simplied prompts as follows:
Prompt Explanation
switch# # indicates manager context (authority).
switch> > indicates operator context (authority).
switch(config)# (config) indicates the cong context.
switch(vlan-x)# (vlan-x) indicates the vlan context of cong,
where x represents the VLAN ID. For example:
switch(vlan-128)#.
switch(eth-x)# (eth-x) indicates the interface context of cong,
where x represents the interface. For example:
switch(eth-48)#.
switch-Stack# Stack indicates that stacking is enabled.
switch-Stack(config)# Stack(config) indicates the cong context while
stacking is enabled.
switch-Stack(stacking)# Stack(stacking) indicates the stacking context of
cong while stacking is enabled.
switch-Stack(vlan-x)# Stack(vlan-x) indicates the vlan context of cong
while stacking is enabled, where x represents the
VLAN ID. For example: switch-
Stack(vlan-128)#.
switch-Stack(eth-x/y)# Stack(eth-x/y) indicates the interface context of
cong, in the form (eth-<member-in-stack>/
<interface>). For example: switch(eth-1/48)#
Chapter 1
About this guide
12 Aruba 2530 Advanced Trac Management Guide for
ArubaOS-Switch 16.09

Understanding VLANs
Aruba-OS wired switches are 802.1Q VLAN-enabled. In the factory default state, the switch is enabled for up
to 256 VLANs. You can recongure the switch to support more VLANs. The maximum VLANs allowed varies
according to the switch series.
A group of networked ports assigned to a VLAN form a broadcast domain congured on the switch. On a
given switch, packets are bridged between source and destination ports that belong to the same VLAN.
VLANs enable grouping users by logical function not physical location. They manage bandwidth usage in
networks by:
• Enabling grouping high-bandwidth users on low-trac segments.
• Organizing users from dierent LAN segments according to their need for common resources and
individual protocols.
• Improving trac control at the edge of networks by separating trac of dierent protocol types.
• Enhancing network security by creating subnets to control in-band access to specic network resources.
• Cross-domain broadcast trac in the switch is eliminated and bandwidth saved by not allowing packets
to ood out all ports.
When conguring VLANs, you will need to plan your VLAN strategy as follows:
Procedure
1. Congure static VLANs with:
• a name
• VLAN ID number (VID)
• port members
2. Include port conguration planning to use dynamic VLANs.
3. Create a map of the logical topology.
4. Create a map of the physical topology.
5. Consider the interaction between VLANs and other features:
• Spanning Tree Protocol
• port trunking
• IGMP
6. Congure at least one VLAN in addition to the default VLAN.
7. Congure all ports that pass trac for a particular subnet address on the same VLAN.
Chapter 2
VLANs
Chapter 2 VLANs 13

8. Assign the desired switch ports to the new VLANs.
9. Ensure that the VLAN through which you manage the switch has an IP address, if you are managing
VLANs with SNMP in an IP network.
For information on the restrictions when you congure an IP address on a VLAN interface, see the
"Comparing port based and protocol based VLAN" table in Static VLAN operation.
Static VLAN operation
Static VLANs are congured with a name, VLAN ID number (VID) and port members. For dynamic VLANs, see
GVRP. 802.1Q compatibility enables you to assign each switch port to multiple VLANs.
14 Aruba 2530 Advanced Trac Management Guide for
ArubaOS-Switch 16.09

Table 1: Port based and protocol based VLAN
Function Port-Based VLANs Protocol-Based VLANs
IP Addressing Usually congured with at least one
unique IP address.
A port-based VLAN can have no IP
address. However, this limits switch
features available to ports on that VLAN.
See "How IP addressing aects switch
operation" in the chapter "Conguring IP
Addressing" in the Basic Operation Guide
for the switch.
Multiple IP addresses allow multiple
subnets within the same VLAN. See the
chapter on "Conguring IP Addressing" in
the ArubaOS-Switch Basic Operation Guide
for the switch.
You can congure IP addresses on all
protocol VLANs, but IP addressing is used
only on IPv4 and IPv6 VLANs.
Restrictions:
Loopback interfaces share the same IP
address space with VLAN congurations.
The maximum number of IP addresses
supported on a switch is 2048; this
includes all IP addresses congured for
both VLANs and loopback interfaces
(except for the default loopback IP
address 127.0.0.1).
Each IP address congured on a VLAN
interface must be unique in the switch; it
cannot be used by a VLAN interface or
another loopback interface.
For more information, see the chapter on
"Conguring IP Addressing" in the
ArubaOS-Switch Basic Operation Guide.
Untagged VLAN
Membership
A port can be a member of one untagged,
port-based VLAN. All other port-based
VLAN assignments for that port must be
tagged.
A port can be an untagged member of
one protocol VLAN of a specic protocol
type, such as IPX or IPv6. If the same
protocol type is congured in multiple
protocol VLANs, then a port can be an
untagged member of only one of those.
For example, if you have two protocol
VLANs, 100 and 200 and both include IPX,
then a port can be an untagged member
of either VLAN 100 or VLAN 200, but not
both.
A port's untagged VLAN memberships
can include up to four dierent protocol
types. It can be an untagged member of
one of the following:
• Four single-protocol VLANs
• Two protocol VLANs where one VLAN
includes a single protocol and the
other includes up to three protocols
• One protocol VLAN where the VLAN
includes four protocols.
Table Continued
Chapter 2 VLANs 15

Function Port-Based VLANs Protocol-Based VLANs
Tagged VLAN
Membership
A port can be a tagged member of any
port-based VLAN.
A port can be a tagged member of any
protocol-based VLAN.
Routing If the switch conguration enables IP
routing, the switch can internally route IP
(IPv4) trac between port-based VLANs
and between port-based and IPv4
protocol-based VLANs.
If the switch is not congured to route
trac internally between port-based
VLANs, then an external router must be
used to move trac between VLANs.
If the switch conguration enables IP
routing, the switch can internally route
IPv4 trac as follows:
• Between multiple IPv4 protocol-based
VLANs
• Between IPv4 protocol-based VLANs
and port-based VLANs.
Other protocol-based VLANs require an
external router for moving trac
between VLANs.
NOTE: NETbeui and SNA are
non-routable protocols. End
stations intended to receive
trac in these protocols
must be attached to the
same physical network.
Commands for
Conguring Static
VLANs vlan <vid> {tagged | untagged
<port-list>}
vlan <vid> protocol {ipx | ipv4
| ipv6 | arp | appletalk | sna
| netbeui}
vlan <vid> {tagged | untagged
<port-list>}
VLAN environments
You can congure dierent VLAN types in any combination. The default VLAN will always be present. For
more on the default VLAN, see VLAN support and the default VLAN.
16 Aruba 2530 Advanced Trac Management Guide for
ArubaOS-Switch 16.09

VLAN environment Elements
The default VLAN (port-
based; VID of 1) only
In the default VLAN conguration, all ports belong to VLAN 1 as
untagged members.
VLAN 1 is a port-based VLAN.
Multiple VLAN environment In addition to the default VLAN, the conguration can include one or
more other port-based VLANs and one or more protocol VLANs.
The maximum VLANs allowed on a switch vary according to the
switch. For details on the maximum VLANs allowed for your switch,
see Changing the number of VLANs allowed on the switch (CLI)
on page 44.
UsingVLAN tagging, ports can belong to multiple VLANs of all
types.Enabling routing on the switch enables it to route IPv4 and IPv6
trac between port-based VLANs and between port-based VLANs
and IPv4 protocol VLANs. Routing other types of trac between
VLANs requires an external router capable of processing the
appropriate protocols.
VLAN operation
General VLAN operation
• A VLAN is composed of multiple ports operating as members of the same subnet or broadcast domain.
• Ports on multiple devices can belong to the same VLAN.
•Trac moving between ports in the same VLAN is bridged (or switched).
•Trac moving between dierent VLANs must be routed.
• A static VLAN is an 802.1Q-compliant VLAN, congured with one or more ports that remain members
regardless of trac usage.
• A dynamic VLAN is an 802.1Q-compliant VLAN membership that the switch temporarily creates on a port
to provide a link to another port either in the same VLAN on another device.
Types of static VLANs available in the switch
Port-based VLANs
This type of static VLAN creates a specic layer-2 broadcast domain comprised of member ports that bridge
trac among themselves. Port-Based VLAN trac is routable on the switches covered in this guide.
Protocol-based VLANs
This type of static VLAN creates a layer-3 broadcast domain for trac of a particular protocol and is
composed of member ports that bridge trac of the specied protocol type among themselves. Some
protocol types are routable on the switches covered in this guide.
Designated VLANs
The switch uses these static, port-based VLAN types to separate switch management trac from other
network trac. While these VLANs are not limited to management trac, they provide improved security
and availability.
Chapter 2 VLANs 17

Default VLAN:
This port-based VLAN is always present in the switch and, in the default conguration, includes all ports as
members. See VLAN support and the default VLAN on page 53.
Except for an IP address and subnet, no conguration steps are needed.
A switch in the default VLAN conguration
In this example, devices connected to these ports are in the same broadcast domain.
Primary VLAN:
The switch uses this port-based VLAN to run certain features and management functions, including DHCP/
Bootp responses for switch management. In the default conguration, the Default VLAN is also the Primary
VLAN. However, any port-based, non-default VLAN can be designated the Primary VLAN. See The primary
VLAN on page 53.
Secure Management VLAN:
This optional, port-based VLAN establishes an isolated network for managing switches that support this
feature. Access to this VLAN and to the switch's management functions are available only through ports
congured as members. See The primary VLAN on page 53.
Voice VLANs:
This optional, port-based VLAN type enables separating, prioritizing, and authenticating voice trac moving
through your network, avoiding the possibility of broadcast storms aecting VoIP Voice-over-IP) operation.
See Using voice VLANs on page 52.
NOTE: In a multiple-VLAN environment that includes older switch models there may be
problems related to the same MAC address appearing on dierent ports and VLANs on the
same switch. In such cases, the solution is to impose cabling and VLAN restrictions. For more on
this topic, see Multiple VLAN considerations on page 27.
Multiple port-based VLANs
In the following example, routing within the switch is disabled (the default). Thus, communication between
any routable VLANs on the switch must go through the external router. In this case, VLANs W and X can
exchange trac through the external router, but trac in VLANs Y and Z is restricted to the respective
VLANs.
VLAN 1(the default) is present but not shown. The default VLAN cannot be deleted from the switch, but ports
assigned to other VLANs can be removed from the default VLAN. If internal (IP) routing is enabled on the
switch, then the external router is not needed for trac to move between port-based VLANs.
18 Aruba 2530 Advanced Trac Management Guide for
ArubaOS-Switch 16.09

A switch with multiple VLANs congured and internal routing disabled
Protocol VLAN environment
The gure in Multiple port-based VLANs illustrates a protocol VLAN environment also. In this case, VLANs
W and X represent routable protocol VLANs. VLANs Y and Z can be any protocol VLAN.
As noted for the discussion of multiple port-based VLANs, VLAN 1 is not shown. Enabling internal (IP) routing
on the switch allows IP trac to move between VLANs on the switch, but routable, non-IP trac always
requires an external router.
Routing options for VLANs
Table 2: Options for routing between VLAN types in the switch
Note that SNA and NETbeui are not routable protocol types. End stations intended to receive trac in these
protocols must be attached to the same physical network.
Port-
Based
IPX IPv4 IPv6 ARP AppleTalk SNA NETbeui
Port-Based Yes — Yes — — — — —
Protocol IPX — Yes — — — — — —
IPX4 Yes — Yes — — — — —
IPV6 — — — Yes1— — — —
ARP — — — — Yes1— — —
AppleTalk — — — — — Yes1— —
SNA — — — — — — — —
NETbeui — — — — — — — —
802.1Q VLAN tagging
A port can be a member of more than one VLAN of the same type if the device to which the port connects
complies with the 802.1Q VLAN standard.
For example, a port connected to a central server using a network interface card (NIC) that complies with the
802.1Q standard can be a member of multiple VLANs, allowing members of multiple VLANs to use the
server.
Chapter 2 VLANs 19

• Although these VLANs cannot communicate with each other through the server, they can all access the
server over the same connection from the switch.
• Where VLANs overlap in this way, VLAN "tags" are used in the individual packets to distinguish between
trac from dierent VLANs.
• A VLAN tag includes the particular VLAN ID. (VID) of the VLAN on which the packet was generated.
For more on this topic, see Conguring or changing static VLAN per-port settings (CLI) on page 34.
Overlapping VLANs using the same server
Similarly, using 802.1Q-compliant switches, you can connect multiple VLANs through a single switch-to-
switch link.
Connecting multiple VLANs through the same link
Introducing tagged VLANs into legacy networks running only untagged VLANs
You can introduce 802.1Q-compliant devices into networks that have built untagged VLANs based on earlier
VLAN technology. The fundamental rule is that legacy/untagged VLANs require a separate link for each
VLAN, while 802.1Q, or tagged VLANs can combine several VLANs in one link. Thus on the 802.1Q-compliant
device, separate ports (congured as untagged) must be used to connect separate VLANs to non-802.1Q
devices.
20 Aruba 2530 Advanced Trac Management Guide for
ArubaOS-Switch 16.09
