HHB UDP-89 User manual

UDP-89
PROFESSIONAL UNIVERSAL
DVD/CD PLAYER
USER MANUAL
#24678 - UDP89 Ops Cover V3:Layout 13/2/09 10:02 Page 2

UDP-89
1
UDP-89 User Manual Version 2.1 www.hhb.co.uk
La versión en español del manual de operaciones la encontrará en la web de HHB: www.hhb.co.uk
La version française de ce manual d’utilisation est disponsible sur le site web de HHB: www.hhb.co.uk
Eine deutsch Version dieser Bedienungsangleitung ist im Internet unter der Adresse: www.hhb.co.uk erhältlich.
UDP-89
PROFESSIONAL UNIVERSAL DVD/CD PLAYER

Statutory Notifications
2UDP-89 User Manual Version 2.1www.hhb.co.uk
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8 Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9 Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11 Only use attachments/accessories specified by the
manufacturer.
12 Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
13 Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15. This apparatus is supplied with a remote control unit which
contains replaceable non-rechargeable batteries. The
remote control unit and the batteries must not be exposed
to excessive heat such as sunshine, fire or the like. The
disposal of used batteries should be in accordance with local
re-cycling and waste disposal regulations. Never dispose
of batteries in a fire because they may explode and cause
injury.
WARNING: To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
It is important that the apparatus shall not be exposed to
dripping or splashing and that no objects filled with liquids, such
as vases shall be placed on the apparatus.
Do not expose this apparatus to drips or splashes.•
Do not place any objects filled with liquids, such as vases, on•
the apparatus.
Do not install this apparatus in a confined space such as a•
book case or similar unit.
Slots and openings in the cabinet are provided for ventilation•
and to ensure reliable operation of the product and to protect
it from overheating. Please ensure adequate space around the
apparatus for sufficient ventilation. Ventilation should not be
impeded by covering the ventilation openings with items, such
as newspapers, tablecloths curtains etc.
The apparatus draws nominal non-operating power from the•
AC outlet when in STANDBY mode.
The apparatus should be located close enough to the AC•
outlet so that you can easily grasp the power cord plug at any
time.
An apparatus with Class I construction shall be connected to•
an AC outlet with a protective grounding connection.
The MAINS plug or the appliance coupler is used as the•
disconnect device. Either device shall remain readily operable
when the apparatus is installed for use.
No naked flames, such as lighted candles, should be placed on•
the apparatus.
WARNING: excessive sound pressure levels from earphones
and headphones can cause hearing loss.
Important Safety Instructions

Statutory Notifications
3
UDP-89 User Manual Version 2.1 www.hhb.co.uk
Important Safety Precautions
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
This appliance has a serial number located on the rear panel.
Please record the model number and serial number and
retain them for your records.
Model Number: .............................................
Serial Number: .............................................
For U.S.A.
TO THE USER
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be
required to correct the interference at his own expense.
CAUTION
Changes or modifications to this equipment not expressly
approved by HHB for compliance could void the user’s
authority to operate this equipment.
For Canada
TO THE USER
This Class A digital apparatus complies with Canadian ICES-
003
Cet appareil numerique de la Classe A est conforme a la
norme NMB-003 du Canada
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
Safety Information
This product has been designed and manufactured according to
FDA regulations “title 21, CFR, chapter 1, subchapter J, based
on the Radiation Control for Health and Safety Act of 1968”, and
is classified as a class 1 laser product. There is no hazardous
invisible laser radiation during operation because invisible laser
radiation emitted inside of this product is completely confined in
the protective housings.
CAUTION
THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
This unit contains a semiconductor laser system and is classified
as a “CLASS 1 LASER PRODUCT”. So, to use this model
properly, read this Instruction Manual carefully. In case of any
trouble, please contact the store where you purchased the unit.
To prevent being exposed to the laser beam, do not try to open
the enclosure.
CAUTION
DO NOT REMOVE THE PROTECTIVE HOUSING USING A•
SCREWDRIVER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF•
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
IF THIS PRODUCT DEVELOPS TROUBLE, CONTACT YOUR•
NEAREST QUALIFIED SERVICE PERSONNEL, AND DO NOT USE
THE PRODUCT IN ITS DAMAGED STATE.
DANGER
VISIBLE LASER AND INVISIBLE RADIATION WHEN OPEN•
AND INTERLOCK FAILED OR DEFEATED. DO NOT STARE INTO
BEAM.
1) This label on the top panel states: CLASS 1 LASER PRODUCT.
The unit employs a laser inside the cabinet;
2) To prevent the laser from being exposed, do not remove the
cover. Refer servicing to qualified personnel.

4UDP-89 User Manual Version 2.1www.hhb.co.uk
Contents
Contents
Important Safety Instructions........................................ 2
Important Safety Precautions ........................................ 3
Safety Information ........................................................ 3
Contents...................................................................... 4
Introduction ................................................................. 6
What’s in the box ........................................................6
Unpacking ............................................................6
UDP-89 Primary Features............................................. 7
Cautions and guidance on installation..............................7
Safety Guidelines ...................................................7
Installation............................................................ 7
Care & cleaning ....................................................8
Installing the Remote Control batteries .....................8
Using the RC-89 Remote Control handset ................. 9
Compatible disc types ............................................9
Compatible audio and video formats .........................9
Connectivity ............................................................... 10
Analogue Audio Outputs.............................................. 10
Digital Audio Outputs..................................................10
Analogue Video Outputs..............................................10
Digital Video Output....................................................10
Other Connectors ......................................................10
Connector Details ......................................................10
Front Panel Features .................................................. 12
Description of Front Panel Features..............................12
Alphanumeric Display .................................................14
On-Screen Displays ....................................................14
RC-89 Remote Control ................................................ 14
Quick Start ................................................................ 16
Connecting for video...................................................16
Connecting for audio ..................................................17
Playing DVD Video discs .............................................17
Playing CDs ..............................................................18
Basic Operation .......................................................... 19
Powering the UDP-89 ................................................19
Loading and Ejecting Discs .......................................... 19
Disc Nomenclature ....................................................19
Audio Level ...............................................................20
Playing Audio Discs ....................................................20
Transport Controls ..............................................20
Track Selection.................................................... 20
Time Displays...................................................... 21
Other Audio Disc Types.........................................21
SACDs (Super Audio Compact Discs)......................21
DVD-As (DVD-Audio discs)..................................... 22
CD-ROMs and DVD-ROMs containing audio files .......23
Playing discs with video content ...................................23
Transport Controls ..............................................23
Accessing the Disc Menus.................................... 24
Chapter Selection ......................................................24
Using the Direct Access Keys................................24
Using the Title Menu............................................ 24
Time & Other Displays................................................25
Other video disc types ................................................ 25
DVD-RandDVD-RW ............................................25
Video CDs and SuperVCDs....................................25
CD-ROMs and DVD-ROMs containing video files........ 25
CD-ROMs and DVD-ROMs containing
JPEG image files .................................................25
Additional Features..................................................... 26
Search..................................................................... 26
Locating to a CD Track or DVD Title or Chapter .......26
Locating to a time point........................................ 26
Storing and Cueing to a Marker Point ..................... 27
Auto-Pause...............................................................27
Slow-motion playback..................................................28
Program Play............................................................ 28
Programming tracks on audio CDs (and
CD/DVD-ROMs containing audio, jpg or avi files) ......28
Programming chapters on DVD-Video and
DVD-Audio, and tracks on SACD ............................29
Repeat Play ..............................................................30
Repeat 1............................................................30
Repeat All ..........................................................31
Selection of Repeat functions from the OSD............. 31
Shuffle Mode ............................................................32
Shuffle Mode – DVDs ...........................................32
SHUFFLE Mode - CDs...........................................32
Music Intro Mode ......................................................32
Audio configuration ....................................................32
Stereo and multi-channel audio .............................. 32
The AUDIO button...................................................... 33
Dolby Digital.............................................................. 33
DTS.........................................................................33
Multichannel bass management................................... 34
Audio level and delay adjustment .................................. 34
Audio Volume...................................................... 34
Multichannel level trims ........................................ 34
Pink Noise calibration...........................................35
Multichannel delays..............................................35
Video configuration ....................................................35
NTSC/PAL .........................................................35
Progressive and interlaced scan ............................35
Replay of 16:9 format video..................................35
HDMI formats.....................................................36
The HI-DEF button................................................36
RGB-to-SCART connections ...................................36
Angle selection.................................................... 36
Zoom ................................................................37
Subtitles.............................................................37
SCMS Compliance .....................................................37
Eject Lock................................................................. 37
Setup Menu.............................................................. 38
Menu Navigation .................................................38
Language Settings ...............................................38
Video settings .....................................................38
Audio settings..................................................... 40
Rating Settings ...................................................40
Misc. submenu .........................................................41
Timer Mode..............................................................41
Remote Control – Parallel Port .................................... 41
Parallel Port Setup Menu............................................ 42
Remote Control – Serial Port.......................................42

Contents
5
UDP-89 User Manual Version 2.1 www.hhb.co.uk
Appendix 1 - Connector Pinouts.................................... 44
Analogue Outputs (Balanced) .......................................44
Balanced Multichannel Outputs .................................... 44
AES/EBU Output .......................................................44
HDMI Digital Video Output ..........................................44
RS232 Serial Control Port .........................................44
Parallel Remote Control Input .....................................44
Electrical characteristics.......................................45
Appendix 2 - Firmware Updates.................................... 46
Software version checks.......................................46
Appendix 3 - Factory Default Settings........................... 47
Appendix 4 - UDP-89 Specifications .............................. 48

Introduction
6UDP-89 User Manual Version 2.1www.hhb.co.uk
Introduction
Thank you for buying this HHB Professional product.
The UDP-89 Universal DVD/CD Player is designed to play most
variants of CD and DVD digital discs in common professional
use, and to provide high-quality audio and/or video playback
from the various encoding methods and file types currently in
use with CDs and DVDs.
We recommend that you read this instruction manual at least
as far as the Basic Operation section, to familiarise yourself with
the unit’s layout, controls and operating system. The Additional
Features section can then be referred to separately when the
need arises, such as playing the less common CD and DVD
variants and using the remote control functions.
Please keep this manual in a safe place once you are sufficiently
familiar with the UDP-89 to use it without referral. You will
probably need it in the future, such is the UDP-89’s versatility.
Important — Please register your UDP-89 with HHB
Communications on-line at http://www.hhb.co.uk Registering
your machine will help us in providing you with after-sales service
should the need arise, and may also be of assistance in the
event of the unit being stolen.
Environment — The UDP-89’s range of operating temperature
and relative humidity (RH) are as follows:
Temperature: +5oC to +35oC (41oF to 95oF)
RH: less than 85%
Do not use the UDP-89 in a location where it is in direct sunlight
or strong artificial light.
What’s in the box
Unpacking
Unpack the UDP-89 and its accessories with care. It is always
a good idea to store all packaging (if practical), in case you ever
need to return the unit to your HHB dealer for any reason.
The shipping carton should contain the items listed below.
Please contact your HHB dealer immediately if any of them are
missing or damaged.
UDP-89 Universal DVD/CD player•
Instruction manual•
IEC mains cable (power cord), with a AC connector•
appropriate to your region
Infra-red remote control handset•
2 x AAA batteries•

Introduction
7
UDP-89 User Manual Version 2.1 www.hhb.co.uk
UDP-89 Primary Features
Plays CD, Video CD, Super Audio CD (SACD), DVD Video•
(DVD-V) and DVD Audio (DVD-A) discs
Supports MPEG4 .avi files•
Dolby™ Digital* and DTS decoding**•
2 x 11-character alphanumeric vacuum-fluorescent display,•
plus on-screen displays
Balanced (+4dBu) and unbalanced (-10dBu) analogue audio•
outputs
24-bit 192kHz Wolfson D/A conversion•
AES/EBU digital audio output•
S/PDIF digital audio outputs (coaxial and optical); Dolby &•
DTS bitstreams available
Per-channel and master volume control•
Simultaneous 5.1 and stereo downmix audio outputs•
available
14-bit 165MHz video D/A conversion•
HDMI, component (RGB/YP• bPrswitchable), S-video and
composite video outputs
NTSC and PAL discs supported with outputs to either•
standard
480p, 576p, 720p and 1080i output as component video•
and HDMI
Professional cueing functions•
RS232 and parallel remote control ports•
1U 19” rack mounting chassis•
Universal power supply•
No on-screen display of transport condition, ideal for•
professional display
Notes:
*ManufacturedunderlicensefromDolbyLaboratories.•
“Dolby”, “MLP Lossless” and the double-D symbol are
trademarks of Dolby Laboratories.
**ManufacturedunderlicenseunderU.S.Patent#’s:•
5,451,942; 5,956,674; 5,974,380; 5,978,762;
6,487,535 & other U.S. and worldwide patents issued
& pending. DTS and DTS Digital Surround are registered
trademarks and the DTS logos and Symbol are trademarks
of DTS, Inc. © 1996-2008 DTS, Inc. All Rights Reserved.
HDMI,theHDMIlogoandHigh-DefinitionMultimedia•
Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
DVDisatrademarkofDVDFormat/LogoLicensing•
Corporation.
Itisforbiddenbylawtocopy,broadcast,show,broadcast•
on cable, play in public, and rent copyrighted material
without permission. DVD videos are copy protected, and
any recordings made from these discs will be distorted.
This product incorporates copyright protection technology
that is protected by U.S. patents and other intellectual
property rights. Use of this copyright protection technology
must be authorized by Macrovision, and is intended for
home and other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or
disassembly is prohibited.
Cautions and guidance on
installation
Safety Guidelines
Operate only on a secure and level surface or securely•
fastened into a rack, noting the precautions below.
This equipment must be earthed (grounded).•
This equipment must be powered from a polarised AC•
supply.
Only suitably trained personnel should service this•
equipment.
Please read and take note of all warning and informative•
labels.
Before starting any servicing operation, this equipment•
must be isolated from the AC supply (mains) by removing
the incoming IEC mains connector.
Fuses should only be replaced with ones of the same type•
and rating as that indicated.
Operate only in a clean, dry and pollutant-free environment.•
Do not operate in an explosive atmosphere.•
Do not allow any liquid or solid objects to enter the•
equipment. Should this accidentally occur then immediately
switch off the unit and contact your service agent.
Installation
Although the UDP-89 does not generate a significant degree
of heat, it should never be installed immediately above or
below another piece of equipment that does, such as a power
amplifier. It is good practice in any case to fit vent blanks of at
least 1U above and below such equipment in a rack (unless they
short-circuit that equipments’ own fan-cooling, in which case
plain blanks should be fitted).
Care with ventilation should similarly be taken if the unit is free-
standing; never stack it on top of or underneath another piece of
equipment which generates a significant amount of heat.
Take care when routing cables around the unit; never drape
cables across the front panel of the UDP-89 as they may
obstruct the disc tray eject mechanism.
Do not install or use the UDP-89 in a position where it is in
direct sunlight or high-intensity artificial light. Never attempt to
move the unit while it is in operation.

Introduction
8UDP-89 User Manual Version 2.1www.hhb.co.uk
Care & cleaning
Always switch off and disconnect the unit from the mains before
cleaning. The outside surfaces of the unit may be cleaned with a
soft dry cloth. For stubborn marks (such as from liquid spillage),
a soft damp cloth may be used in conjunction with a mild
detergent solution (dilute a household detergent cleaner 5:1 with
water). Wipe thoroughly dry with a dry cloth after. NEVER use
solvent cleaners of any kind.
Always switch the unit off and disconnect it from the AC supply
before moving it. NEVER move the unit while it is in use, as this
may permanently damage the disc.
CDs and DVDs should ALWAYS be handled with care. Hold
discs only by the edge or the centre hole. Never put discs “face
down” on any surface as they can scratch easily. Smudges
and fingerprints may be removed from a disc’s playing surface
by wiping it gently with a soft, lint-free cloth “across” the disc
radius. Never rub circumferentially. Stubborn marks can be
removed by applying a small amount of isopropyl alcohol (distilled
water is often as effective), again with a soft, lint-free cloth.
Alternatively, use a commercially available CD cleaning kit.
NEVER use solvent cleaners of any kind.
Installing the Remote Control batteries
To insert the batteries in the infra-red remote control handset:
Slide off the battery compartment lid on the rear of the•
handset
Insert two AAA batteries, taking care to orientate them•
the correct way (refer to markings within the battery
compartment)
Slide battery compartment lid back on•
Important! Please observe the following guidelines when
replacing batteries:
Always change both batteries at the same time.•
Always use two batteries of the same brand and type.•
Dispose of the old batteries in a responsible manner –•
always observe local environmental guidelines.

Introduction
9
UDP-89 User Manual Version 2.1 www.hhb.co.uk
Using the RC-89 Remote Control
handset
Make sure there are no obstacles between the handset•
and the unit.
The handset should work reliably within 7m of the unit, and•
within 30° of the direct line between the handset and the
unit.
Strong sunlight or fluorescent lighting may make remote•
control operation less reliable.
Remote control handsets for different equipment•
sometimes interact. If the UDP-89 is installed adjacent
to other infra-red-controlled equipment, you should satisfy
yourself that the UDP-89’s handset is not affecting the
other equipment, or vice-versa. One or more items may
need to be moved if interaction is observed.
A falling-off of the operating range of the handset will•
generally indicate that it is time to change the batteries.
Compatible disc types
The UDP-89 supports the following types of media: CD, CD-R,
CD-RW, DVD-V, DVD-A, DVD+R, DVD+RW, DVD-R, DVD-RW,
SACD.
Compatible audio and video formats
Numerous encoding schemes for both audio and video data have
been implemented since the initial introduction of the CD and
DVD media formats. Most - but not all - schemes are defined
for one particular type of media. The number of combination
of media types and encoding schemes is now quite large, and
it is a fundamental purpose of the UDP-89 to replay audio
and/or video from as many of the disc types currently in use as
possible.
The UDP-89 is able to replay the following disc types:
Standard red-book-compliant• audio CDs
Standard DVD• video discs (DVD-V) including decoding of
Dolby Digital, DTS and MPEG audio bitstreams, or PCM
audio up to 24-bit at fs=96 kHz
Scarlet book 2.0-compliant• Super Audio CDs (SACD),
including single, dual and hybrid layer versions
DVD-Audio• discs (DVD-A) containing audio in various
formats, including 16-bit stereo at fs=44.1 or 48 kHz,
24-bit 6-channel at fs=88.2 or 96 kHz, and 24-bit stereo
at fs=176.4 or 192 kHz
White book-compliant• Video CDs (VCD) containing MPEG1
video with MPEG Layer 2 stereo audio at fs=44.1 kHz
Super Video CDs• (SVCD) containing MPEG2 video with
either one or two MPEG Layer 2 stereo audio tracks at
fs=44.1 kHz, or MPEG2 5.1 audio
CD-R/RW and DVD-R/RW discs containing audio and/or•
video files recorded with the following schemes
MPEG1andMPEG2filescontainingbothaudioand•
video objects
MPEG4ASP-codedvideofiles(e.g.*.avifiles)•
containing embedded MPEG, Dolby Digital or PCM
audio
*.jpgpicturefiles•
More detailed descriptions of the various disc types will be found
throughout the manual.
