HHB UDP-89 User manual
HHB Communications Ltd
In the USA, Central & South America: Sennheiser Electronic Corporation
In Canada: HHB Communications Canada Ltd
Trademarks are acknowledged as the property of their respective owners. HHB reserves the right to alter specifications without notice. E&OE.
UDP-89 TECHNICAL DATA
Video Output Formats PAL: 1080i, 720p, 576p, 576i
NTSC: 1080i, 720p, 480p, 480i
Composite Video 1V p-p, 75Ω
S-Video Y: 1V p-p, 75Ω
C: 0.3V p-p, 75Ω(Europe)
C: 0.286V p-p, 75Ω(USA)
Component Video Y: 1V p-p, 75Ω
Pb: 0.7V p-p, 75Ω
Pr: 0.7V p-p, 75Ω
Audio Performance
Frequency Response 10Hz-20kHz ±0.5dB
S/N Ratio 100dB
THD+N 0.005%
Channel Separation >90dB
Max output level (0dBFS) 22dBu (XLR)
8dBV (RCA/Phono)
Output Impedance <50Ω
Headphone Output 1/4" stereo jack
Digital Output AES/EBU 110ΩXLR
S/PDIF RCA/Phono coaxial
0.5V p-p, 75Ω
S/PDIF TOSlink optical
Remote Control Infra-red
RS232
9-pin opto-isolated parallel
General
Display Languages English, French, Spanish
German, Italian
Power Supply 100-240V 50/60Hz
Power Consumption 25W
Weight (Ex Packaging) 4.3kg/9.4lbs
Dimensions
Height 44mm (1.75 inches)
Depth incl. connectors 343mm (13.5 inches)
Width 482mm (19 inches)
Supplied Accessories RC89 Remote control
2 x AAA batteries
Power cord
Operating instructions
UDP-89
PROFESSIONAL
UNIVERSAL DVD/CD
PLAYER
www.hhb.co.uk
UDP-89 APPLICATIONS
• Broadcast facilities
• Theatres
• Houses of worship
• Visitor attractions
• Custom A/V installations
• Leisure centres
• Night clubs
• Entertainment systems
• Sports stadia
• Boardrooms
• Home theatre
• Information systems
• Retail systems
• Screening rooms
• Exhibitions
#24150 - UDP89 4pp V2 2/9/08 16:54 Page 1
UDP-89 OUTPUTS
UDP-89 features Wolfson 24-bit/192kHz audio DACs and
high-end analogue circuitry for audiophile performance. And
the UDP-89 is the only DVD player available with stereo and
5.1 balanced audio outputs to get the very best from high-
resolution SACD and DVD-Audio formats.
TOUGH, PROFESSIONAL BUILD QUALITY
Definitely not based on a consumer device, the UDP-89 is
designed and built from the ground up for demanding
professional use. The rugged, rack-mounting chassis houses a
pro-grade disc drive comprising of a durable disc loader with a
smooth, positive action, and a high-performance laser
assembly, extensively tested for dependable, long-term use.
COMPREHENSIVE FEATURE SET
A complete set of professional audio and video outputs (see
above) and a full complement of professional features equip
the UDP-89 for use in almost any audio or video disc playing
application. The A-B repeat mode makes the UDP-89 ideal for
use in fixed installations, while professional cueing functions,
RS232 control and a parallel fader start interface are
essential features that make it ideal for any playout
application.
ON-BOARD AUDIO PREAMP
The inclusion of a multichannel preamplifier
makes it possible to connect the UDP-89
directly to an active 5.1 speaker system,
with versatility and convenience enhanced
yet further by the inclusion of a volume
control which can also be controlled
remotely via RS232 or the supplied infra-
red remote control.
And wherever space is at a premium, users
will appreciate that the UDP-89 can be
securely mounted in just 1U of rack space.
Video/graphics - five outputs: Composite, CVBS, S-Video, HDMI, Component/RGB
Stereo audio - seven outputs: Balanced x 2, Unbalanced x 2, AES/EBU, S/PDIF optical, S/PDIF coax
Surround 5.1 audio - two outputs: Balanced and Unbalanced
Dolby Digital/DTS encoded surround - two outputs: S/PDIF optical and coax
THE ULTIMATE UNIVERSAL DVD/CD PLAYER
DVD playback is an ever expanding
requirement in virtually every type of
AV installation, from broadcast
facilities and boardroom presentations
to public information displays and
entertainment systems.
The HHB UDP-89 is designed to provide the
system integrator with a highly robust, flexible
and professionally specified alternative to the
consumer players that have previously been
pressed into service.
The UDP-89 is a universal DVD/CD player that
delivers broadcast-quality video and audio
playback and has a host of professional
interfacing features that make it ideal for use in a
wide variety of mobile and fixed installations.
IF IT’S ON A DISC, CHANCES ARE THE UDP-89
WILL PLAY IT
By making the UDP-89 compatible with a huge
array of disc and file formats, HHB has effectively
removed the limitations imposed by conventional
devices to produce a truly universal player. CD,
CD-R, CD-RW, Video CD, SACD, DVD-Video,
DVD-Audio, DVD-R, DVD+R, DVD-RW and
DVD+RW are all supported, and mp3 audio and
MPEG4 .avi video files can also be played.
UNCOMPROMISED DESIGN FOR REFERENCE
AUDIO AND VIDEO PERFORMANCE
The UDP-89 delivers the ultimate in DVD video
quality via its digital HDMI output, six 14-bit
165MHz video DACs providing progressive scan
480p/576p, plus upscaling to 720p and 1080i
(available from both HDMI and component
outputs). Unlike the majority of DVD players in
which audio is so often the poor partner, the
UDP-89 KEY FEATURES
• Fully professional, multi-
format disc player
• Plays CD, Video CD, SACD,
DVD-Video, and DVD-Audio
• Plays mp3 and MPEG4 .avi files
• Audiophile sound quality
• Broadcast-quality video
performance
• Built-in preamp with volume
control for direct connection
to active 5.1 speaker systems
• Dolby™ Digital and DTS
decoding
• MPEG audio decoding
• Composite, S-Video,
Component, RGB and HDMI
video outputs
• Balanced analog audio
outputs: L/R via XLR; L/R
and 6 channel surround via
25-pin D-type
• Unbalanced analog audio
outputs: L/R plus discrete 6
channel surround via
RCA/phonos
• AES/EBU and S/PDIF (coax
and optical) digital audio and
bitstream outputs
• Full 24-bit/192kHz Wolfson
DACs for uncompromised
audio performance
• 14-bit 165MHz video DACs
• Rugged build quality for
dependable use in demanding
professional applications
• Professional cueing function
• RS232 and parallel remote
control
• HD JPEG viewer
• Infra-red remote control
(supplied)
• Volume controllable via
remote
• 1U rack mounting chassis
RS232 Parallel remote
Unbalanced analogue
stereo and 5.1 surround
Balanced analogue
stereo and 5.1
surround
Balanced analogue stereo HDMI Component/RGB S-Video S/PDIF optical and coax stereo
and Dolby Digital/DTS bitstreams
AES/EBU
stereo
CVBS (Composite) Composite
UDP-89 PROFESSIONAL UNIVERSAL DVD/CD PLAYER
Universal power supply
100V - 240V
