HiFiMAN HM-650 User manual

Owner’s Guide
High-Resolution Digital Music Player
HM-650

02
HM-650 Owner's Guide
1 HM-650 Basics 01
Function Buttons 02
Power ON/OFF key 03
Accessories 04
Using HM-650 05
Note 05
Card Installation 05
Power ON/OFF 05
Charging 06
Reset 06
Replacing the Battery 06
Replacing the Amp Module 07
Table of Contents
Setting 10
Play Menu 10
System Version 11
Repeat 11
12
12
Brightness 13
CUE Support
Language
13
Updating Media Database
14
15
Reset Settings 15
Backlight
2 Operation 08
Main Menu 08
SD Card 08
Artist, Album and Genre 09
All Songs 09
Favorite 09
10
316
HM-650 Service and Support 17
Recycling Information 18
Other information
F

01
HM-650 Owner's Guide
Basics Operation Other information
Dimensions:72mm Wx117mm Hx 29mm D
Weight: 250g
Battery life: 9 hours
D/A Chip: WM8740
Frequency response: 20HZ-20KHz
Distortion: 0.008%(Line out)
S/N: 106±4dB
SD Card Memory: 128G
Acceptable music formats:
24
1
24-pin Dock
MP3, ACC, WMA, OGG
APE(16Bit/44.1KHz,48.0KHz,88.2KHz,
96.0KHz,192.0KHz)
16Bit & 24Bit:
WAV, FLAC, AIFF (except 176.4KHz)
GND EXT-DP EXT-DM NC EXT-USB TX-IN +7.5v-BAT +7.5v-BAT -7.5v-BAT -7.5v-BAT GND BAT-GND BAT-GND USB-DM
USB-DP VUSB DET-B DET-A LOUT-R AGND LOUT-L

02
HM-650 Owner's Guide
Basics Operation Other information
Phone Out
Volume
Screen
Hold
Power ON/OFF
Back
Low/High Gain
Direction Button
Central Button
Classic/HD
Balanced/Normal
Home
Play/Pause
Next
Previous
Base Port
Function Buttons
Reset
Lock

03
HM-650 Owner's Guide
Basics Operation Other information
Power ON/OFF
Hold the power key up for 2-3 sec to turn on the player when HM-650
is powered off.
Hold the power key up for 2-3 sec to turn off the player when HM-650
is powered on. A dialog box will appear for you to select the mode.
Direction Button
The icon will show on the main menu after the player is powered on.
In play menu, press the left/right button to fast forward/rewind;
press the up/down button to play previous/next song.
Central Button
Press the central button in play menu to play music or pause.
Back
Press the button to return to the previous folde
HOME
In play menu, press the HOME button to go to the main menu;
press HOME again to return to play menu.
Play/Pause
After pressing the Play/Pause button, the player will play music or
pause.
NEXT
Press the button to go to next song.
PREVIOUS
Press the button to return to previous song.

04
HM-650 Owner's Guide
Accessories
1.Line out cable with 3.5mm plug.
2.Charger, for charging HM-650.
3.Battery: Li-ion +7.4V 1600 mAh, -7.4V 500 mAh
4.Owner’s Guide/Manual.
Basics Operation Other information
Low/High Gain
The player is set in Low Gain. Press the button to choose Low or High Gain.
Balanced/Normal
Phone output: Normal/Balanced. Select “Normal” for normal headphones or
earphones but for balanced output, please select “Balanced”.
Volume
Please turn the volume to “0” before playing music to protect your hearing.
After the player is powered on, adjust the volume as you like.
HOLD
Press the HOLD button to lock or unlock the player. When the switch is set
to hold, all the buttons (except for the volume button) are disabled.When the
player is unlocked, all the buttons are back to work.

05
HM-650 Owner's Guide
Using HM-650
Note
Please read this manual thoroughly on how to best install and operate your
player for many years of enjoyment.
Card Installation
It is recommended that you install or remove the SD card when the player is
Power ON/OFF
Hold the power key on the right side of HM-650 up for 2 sec. After releasing
the power key, the player will power on and the HIFIMAN logo will appear.
With HM-650 on, push the power key on the right side of the player up. A dialog
box will appear for you to select the mode: power off or cancel. If you select
“power off”, the player will shut down.
Basics Operation Other information
The HM-650 will automatically detect and update the files on the SD card after
the player is turned on. The time for detection depends on the size of the files
on the SD card. After the update, the HM-650 will be ready to play.

06
HM-650 Owner's Guide
Reset
Should the player LCD become “frozen”, insert a proper tool in the reset hole
to reboot the player.
Charging
The average battery time of HM-650 is nine hours. Please charge the player
when you see a reminder of low power. We recommend that you use the
original HIFIMAN charger.
Note: The player can only be charged fully with Power OFF.
Replacing the Battery
When your battery is out of life, you should replace it with a new one which
can only be supplied by HIFIMAN or HIFIMAN authorized dealers.For more
information on replacing the battery, please visit: http://head-direct.com/
Basics Operation Other information
How to install the battery:How to remove the battery:

07
HM-650 Owner's Guide
Press the
clamp down
Take out the
amp module
Amp module bay
Clamp
Please install the amp module in the opposite way of removing it.
Basics Operation Other information
Replacing the Amp Module
your HM-650 to

08
HM-650 Owner's Guide
HM-650 Owner's Guide
2 Operations
Main Menu
When the player is starting, the
system will automatically detect
update database. After the update,
the HM-650 will go to main menu.
SD Card
On the main menu, rotate the wheel
to SD card and click the central
button to enter the SD card menu
the wheel highlights a single track,
press the central button to play the
will not be visible.
Basics Operation Other information

HM-650 Owner's Guide
Artist, Album and Genre
according to
the artist, album and genre. Accordingly,
three menus are shown on the main menu.
All Songs
After the player is started, you can
go to “browse all songs” from the
main menu and play music.
Basics Operation Other information
Favorite
When you browse all songs, you will
view a hollow star following each
song on the right. If you press the
central button for several seconds,
the song you are browsing will be
added to “Favorite” with the star
being solid. By entering Favorite
from the main menu, you will see all
the added songs.
09

HM-650 Owner's Guide
Basics Operation Other information
On the song list, press the Back
button for seconds and a window will
show up. Press Yes to delete the file
you select. Note: Songs in play list
cannot be deleted.
When play music, or select Now
Playing, you will enter the interface
below. You can press Central Button
to pause/play music.
Play Menu
Setting
F
10

On Main Menu, select “Setting”then
go to “Repeat” to make your selection.
HM-650 Owner's Guide
System Version Repeat
Click to see the information on your
HM-650’s current software version.
Basics Operation Other information 11

12
HM-650 Owner's Guide
On Main Menu, select “Setting”
selection.
Basics Operation Other information
Backlight
You have the option to set the time
for the player on as “always on,
10s, 30s, 1min and 2 mins”.

Brightness
Set the display brightness from 1 to
5.Note: The brighter your display the
more battery life will be affected.
13
HM-650 Owner's Guide
Basics Operation Other information
You can select to turn on/off
CUE Support function.
CUE Support

14
HM-650 Owner's Guide
Basics Operation Other information
Language
On Main Menu, select “Setting” then
go to “Language” to make your
selection.
Updating Media
Database
update the index information for all

15
HM-650 Owner's Guide
Basics Operation Other information
Reset Settings
Perform Factory Data Reset.
Warning: Performing a Factory
Data Reset will clear the player's
memory and put it back to the
original factory default state.

16
HM-650 Owner's Guide
3 Other information
Product Safety
Note:
Make sure not to place heavy items on HM-650 to avoid possible
damage to the player.
Be careful not to drop or hit your player.
Keep the player away from rain, water, drinks, chemicals and
cosmetics, etc. Any damage caused by the player being soaked
will not be covered in the warranty whether it is within or without the
warranty period.
Avoid putting the player in a humid, dusty or smoky environment.
Any attempt to remove, repair or modify the player without permission
is forbidden and will void the warranty.
Keep the player from direct sunlight. Proper operating environment:
21.2 ~104 (-6 ~40 ).
Basics Operation Other information

17
HM-650 Owner's Guide
Basics Operation Other information
HM-650 Service and Support
for warranty service and support.
Do not use any chemicals or detergents to clean the player.
Do not plug any other device into the headphone output port except for
headphones or earphones.
It is recommended not to use headphones while riding, driving or operating
motor vehicles.
If you experience ringing in your ears, please reduce the volume or turn off
your player.

18
HM-650 Owner's Guide
Basics Operation Other information
Disposal and Recycling Information
HM-650 Disposal and Recycling:
Dispose of your HM-650 according to your local environmental laws
and regulations. The disposal of your HM-650 should be separated from
household waste because the player contains electronic parts and battery.
When your HM-650 reaches its end of life, please contact your local
environmental department for disposal and recycling information or you could
simply send it back to us. The battery will be removed and recycled without
causing pollution.
European Union—Disposal information:
This symbol means that according to local laws and regulations your product
should be disposed of separately from household waste. When this product
reaches its end of life, take it to a collection point designated by local
authorities. Consumers can be punished by penalty for inappropriate disposal
of electronic device. The separate collection and recycling of your product at
the time of disposal will help conserve natural resources and ensure that it is
recycled in a manner that protects human health and the environment.
