Thank you for purchasing

MySpace™ Model

Breathe the Difference™

Document Ref.=MSP01LP010 _ Revision 20170425

OHAir, HGU, and MySpace are trademarks or registered trademarks

of HGI Industries Incorporated, Boynton Beach Florida, USA.

Whatarehydroxyls?

Hydroxyls (HO•) are naturally occurring radicals. They are created in our atmosphere when the

sun's ultraviolet rays react with water vapor in the air. Hydroxyls arean important agent that

scrub and cleanse our planet's environment. OHAir ®HydroxylGeneratorsreplicate this

naturally occurring process and bringit indoors.

Howdohydroxylscleansurfacesandhardtoreachplaces?

Once the hydroxyls are created, they are sent to 'seek and destroy' odor molecules, bacteria,

viruses, mold, volatile organic compounds (VOCs),and other chemicals.

This system does not requireall of the contaminants within a room to passthrough the

processing chamber. Outside the devicethe hydroxyls immediately begin a cascade reaction

in the air. The cascade of hydroxyls quickly disperse throughout the air and penetrates surfaces and

objects and reachplaces that otherwise can’t be reached. Other technologies only clean or filter the

airthat passesthrough thedevice (asmallpercentageofthe airin a room).

Howdoesitkillmold?

As wellasdirectly destroying spores, theOHAir® system treats infected areas by cuttingoffthe

foodsource for mold. As a result, there is nothing for mold to feed on since the very bacteria

andmicro-organisms that it relies on to survive have been killed. Only thisway can mold

be rendered inert.

Arehydroxylgeneratorssafetoruninoccupiedareas?

OHAir ®Hydroxyls generators developed by HGIare safe to run (andhave been independently

tested) in occupied areas. Unlike ozoneand harsh chemicals, hydroxylsare completely safefor

people, pets and plants. They will not damage rubber, plastic, leather, vinyl, electronics or

other sensitive materials. They will also not bleach or discolor items -wet or dry.

Howlongdoesittaketowork?

Hydroxyls are veryfast acting and do their work through a chemical reaction. There needs to

be a high enough concentration - If there is no noticeable reduction in odor, asecond or

stronger device may be required. Resultsareoften noticedwithin the1rstfewminutes of

operation, with heavy odorsbeing permanently eliminated within days.

Dohydroxylssmell?

Hydroxyls themselves don’t have any smell. When hydroxyls interact with the environment,

that may create some odor. If the odor is too strong, turn the fan speed on your MySpace™

device to a lower setting. Theodor may be strong initially as aroom is first treated.

Theodor/moldthatwastreatedisgone,willitcomeback?

Airand Surfaces will be fully treated. If the cause (urine, feces,smoke, cleaning agents, mold,

etc) is within/embedded in the material, the device will need to be rununtil the source is

exhausted orremoved.

For moreFAQ’s, please visit the website http://www.oh-air.com

PRODUCT INTRODUCTION………………………………………………... 1

OPERATIONAL INSTRUCTIONS……………………………………..………. 2

SPECIFICATIONS…………...………………………………………………..... 3

AIR FLOW ORIENTATION ……………………..……………………………. 4

RECOMMENDED USES…………………..……………………………………. 5

GETTING STARTED………….………….…………………………………….. 6

CONNECTING YOUR MYSPACE™ UNIT TO YOUR WI-FI…………….... 7

TROUBLESHOOTING GUIDE……………...…………………………………. 8

HOW TO REMOVE FRONT COVER…………………………………………. 9

TIPS……………………………………..….…………………………………….. 10

HGU™MAINTENANCE AND REPLACEMENT ……...........…..….........…. 11

HGU™MAINTENANCE AND REPLACEMENT ………………….........…. 12

FAN MAINTENANCE AND REPLACEMENT…...…………..……..………. 13

CARING FOR YOUR MYSPACE™ UNIT ………………………………….. 14

WARRANTY INFORMATION………………………………….…….……..... 15

WARRANTY CARD……………………………..………………………………16

FREQUENTLY ASKED QUESTIONS (FAQ’S)…………………………...….17

Table Of Contents Frequently Asked Questions (FAQ’s)

Document Ref.=MSP01LP010 _ Revision 20170425

The OHAir™ product line is a technologically sophisticated and

advanced air and surface treatment device. Using an OHAir®hydroxyl

generator, the MySpace™ device replicates nature’s ability to generate

atmosphere hydroxyls that are found in earth’s atmosphere allowing

us to remain healthy.

OHAir®technology mimics the natural effect of sunlight to produce safe,

normal occurring atmospheric hydroxyls which act as natures cleaning

agents within our environment.

Affix

stamp

here

HGI Industries, Inc.

2055 High Ridge Road,

Boynton Beach, FL 33426

United States of America

Product IntroductionWarranty Card

For the warranty management,

please cut the card bellow and send it to our

claim processing department

ITEM

BLUE

RED

WHITE

BLACK

Document Ref.=MSP01LP010 _ Revision 20170425

YourMySpace™units arethe bestalternative for small/medium area air treatment, such as workareas,

office spaces, kitchens, bedrooms, etc. We recommend a treatment areaof up to 40m2

or 430ft2 assuming2.5m (8ft) ceiling with an air exchange of 2-6 times per hour,

although this will vary depending on demand and conditions ofthe treatment area.

This device will provide a constantstream of hydroxyls to treat air and surfaces.

The hydroxylsgenerated by theOHAir®MySpace™ unit will destroybacteria, viruses,

mold, allergensand odor from the air. Surfaces in the operating area will alsobe

treated, reducingor eliminating thesecontaminants.

NOTE: Your MySpace™ unit is designedto protectyouand yourenvironment.

Safety Warnings - Please read and save this manual

-Skinor eyedamage may result from directly viewing the light/UV source inthis apparatus.

-Do not look at the light directly.

-Do not expose skin tothe light.

- Device must be turned off before unplugging from the mains.

-Disconnect/unplugged power before removing the cover, replacing HGU™ assembly or servicing.

-The device is not intended to be used in wet/pooling environments.

-The device is not to be used by children, nor should children be permitted to play with the device.

-The device is not to be used by people with reduced physical, sensory ormental capabilities unless they have

been given supervision or instructions.

-AC orDC power input must only be supplied atvoltage corresponding tothemarking on the device.

-If the device is obviously damaged, it mustnot be operated.

- Keep objects away from moving parts.

- Keep liquids away from the appliance and do not wash.

-Do not expose UVsensitive materials tothelight.

-Always replace the UV source with part number HGU01 manufactured by HGI Industries, Incorporated.

What’s intheBox?

1x MySpace™Device 1x UserManual 1 x PowerCord

HGI Industries, Inc. warrants that the product set forth below will be free from defects in materials and workmanship for the

period of two (2) years from the date of original purchase under the following terms and conditions:

To obtain service under this warranty, send or deliver this product within the warranty period together with the warranty

certificate to any HGI Industries, Inc. authorized warranty service center.

If requested by HGI Industries, Inc. authorized warranty service center, you must present proof of purchase

showing date and place of purchase. If upon inspection by HGI Industries, Inc. authorized warranty service center, the product is proved to

be defective, it will be repaired without charge using, if necessary, new parts or comparable used parts that have been fully reconditioned

and returned to you. The warranty period for replacement parts shall extend for a period of six (6) months following the installation of same

or for the remaining period of this warranty whichever is longer. This warranty card does not apply in the following cases: (a) damage to

product due to mishandling, alteration, failure to follow operation, maintenance or environmental instructions prescribed by applicable

instruction manual or shipping damage; (b) damage caused during service performed other than HGI Industries, Inc. authorized service

center; (c) if the product has had its serial number(s) or other identifying data removed: or (d) damage, defect or unsatisfactory performance

caused by the use of equipment not manufactured or distributed by HGI Industries, Inc.

This warranty does not cover the consumable parts which consist of the HGU™ optic and/or Intake filter.

IN NO EVENT WILL HGI INDUSTRIES, INC. BE LIABLE FOR ANY DAMAGE, INCLUDING INCONVENIENCE, LOST PROFITS, OR

LOST SAVINGS, OTHER INCIDENTAL DAMAGE STEMMING FROM THE USE OF THE PRODUCT OR OUT OF DEFECTS THEREIN,

OR BY BREACH OF THIS EXPRESSED WARRANTY OR ANY IMPLIED WARRANTY WITH THE RESPECT OF THIS PRODUCT,

WHETHER ON ACCOUNT OF NEGLIGENCE OR OTHERWISE, EVEN IF HGI INDUSTRIES, INC. AUTHORISED WARRANTY SERVICE

CENTRE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

This warranty is not valid if warranty card below is not completed and returned to HGI Industries, Inc. within sixty (60)

days of purchase date.

Some states do not allow limitations on how long the implied warranty lasts or limitations of incidental or consequential

damages, so the above limitations may not apply to you. This warranty gives you specific legal rights and you may also have

other rights which vary from state to state.

Please register online at oh-air.com

Alternatively fill in, cut off and return it to HGI Industries, Inc. for registration.

Purchaser’s Details

Full Name:_______________________________________________________________

Address:_________________________________________________________________

City:____________________________________ State:___________________________

Post Code:______________________ Country: _________________________________

Purchaser’s Business Type:__________________________________________________

Primary Use for Machine:____________________________________________________

Device Details

Model: OHAir MySpace™

Serial Number:____________________________________________________________

Purchase Date:____________________________________________________________

Vendor Details

Name:____________________________________________________________________

Address:__________________________________________________________________

Operational Instructions Warranty Information

Document Ref.=MSP01LP010 _ Revision 20170425

MySpace™

Units are devices with multiple attributes suitable for a wide range of applications.

See table bellow for references:

AC:110 –240V 50-60Hz

DC: 12 –24V

Maximum Power: 45W

Description

Attribute

13" x 4.5" x 11.5“

(330 L mm x 110 W mm

x 290 Hmm)

Dimensions

8.37 lbs, (3.8 Kg)

Weight

Power

Digital Speed Control ,

Selector Switch

Touch Control

Control

Wi-fi module

Wireless Component

Standing Feet

Placements

32 –38 dbl @ 3’ – 1 M

Noise Level

1 HGU™ Assembly

Number of HGU™

White, Red, Black, and Blue

Color Options

14 3

Caring for your MySpace

™ unit

Specifications

Document Ref.=MSP01LP010 _ Revision 20170425

CAUTION: DISCONNECT the unit from an electrical power source before

performing any maintenance or cleaning on the unit.

SYSTEM CASE CLEANING

Exterior

The exterior of the OHAir® product can be cleaned with mild dishwashing

detergent and a clean cloth, and then wiped down with clean water. DO

NOT use any all-purpose cleaners with harsh detergents or abrasives, as

these may damage the decals and the exterior finish. Care should also

be taken to avoid spraying or otherwise directing detergent or water into

or around electrical components.

Interior

The interior of the OHAir® product can be cleaned in the same manner as

the exterior.

HGU™ (OPTIC) CLEANING

Cleaning of the optics is recommended to maintain peak processing efficiency.

Fingerprints, smudges, dirt, dust particles, etc. will interfere with the hydroxyl

production and should be avoided.

Note: Remove the optics from the optic chamber prior to cleaning to avoid

any damage to the optics during the cleaning process (refer to the Optic

Replacement Instructions for proper removal).

To clean the optics, use a solution of 10% Isopropyl Alcohol and 90%

filtered/distilled water on a clean lint-free cloth and wipe gently. Do not use any

type of commercial glass cleaner. Using another lint-free cloth, gently wipe the

optic until completely dry. Allow the optic to dry completely (20 minutes)

before operating the system.

Step 1 - Remove the fasteners located on the

Counterpart.

Step 3 – Lightly remove intake cover and

store it safely.

Step 5 – Lightly, remove and replace fan.

Step 6 – Reverse step 5,4,3,2,1.

Air Flow Orientation

Fan Maintenance And Replacement

CAUTION: Your device MUST BE unplugged/disconnected from the mains.

Step 2 – Lightly, remove front case and store it

safely.

Step 4 – Remove fan holder and store it safely.

Document Ref.=MSP01LP010 _ Revision 20170425

Your MySpace™device’s front cover

has been designed with an unique

grill pattern for better inlet and outlet

air flow circulation.

Air out

Air in

Your MySpace™ units are recommended for a treatment area of up to 40m2 or 430ft2

assuming 2.5m (8ft) ceiling with an air exchange of 2-6 times per hour. This deviceis

recommended for the following areas and more:

BATHROOMS

Your MySpace™ unit helps in removing odors and prevents mold growing on the walls

through moisture present and water related activities. It also eliminates any bacteria

and viruses present on the bathroom surfaces.

WORK SPACE

Applications of your MySpace™ units are almost unlimited from offices and classrooms to

indoor smoking areas and bedrooms. Larger spaces with high demand can also be

treated with multiple devices.

TREATING A LARGE AREA WITH LOW DEMAND

A large area with low use and low chemical/odor load can be treated with the MySpace™

unit fan setting seton high and with the use of an external fan to distribute the

treated air.

TREATING COOKING AREA IN THE KITCHEN

Your MySpace™ unit helps to prevent mold and grease from growing on kitchen surfaces

which may result from airborne odors and chemical compounds released during cooking

activities.

Kitchen surfaces that are vulnerable to mold build up and damaged surfaces due to

daily cooking activities, can be treated with MySpace™ unit with fan setting set on high

and the device placed 0.5m (20”) away from the stove. It is recommended that the

MySpace™ unit should have the air blowing across the stove at a height of about 0.5m

(20”). This is so the hydroxyls can effectively treat the area.

It is recommended that your MySpace™ unit runs continuously whether cooking or not to

prevent build up of mold and oil on kitchen surfaces. When cooking, hydroxyls

break down the steam/smoke and contaminants present within the steam/smoke.

When not cooking, hydroxyls break down the grease, mold, bacteria and viruses

already present onthe kitchen surfaces. Therefore, your MySpace™ unit willbe working

for you around the clock to keep your kitchen safe and healthy.

For more examples, please visit the website http://www.oh-air.com

HGU™ Maintenance and Replacement Recommended Use

CAUTION: Your device MUST BE unplugged/disconnected from the mains.

F G

Step 8 –Re-fit HGU™ screws “F” and “G” confirming

HGU™ assembly is correctly seated.

Step 9 – Replace the chamber cover and insert screw

“E”.

Step 10 – Replace metal cover plate and re-fit screws

in the following sequence, loosely first, tighten once

all in place:

1. A (press cover down to locate screw correctly)

2. B

3. C

4. D

Step 11 – Replace the air filter and front cover of the

device as per previous instructions.

NOTE: HGU™ trademark is an acronym for Hydroxyl Generator Unit

and it is referred to as either Optic Assembly or HGU™ assembly in this

user manual.

Document Ref.=MSP01LP010 _ Revision 20170425

CAUTION: Your device MUST BE unplugged/disconnected from the mains.

Getting Started HGU™ Maintenance and Replacement

Step 1- Refer to previous section ‘Removing Cover for

Cleaning and Replacement’ to remove the front cover.

Step 2 - To remove the metal cover plate, remove screws

“A-D” using PH1 Philips head screw driver. Lift up the plate

to remove it.

Step 3 - To remove the chamber cover, remove screw

“E” using PH1 Philips screw driver. Lift up the chamber

cover to expose the optic assembly (HGU™ assembly).

Step 4 - To remove the HGU™ assembly, remove two

HGU™ mounting screws “F” and “G”. Grasp the center

baffle “H” and manipulate side to side whilst firmly pulling

it away from the connector and lifting out.

Step 5 - Gently clean the optic with a glass cleaner and

a lint free cloth. Ensure optic is completely dry before re-

insertion.

Step 6 - While the HGU™ assembly is out, remove dust

and clean with dry cloth.

Step 7 - Carefully locate wafer connection “I” into black

socket,

Plug your Hydroxyl Generator into power, your display will illuminate to one of these two states:

NOTE:

ON/ OFF option

will not work

on this screen

Fan Speed Decrease

Fan Speed Increase

Indicates unit is on Indicates unit is off

MAIN

SCREEN

Powering On/Off the Device

To turn your MySpace™device on or off, navigate your menu screen to any screen except

the language screen using the left and right buttons ( ), then tap the center button

( ) once to turn your device on or off. Please note that device on/off option does not

work on the language screen.

Menu Screen Standby/Wakeup

Your MySpace™device is designed to conserve energy and provide you with a distraction

free experience, therefore the menu screen of your MySpace™ device will go into standby

mode after 30 seconds of inactivity. In order to wake the menu screen, tap any of the

buttons once.

Language Selection

Once on the language selection menu (see previous section ‘Getting Started’), select the

language that you want using the up and down arrows ( ) and then press center

button ( ) to confirm selection and apply the language to the menus. You will see an

asterisk (*) on the selected language.

F G

Document Ref.=MSP01LP010 _ Revision 20170425

See next page

Station Details

SSID: OHAIR

IP:

Live data

OH Run 1520

OH Temp: 33.4 C

OH Humid: 41.0 %

Access Point

SSID:

OH-AIR_UI_0143

IP: 255.255.239.25

Access Point

OH-AIR_UI_0143

IP: 255.255.239.25

pwd: admin007

Live data

Fan: 12.0 V

OH Hours: 1666

Status: OK

Live data

FW ver: UI_3.03-17

DriveTemp: 55.2

Serial number:

Live data

DriveTemp: 55.8

Serial number:

UII_00…00143

Language

Chinese

English

10 7

Tips Connecting Your MySpace™ unit to Your Wi-Fi

Infrastructure Mode:

You can connect your MySpace™ unit to your home or office Wi-Fi to control it remotely

and monitor its operation.

By viewing these screens on your MySpace™ unit,

you can get the information you need to connect

your device to Wi-Fi.

Access Point Mode:

Step 1: Search your MySpace™ (SSID) on Wi-Fi search list on your preferred device

Step 2: Select your MySpace™ unit

Step 3: Put in the password shown on your MySpace™ screen (admin007)

Once it is Connected

Step 1: Open your browser on your preferred device

Step 2: Type in the IP address 192.168.4.1 in the address bar of your browser

Step 3: Once you are on the login page, type in your home or office wireless SSID name

under the SSID section

Step 4: Put in your home or office wireless SSID password (WPA2) under the password

section

Step 5: Leave the server and port details as it is, by default values should be present in

those sections

Step 6: (only if required) If server and port sections have no values, then type in the

following:

Server: ohair.hydroxyl.info Port: 1883

Wi-Fi Tips

Your MySpace™ unit enables you to control and monitor the device over your wireless

network. When you connect your MySpace™ unit with any of the smart devices, your

device will either warn you about no internet connectivity or in some cases your device

might disconnect from your network and reconnect to one of your saved networks that

happen to be within range. To overcome this problem:

Samsung and HTC Devices (Android Platform)

Please switch ‘off’ your smart network switch option before connecting your MySpace™

unit .

Nexus Devices

When prompted to stay connected or disconnect from wireless network with no internet

connection, select ‘yes’ to stay connected.

Wi-Fi Tips

iOS Devices, Mac OS and Windows PC

No user action is required on these platforms; however they may prompt a warning

dialogue/notification that there is no internet connectivity.

For other operating systems and specific device questions and answers, please

contact OHAirsupport at oh-air.com.

Reconnecting to Existing Device

If you are having trouble reconnecting to your MySpace™ unit using an existing device,

please do the following:

Step 1: Search your MySpace™ SSID on Wi-Fi search list on your device

Step 2: Select your MySpace™ unit network

Step 3: Select ‘Forget Network’

Step 4: Follow the steps from the beginning in the previous section ‘Connecting Your

MySpace™ unit to Your Wi-Fi’

Internal Cooling Fan

The internal cooling fan is automatically controlled by the temperature of the drive

circuit. It may come on and off during operation of the device and can continue to run for a

couple of minutes after the main unit has been turned off.

Your Notes

Document Ref.=MSP01LP010 _ Revision 20170425

Access Point

SSID:

OH-AIR_UI_0143

IP: 255.255.239.25

Access Point

OH-AIR_UI_0143

IP: 255.255.239.25

pwd: admin007

8 9

PROBLEM POSSIBLE CAUSE SOLUTION

Power source

failed "POWER

ON" LED will not

light

MySpace

™unit is

not plugged into an

energized electrical receptacle.

Ensure circuit breaker is 'ON'

and the electrical receptacle has

proper power available.

Air flow outlet

restrictive

Dirty or damaged filter Clean or replace filter

Optic/s

not

functioning

Rated life of optic has been met.

Contact local distributor for

replacement optics/service.

Optics have been damaged.

Contact local distributor for

replacement optics/service.

Internal component failure. Contact local distributor for

service.

How to Remove Front CoverTroubleshooting Guide

CAUTION: Your device MUST BE unplugged/disconnected from the mains.

Step 1 - Place the device on its back with power cord removed

Step 2 - Remove one screw with PH2 Phillips screw driver

Step 3 - Push both tabs in together to release cover

Step 4 - Lift cover upwards and towards you to remove the cover

Step 5 -Re-assemble cover in reverse order

Document Ref.=MSP01LP010 _ Revision 20170425

Table of contents

Popular Air Cleaner manuals by other brands

Philips

Philips MicroCube AC5659 user manual

Grizzly

Grizzly G9956 owner's manual

Blueair

Blueair blue PURE 231 user manual

Second Wind

Second Wind 2414 installation manual

Wood’s

Wood’s AL 300 Series user manual

Trion

Trion Air Boss T5200 Installation and operation

Panasonic

Panasonic F-PXV55H operating instructions

acerpure

acerpure Pro Series user manual

Toyotomi

Toyotomi ETK-20E instruction manual

Kärcher

Kärcher AFG 100 manual

Phoenix

Phoenix 4031350 owner's manual

Second Wind

Second Wind 2412-FC installation manual

DH Lifelabs

DH Lifelabs Sciaire Portable quick start guide

LG AS601H Series owner's manual

AllerAir

AllerAir 5000 Exec Technical specifications

Philips

Philips 2000i Series manual

Honeywell

Honeywell HFD-120 Series user manual

White Rodgers

White Rodgers ComfortPro Programming options

HGI Industries OhAir MySpace User manual

Popular Air Cleaner manuals by other brands
